490 JARVIS DRIVE
MORGAN HILL, CA 95037-2809
SERIES
MG369XA
SYNTHESIZED SIGNAL GENERATORS
OPERATION MANUAL
P/N: 10370-10353
REVISION: F
PRINTED: JANUARY 2004
COPYRIGHT 2004 ANRITSU CO.

WARRANTY
The Anritsu product(s) listed on the title page is (are) warranted against defects in materials and
workmanship for three years from the date of shipment.
Anritsu's obligation covers repairing or replacing products which prove to be defective during the
warranty period.Buyers shall prepay transportation charges for equipment returned to Anritsu for
warranty repairs.Obligation is limited to the original purchaser. Anritsu is not liable for consequen-
tial damages.
LIMITATION OF WARRANTY
The foregoing warranty does not apply to Anritsu connectors that have failed due to normal wear.
Also,the warranty does not apply to defects resulting from improper or inadequate maintenance by
the Buyer,unauthorized modification or misuse,or operation outside of the environmental specifica-
tions of the product. No other warranty is expressed or implied, and the remedies provided herein
are the Buyer's sole and exclusive remedies.
TRADEMARK ACKNOWLEDGMENTS
Adobe Acrobat is a registered trademark of Adobe Systems Incorporated.
NOTICE
Anritsu Company has prepared this manual for use by Anritsu Company personnel and customers
as a guide for the proper installation, operation, and maintenance of Anritsu Company equipment
and computer programs. The drawings, specifications, and information contained herein are the
property of Anritsu Company, and any unauthorized use or disclosure of these drawings, specifica-
tions,and information is prohibited;they shall not be reproduced,copied,or used in whole or in part
as the basis for manufacture or sale of the equipment or software programs without the prior writ-
ten consent of Anritsu Company.
UPDATES
Updates to this manual, if any, may be downloaded from the Anritsu Internet site at:
http://www.anritsu.com.

Safety Symbols
To prevent the risk of personal injury or loss related to equipment malfunction, Anritsu Company uses the
following symbols to indicate safety-related information. For your own safety, please read the information
carefully BEFORE operating the equipment.
WARNING WARNING indicates a hazard. It calls attention to a procedure that
could result in personal injury or loss of life if not performed properly.
Do not proceed beyond a WARNING notice until the indicated condi-
tions are fully understood and met.
CAUTION CAUTION indicates a hazard. It calls attention to a procedure which,
if not performed properly, could result in damage to or destruction of a
component of the instrument. Do not proceed beyond a CAUTION note
until the indicated conditions are fully understood and met.
The instrument is marked with this symbol to indicate that it is neces-
sary for the user to refer to the instructions in the operation manual.
Indicates ground.
MG369XA OM Safety-1

Safety-2 MG369XA OM
There are no operator serviceable components inside. Refer
servicing of the instrument to qualified service technicians.
To prevent the risk of electrical shock or damage to preci-
sion components, do not remove the equipment covers.
WARNING
When supplying power to this equipment, always use a
three-wire power cable connected to a three-wire power line
outlet. If power is supplied without grounding the equip-
ment in this manner, there is a risk of receiving a severe or
fatal electric shock.
WARNING
For Safety
If the equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment
may be impaired.
WARNING
Before changing the fuse, always remove the power cord
from the power outlet. There is the risk of receiving a fatal
electric shock if the fuse is replaced with the power cord
connected.
Always use a new fuse of the type and rating specified by
the fuse markings on the rear panel of the instrument.
WARNING

