Anmytek Seattle H0033 Installation guide

Contact Us: [email protected]
C
H0033
1 HOUR 2 PEOPLE
2 x 1 m
Seale Media Console
Cabinet or TV Stand

SAFETY PRECAUTIONS
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
WA RNING : ENSURE THE WA RTSLL A P SI AT TA TDEHC O
AVOID SERIOUS INJURY .
Toavoidany seriousor fatalinjury, this product hasbeenedwith a wall strap to
prevent toppling. We strongly recommendthatthis product is permanently fixedto the
wallor othersuitable surface. Fixing devicesare not includedsince different surface
materials require different a achments. Please seek professionaladvice
if you are in doubtof whatfixing device to use.
Donot standon the product. Donot climb on the product. Donot swing on the product.
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND USING THE PRODUCT.
1. Please check that all parts are present A P p
dc wdv ( c d d) q d d pdc
2. For ease and speed of assembly, we recommend that before you commence each step
quired for that step.
3. For larger items, please ensure that you have sufficient space and people to assemble your
product safely.
4. We recommend that, where possible, all items are assembled near to the area in which they
will be placed in use, to avoid moving the product unnecessarily once assembled.
5.
protected surface during assembly to prevent any damage.
6. During assembly,cd edw
iewd ,cd edw wd ,cd edw
7. Always place the product on a flat, steady and stable surface.
8. Do not stand on the product. Do not use the product as a stepladder.
9. This product is intended for indoor, household use only as it is a non industrial product.
CARE AND CLEANING
• Please periodically .
• To clean your item, please use a damp cloth and wipe clean.
• Never allow any kind of liquid to remain on your furniture. If liquid spills onto the
product, please wipe clean as soon as possible.
Item No.: H0033
Contact Us: [email protected]
Contact Us: [email protected]
2

ASSEMBLY DIAGRAM
AFTER SALES SUPPORT
If you have any general enquiries or require spare parts for this product, please
:[email protected]
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑨
⑩
⑩
⑪
⑪
⑫
⑬
Item No.: H0033
Contact Us: [email protected]
Contact Us: [email protected]
3

3.5x35mm
3.5x45mm
3.5x10mm
3x10mm
3.5x14mm
6x35mm
3x12mm
A
B
C
D
E
F
G
H
I
J
P
K
L
M
N
O
Screw
Door Hinge
Metal Sheet
Cam Bolt
Wooden Dowel
Screw
Screw
Screw
Screw
Screw
Magnetic Door Catch
Allen Key
Bolt
Cam Lock
Plastic Wedge
24 pcs
2 pcs
4 pcs
2 pcs
2 pcs
12 pcs
20 pcs
18 pcs
1 pcs
8 pcs
8 pcs
12 pcs
4 pcs
8 pcs
Item No.: H0033
Contact Us: [email protected]
Contact Us: [email protected]
4
Handle
14 pcs
14 pcs

TIPS Before ASSEMBLY
IMPORTANT:
1. Do not tighten bolts / screws completely until all bolts / screws are
lined up and inserted into holes.
2. Do not over tighten screws and bolts to avoid stripping.
What you need
• Some of your favourite fruits or your
preferred snacks.
• Use the packaging carton as a working
surface to prevent possible product damage
during assembly .
Safety First,
Fun Later
We want your Furniture Unit to last as long as possible, so we
recommend that you tighten the screws 2 weeks after assembly,and
for added safety, check the tightness of all screws every 2 months.
We do our best to ensure your F urniture arrives without any problems,
but occasionally mistakes happen - as humans we are imperfect
beings. In the event that a part is damaged or missing, we will be more
than happy to provide you with replacement part(s) for free.
For more help, you can send a message to our customer support
email servic e @anmytek.com in any time.
Ready? Ok, let’s get rolling!
This should be very easy, just follow our simple instructions
step by step and you will put it together in no time .

ASSEMBLY STEPS
Step 1
B
O
B
O
2
3
Step 2
P
PP
A
A
P
A
AA
A
A
E
E
D
D
C
C
C
C
13
12
Item No.: H0033
Contact Us: [email protected]
Contact Us: [email protected]
5
Attach 2 x magnetic door catches (B) to panel (2) and panel (3) using 4 x screws (O) with a
screwdriver.
Attach 2 x door hinges (C) to door panel (13) using 4 x screws (A). Attach 1 x metal sheet (E), 1 x
handle (D) to panel (13) using 4 x screws (P) with a screwdriver.
Repeat this step for door panel (12).

ASSEMBLY STEPS
Step 3
3
2
Step 4
G
1
3
2
L
Item No.: H0033
Contact Us: [email protected]
Contact Us: [email protected]
6
Attach 2 x cam bolts (F) to panel (2) with a screwdriver.
Repeat this step for panel (3).
Attach the middle shelf (1) to panel (2), (3) using 4 x wooden dowels (G), 4 x cam locks (L).
Tighten with a screwdriver.
F

ASSEMBLY STEPS
Step 5
6
F
Step 6
G
6
432
5
L
Item No.: H0033
Contact Us: [email protected]
Contact Us: [email protected]
7
Attach 8 x cam bolts (F) to the top panel (6) using a screwdriver.
Attach the side panels (4, 5) and the assembled unit to the top panel (6) using 8 x wooden dowels
(G) and 8 x cam locks (L) with a screwdriver.

ASSEMBLY STEPS
Step 7
4
3
2
5
⑦
Step 8
K
4
5
3
2
G
⑧
Item No.: H0033
Contact Us: [email protected]
Contact Us: [email protected]
8
Put the upside down to slide the back side panel (7) into position.
Attach the bottom panel (8) to assembled unit using 8 x wooden dowels (G), 8 x screws (K)
with a screwdriver.

ASSEMBLY STEPS
Step 9
H
⑨
⑨
⑩
⑩
Step 10
11
11
H
J
I
Item No.: H0033
Contact Us: [email protected]
Contact Us: [email protected]
9
Attach 2 x metal frame parts (H), 2 x legs (10) to the bottom panel using 8 x screws (H) with a
screwdriver.
Attach 2 x metal frame parts (11) to the bottom panel using 10 x screws (H), 8 x bolts (J). Tighten
with an Allen Key (I) and a screwdriver.

ASSEMBLY STEPS
7
N
M
4
5
C
A
A
A
12
⑬
Step 11
Step 12
Item No.: H0033
Contact Us: [email protected]
Contact Us: [email protected]
10
Attach the door panel (12, 13) to assembled unit using 6 x screws (A) with a screwdriver.
Fix 14 x plastic wedges (N) to the back side panel using 14 x screws (M) with a screwdriver.

ASSEMBLY STEPS
Item No.: H0033
Contact Us: [email protected]
Contact Us: [email protected]
11
Final assembly.
Step 13
