Seventh Edition
Read this manual before using the equipment.
Keep this manual with the equipment.
MT9810A
Optical Test Set
Operation Manual
ANRITSU CORPORATION
Document No.: M-W1482AE-7.0

ii
To prevent the risk of personal injury or loss related to equipment malfunction, Anritsu Corporation uses the following
safety symbols to indicate safety-related information. Insure that you clearly understand the meanings of the
symbols BEFORE using the equipment.
Some or all of the symbols may not be used on this equipment. In addition, when drawings are included in this
manual, labels on the equipment may not be shown on them.
Safety Symbols Used in Manual
DANGER
WARNING
CAUTION
Safety Symbols Used on Equipment and/or in Manual
The following safety symbols are used inside or on the equipment near operation locations, and/or in manual to
provide information about safety items and operation precautions. Insure that you clearly understand the
meanings of the symbols and take the necessary precautions BEFORE using the equipment.
This indicates a prohibited operation. The prohibited operation is indicated
symbolically in or near the barred circle.
This indicates an obligatory safety precaution. The obligatory operation is
indicated symbolically in or near the circle.
This indicates warning or caution. The contents are indicated symbolically
in or near the triangle.
This indicates a note. The contents are described in the box.
These indicate that the marked part should be recycled.
MT9810A
Optical Test Set
Operation Manual
10 August 1998 (First Edition)
20 February 2003 (Seventh Edition)
Copyright © 1998-2003, ANRITSU CORPORATION.
All rights reserved. No part of this manual may be reproduced without the prior written permission of
the publisher.
The contents of this manual may be changed without prior notice.
Printed in Japan
This indicates a very dangerous procedure that could result in death or serious
injury if not performed properly.
This indicates a hazardous procedure that could result in death or serious injury
if not performed properly.
This indicates a hazardous procedure or danger that could result in light-to-severe
injury, or loss related to equipment malfunction, if proper precautions are not taken.
Safety Symbols

iii
For Safety
WARNING
1. ALWAYS refer to the operation manual when working near loca-
tions at which the alert mark shown on the left is attached. If the
operation, etc., is performed without heeding the advice in the
operation manual, there is a risk of personal injury. In addition,
the equipment performance may be reduced.
Moreover, this alert mark is sometimes used with other marks and
descriptions indicating other dangers.
2. Laser radiation warning
• NEVER look directly into the cable connector on the equip-
ment nor into the end of a cable connected to the equipment.
If laser radiation enters the eye, there is a risk of injury.
• Laser Radiation Markings on a following page show the Laser
Safety label attached to the equipment near the cable connec-
tor.
3. When supplying power to this equipment, connect the accessory
3-pin power cord to a 3-pin grounded power outlet. If a grounded
3-pin outlet is not available, before supplying power to the equip-
ment, use a conversion adapter and ground the green wire, or
connect the frame ground on the rear panel of the equipment to
ground. If power is supplied without grounding the equipment,
there is a risk of receiving a severe or fatal electric shock.
4. This equipment cannot be repaired by the user. DO NOT attempt
to open the cabinet or to disassemble internal parts. Only Anritsu-
trained service personnel or staff from your sales representative
with a knowledge of electrical fire and shock hazards should ser-
vice this equipment. There are high-voltage parts in this equip-
ment presenting a risk of severe injury or fatal electric shock to
untrained personnel. In addition, there is a risk of damage to pre-
cision parts.
5. This equipment should be used in the correct position. If the cabi-
net is turned on its side, etc., it will be unstable and may be dam-
aged if it falls over as a result of receiving a slight mechanical
shock.
or
Repair
WARNING
Falling Over

iv
For Safety
CAUTION
1. Before changing the fuses, ALWAYS remove the power cord from
the poweroutlet and replace the blown fuses. ALWAYS use new
fuses of the type and rating specified on the fuse marking on the
rear panel of the cabinet.
T___A indicates a time-lag fuse.
___A or F___ A indicate a normal fusing type fuse.
There is risk of receiving a fatal electric shock if the fuses are
replaced with the power cord connected.
2. Keep the power supply and cooling fan free of dust.
•Clean the power inlet regularly. If dust accumulates around
the power pins, there is a risk of fire.
•Keep the cooling fan clean so that the ventilation holes are not
obstructed. If the ventilation is obstructed, the cabinet may
overheat and catch fire.
Changing Fuse
CAUTION
Cleaning