Table of Contents
Chapter 1 General Information
1-1 Scope of Manual ............................1-3
1-2 Introduction ..............................1-3
1-3 Description ...............................1-3
1-4 Identification Number .........................1-3
1-5 Electronic Manual ...........................1-4
1-6 Related Manuals ............................1-4
GPIB Programming Manual .................1-4
Maintenance Manual .....................1-4
1-7 Options .................................1-4
1-8 Performance Specifications ......................1-8
1-9 Recommended Test Equipment ....................1-8
Chapter 2 Installation
2-1 Introduction ..............................2-3
2-2 Initial Inspection............................2-3
2-3 Preparation For Use ..........................2-3
2-4 Rack Mounting Kit Installation ....................2-5
Preliminary .........................2-5
Procedure ..........................2-5
Power Requirements .....................2-8
Power Connection ......................2-8
Standby Operation ......................2-9
Warmup Time ........................2-9
Operating Environment ...................2-9
2-5 GPIB Setup and Interconnection...................2-10
Interface Connector .....................2-10
Cable Length Restrictions ..................2-10
GPIB Interconnection ....................2-10
Setting the GPIB Address ..................2-11
Selecting the Line Terminator ................2-12
Interface Language .....................2-12
MG369XA OM i

2-6 Preparation for Storage/Shipment ..................2-13
Preparation for Storage ...................2-13
Preparation for Shipment ..................2-13
2-7 Anritsu Service Centers .......................2-14
Chapter 3 Local (Front Panel) Operation
3-1 Introduction ..............................3-5
Typographic Conventions ...................3-5
3-2 Front Panel Layout...........................3-6
Line Key ...........................3-6
Data Display Area ......................3-6
Data Entry Area .......................3-7
RF Output Control Key....................3-7
RF Output Connector.....................3-7
3-3 Data Display Area ...........................3-8
Menu Display Format ....................3-9
Menu Keys .........................3-10
3-4 Data Entry Area ...........................3-12
3-5 Instrument Start-Up .........................3-14
Powering Up the MG369XA .................3-14
Start-Up Display ......................3-14
Standby Operation .....................3-14
Self-Testing the MG369XA .................3-15
Resetting to Default Parameters...............3-15
3-6 Entering Data.............................3-17
Opening the Parameter ...................3-17
Editing the Current Value..................3-18
Entering a New Value....................3-19
3-7 CW Frequency Operation.......................3-20
Selecting CW Mode .....................3-20
Selecting a CW Frequency..................3-20
Selecting a Power Level ...................3-22
CW Ramp..........................3-23
Phase Offset ........................3-24
Electronic Frequency Control ................3-25
ii MG369XA OM
Table of Contents (Continued)

3-8 Sweep Frequency Operation .....................3-26
Analog Sweep Mode .....................3-26
Selecting Analog Sweep Mode ................3-26
Setting Sweep Time .....................3-27
Step Sweep Mode ......................3-28
Selecting Step Sweep Mode .................3-28
Setting Step Size, Dwell Time, and Sweep Time .......3-29
Selecting a Sweep Trigger ..................3-31
Manual Sweep Mode ....................3-32
Selecting Manual Sweep Mode................3-33
Selecting a Sweep Range ..................3-33
Selecting a Power Level ...................3-36
Frequency Markers .....................3-36
Selecting Alternate Sweep Mode...............3-38
List Sweep Mode ......................3-42
Selecting List Sweep Mode .................3-43
List Frequency Editing ...................3-45
List Power Editing .....................3-46
Selecting a List Sweep Range ................3-48
Selecting a List Sweep Trigger ...............3-49
3-9 Fixed Power Level Operation.....................3-51
Selecting Fixed Power Level Mode ..............3-51
Selecting a Power Level ...................3-51
Level Offset .........................3-54
3-10 Power Level Sweep Operation ....................3-56
Selecting CW Power Sweep Mode ..............3-56
Setting CW Power Sweep Step Size and Dwell Time .....3-57
Selecting a CW Power Sweep Trigger ............3-57
Selecting a Power Level Sweep Range ............3-59
Selecting a Sweep Frequency/Step Power Mode .......3-61
Setting Power Level Step Size ................3-62
3-11 Leveling Operations .........................3-63
Selecting a Leveling Mode..................3-63
Attenuator Decoupling ...................3-66
ALC Power Slope ......................3-67
User Cal (User Power Level Flatness Calibration) ......3-69
MG369XA OM iii
Table of Contents (Continued)

