Anmytek H0013 User manual

ASSEMBLY AND CARE GUIDE
2 x 2 m
FLOOR SPACE REQUIRED
2 PEOPLE
REQUIRED FOR ASSEMBLY
1 HOUR
ASSEMBLY TIME
Contact Us : [email protected]
Contact Us : [email protected]
Item No. : H0013
Two Doors Storage Cabinet
with Rattan Texture
1

CARE AND CLEANING
SAFETY PRECAUTIONS
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
Please periodically check all• ĮƫŶŐƐĂŶĚreͲƟŐŚƚĞŶĂƐŶĞĐĞssary.
To clean your item, please use a damp cloth and wipe clean.•
Never allow any kind of liquid to remain on your furniture. If liquid spills onto the•
product, please wipe clean as soon as possible.
Contact Us : [email protected]
Contact Us : [email protected]
WA RNING : ENSURE THE WA LL STR A P IS A T TA CHED TO
AVOID SERIOUS INJURY .
To avoid any serious or fatal injury, this product has been fied with a wall strap to
prevent toppling. We strongly recommend that this product is permanently fixed to the
wall or other suitable surface. Fixing devices are not included since different surface
materials require different aachments. Please seek professional advice
if you are in doubt of what fixing device to use.
Do not stand on the product. Do not climb on the product. Do not swing on the product.
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND USING THE PRODUCT.
1. Please check that all parts are present , need Phillips head screwdriver (not included) before
you start the assembly of your furniture.
2. For ease and speed of assembly, we recommend that before you commence each step
of the assembly, that you idenfy all the parts required for that step.
3. For larger items, please ensure that you have sufficient space and people to assemble your
product safely.
4. We recommend that, where possible, all items are assembled near to the area in which they
will be placed in use, to avoid moving the product unnecessarily once assembled.
5. For the protecon of your furniture, we recommend that the product is placed on a
protected surface during assembly to prevent any damage.
6. During assembly, Do not tighten bolts / screws completely until all bolts / screws are lined up and
inserted into holes, Do not over tighten screws and bolts to avoid stripping, Do not use power tools
7. Always place the product on a flat, steady and stable surface.
8. Do not stand on the product. Do not use the product as a stepladder.
9. This product is intended for indoor, household use only as it is a non industrial product.
Item No. : H0013
2

Item No. : H0013 Contact Us : [email protected]
3
1
2
3
4
5
6
6
7
8
9
9
10
10
ASSEMBLY DIAGRAM
AFTER SALES SUPPORT
If you have any general enquiries or require spare parts for this product, please feel free to
contact us via the following email:
Email： [email protected]
You can contact us for support at any time. We'll answer you in 24hrs.
Contact Us : [email protected]

Item No. : H0013 Contact Us : [email protected]
Contact Us : [email protected] 4
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
M4 Allen Key 1 PC
M6x40mm Allen Bolt 4 PCS
Φ4x40mm Screw 4 PCS
Φ3x14mm Screw 8 PCS
Plasctic Wedge 8 PCS
Φ4x14mm Screw 2 PCS
Safety Strap
2 PCS
Φ4x30mm Screw 2 PCS
Wall Anchor 2 PCS
Φ3.5x16mm Screw 4 PCS
Φ3x12mm Screw 4 PCS
Φ3x12mm Screw 4 PCS
Φ3.5x12mm Screw 16 PCS
Magnet Plate 2 PCS
Hinge 4 PCS
Handle 2 PCS
Metal Sheet 4 PCS
Φ6x35mm Cam Bolt 8 PCS
Φ15x9mm Cam Lock 8 PCS
Φ4x35mm Screw 10 PCS
Φ6x30mm Wooden Dowel 12 PCS
The hardware quantities listed above are required for proper assembly.
Some extra hardware may also have been included.
Philips head screwdriver required for assembly
(not included)

Item No. : H0013 Contact Us : [email protected]
Contact Us : [email protected] 5
Bx 2
Fx 4
Sx 4
F
F
F
F
S
S
B
S
S
B
2
1
F
S
B
Fx 4
F
F
F
F
F
4
5
STEP 1.
STEP 2.
Φ3.5x16mm
Φ6x35mm
Φ6x35mm
ASSEMBLY STEPS