v
For Safety
WARNING
This equipment uses parts radiating Class 2 or Class 3 laser radia-
tion. The warning labels shown on the next page are attached near
the laser-radiation locations.
The product name and the danger classification specified by JIS,
IEC825 and 21CFR1040.10 are explained below.
Type JIS, IEC825 21 CFR 1040
MU952501A Class 3A Class III b
MU952502A Class 3A Class III b
MU952503A Class 3A Class III b
MU952504A Class 3A Class III b
MU952505A Class 3A Class III b
MU951301A Class 3A Class III b
MU951501A Class 3A Class III b
MU951001A Class 3A Class III b
MU952601A Class 3A Class III b
MU952602A Class 3A Class III b
MU952603A Class 3A Class III b
MU952604A Class 3A Class III b
MU952605A Class 3A Class III b
MU952606A Class 3A Class III b
Class 1, Class 2 and Class 3 indicates the degree of danger of the
laser radiation outlined below as defined by JIS, IEC825 and
21CFR1040.10.
Class 1 Safe laser presenting no danger when used according to
design specifications.
Class 2 Laser radiating in 400 to 700 nm wavelength range. In
principal, this class of laser is not safe, but the danger to
the eyes is eliminated by the eye avoidance reaction in-
cluding the blink response.
Class 3A Laser radiating in 400 to 700 nm wavelength range. The
danger to the eyes is eliminated by the eye avoidance
reaction including the blink response. For lasers radiat-
ing at other wavelengths, the degree of danger to the na-
ked eyes is not greater than Class 1.
Class 3B The eyes will be damaged if direct laser radiation enters
the eyes. Normally there is no danger if the diffused
beam is observed.
Laser Radiation Markings

vi
For Safety
Laser Radiation Markings
;y
;
;
y
y
;
;
y
y
;;
;;
yy
yy
INVISIBLE LASER RADIATION
CLASS 3A LASER PRODUCT
DO NOT STARE INTO BEAM OR VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS
(MAX) (PULSE DURATION) (WAVELENGTH)
AVOID EXPOSURE
INVISIBLE LASER RADIATION
EMITTED FROM THIS APERTURE
INDENTIFICATION LABEL
ANRITSU CORP.
10-27 MINAMIAZABU 5-CHOME
MINATO-KU, TOKYO, 106, JAPAN
MANUFACTURED AT:ANRITSU CORP.
ATSUGI PLANT. 19
CERTIFICATION LABEL
THIS PRODUCT CONFORMS TO
ALL APPLICABLE STANDARDS
UNDER 21 CFR 1040.10
<IEC> <IEC>
<21 CFR 1040>
<21 CFR 1040>
<21 CFR 1040>

vii
For Safety
CAUTION
This equipment uses a lithium battery to back-up the memory. This
battery must be replaced by a service engineer when it has reached
the end of its useful life; contact the Anritsu sales section or your near-
est representative.
Note: The battery used in this equipment has a maximum useful life of
7 years. If should be changed before this period has elapsed.
Changing memory
back-up battery

viii
Equipment Certificate
Anritsu Corporation certifies that this equipment was tested before shipment us-
ing calibrated measuring instruments with direct traceability to public testing or-
ganizations recognized by national research laboratories including the
Electrotechnical Laboratory, the National Research Laboratory of Metrology and
the Communications Research Laboratory, and was found to meet the published
specifications.
Anritsu Warranty
Anritsu Corporation will repair this equipment free-of-charge if a malfunction
occurs within 1 year after shipment due to a manufacturing fault, provided that
this warranty is rendered void under any or all of the following conditions.
• The fault is outside the scope of the warranty conditions described in the op-
eration manual.
• The fault is due to mishandling, misuse, or unauthorized modification or repair
of the equipment by the customer.
• The fault is due to severe usage clearly exceeding normal usage.
• The fault is due to improper or insufficient maintenance by the customer.
• The fault is due to natural disaster including fire, flooding, earthquake, etc.
• The fault is due to use of non-specified peripheral equipment, peripheral parts,
consumables, etc.
• The fault is due to use of a non-specified power supply or in a non-specified
installation location.
In addition, this warranty is valid only for the original equipment purchaser. It is
not transferable if the equipment is resold.
Anritsu Corporation will not accept liability for equipment faults due to unfore-
seen and unusual circumstances, nor for faults due to mishandling by the cus-
tomer.
Anritsu Corporation Contact
If this equipment develops a fault, contact Anritsu Corporation or its representa-
tives at the address in this manual.

