Anritsu MU150101A User manual

Document No.: M-W2425AE-12.0
ANRITSU CORPORATION
MU150101A
2.5/2.6G EoS Unit
Operation Manual
12th Edition
•For safety and warning information, please read this
manual before attempting to use the equipment.
•
Additional safety and warning information is provided
in the MP1590B Network Performance Tester
Operation Manual and
MP1591A Network Performance
Tester Operation Manual. Please also refer to
one of
these documents before using the equipment.
•
Keep this manual with the equipment.

ii
Safety Symbols
To prevent the risk of personal injury or loss related to equipment malfunction, Anritsu Corporation uses the
following safety symbols to indicate safety-related information. Ensure that you clearly understand the meanings of
the symbols BEFORE using the equipment. Some or all of the following symbols may be used on all Anritsu
equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this
manual.
Symbols used in manual
This indicates a very dangerous procedure that could result in serious injury or
death if not performed properly.
This indicates a hazardous procedure that could result in serious injury or death if
not performed properly.
This indicates a hazardous procedure or danger that could result in light-to-severe
injury, or loss related to equipment malfunction, if proper precautions are not taken.
Safety Symbols Used on Equipment and in Manual
The following safety symbols are used inside or on the equipment near operation locations to provide information
about safety items and operation precautions. Ensure that you clearly understand the meanings of the symbols and
take the necessary precautions BEFORE using the equipment.
This indicates a prohibited operation. The prohibited operation is indicated
symbolically in or near the barred circle.
This indicates an obligatory safety precaution. The obligatory operation is
indicated symbolically in or near the circle.
This indicates a warning or caution. The contents are indicated symbolically in or
near the triangle.
This indicates a note. The contents are described in the box.
These indicate that the marked part should be recycled.
MU150101A
2.5/2.6G EoS Unit
Operation Manual
1 September 2004 (First Edition)
12 July 2013 (12th Edition)
Copyright © 2004-2013, ANRITSU CORPORATION.
All rights reserved. No part of this manual may be reproduced without the prior written permission of the
publisher.
The contents of this manual may be changed without prior notice.
Printed in Japan
DANGER
WARNING
CAUTION

iii
Equipment Certificate
Anritsu Corporation certifies that this equipment was tested before shipment
using calibrated measuring instruments with direct traceability to public
testing organizations recognized by national research laboratories, including
the National Institute of Advanced Industrial Science and Technology, and
the National Institute of Information and Communications Technology, and
was found to meet the published specifications.
Anritsu Warranty
Anritsu Corporation provides the following warranty against stoppages
arising due to manufacturing error, and against problems with operation
occurring even though the procedures outlines in the operation manual were
followed.
Hardware:
Problems occurring within a period of one year from the date of delivery will
be corrected by Anritsu Corporation at no cost to the user.
Software:
Software reported as faulty within a period of 6 months from the date of
delivery will be corrected or replaced by Anritsu Corporation at no cost to the
user.
Following correction or replacement the software will remain under warranty
for either the remainder of 6 months from the date of initial delivery, or for a
period of 30 days, whichever is shorter.
The hardware and software warranties are not valid under any of the
following conditions:
•The fault is outside the scope of the warranty conditions separately
described in the operation manual.
•The fault is due to mishandling, misuse, or unauthorized modification or
repair of the equipment by the customer.
•The fault is due to severe usage clearly exceeding normal usage.
•The fault is due to improper or insufficient maintenance by the customer.
•The fault is due to natural disaster, including fire, wind, flooding,
earthquake, lightning strike, or volcanic ash, etc.
•The fault is due to damage caused by acts of destruction, including civil
disturbance, riot, or war, etc.
•The fault is due to explosion, accident, or breakdown of any other
machinery, facility, or plant, etc.
•The fault is due to use of non-specified peripheral or applied equipment
or parts, or consumables, etc.

