Anzzi TUNDRA SP-AZ039 User manual

INSTALL GUIDE
Model#
SP-AZ039
TUNDRA
PERFECTION IS OUR TRADITION™
v2.0516

Parts List Pg. 1
Before You Start Pg. 2
Spec Drawing Pg. 3
Installation Pg. 4
Care & Maintenance Pg. 10
Warranty Pg. 11
Registration Final Page
TABLE OF CONTENTS
YOUR REVIEWS MATTER!
For more information please call 1-844-44-ANZZI
or email us at [email protected]
The ANZZI™ Family thanks you for your purchase and hopes you enjoy your very own ANZZI
product for years to come! In the meantime let us know about your experience? We would love
to hear your thoughts from the packaging to the quality and function of the product.
Leave a review on www.ANZZI.com/reviews and let everyone know how satisfied you are with
ANZZI!
Also, we humbly request submitting as many pictures as possible along with your review.
Millions of shoppers will want to know about your experience with our products. Don’t just tell
but show, too!

PARTS LIST
PERFECTION IS OUR TRADITION™
pg. 1
1. Shower Head
2. Diverter
3. Body Jets
4. Mixer
5. Hand Shower
1
2
4
3
3
3
5
Component no.
Component
Material
1
head shower
ABS
2
3
body panel
s/s
4
knob
zinc
5
function cartridge
ABS
6
handle
zinc
7
catridge cap
ABS
8
thermostatic cartridge
ABS
9
body jets
ABS
10
fixing bar
s/s
11
one way joint
ABS
12
clip
s/s
13
faucet 1
brass
14
two way joint
ABS
15
faucet 2
brass
16
hand shower
ABS
17
hand shower holder
ABS
18
pvc hose
PVC
19
braided hose 1
s/s
20
braided hose 2
s/s
21
flexible hose
s/s
top part
s/s
1
2
4
3
6
5
7
8
16
17
18
13
14
15
9
10 11
20
21
12 19

PERFECTION IS OUR TRADITION™
pg. 2
For any questions or concerns contact
our dedicated technical support team
at 1-844-44-ANZZI.
BEFORE YOU START
Screwdriver Channel Locks
Adjustable Wrench Allen key
Goggles
Teflon tape
Recommended Items
ATTENTION: Please read all instructions thoroughly
including all warnings, attentions and notes before
beginning installation.

TUNDRA
PERFECTION IS OUR TRADITION™
pg. 3
SPEC
DRAWING
SP-AZ039
Perfection is our Tradition™
Material: Stainless Steel
Finish: Brushed
Handles: 2
Jets: 3
Shower: Ø6.22”
Sprayer: 60” reach
Weight: 19.36 lbs
Height: 62.99”
Supply: 1/2” connections
Flow: 2.5 gpm
Features
Heavy Rain™ Showerhead
Acu-Stream™ high pressure body jets
Euro-Grip™ hand held sprayer
Rhino Alloy™ certified materials
20.47
7.87
62.99

Figure A
INSTALLATION (SETUP)
PERFECTION IS OUR TRADITION™
pg. 4
Before drilling any holes for the shower panel brackets, ensure there are no hidden cables or
pipelines aligned with the desired drilling position.
Drill the two holes for the top bracket 1” apart at the desired height.
Drill the two holes for the bottom bracket 1” apart at approximately 45” below the top bracket.
IMPORTANT
Step A
Step A.2
Ø 6mm Drill
1 INCH

Figure B
INSTALLATION (SETUP)
PERFECTION IS OUR TRADITION™
pg. 5
Insert the wall anchors into the pre-drilled holes as shown in Figure B.
Place the shower panel brackets aligned with the drilled holes and using a Philips screw-
driver tighten the screws to secure the brackets.
Step B
Step C
Figure C

Figure 1
INSTALLATION (HANDSHOWER)
PERFECTION IS OUR TRADITION™
pg. 6
Insert the shower wand holder through the pre-drilled hole on the shower panel.
Install the water supply hose for the shower wand onto the holder, as shown.
Make sure all O-rings are inserted to prevent leakage.
Once the shower panel is fully installed and hung on the bracket, you can install the shower
wand hose to the holder connection.
Step 1A
Step 1B
Step 1C
Step 1D

Figure 2
INSTALLATION (HANDSHOWER)
PERFECTION IS OUR TRADITION™
pg. 7
Finally, install the shower wand to the hose, as shown.Step 2A
1 Setting
Hand
Shower
3 Setting
Hand
Shower
or

Figure 3
INSTALLATION (SHOWER HEAD)
PERFECTION IS OUR TRADITION™
pg. 8
Place and align the top shower panel with the pre-drilled holes on the top side of the wall
mounted panel.
Using the screws and washers provided, secure the top panel with the wall mounted panel.
Once the top panel is set in place you can continue with the wall mounting process.
Step 3A
Step 3B
Step 3C

Figure 4
INSTALLATION (WALL MOUNTING)
PERFECTION IS OUR TRADITION™
pg. 9
Screw the cold and hot water hose from the shower panel to the supply lines in the wall.
Carefully hang the shower panel on the secured mounting brackets as shown in Figure 4.
Step 4A
Step 4B
Hot
Cold

pg. 10
CARE AND MAINTENANCE
ANZZI™ products are crafted with superior quality standards and workmanship and are engineered to
stand the test of time. However, that does not mean the product can be neglected and will need some
care and cleaning.
It is recommended to use regular soap and hot water along with a non-abrasive cloth or sponge to
regularly clean the product. This avoids any nasty build up or deposits which would be tougher to
remove.
If you feel the use of stronger cleaning solutions or chemicals is necessary always test the cleaning
solution or chemical on an inconspicuous area before applying to the entire surface.
Wipe all surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and
dry any overspray that lands on nearby surfaces.
DO NOT ALLOW THE CLEANER TO SOAK.
Following these simple principles will ensure your ANZZI™ product will remain as lustrous and
stun-ning as the day it was first received. ENJOY!
Sincerely,
La Familia ANZZI™
For more information visit us at www.ANZZI.com
Perfection is our Tradition™
For more information visit us at www.ANZZI.com
Perfection is our Tradition™

pg. 11
LIMITED LIFETIME WARRANTY
ANZZI™ products are manufactured with superior quality standards and workmanship and are
backed by our limited lifetime warranty. ANZZI™ products are warranted to the original consumer
purchaser to be free of defects in materials or workmanship. We will replace FREE OF CHARGE* any
product or parts that proves defective. Simply call 1-844-44-ANZZI (1-844-442-6994) to submit a
warranty claim and request an RMA. Proof of purchase (original sales receipt) from the original con-
sumer purchaser must be made available for all ANZZI™ warranty claims.
This warranty excludes incidental/inconsequential damages and failures due to misuse, abuse or
normal wear and tear. This warranty excludes all industrial, commercial & business usage, whose
purchasers are hereby, extended a five year limited warranty from the date of purchase, with all other
terms of this warranty applying except the duration of warranty.
Some states and provinces do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations may not apply to you. This warranty gives you specific legal rights
and you may also have other rights that vary from state to state and province to province. Please con-
tact 1-844-44-ANZZI (1-844-442-6994) or visit www.ANZZI.com/Warranty for more details.
Sincerely,
La Familia ANZZI™
Perfection is our Tradition™
*Shipping and handling fees are not covered under the ANZZI™ Warranty.