ix
CE Marking
Anritsu affixes the CE Conformity Marking on the following product (s) in accor-
dance with the Council Directive 93/68/EEC to indicate that they conform with
the EMC directive of the European Union (EU).
CE Conformity Marking
1. Product Name/Model Name
Product Name: Optical Test Set
Model Name: MT9810A, MU93131×A, MU93142×A, MU95130×A,
MU95150×A, MU95100×A, MU95250×A, and MU95260×A
2. Applied Directive
EMC: Council Directive 89/336/EEC
LVD: Council Directive 73/23/EEC
3. Applied Standards
EMC:
Emission: EN61326: 1997/A1: 1998 (Class A)
Immunity: EN61326: 1997/A1: 1998 (Annex A)
Performance Criteria*
IEC61000-4-2 (ESD) B
IEC61000-4-3 (EMF) A
IEC61000-4-4 (Burst) B
IEC61000-4-5 (Surge) B
IEC61000-4-6 (CRF) A
IEC61000-4-8 (RPFMF) A
IEC61000-4-11 (V dip/short) B
*: Performance Criteria
A: During testing normal performance within the specifica-
tion limits.
B: During testing, temporary degradation, or loss of function
or which is self-recovering.
Harmonic current emissions:
EN61000-3-2: 1995/A2: 1998 (Class A equipment)
LVD:
EN61010-1: 1993/A2:1995 (Installation Category II, Pollution
Degree 2)

x
Anritsu affixes the C-tick marking on the following product (s) in accor-
dance with the regulation to indicate that they conform with the EMC
framework of Australia/New Zealand
C-tick marking
N274
1. Product Name/Model Name
Product Name: Optical Test Set
Model Name: MT9810A, MU93131×A, MU93142×A, MU95130×A,
MU95150×A, MU95100×A, MU95250×A, and MU95260×A
2. Applied Directive
EMC:
Emission:
AS/NZS 2064.1/2 (ISM, Group 1, Class A equipment)
Immunity:
AS/NZS 4252.1
Performance Criteria*
IEC61000-4-2 (ESD) B
IEC61000-4-3 (EMF) A
IEC61000-4-4 (Burst) B
IEC61000-4-5 (Surge) B
IEC61000-4-6 (CRF) A
IEC61000-4-8 (RPFMF) A
IEC61000-4-11 (V dip/short) B
*: Performance Criteria
A: During testing normal performance within the specifica-
tion limits.
B: During testing, temporary degradation, or loss of function
or which is self-recovering.

xi
Power Line Fuse Protection
For safety, Anritsu products have either one or two fuses in the AC power lines as
requested by the customer when ordering.
Single fuse: A fuse is inserted in one of the AC power lines.
Double fuse: A fuse is inserted in each of the AC power lines.
Example 1: An example of the single fuse is shown below:
Fuse Holder
F
U
S
E
Example 2: An example of the double fuse is shown below:
Fuse Holders
F
U
S
E
F
U
S
E

xii

I
1
2
3
4
5
6
Appendix
Index
About This Manual
This manual provides descriptions of the operation, calibration and maintenance
methods of the MT9810A Optical Test Set. Chapter 4 outlines the basic functions
and operations of this device.
Indicator indicates item numbers for which more detailed explana-
tions and relevant descriptions are available.
Moreover, matters that require attention in terms of operations and useful infor-
mation are given as "Point"; use these as reference.
It is possible to connect the computer to execute remote control of this device or
capture measured values into the computer. See the following manual for more
information on the interface to connect the computer.
MT9810A Remote Control Operation Manual (M-W1483AE)