3-12 System Configuration.........................3-75
Accessing the System Configuration Menu..........3-75
Configuring the Front Panel ................3-76
Configuring the Rear Panel .................3-77
Configuring the RF .....................3-78
Configuring the GPIB ....................3-80
Setting Increment Sizes ...................3-83
3-13 Saving/Recalling Instrument Setups.................3-84
Saving Setups........................3-84
Recalling Setups ......................3-85
Erasing Stored Setups....................3-85
3-14 Secure Operation ...........................3-86
Memory Profile and Security Issues .............3-86
3-15 Reference Oscillator Calibration ...................3-87
3-16 Signal Modulation ..........................3-90
Accessing Modulation Modes ................3-90
Amplitude Modulation Operating Modes ...........3-91
Providing Amplitude Modulation ..............3-91
Frequency Modulation Operating Modes ...........3-94
Providing Frequency Modulation ..............3-95
Phase Modulation Operating Modes .............3-99
Providing Phase Modulation ................3-100
Pulse Modulation Operating Modes.............3-104
Providing Pulse Modulation ................3-105
3-17 Internal Power Meter (Option 8) ..................3-114
3-18 Scan Modulation (Option 20) ....................3-117
Chapter 4 Local Operation—Menu Maps
4-1 Introduction ..............................4-3
4-2 Menu Map Description.........................4-3
Chapter 5 Operation Verification
5-1 Introduction ..............................5-3
5-2 Test Equipment ............................5-3
5-3 Test Records ..............................5-4
iv MG369XA OM
Table of Contents (Continued)

5-4 Initial MG369XA Checkout ......................5-4
Power Up ..........................5-4
Self-Test ...........................5-4
Resetting the MG369XA ...................5-4
Warmup Time ........................5-4
5-5 CW Frequency Accuracy Test .....................5-5
Test Setup ..........................5-5
Test Procedure ........................5-5
5-6 Level Accuracy and Flatness Tests..................5-10
Test Setup .........................5-10
Power Level Accuracy Test Procedure ............5-11
Power Level Flatness Test Procedure ............5-12
Chapter 6 Operator Maintenance
6-1 Introduction ..............................6-3
6-2 Error and Warning/Status Messages .................6-3
Self-Test Error Messages ...................6-3
Normal Operation Error and Warning/Status Messages ....6-8
6-3 Troubleshooting............................6-11
6-4 Routine Maintenance.........................6-14
Cleaning the Fan Filters...................6-14
Cleaning the Data Display..................6-14
Replacing the Line Fuses ..................6-14
Chapter 7 Use With Other Instruments
7-1 Introduction ..............................7-3
7-2 Master-Slave Operation ........................7-4
Connecting the Instruments .................7-4
Initiating Master-Slave Operation ..............7-5
Master-Slave Operation....................7-7
Master-Slave Operation in VNA Mode ............7-7
Terminating Master-Slave Operation .............7-9
7-3 Use with a 56100A Scalar Network Analyzer ............7-10
Connecting the MG369XA to the 56100A ..........7-10
7-4 Use with a 8003 Scalar Network Analyzer .............7-11
Connecting the MG369XA to the 8003 ............7-11
Setting Up the MG369XA ..................7-12
Initiating 8003 SNA Operation ...............7-13
MG369XA OM v
Table of Contents (Continued)

7-5 Use with a HP8757D Scalar Network Analyzer...........7-15
Connecting the MG369XA to a HP8757D ..........7-15
Setting Up the MG369XA ..................7-16
Initiating HP8757D SNA Operation .............7-18
7-6 IF Up-Conversion (Option 7) .....................7-19
MG369XA Mixer Setup ...................7-20
Appendix A Rear Panel Connectors
A-1 Introduction ..............................A-1
A-2 Rear Panel Connectors ........................A-1
A-3 Connector Pin-out Diagrams .....................A-1
Appendix B Performance Specifications
Subject Index
vi MG369XA OM
Table of Contents (Continued)

