Anmytek H0012 Installation guide

1 x 1 m
Contact Us: [email protected]
C
1 HOUR
2 PEOPLE
H0012/H0047
Two Doors Storage Cabinet
with Rattan Texture

CARE AND CLEANING
SAFETY PRECAUTIONS
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Please periodically check all ĮƫŶŐƐĂŶĚreͲƟŐŚƚĞŶĂƐŶĞĐĞssary.
• To clean your item, please use a damp cloth and wipe clean.
• Never allow any kind of liquid to remain on your furniture. If liquid spills onto the
product, please wipe clean as soon as possible.
WA RNING : ENSURE THE WA LL STR A P IS A T TA CHED TO
AVOID SERIOUS INJURY .
To avoid any serious or fatal injury, this product has been fied with a wall strap to
prevent toppling. We strongly recommend that this product is permanently fixed to the
wall or other suitable surface. Fixing devices are not included since different surface
materials require different aachments. Please seek professional advice
if you are in doubt of what fixing device to use.
Do not stand on the product. Do not climb on the product. Do not swing on the product.
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND USING THE PRODUCT.
1. Please check that all parts are present , need Phillips head screwdriver (not included) before
you start the assembly of your furniture.
2. For ease and speed of assembly, we recommend that before you commence each step
of the assembly, that you idenfy all the parts required for that step.
3. For larger items, please ensure that you have sufficient space and people to assemble your
product safely.
4. We recommend that, where possible, all items are assembled near to the area in which they
will be placed in use, to avoid moving the product unnecessarily once assembled.
5. For the protecon of your furniture, we recommend that the product is placed on a
protected surface during assembly to prevent any damage.
6. During assembly, Do not tighten bolts / screws completely until all bolts / screws are lined up and
inserted into holes, Do not over tighten screws and bolts to avoid stripping, Do not use power tools
7. Always place the product on a flat, steady and stable surface.
8. Do not stand on the product. Do not use the product as a stepladder.
9. This product is intended for indoor, household use only as it is a non industrial product.
2
Contact Us : [email protected]

HARDWARE LIST
AFTER SALES SUPPORT
PARTS LIST
1 - 1 PC 2 - 1 PC 3 - 1 PC 4 - 1 PC 5 - 1 PC
7 - 2 PCS 8 - 1 PC
6 - 1 PC 10 - 2 PCS 9 - 2 PCS
a
24 PCS
t
8 PCS
b
2 PCS
c
4 PCS
d
2 PCS
f
8 PCS
g
8 PCS
h
10 PCS
e
4 PCS
i
1 PC
j
4 PCS
k
4 PCS
l
12 PCS
n
8 PCS
o
2 PCS
p
2 PCS
m
8 PCS
r
2 PCS
s
4 PCS
q
2 PCS
Contact Us : [email protected]
If you have any general enquiries or require spare parts for this product, please feel free to
contact us via the following email:
Email: [email protected]
You can contact us for support at any time. We'll answer you in 24hrs.
3

TIPS Before ASSEMBLY
IMPORTANT:
1. Do not tighten bolts / screws completely until all bolts / screws are
lined up and inserted into holes.
2. Do not over tighten screws and bolts to avoid stripping.
What you need
• Some of your favourite fruits or your
preferred snacks.
• Use the packaging carton as a working
surface to prevent possible product damage
during assembly .
Safety First,
Fun Later
We want your Furniture Unit to last as long as possible, so we
recommend that you tighten the screws 2 weeks after assembly,and
for added safety, check the tightness of all screws every 2 months.
We do our best to ensure your F urniture arrives without any problems,
but occasionally mistakes happen - as humans we are imperfect
beings. In the event that a part is damaged or missing, we will be more
than happy to provide you with replacement part(s) for free.
For more help, you can send a message to our customer support
email servic e @anmytek.com in any time.
Ready? Ok, let’s get rolling!
This should be very easy, just follow our simple instructions
step by step and you will put it together in no time .
4
Contact Us : [email protected]

ASSEMBLY STEPS
STEP 1.
STEP 2.
Fix magnet plates (b) to parts 1 and 5
using screws (s), as shown.
Fix magnet plates (e) to parts 2 and 3
using screws (t), as shown.
Fix hinges (c) to parts 2 and 3 using
screws (a), as shown.
Fix door handles (d) to parts 2 and 3
using screws (t).
b x 2
s x 4
f x 4
ss
b
ss
b
1
5
aaa
aa
t
t
t
t
t
tt
d
d
t
t
e
e
e
t
e
t
aa
ac
aa
ac
c
a
3
2
c x 2
d x 2
t x 8
a x 12
e x 4
f
f
f
f
5