iv
•The fault is due to use of a non-specified power supply or in a
non-specified installation location.
•The fault is due to use in unusual environments(Note).
•The fault is due to activities or ingress of living organisms, such as
insects, spiders, fungus, pollen, or seeds.
In addition, this warranty is valid only for the original equipment purchaser. It
is not transferable if the equipment is resold.
Anritsu Corporation shall assume no liability for injury or financial loss of the
customer due to the use of or a failure to be able to use this equipment.
Note:
For the purpose of this Warranty, "unusual environments" means use:
•In places of direct sunlight
•In dusty places
•Outdoors
•In liquids, such as water, oil, or organic solvents, and medical fluids, or
places where these liquids may adhere
•In salty air or in places where chemically active gases (sulfur dioxide,
hydrogen sulfide, chlorine, ammonia, nitrogen dioxide, or hydrogen
chloride etc.) are present
•In places where high-intensity static electric charges or electromagnetic
fields are present
•In places where abnormal power voltages (high or low) or instantaneous
power failures occur
•In places where condensation occurs
•In the presence of lubricating oil mists
•In places at an altitude of more than 2,000 m
•In the presence of frequent vibration or mechanical shock, such as in
cars, ships, or airplanes
Anritsu Corporation Contact
In the event that this equipment malfunctions, contact an Anritsu Service and
Sales office. Contact information can be found on the last page of the printed
version of this manual, and is available in a separate file on the CD version.

v
Notes On Export Management
This product and its manuals may require an Export License/Approval by
the Government of the product's country of origin for re
-export from your
country.
Before re
-exporting the product or manuals, please contact us to confirm
whet
her they are export-controlled items or not.
When you dispose of export
-controlled items, the products/manuals need
to be broken/shredded so as not to be unlawfully used for military purpose.
Notice
The following actions are strictly prohibited for all of the soft
ware installed
in this product or otherwise provided by Anritsu:
1. Copying, except for archival purposes.
2. Transferring to a third party separately from this product.
3.
Analyzing the incorporated software including but not limited to
modifying, decompiling, disassembling, and reverse engineering.

vi
CE Conformity Marking
Anritsu affixes the CE Conformity marking on the following product(s) in
accordance with the Council Directive 93/68/EEC to indicate that they
conform to the EMC and LVD directive of the European Union (EU).
CE marking
1. Product Model
Plug-in Units: MU150101A 2.5/2.6G EoS Unit
2. Applied Directive and Standards
When the MU150101A 2.5/2.6G EoS Unit is installed in the MP1590B or
MP1591A, the applied directive and standards of this unit conform to
those of the MP1590B or MP1591A main frame.
PS: About main frame
Please contact Anritsu for the latest information on the main frame
types that MU150101A can be used with.

vii
C-Tick Conformity Marking
Anritsu affixes the C-Tick mark on the following product(s) in accordance
with the regulation to indicate that they conform to the EMC framework of
Australia/New Zealand.
C-Tick marking
1. Product Model
Plug-in Units: MU150101A 2.5/2.6G EoS Unit
2. Applied Directive and Standards
When the MU150101A 2.5/2.6G EoS Unit is installed in the MP1591B or
MP1591A, the applied directive and standards of this unit conform to
those of the MP1590B or MP1591A main frame.
PS: About main frame
Please contact Anritsu for the latest information on the main frame
types that MU150101A can be used with.

viii

I
About This Manual
The MP1590 family operation manuals consist of separate documents for the
mainframe, module(s), control software, remote control operation, and options,
as shown below.
Note:
The MP1590 family is a general name for the MP1590B Network Per-
formance Tester, the MP1591A Network Performance Tester, and the
MP1595A 40G SDH/SONET Analyzer.
indicates this document.
MP1590B Network Performance Tester
Operation Manual
Describes basic operations of the MP1590B.
MX159501A 40G SDH/SONET Analyzer
Control Software Operation Manual SDH Edition
Describes how to operate the MP1595A control
software (SDH Edition).
MX159501A 40G SDH/SONET Analyzer
Control Software Operation Manual SONET Edition
Describes how to operate the MP1595A control
software (SONET Edition).
MX159001B Network Performance Tester
Control Software Operation Manual SONET Edition
Describes how to operate the MP1590B/MP1591A
control software (SONET Edition).
MX159001B Network Performance Tester
Control Software Operation Manual SDH Edition
Describes how to operate the MP1590B/MP1591A
control software (SDH Edition).
Describes basic operations of the MP1595A.
MP1595A 40G SDH/SONET Analyzer
Operation Manual
Configuration of MP1590
family Operation Manual

