Anmytek David H0034 User manual

1
ASSEMBLY AND CARE GUIDE
2 x 1 m
FLOOR SPACE REQUIRED
2 PEOPLE
REQUIRED FOR ASSEMBLY
1 HOUR
ASSEMBLY TIME
Item No. : XXXX
Item No. : H0034
Contact Us : [email protected]
Contact Us : [email protected]
David 2 Doors Tall
Storage Cabinet

CARE AND CLEANING
SAFETY PRECAUTIONS
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND USING THE PRODUCT.
2
1.
2.
3.
4.
5.
6.
7.
8.
9.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Please periodically check all fings and re-ghten as necessary.
• To clean your item, please use a damp cloth and wipe clean.
• Never allow any kind of liquid to remain on your furniture. If liquid spills onto the
product, please wipe clean as soon as possible.
WA RNING : ENSURE THE WA LL STRA P IS AT TACHED TO
AVOID SERIOUS INJURY .
To avoid any serious or fatal injury, this product has been fied with a wall strap to
prevent toppling. We strongly recommend that this product is permanently fixed to the
wall or other suitable surface. Fixing devices are not included since different surface
materials require different aachments. Please seek professional advice
if you are in doubt of what fixing device to use.
Do not stand on the product. Do not climb on the product. Do not swing on the product.
Item No. : XXXX
Item No. : H0034
Contact Us : [email protected]
Contact Us : [email protected]
Please check that all parts are present beforeyou start the assembly of your furniture. A Philips
head screwdriver (not included) is required for the assembled of this product.
For ease and speed of assembly, we recommend that before you commence each step
of the assembly, that you idenfy all the parts required for that step.
For larger items, please ensure that you have sufficient space and people to assemble your
product safely.
We recommend that, where possible, all items are assembled near to the area in which they
will be placed in use, to avoid moving the product unnecessarily once assembled.
For the protecon of your furniture, we recommend that the product is placed on a
protected surface during assembly to prevent any damage.
During assembly, Do not tighten bolts / screws completely until all bolts / screws are lined up and
inserted into holes, Do not over tighten screws and bolts to avoid stripping, Do not use power tools
Always place the product on a flat, steady and stable surface.
Do not stand on the product. Do not use the product as a stepladder.
This product is intended for indoor, household use only as it is a non industrial product.

3
Item No. : XXXX
Item No. : H0034
Contact Us : [email protected]
Contact Us : [email protected]
PARTS LIST
Ax24
3.5x12mm
Bx4 Cx4
Dx2 Ex4 Fx12
Gx12 Hx12 Ix1
Jx4 Kx10 Lx12
Mx12 Nx2 Ox2
Px2 Qx2 Rx4
3.5x35mm
3.5x10mm
3x12mm
3.5x30mm
3.5x35mm
3.5x10mm
6x10mm

AFTER SALES SUPPORT
If you have any general enquiries or require spare parts for this product, please feel free to
contact us via the following email:
Email: [email protected]
You can contact us for support at any time. We'll answer you in 24hrs.
4
Contact Us : [email protected]
Item No. : H0034
Contact Us : [email protected]
ASSEMBLY DIAGRAM
1
2
6
8
6
5
7
9
11
10
13
13
12
12
4
3

ASSEMBLY STEPS
STEP 1.
STEP 2.
Item No. : XXXX
Item No. : H0034
Contact Us : [email protected]
Contact Us : [email protected]
Attach panel (5) to panel (1) using 2 x cam bolts (F) and 2 x cam locks (G).
Tighten with a screwdriver.
Attach panel (2) to assembled unit using 4 x wooden dowels (H), 4 x cam bolts (F) and 4 x cam
locks (G). Tighten with a screwdriver.
5
F
F
G
G
H
1
4
5
Attach panel (4) to panel (1) using 2 x wooden dowels (H), 2 x cam bolts (F) and 2 x cam locks (G).
Slide panel (6) into position as shown.

