Anzzi SD-AZ054-01 Series User manual

INSTALLATION & OPERATION MANUAL
V1.1 – This version supersedes all previous versions as of 3/31/2022

Pleasechecktheproduct for damage and missing parts immediately upon delivery.
Damage reported later will not be covered by our warranty. Please handle the
product with care. Avoid any impact to the sides and edges of the glass.
is being
(if required by local code) plumber for all plumbing installations.
Before beginning installation, make sure all surfaces are level, solid and will
support the total weight of the unit. Also, make sure the walls are at right angles.
Irregular installation surface level, radius corners, or improper angle of side walls
will result in serious problems for your installation. Please note that some
adjustments and drilling might be necessary during the installation process.
in
When cutting or drilling metal components or handling glass, wear protective
eye wear, gloves, and closed-toe shoes to reduce the risk of personal injury.
Failure to follow instructions when installing this product may result in personal
injury, property damage, or product failure and may void the warranty.

Phillips
Screwdriver
Level Tape
Measure
Drill 1/8''
(3mm)
Drill Bit
1/4''
(6mm)
Drill Bit
Surface of the tub deck must be level for better sealing.
This product is heavy
and may require two
people to install.
.
Use cut-resistant,
non-slip gloves to
reduce the risk of
personal injury and
to hold the glass firmly.
.
100%
Silicone
Sealant
Pencil Rubber
Mallet
Safety
Glasses
Stud Finder
This product is heavy and may require two people to install.

[01] x1 [02] x1 [03] x1 [04] x1 [05] x1 [07] x1
[06] x2
[11] x7 (ST4x35mm
[1-3/8"])
[12] x3 (ST4x8mm
[5/16"])
[10] x3
[08] x1 [09] x1
[13] x3 [14] x1 (1.5mm) [15] x4 [16] x2
3

Part Description Qty.
[01] Wall Post 1
[02] Side Water Sealing Strip 1
[03] Water Sealing Strip 1
[04] Fixed Panel
[05] Door Panel
[06] Glass shelves
[07] Handle Sets
[08] Top Shaft Seat
[09] Bottom Shaft Seat
[10] Anchors 3
[11] Screws ST4X35 7
[12] Screws ST4X8 3
[13] Screw Caps 3
[14] 1.5mm Allen Key 1
[15] Brackets 4
[16] Bracket Set 2
Part Qty.
1
1
1
2
1
1
4
Description

5

Using a stud finder, ensure the wall intended to hold the door has a
stud at the installation point. If there is no stud in the shown area, we recommend
employing a qualified contractor to install one.
1. This shower door must be mounted to a stud. Minimum tub desk space is required.
Fig 1
6
2. This manual shows left side installation. For right side installation, transpose all instructions.

4. Fasten the Wall Post [01] to the wall with the Screw ST4X35 [11] (Fig 2.5).
3. Apply silicone sealant along the back of the Wall Post [01] (Fig 2.4).
2. Drill a 1/4" hole at each location and insert the Anchors [10] (Fig 2.2, Fig 2.3).
1.Mark the drill hole locations on the wall using the predrilled holes in the Wall Post [01]
(Fig 2.1).
7
Step 2
Fig 2

Slide the Side Water Sealing Strip [02] to the groove
of Fixed Panel [04]. (Fig 3)
Note: Make sure the flange of Side Water Sealing
Strip [02] points inside after the Fixed Panel [04] is
secured to Wall Post [01]. (Fig 3.1)
1.
Attach Door Panel [05] to the Fixed Panel [04]
and secure by Top Shaft Seat [08] and Bottom
Shaft Seat [09] and 4 Screw ST4X35 [11] at
the top (Fig 4.1) and the bottom (Fig 4.2).
Note: Make sure the round corner is at the top.
1.
round corner
8
Fig 3
Fig 4

9
Fig 5
1. Attach the Water Sealing Strip [03] to the bottom edge of the Door Panel [05] (Fig 5.1).
The flange of Water Sealing Strip [03] should face the wall.