II
Describes specifications for the MU150101A.
MU150121A 10/10.7G Optical Unit (Tx)
MU150122A 10/10.7G Optical Unit (Rx Narrow)
MU150123A 10/10.7G Optical Unit (Rx Wide)
MU150134A 10/10.7G Optical Unit (Tx Ex. Mod)
Operation Manual
MU150101A 2.5/2.6G EoS Unit Operation Manual
MU150110A Multirate Unit Operation Manual
Describes specifications for the MU150125A.
MU150125A 10/10.7G Jitter Unit Operation Manual
Describes specifications for the MU150110A.
Describes specifications for the MU150121A/122A/
123A/134A.
Describes specifications for the MU150121B/23B.
MU150121B 10/10.7G Optical/Electrical Unit (Tx)
MU150123B 10/10.7G Optical/Electrical Unit (Rx Wide)
Operation Manual
Describes specifications for the MU150124B.
MU150124B 10.3G Optical/Electrical Unit (Rx Wide)
Operation Manual
Describes specifications for the MU150135A.
MU150135A 10/10.7G Optical Unit (XFP)
Operation Manual
Describes specifications for the MU150140A.
MU150140A 40/43G Unit Operation Manual
Describes specifications for the MU150141A/B.
MU150141A 40G Optical Unit
MU150141B 40/43G Optical Unit
Operation Manual
Describes specifications for the MU150142A.
MU150142A 40/43G Electrical Unit
Operation Manual
Describes specifications for the MU150100A.
MU150100A 10/10.7G Unit Operation Manual

III
Describes remote control of the MP1590B/MP1591A
via RS-232C, GPIB, and Ethernet Interfaces.
Describes specifications for the MP1590A/B-30.
MP1590A/B-30 High Precision Jitter Measurement
Operation Manual
Describes how to operate the software for monitoring
Ethernet traffic.
A
pplication Traffic Monitor
Operation Manual
Ethernet Module
Operation Manual
Describes basic operations of Ethernet modules.
MP1590B/MP1591A Network Performance Tester
Remote Control Operation Manual
Describes remote control of the MP1595A via
RS-232C, GPIB, and Ethernet Interfaces.
MP1595A 40G SDH/SONET Analyzer
Remote Control Operation Manual
Describes basic operations of SDH/SONET modules.
MU120119A OC-3/12 STM-1/4 Module (1310 nm)
MU120120A OC-3 STM-1 Module (1310 nm)
Operation Manual
MU120103A/B 2.5G (1.31) Module
MU120104A/B 2.5G (1.55) Module
MU120105A 10G (1.31) Module
MU120106A 10G (1.55) Module
Operation Manual
Describes basic operations of SDH/SONET modules.
Note:
The MU150142A 40/43G Electrical Unit is not for general sale and must
be special-ordered. Contact an Anritsu Service and Sales office re-
garding the purchase of this product.

IV.
Table of Contents
About This Manual........................................ I
Chapter 1 Overview.................................... 1-1
1.1 Product Overview......................................................... 1-2
Chapter 2 Before Use................................. 2-1
2.1 Environmental Conditions at Installation Site............... 2-2
2.2 Cautions on Handling Optical Fiber Cables ................. 2-3
Chapter 3 Names and Functions
of Each Part............................... 3-1
3.1 Names and Functions of each Plug-in Module Part..... 3-2

Chapter 1 Overview
1-1
1.1 Product Overview ...................................................... 1-2
1.1.1 MU150101A 2.5/2.6G EoS Unit .................... 1-2

Chapter 1 Overview
1-2
1.1 Product Overview
1.1.1 MU150101A 2.5/2.6G EoS Unit
No. Item Specifications
1.
1.1
Tx Interface
External Clock Input
up to 2.6G
Frequency
External clock input
1.544 MHz, 2.048 MHz, 8.448 MHz, 34.368 MHz, 44.736
MHz, 139.264 MHz
51.84 MHz, 155.52 MHz, 622.08 MHz, 2488.320 MHz,
2666.057 MHz (Option 05)
Frequency range
Level
Interface
±
100 ppm
0.55 to 1.05 Vp-p
SMA 50 ΩGND
1.2
1.5 Mbit/s Output
Bitrate
Accuracy
Pulse mask
Code
Interface
1.5 Mbit/s balanced
1.544 Mbit/s
Refer to 3.1.1.
DSX-0 ft: ANSI T1.102 fig.1
(After passing through 655 feet ABAM cable)
DSX-655 ft: ANSI T1.102 fig.1
AMI/B8ZS
BANTAM 100 ΩBalanced
1.3
2 Mbit/s Output
Bitrate
Accuracy
Pulse mask
Code
Interface
2 Mbit/s balanced
2.048 Mbit/s
Refer to 3.1.1.
ITU-T G703 table7 fig.15
HDB3
3 pin Siemens 120 ΩBalanced