Table of Contents
1-1 Scope of Manual ............................1-3
1-2 Introduction ..............................1-3
1-3 Description ...............................1-3
1-4 Identification Number .........................1-3
1-5 Electronic Manual ...........................1-4
1-6 Related Manuals ............................1-4
GPIB Programming Manual .................1-4
Maintenance Manual .....................1-4
1-7 Options .................................1-4
1-8 Performance Specifications ......................1-8
1-9 Recommended Test Equipment ....................1-8
Chapter 1
General Information

1-2 MG369XA OM
Figure 1-1. Series MG369XA Synthesized Signal Generator

Chapter 1
General Information
1-1 Scope of Manual This manual provides general information, installation, and operating
information for the Anritsu series MG369XA synthesized signal gener-
ator. Throughout this manual, the terms MG369XA,signal generator,
and synthesizer will be used interchangeably to refer to the instru-
ment. Manual organization is shown in the table of contents.
1-2 Introduction This chapter contains general information about the series MG369XA
signal generators. It includes a general description of the instrument
and information on its identification number, related manuals, options,
and performance specifications. A listing of recommended test equip-
ment is also provided.
1-3 Description The series MG369XA synthesized signal generators are microproces-
sor-based, synthesized signal sources with high resolution phase-lock
capability. They generate both discrete CW frequencies and broad (full
range) and narrow band step sweeps across the frequency range of
2 GHz to 65 GHz. Options are available to extend the low end of the
frequency range to 0.1 Hz. All functions of the signal generator are
fully controllable locally from the front panel or remotely (except for
power on/standby) via the IEEE-488 General Purpose Interface Bus
(GPIB). Table 1-1, page 1-5, lists models, frequency ranges, and maxi-
mum leveled output.
1-4 Identification
Number All Anritsu instruments are assigned a unique six-digit ID number,
such as “020312”. The ID number is imprinted on a decal that is af-
fixed to the rear panel of the unit. Special-order instrument configura-
tions also have an additional specials number tag attached to the rear
panel of the unit, such as SM1234.
When ordering parts or corresponding with Anritsu Customer Service,
please use the correct serial number with reference to the specific in-
strument's model number (for example, model MG3693A synthesized
signal generator, serial number: 020312).
MG369XA OM 1-3

1-5 Electronic Manual Updated manuals are available for download from the Anritsu web
site, www.anritsu.com.
1-6 Related Manuals This is one of a three manual set that consists of an operation manual,
a GPIB programming manual, and a maintenance manual.
GPIB
Programming
Manual
The Series MG369XA Synthesized Signal Generator
GPIB Programming Manual provides information
for remote operation of the signal generator with
product specific commands sent from an external
controller via the IEEE 488 General Purpose Inter-
face Bus (GPIB). It contains a general description of
the GPIB and bus data transfer and control func-
tions, a complete listing and description of all
MG369XA GPIB product specific commands, and
several programming examples. The Anritsu part
number for the GPIB programming manual is
10370-10354.
Maintenance
Manual The Series MG369XA Synthesized Signal Generator
Maintenance Manual supplies service information
for all models in the MG369XA series. The service
information includes functional circuit descriptions,
block diagrams, performance verification tests, cali-
bration procedures, troubleshooting data, and as-
sembly and component removal/replacement
procedures. The Anritsu part number for the main-
tenance manual is 10370-10355.
1-7 Options The series MG369XA synthesizer provides a wide array of instrument
configurations through a series of base model and option configura-
tions. Table 1-1, on page 1-5, is a sample list with performance specifi-
cations of the available models and options. Refer to Appendix B,
MG3690A RF/Microwave Signal Generators product brochure
p/n: 11410-00327, for current information.
1-4 MG369XA OM
Options General Information