II
Table of Contents
For Safety ....................................................... iii
About This Manual ........................................ I
Section 1 General ......................................... 1-1
1.1 MT9810A Optical Test Set......................................... 1-2
1.2 Plug-in Unit ................................................................ 1-3
1.3 Main Functions .......................................................... 1-4
1.4 Features ..................................................................... 1-5
Section 2 Nomenclature and Function ....... 2-11
2.1 Unpacking .................................................................. 2-2
2.2 Front Panel ................................................................ 2-3
2.3 Back Panel................................................................. 2-4
2.4 Indicator ..................................................................... 2-6
2.5 Display and Function of Key Switch .......................... 2-8
2.6 Front Panel of Plug-in Unit......................................... 2-10
Section 3 Before Use .................................... 3-29
3.1 Installation .................................................................. 3-2
3.2 Connection of Power Cable and Ground Line ........... 3-4
3.3 Mounting and Removal of Plug-in Unit ...................... 3-5
3.4 Laser Safety............................................................... 3-6
3.5 Connection of Remote Interlock Connector ............... 3-7
3.6 Optical Output Modifier Key Switch ........................... 3-9
3.7 Connection of Optical Fiber Cable ............................. 3-10
3.8 Replacement of Optical Connector ............................ 3-11
3.9 Replacement of Fuse................................................. 3-12
3.10 Others ........................................................................ 3-13
Section 4 Operation ...................................... 4-51
4.1 Let's start! .................................................................. 4-3
4.2 Optical Sensor Operations......................................... 4-10
4.3 Light Source Operations ............................................ 4-43
4.4 System Setup ............................................................ 4-54

III
1
2
3
4
5
6
Appendix
Index
Section 5 Performance Test
and Calibration ............................... 5-1
5.1 Optical Sensor Performance Test.............................. 5-2
5.2 Light Source Performance Test ................................. 5-5
5.3 Calibration .................................................................. 5-7
Section 6 Maintenance and
Re-Transportation ............................. 6-1
6.1 Daily Care and Cleaning ............................................ 6-2
6.2 Matters Requiring Attention for Storage .................... 6-4
6.3 Re-Transportation ...................................................... 6-5
6.4 Error Indication in Self Diagnostics ............................ 6-6
6.5 Troubleshooting ......................................................... 6-7
Appendix A Specifications........................... A-1
Appendix B Ordering Information ............... B-1
Appendix C Default Setting.......................... C-1
Appendix D Error Code ................................ D-1
Appendix E Performance Test Result
Recording List .......................... E-1
Appendix F Overrange and Underrange
Indication when Optical
Sensor is Used ......................... F-1

IV.

1-1
1
General
Section 1 General
This chapter provides an outline of functions of the MT9810A Optical Test Set and the plug-in unit, and explana-
tions of the product structure.
1.1 MT9810A Optical Test Set ............................................. 1-2
1.2 Plug-in Unit ..................................................................... 1-3
1.3 Main Functions ............................................................... 1-4
1.4 Features ......................................................................... 1-5

Section 1 General
1-2
1.1 MT9810A Optical Test Set
The main unit of the MT9810A Optical Test Set (hereafter referred to as the “Device”) forms the core of a group of
optical test set models. It has slots to enable mounting of two plug-in units. The Device is designed to operate units
mounted in the slots and display the status and measured results.
The MT9810A-01 (Option 01) for high power sensor is an option to use the MA9331A/MU931001A Optical-
Sensor/Sensor-Adapter and MU931431A Optical Sensor.
The MT9810A with this Option 01 installed can use all the plug-in units for the MT9810A.
The function, performance, and operation are the same as those of the MT9810A without this Option 01. For those
of the MA9331A/MU931001A Optical-Sensor/Sensor-Adapter and MU931431A Optical Sensor, refer to each the
separate operation manual.

1-3
1
General
1.2 Plug-in Unit
The Device enables mounting of the units shown below.
MU931311A Optical Sensor
High-sensitivity type Appendix A Specifications
MU931421A Optical Sensor
General-purpose type Appendix A Specifications
MU952501A - MU952505A Light Source
DFB-LD light source (With optical frequency variable function.) Appendix A Specifications
See the ordering information to select the model name and option number when specifying the optical frequency
(wavelength) of the light source.
Appendix B Ordering Information
MU951301A Light Source
FP-LD light source Appendix A Specifications
MU951501A Light Source
FP-LD light source Appendix A Specifications
MU951001A Light Source
Switchable FP-LD light source Appendix A Specifications
MU952601A - MU952606A Light Source
DFB-LD light source (With optical frequency variable function.) Appendix A Specifications
Incidentally, to specify an optical connector, add the double figure shown below together with a hyphen at the end
of each unit model name. The absence of the double figure means to specify a unit with an FC connector.
Unit with a FC-PC connector (Model name)-37
Unit with an ST connector (Model name)-38
Unit with a DIN connector (Model name)-39
Unit with an SC connector (Model name)-40
Unit with a HMS-10/A connector (Model name)-43
Appendix B Ordering Information
1.2 Plug-in Unit