1.1 Product Overview
1-3
No. Item Specifications
1.4
1.5
2 to 139/45/52/156Mbit/s
Output
Bitrate
Accuracy
Pulse mask
Code
Interface
Optical Output
Bitrate
Accuracy
Level
Safety Classification
Waveform
Extinction ratio
Code
Interface
Source type/modulation
Peak wavelength
Wavelength accuracy
2Mbit/s, 8Mbit/s, 34Mbit/s, 139Mbit/s,
45Mbit/s , 52Mbit/s, 156Mbit/s Unbalanced
2.048 Mbit/s, 8.448 Mbit/s, 34.368 Mbit/s, 44.736 Mbit/s,
139.264 Mbit/s, 51.84 Mbit/s, 155.52 Mbit/s
Refer to 3.1.1 and 3.1.2.
2.048 Mbit/s: ITU-T G703 table7 fig.15
8.448 Mbit/s: ITU-T G703 table8 fig.16
34.368 Mbit/s: ITU-T G703 table9 fig.17
139.264 Mbit/s: ITU-T G703 table10 fig.18, fig.19
155.520 Mbit/s: ITU-T G703 table12 fig.22, fig.23
44.736 Mbit/s, 51.84 Mbit/s:
DSX-0 ft:ANSI T1.102 fig.4 (44.736 Mbit/s)
(After passing through 450 feet 780Acable)
ANSI T1.102 fig.5 (51.84 Mbit/s)
(After passing through 450 feet 780Acable)
DSX-450 ft:ANSI T1.102 fig.4 (44.736 Mbit/s)
ANSI T1.102 fig.5 (51.84 Mbit/s)
DSX-900 ft: Same as DSX-450 ft + 450 feet 782 A cable
2.048 Mbit/s, 8.448 Mbit/s, 34.368 Mbit/s: HDB3
44.736 Mbit/s, 51.84 Mbit/s: B3ZS
139.264 Mbit/s, 155.52 Mbit/s: CMI
BNC 7 5Ω
52Mbit/s, 156Mbit/s, 622Mbit/s, 2.5Gbit/s, 2.6Gbit/s
Optical Output
51.84 Mbit/s, 155.52 Mbit/s, 622.08 Mbit/s,
2488.32 Mbit/s, 2666.057 Mbit/s (Option 05)
Refer to 3.1.1 and 3.2.1.
−1 to +3 dBm (att @0 dB, SDH VC4-Xc)
IEC 60825-1:2007: CLASS 1 LASER PRODUCT
Refer to Fig. 1.5-1 and Table 1.5-1.
10 dB or more
NRZ
FC-PC (SMF) (Can exchange connector by option)
DFB Direct modulation
1550 nm ±20 nm (Option02, 03)
1310 nm ±20 nm (Option01, 03)
±0.1 nm

Chapter 1 Overview
1-4
No. Item Specifications
1.6
−
20 dB width
SMSR
Optical attenuator
Attenuation
Accuracy
Resolution
1 nm or less
30 dB or more
Fig. 1.5-1 52M – 2.6G Pulse mask
Table 1.5-1 52M – 2.6G Pulse mask table
(need Option04)
0 to 30 dB
±0.5 dB (0 to 10 dB), ±1.0 dB (10.1 to 30 dB) (23 ±2°C)
0.1 dB
52M/156M 622M 2.5G/2.6G
X1/X4
0.15/0.85
0.25/0.75
−
X2/X3
0.35/0.65
0.40/0.60
0.40/0.60
Y1/Y2
0.20/0.80
0.20/0.80
0.25/0.75
Y
Mean level
of logical “1”
X
(0,0)
(1,0)
X
2
X
3
Y
1
-Y
1
1+Y
1
Y
2
Mean level
of logical “0”
(0,0.5)
(0,1)
X
1
X
4