10
1. Disassemble the Bracket Set [16] and install to the hole the Fixed Panel [04].
2. Install the button and o-ring to the outside of outer surface. Then install thesleeve,
o-ring, anchor, screw to the inner surface. (Fig 6.1)
3. Adjust groove of the Bracket Set [16] to the horizontal position and secure by
tightening the screw. (Fig 6.2)
Fig 6

Remove the Glass Shelves
[06].
4.
Mark the Brackets [15] outline
on the wall.
3.
Adjust Glass Shelves [06] to
the horizontal position.
2.
Brackets [15] to the Bracket
Set [16] and wall. (Fig 8)
Install Glass Shelves [06] with
1.
Remove the Brackets [15]
from the Glass Shelves [06].
5.
11
Step 7
Install Brackets [15] to the Glass Shelves [06] according to the measurements in
Fig 7.
Secure the Brackets [15] by tightening the screws. Do Not over tighten.
1.
2.
Step 8
Fig 7
Fig 8

Wear safety glasses and cut-resistant, non-slip gloves when drilling or cutting to avoid
risk of injury.
Step 9
1. Place the Brackets [15] on the marks and mark the holes on the wall. (Fig 9.1)
2. Drill a 1/4" hole at each location. (Fig 9.2)
3. Insert the Wall Plugs. (Fig 9.3)
4. Mount the Brackets [15] to the wall using the flat head screws .
NOTE: The padded set screw of the Brackets [15] should be facing down.
12
Fig 9
1
2
3
4

1. Slide the Glass Shelves [06] into the Brackets [15] and tighten the set screws
to secure.
Step 10
13
Fig 10
1

Fig 12
Allow 24 hours for the silicone to
fully cure before using the shower.
Step 12
1. Apply a good quality Silicone Sealant at the
outer corner formed by the wall and the Wall
Post [01], and the outer corner formed by tub
deсk and Fixed Panel [04] (Fig 12).
Hours
24
Step 11
1. Disassemble gaskets by removing handle knobs (Fig 11.1).
2. Install handle, washers and handle knobs to the Door Panel [05]. Tighten handle knob with
allen key to secure (Fig 11.2).
IMPORTANT: Ensure handle gaskets and washers are placed on each side of glass.
1 2
Fig 11
gasket
Allen Key
14
handle knob
handle

Care & Maintenance
BASES and BACK WALLS: To ensure long-lasting life for your acrylic tub and back walls
(if installed), wipe them off after each use with a soft cloth. To clean the acrylic surface, use
non-abrasive sprays or cream based cleaners. Avoid the use of aerosol spray cleaners.
Never use abrasive cleansers, metal brushes, or scrapers, as they can scratch or dull the
surface.
GLASS: To ensure long-lasting life for your glass shower products, after each use rinse
and wipe off the glass using either a soft cloth or a squeegee to prevent soap buildup
and water spots (hard water can etch the surface of the glass over time if left to dry).
To avoid damaging the surface, never use abrasive cleaners or cleaning products that
contain scouring agents. Likewise, never use bristle brushes or abrasive sponges that can
scratch the surface.
HARDWARE: To ensure a long-lasting finish, wipe off the metal parts after using with a
soft cloth. Do not use abrasive cleaners or cleaning products containing ammonia, bleach,
or acid. If accidentally used, rinse the surface as soon as possible to prevent damage to the
finish (peeling or corrosion). After cleaning the polished finishes, rinse thoroughly and wipe
dry with a soft cloth. Clean stainless steel surfaces at least once a week. When applying
stainless steel cleaner or polish to stainless steel hardware, work with (not across) the
grain. Never use an abrasive sponge or cloth, steel wool, or wire brush, which may
permanently scratch the surfaces.
NOTE: Regularly inspect the glass and all hardware for misalignment, proper
attachment, and damage. Contact ANZZI with any questions or concerns.