General Information Options
MG369XA OM 1-5
Model
Number Configuration Frequency Range Max Leveled Output Power
Max Leveled
Output Power
w/Step Attenuator
Max Leveled
Output Power
w/Electronic
Step Attenuator
MG3691A w/opt 4 w/opt 5
Standard
³0.01 – £2.2 GHz
³0.01 – £2.0 GHz
³2.0 – £8.4 GHz
+17.0 dBm
+17.0 dBm
+13.0 dBm
+15.0 dBm
+15.0 dBm
+11.0 dBm
+13.0 dBm
+13.0 dBm
+9.0 dBm
MG3692A w/opt 4 w/opt 5
Standard
³0.01 – £2.2 GHz
³0.01 – £2.0 GHz
³2.0 – £20.0 GHz
+17.0 dBm
+17.0 dBm
+13.0 dBm
+15.0 dBm
+15.0 dBm
+11.0 dBm Not Available
MG3693A
w/opt 4
w/opt 5
Standard
Standard
³0.01 – £2.2 GHz
³0.01 – £2.0 GHz
³2.0 – £20.0 GHz
>20.0 – £30.0 GHz
+13.0 dBm
+13.0 dBm
+9.0 dBm
+6.0 dBm
+11.0 dBm
+11.0 dBm
+7.0 dBm
+3.0 dBm
Not Available
MG3694A
w/opt 4
w/opt 5
Standard
Standard
³0.01 – £2.2 GHz
³0.01 – £2.0 GHz
³2.0 – £20.0 GHz
>20.0 – £40.0 GHz
+13.0 dBm
+13.0 dBm
+9.0 dBm
+6.0 dBm
+11.0 dBm
+11.0 dBm
+7.0 dBm
+3.0 dBm
Not Available
MG3695A
w/opt 4
w/opt 5
Standard
Standard
³0.01 – £2.2 GHz
³0.01 – £2.0 GHz
³2.0 – £20.0 GHz
>20.0 – £50.0 GHz
+12.0 dBm
+12.0 dBm
+10.0 dBm
+3.0 dBm
+10.0 dBm
+10.0 dBm
+8.0 dBm
+0.0 dBm
Not Available
MG3696A
w/opt 4
w/opt 5
Standard
Standard
³0.01 – £2.2 GHz
³0.01 – £2.0 GHz
³2.0 – £20.0 GHz
>20.0 – £65.0 GHz
+12.0 dBm
+12.0 dBm
+10.0 dBm
+3.0 dBm
+10.0 dBm
+10.0 dBm
+8.0 dBm
+0.0 dBm*Not Available
With Option 15 (High Power) Installed
MG3691A w/opt 4 w/opt 5
Standard
³0.01 – £2.2 GHz
³0.01 – £2.0 GHz
³2.0 – £8.4 GHz
+19.0 dBm
+19.0 dBm
+19.0 dBm
+18.0 dBm
+18.0 dBm
+18.0 dBm
+15.0 dBm
+15.0 dBm
+13.0 dBm
MG3692A
w/opt 4
w/opt 5
Standard
Standard
³0.01 – £2.2 GHz
³0.01 – £2.0 GHz
³2.0 – £10.0 GHz
>10.0 – £20.0 GHz
+19.0 dBm
+19.0 dBm
+19.0 dBm
+17.0 dBm
+18.0 dBm
+18.0 dBm
+18.0 dBm
+15.0 dBm
Not Available
MG3693A
w/opt 4
w/opt 5
Standard
Standard
Standard
³0.01 – £2.2 GHz
³0.01 – £2.0 GHz
³2.0 – £10.0 GHz
>10.0 – £20.0 GHz
>20.0 – £30.0 GHz
+15.0 dBm
+15.0 dBm
+15.0 dBm
+12.0 dBm
+14.0 dBm
+14.0 dBm
+14.0 dBm
+14.0 dBm
+10.0 dBm
+12.0 dBm
Not Available
MG3694A
Option 4
Option 5
Standard
Standard
Standard
³0.01 – £2.2 GHz
³0.01 – £2.0 GHz
³2.0 – £10.0 GHz
>10.0 – £20.0 GHz
>20.0 – £40.0 GHz
+15.0 dBm
+15.0 dBm
+15.0 dBm
+12.0 dBm
+14.0 dBm
+14.0 dBm
+14.0 dBm
+14.0 dBm
+10.0 dBm
+12.0 dBm
Not Available
Note: For models with Option 22, rated output power is reduced by 2 dB.
* Typical 60 - 65 GHz.
Table 1-1. Series MG369XA Models