1.1 Product Overview
1-5
No. Item Specifications
2.1
2.2
2.3
Rx Interface
1.5 Mbit/s Input
Bitrate
Level
Code
Interface
2 Mbit/s Input
Bitrate
Level
Code
Interface
2 to 139/45/52/156 Mbit/s
Input
Bitrate
Frequency range
Level
Code
Interface
1.5 Mbit/s balanced
1.544 Mbit/s ±100 ppm
3 V0-p, −6 to 2dB
(DSX-655 ft or DSX-0 ft+655 ft ABAM cable)
Monitor point 20, 26 dB
AMI/B8ZS
BANTAM 100 Ωbalanced
2 Mbit/s balanced
2.048 Mbit/s ±100 ppm
3 V ±0.3 V + cable loss 0 to 6 dB
Monitor point 20, 26 dB
HDB3
3pin Siemens 120 Ωbalanced
2 Mbit/s, 8 Mbit/s, 34 Mbit/s, 139 Mbit/s,
45 Mbit/s, 52 Mbit/s, 156 Mbit/s unbalanced
2.048 Mbit/s, 8.448 Mbit/s, 34.368 Mbit/s, 44.736 Mbit/s,
139.264 Mbit/s, 51.84 Mbit/s, 155.52 Mbit/s
±100 ppm
2.048 Mbit/s, 8.448 Mbit/s:
2.37 V ±0.237 V + cable loss 0 to 6 dB
Monitor point 20, 26 dB
34.368 Mbit/s:
1 V ±0.1 V + cable loss 0 to 12 dB
Monitor point 20, 26 dB
44.736 Mbit/s, 51.84 Mbit/s:
0.91 V0-p, −6 to 6dB +0 to 900 ft cable (728Cable)
Monitor point 20, 26 dB
139.264 Mbit/s, 155.52 Mbit/s:
1 V ±0.1 V + cable loss 0 to 12 dB
Monitor point 20 dB (non cable loss)
2.048 Mbit/s, 8.448 Mbit/s, 34.368 Mbit/s: HDB3
44.736 Mbit/s, 51.84 Mbit/s: B3ZS
139.264 Mbit/s, 155.52 Mbit/s: CMI
2/8/34 Mbit/s HDB3 BNC75 Ω
45/52 Mbit/s B3ZS BNC75 Ω
139/156 Mbit/s CMI BNC75 Ω

Chapter 1 Overview
1-6
No. Item Specifications
2.4
2.5
2.6
2.7
2.8
Optical Input
Bitrate
Frequency range
Wavelength
Level
Optical input return loss
Absolute Maximum
input power
Code
Interface
Optical power meter
Wavelength band
Measurement range
Accuracy
Receive Clock Output
Frequency
Level
Interface
Clock/Frame Sync. Out.
Tx, Rx Clock
Tx, Rx Frame
Level
Interface
Frequency counter
Frequency (f0)
Measurement range
Accuracy
51 Mbit/s, 156 Mbit/s, 622 Mbit/s, 2.5 Gbit/s, 2.6 Gbit/s
Optical input
51.84 Mbit/s, 155.52 Mbit/s, 622.08 Mbit/s,
2488.32 Mbit/s, 2666.057 Mbit/s
±100 ppm
1260 to 1610 nm
−33 to −8 dBm (51.84 Mbit/s, 155.52 Mbit/s)
−29 to −8 dBm (622.08 Mbit/s, 2488.32 Mbit/s, 2666.057
Mbit/s)
27 dB or more
+3 dBm (Average)
NRZ
FC-PC (SMF) (Can exchange connector by option)
1260 to 1360 nm (O band)
1460 to 1530 nm (S band)
1530 to 1565 nm (C band)
1565 to 1625 nm (L band)
−40 to −7 dBm
±1 dB (−30 to −10 dBm),
±2 dB (−9.9 to −7 dBm, −40.0 to −30.1 dBm) (23 ±2°C)
Receive Clock Output
1.544 MHz, 2.048 MHz, 8.448 MHz, 34.368 MHz,
44.736 MHz, 139.264 MHz
51.84 MHz, 155.52 MHz, 622.08 MHz, 2488.320 MHz,
2666.057 MHz (Option 05)
0.5 to 1.0 Vp-p
SMA 50 ΩGND
Clock/Frame Sync. Out.
OTU/SONET/SDH (52 MHz to 2.6 GHz)/PDH (139 MHz):
1/16 clock
PDH/DSn (1.5 to 45 MHz): 1/4 clock
OTU/SONET/SDH/PDH frame
H: 1.0 ±0.3 V L: 0.2 ±0.3 V
SMA 50 ΩGND
1.544 MHz, 2.048 MHz, 8.448 MHz, 34.368 MHz,
44.736 MHz, 139.264 MHz
51.84 MHz, 155.52 MHz, 622.08 MHz, 2488.320 MHz,
2666.057 MHz (Option 05)
f0 ±100 ppm
±0.2 ppm