Item No. : H0013 Contact Us : [email protected]
Contact Us : [email protected] 6
Ax 8
Cx 4
Dx 2
Gx 4
STEP 3.
STEP 4.
A
A
A
A
A
A
A
A
Ex 4
Ux 4
Tx 4
E
E
E
E
D
D
C
C
C
C
T
T
T
TU
U
U
U
7
8
E
U
D
T
T
A
A
C
Lx 4
G
G
L
G
G
L
L
L
2
4
5
G
Φ3.5x12mm
Φ3x12mm
Φ3x12mm
Φ6x30mm
Φ15x9mm
3
2
1
ASSEMBLY STEPS

Item No. : H0013 Contact Us : [email protected]
Contact Us : [email protected] 7
Kx 4
STEP 5.
STEP 6.
Lx 4
5
6
6
5
6
4
3
L
L
L
L
K
K
K
K
K
Φ6x30mm
Φ4x40mm
ASSEMBLY STEPS

Item No. : H0013 Contact Us : [email protected]
Contact Us : [email protected] 8
Ix 1
STEP 7.
STEP 8.
Jx 4
Gx 4
Lx 4
G
L
L
L
L
G
G
5
4
1
G
G
Φ6x30mm
Φ15x9mm
M6x40mm
J
I
10
10
9
9
J
J
J
J
3
2
1
ASSEMBLY STEPS

Item No. : H0013 Contact Us : [email protected]
Contact Us : [email protected] 9
Ax 8
STEP 9.
STEP 10.
Hx 10
Φ4x35mm
H
H
H
H
H
H
H
HH
H
3
9
910
10
H
Φ3.5x12mm
7
8
A
A
A
A
A
A
A
A
A
A
4
ASSEMBLY STEPS

Item No. : H0013 Contact Us : [email protected]
Contact Us : [email protected] 10
Qx 2
STEP 11.
STEP 12.
Mx 8
Φ3x14mm
Φ4x30mm
Nx 8
M&N
M&N
M&N
M&N
M&N
M&N
M&N
M&N
N
M
Ox 2
Φ4x14mm
Px 2
O
O
P
P
WALL
Rx 2
RP
Q
RP
Q
RP
Q
6
6
1
ASSEMBLY STEPS

11
WALL FIXING GUIDE
Contact Us : [email protected]
Contact Us : [email protected]
NOTE: Supplied wall plugs are only suitable f or use in masonry walls.
If you have any doubts about using the correct plug for your wall, please seek professional advi ce. Failu re of
the pr oduct due to using incor rect fixings is the r esponsibility of the install er.
IMPORTANT:
When drilling into walls, always check f or hidden wi res or pipes , etc .
Tips & Tricks
Make sure that the hardware used is suitable for supporng your unit.
Please consult a qualified trades person if unsure.
If you are unsure, please select a larger screw and wall plug.
Ensure that you use the recommended drill bit to match the wall plug and hole size.
Take extra care when drilling high walls, ceiling and ceramic les. Ensure wall plugs are
inserted beyond the thickness of the ceramic les to avoid spling or cracking.
Ensure that wall plugs are w ell fit ted and ar e a ght fit in the dril led hol e.
Types of Walls
Use one of the following types of wall plug (not included) if your walls are made of brick, breeze block, concrete,
stone or wood. Screws may be able to be fixed directly to solid wood walls as they will provide a secure anchor point.
1. General Purpose Wall Plug
Generally, aerated blocks should not be used to
case. For light loads, general purpose wall plugs
can be used.
2. Plasterboard Wall Plug
For use when aaching light loads onto
plasterboard parons.
3. Cavity Fixing Wall Plug
For use with plasterboard parons or hollow
wooden doors.
4. Cavity Fixing Heavy Duty Wall Plug
such as shelving and wall cabinets.
5. Hammer Fixing Wall Plug
For use with concrete block or brick walls, or walls
6. Shield Anchor Wall Plug Heavy Loads
For use with concrete or brick walls, or for use
with heavier loads such as TV & HiFi speakers
and satellite dishes, etc.
Item No. : H0013