Option 1A: Rack Mounting with Slides—Rack mount kit containing a set of track slides (90°tilt
capability), mounting ears, and front panel handles for mounting the instrument in a
standard 19-inch equipment rack.
Option 1B: Rack Mounting without Slides—Modifies rack mounting hardware to install unit in a
console that has mounting shelves. Includes mounting ears and front panel handles.
Option 2X: 110 dB Mechanical Step Attenuator—Adds a 10 dB per step attenuator with a 110 dB
range. Output power is selected directly in dBm on the front panel (or via GPIB). Rated RF
output power is reduced. This option comes in different versions based on instrument
configuration.
Option 2E: 120 dB Electronic Step Attenuator—Adds a 10 dB per step attenuator with a 120 dB
range for models having a high-end frequency of £20 GHz. Output power is selected directly
in dBm on the front panel (or via GPIB). Rated RF output power is reduced.
Option 3: Ultra-Low Phase Noise—Adds new modules that significantly reduces single-sideband
phase noise, ³2 GHz.
Option 4: Digital Down Converter—Adds a digital down converter for ultra-low phase noise for
0.01 to 2.2 GHz RF coverage.
Option 5: Analog Down Converter—Adds an analog down converter for 0.01 to 2 GHz RF coverage.
Option 7: IF Up-Conversion—Adds an internal 40 GHz mixer for up-converting an IF signal. Not
available in MG3695A, MG3696A, or with Option 18.
Option 9X: Rear Panel RF Output—Moves the RF output connector to the rear panel.
Option 10: User-Defined Modulation Waveform Software—Adds a software package that pro-
vides the ability to serially (or via GPIB) download user-defined waveforms into the mem-
ory of the internal waveform generator. Requires an external PC and an instrument with
an internal low frequency generator (Option 23).
Option 12: External Frequency and Phase Modulation—Adds external FM/FM capabilities via a
rear panel BNC connector. Requires an external modulating signal input or an internal low
frequency generator (Option 23).
Option 13X: External Pulse Modulation—Adds external pulse modulation capability via a rear panel
BNC connector. Requires an external modulating signal input.
Option 14: Amplitude Modulation—Adds external AM capability via a rear panel BNC connector.
Requires an external modulating signal input or an internal low frequency generator (Op-
tion 23).
Option 15X: High Power Output—Adds high-power RF components to the instrument providing in-
creased RF output power. This option comes in different versions based on instrument con-
figuration.
Option 16: High-Stability Time Base—Adds an ovenized 10 MHz crystal oscillator with frequency
stability of <5 x 10–10/day.
1-6 MG369XA OM
Options General Information

Option 17: Delete Front Panel—Deletes the front panel for use in remote control applications where
a front panel display or keyboard control are not needed.
Option 18: mmW Bias Output—Adds a rear panel BNC Twinax connector to bias the 5400-xWRxx
millimeter wave source modules. Not available with Option 7.
Option 22: 0.1 Hz to 10.0 MHz Audio Frequency—Adds frequency coverage below 10 MHz. The fre-
quency resolution below 10 MHz is 0.02 Hz. Rated RF output power is reduced.
Option 23: Low Frequency Generator—Provides modulation waveforms for internal AM, FM, or
FM. Not available without Option 12 or 14.
Option 24: Internal Pulse Generator—Provides pulse waveforms for internal pulse modulation. Not
available without Option 13.
Option 25X: Analog Modulation Suite—The analog modulation suite bundles Options 12, 13, 14, 23
and 24, offering internal and external AM, FM, FM, and pulse modulation. This option co-
mes in different versions, based on instrument configuration.
General Information Options
MG369XA OM 1-7