1.1 Product Overview
1-7
No. Item Specifications
3.
3.1
3.1.1
Function
OTN/SDH/SONET mode
PDH/DSn
3.1.1.1
Clock
Internal:Accuracy:
±
0.1 ppm*1
Offset: ±100 ppm (in 0.1 ppm steps)
External: Refer to 1.1.
Receive: synchronous with receive signal
3.1.1.2
Frame format
No frame
Framed
MUX/DEMUX
1.544 Mbit/s, 2.048 Mbit/s, 8.448 Mbit/s, 34.368 Mbit/s,
44.736 Mbit/s, 139.264 Mbit/s
1.544 Mbit/s: D4/ESF/Japan ESF
2.048 Mbit/s: 30, 31ch with or without CRC4
8.448 Mbit/s: G.742
34.368 Mbit/s: G.751
44.736 Mbit/s: M13/C-bit
139.264 Mbit/s: G.751
139 M ⇔34 M ⇔8 M ⇔2 M ⇔64 K
139 M ⇔34 M ⇔8 M ⇔2 M
139 M ⇔34 M ⇔8 M
139 M ⇔34 M
45 M ⇔2 M ⇔64 K
45 M ⇔2 M
45 M ⇔1.5 M ⇔64 K
45 M ⇔1.5 M
34 M ⇔8 M ⇔2 M ⇔64 K
34 M ⇔8 M ⇔2 M
34 M ⇔8 M
8 M ⇔2 M ⇔64 K
8 M ⇔2 M
2 M ⇔64 K
1.5 M ⇔64 K
*1: After power-on, calibrate after 24 hour warm-up (when shipping, 23 ±5°C).
Aging: ±0.05 ppm/day, ±0.5 ppm/year (Max.)
Depends on the clock accuracy of the MP1590B/MP1591A/MP1595A.

Chapter 1 Overview
1-8
No. Item Specifications
3.1.1.3
Test pattern
PRBS: 211
−
1, 215
−
1, 220
−
1, 220
−
1z, 223
−
1 Invert ON/OFF
(220−1z: Only 1.5 Mbit/s, 45 Mbit/s)
Word: 16 bits Program, all0, all1, 3in24
(3in24: Only 1.5 Mbit/s)
(Can set Tx/Rx independently.)
3.1.1.4
Error addition
Type
Timing
No frame: Bit all, Code,
EXZ (1.5 Mbit/s (B8ZS), 45 Mbit/s)
1.5 Mbit/s frame: Bit all, Bit info, FAS, Code,
EXZ (B8ZS),CRC6 (ESF/Japan ESF)
2 Mbit/s frame: Bit all, Bit info, FAS, Code,
Ebit (CRC4 On)
8 Mbit/s frame: Bit all, Bit info, FAS, Code
34 Mbit/s frame: Bit all, Bit info, FAS, Code
45 Mbit/s frame: Bit all, Bit info, FAS, Code, EXZ,
Parity (M13/Cbit), Cbit (C-bit),
REI (C-bit)
139 Mbit/s frame: Bit all, Bit info, FAS, Code
Single, Rate (1.0E-n, n: 3 to 9), all
FAS: 1 in 16, 2 in 16, 3 in 16, 4 in 16, All
3.1.1.5
Alarm addition
Type
Timing
No frame: LOS, AIS (1.5 Mbit/s, 2 Mbit/s, 8 Mbit/s,
34 Mbit/s, 139Mbit/s)
1.5 Mbit/s frame: LOS, LOF, AIS, RDI
2 Mbit/s frame: LOS, LOF, AIS, RDI,
RDI (MF) (CRC4 On)
8 Mbit/s frame: LOS, LOF, AIS, RDI
34 Mbit/s frame: LOS, LOF, AIS, RDI
45 Mbit/s frame: LOS, LOF, AIS, RDI
139 Mbit/s frame: LOS, LOF, AIS, RDI
All, Alternative (except for LOS), Burst