ASSEMBLY STEPS
STEP 3.
STEP 4.
Item No. : XXXX
Item No. : H0034
Contact Us : [email protected]
Contact Us : [email protected]
Slide back side panel (6) into position as shown. Attach top panel (8) to assembled unit using 4 x
wooden dowels (H), 4 x cam bolts (F) and 4 x cam locks (G). Tighten with a screwdriver.
Turn the assembled unit upside down. Slide back side panel (7) into position as shown.
Attach bottom panel (9) to assembled unit using 4 x wooden dowels (H) and 4 x screws (C).
Tighten with a screwdriver.
6
6
F
G
H
1
2
8
7
C
H
1
2
9

7
ASSEMBLY STEPS
STEP 5.
STEP 6.
Item No. : XXXX
Item No. : H0034
Contact Us : [email protected]
Contact Us : [email protected]
Attach metal frame to the bottom of cabinet using 4 x bolts (J) and 6 x screws (K).
Tighten with a hex key (I).
Attach 2 x door handles (D) to door panels (10), (11) using 4 x screws (E). Attach door panels
(10), (11) to assembled unit using 4 x door hinges (B), 24 x screws (A). Insert 8 x shelf support
both sides panels as shown. Put panel (3) into position.
I
J
K
13
13
12
12
E
A
A
D
B
B
11
10
3
R
R
on
pins (R) into holes

Is your cabinet door
looking crooked or
unevenly spaced?
Then you’ve come to the right place.
Follow the illustrations below to get
your cabinet door aligned and ready for
action.
If your door is too low or too high...
Loosen the height screws, then move the door up or down to
make it level.
If the space between your doors is o...
Loosen the side-to-side screws, then screw counter-clockwise
to make the gap wider or clockwise to close any gaps.
If you need to adjust the depth of the doors...
Adjust the in-and-out screws until the door is aligned with the
side of the cabinet.
Item No. : XXXX
Item No. : H0034
Contact Us : [email protected]
Contact Us : [email protected]
8

9
ASSEMBLY STEPS
STEP 7.
STEP 8.
Item No. : XXXX
Item No. : H0034
Contact Us : [email protected]
Contact Us : [email protected]
Attach 12 x plastic wedges (L) to back side panels using 12 x screws (M).
Tighten with a screwdriver.
assembled cabinet to the wall using 2 x wall anchors (Q), 2 x screws (O).
Ensure unit is balanced and steady before use.
Attach 2 x safety straps (N) to the back of the cabinet as shown. Secure with 2 x screws (P). Fasten
M
L
6
6
7
P
N
OQ

WALL FIXING GUIDE
NOTE: Supplied wall plugs are only suitable for use in masonry walls.
If you have any doubts about using the correct plug for your wall, please seek professional advice. Failure of
the product due to using incorrect fixings is the responsibility of the installer.
IMPORTANT:
When drilling into walls, always check for hidden wires or pipes, etc.
Tips & Tricks
Make sure that the hardware used is suitable for supporng your unit.
Please consult a qualified trades person if unsure.
 If you are unsure, please select a larger screw and wall plug.
 Ensure that you use the recommended drill bit to match the wall plug and hole size.
 Take extra care when drilling high walls, ceiling and ceramic les. Ensure wall plugs are
inserted beyond the thickness of the ceramic les to avoid spling or cracking.
 Ensure that wall plugs are well fitted and are a ght fit in the drilled hole.
Types of Walls
Use one of the following types of wall plug (not included) if your walls are made of brick, breeze block, concrete,
stone or wood. Screws may be able to be fixed directly to solid wood walls as they will provide a secure anchor point.
1. General Purpose Wall Plug
Generally, aerated blocks should not be used to
case. For light loads, general purpose wall plugs
can be used.
2. Plasterboard Wall Plug
For use when aaching light loads onto
plasterboard parons.
3. Cavity Fixing Wall Plug
For use with plasterboard parons or hollow
wooden doors.
4. Cavity Fixing Heavy Duty Wall Plug
such as shelving and wall cabinets.
5. Hammer Fixing Wall Plug
For use with concrete block or brick walls, or walls
6. Shield Anchor Wall Plug Heavy Loads
For use with concrete or brick walls, or for use
with heavier loads such as TV & HiFi speakers
and satellite dishes, etc.
Item No. : XXXX
Item No. : H0034
Contact Us : [email protected]
Contact Us : [email protected]
10