ASSEMBLY STEPS
STEP 3.
STEP 4.
Insert quickfit screws (f) and wooden
dowels (l) to parts 4 and 6 and insert
cam locks (g) to part 5, as shown.
ƩĂĐŚƉĂƌƚƐϰĂŶĚϲƚŽƉĂƌƚϱ
dƵƌŶĐĂŵůŽĐŬƐĐůŽĐŬǁŝƐĞƚŽƟŐŚƚĞŶ
Slide parts 7 into grooves of parts 4, 5 and 6,
as shown.
l x 4
g
g
g
g
l
l
l
l
4
5
6
g x 4
f x 4
4
5
7
7
6
f
f
f
f64
6

ASSEMBLY STEPS
STEP 5.
STEP 6.
Fit wooden dowels (l) to parts 4
and 6.
Fix parts 4 and 6 to part 8 using
screws (k), as shown.
Insert quickfit screws (f) and wooden
dowels (l) to part 1 and insert cam
locks (g) to parts 4 and 6, as shown.
ƩĂĐŚƉĂƌƚϭƚŽƉĂƌƚƐϰĂŶĚϲ
dƵƌŶĐĂŵůŽĐŬƐĐůŽĐŬǁŝƐĞƚŽƟŐŚƚĞŶ
k x 4
l x 4
k
l
l
l
l
k
k
k
8
6
4
gg
g
g
ll
ll
1
6
4
l x 4
g x 4
7

ASSEMBLY STEPS
STEP 7.
Fix parts 9 to part 10 using Bolt (j),
as shown.
STEP 8.
j x 4
i x 1
9
9
9
j
j
j
i
j
h x 10
10
10
10
10
h
h
h
h
h
h
h
h
h
h
Secure parts 10 and parts 9 assembled unit
using screws (h), as shown.
9
9
8

ASSEMBLY STEPS
STEP 9.
a x 12
2
3
c
a
aa
Fix doors 2 and 3 using screws (a),
as shown.
9

m x 8
ASSEMBLY STEPS
STEP 10.
Secure back panels 7 using screws (m)
and wedges (n), as shown.
Fix wall straps (p) to part 1 using screws (o),
as shown.
n x 8
o x 2
p x 2
p
p
n
n
n
n
n
n
n
mm
m
m
m
m
m
m
n
o
o
1
7
7
10

q x 2
ASSEMBLY STEPS
STEP 11.
Your 2 door cabinet is ready for use.
Please note: Maximum recommended weight is 10kg.
ƩĂĐŚLJŽƵƌϮĚŽŽƌĐĂďŝŶĞƚƚŽƚŚĞǁĂůůďLJǁĂůůƐƚƌĂƉƐ;ƉͿ
fixing screws (q) and wall plugs (r), as shown.
If unsure seek advice from
a qualified trades person on
ŚŽǁƚŽĂƩĂĐŚƚŚĞǁĂůů
fixtures to your specific
wall.
r x 2
p x 2
r
WALL q
p
r
q
p
11
Contact Us : [email protected]

WALL FIXING GUIDE
Contact Us : [email protected]
NOTE: Supplied wall plugs are only suitable f or use in masonry walls.
If you have any doubts about using the correct plug for your wall, please seek professional advi ce. Failu re of
the pr oduct due to using incor rect fixings is the r esponsibility of the install er.
IMPORTANT:
When drilling into walls, always check f or hidden wi res or pipes , etc .
Tips & Tricks
Make sure that the hardware used is suitable for supporng your unit.
Please consult a qualified trades person if unsure.
If you are unsure, please select a larger screw and wall plug.
Ensure that you use the recommended drill bit to match the wall plug and hole size.
Take extra care when drilling high walls, ceiling and ceramic les. Ensure wall plugs are
inserted beyond the thickness of the ceramic les to avoid spling or cracking.
Ensure that wall plugs are w ell fit ted and ar e a ght fit in the dril led hol e.
Types of Walls
Use one of the following types of wall plug (not included) if your walls are made of brick, breeze block, concrete,
stone or wood. Screws may be able to be fixed directly to solid wood walls as they will provide a secure anchor point.
1. General Purpose Wall Plug
Generally, aerated blocks should not be used to
case. For light loads, general purpose wall plugs
can be used.
2. Plasterboard Wall Plug
For use when aaching light loads onto
plasterboard parons.
3. Cavity Fixing Wall Plug
For use with plasterboard parons or hollow
wooden doors.
4. Cavity Fixing Heavy Duty Wall Plug
such as shelving and wall cabinets.
5. Hammer Fixing Wall Plug
For use with concrete block or brick walls, or walls
6. Shield Anchor Wall Plug Heavy Loads
For use with concrete or brick walls, or for use
with heavier loads such as TV & HiFi speakers
and satellite dishes, etc.
