PARTS LIST
PERFECTION IS OUR TRADITION™
pg. 1
2. Shower Head
1. Waterfall
3. Diverter
4. Body Jets
5. Mixer
6. Hand Shower
12
6
4
5
3
4
4
3
22
23
3
2
1
4
5
8
7
6
11
10
9
15
16 17
18
19
13
21
20
12
14
Component no.
Component
Material
1
water fall
2
head shower
ABS
3
clip
s/s
4
body
5
PVC hose
PVC
6
ABS
7
8
9
faucet part 1
10
ABS
11
knob plate cover
12
knob
zinc
13
two way joint
ABS
14
faucet part 2
brass
15
thermostatic cartidge
ABS
16
17
18
handle
zinc
19
one way joint
ABS
20
braided hose
s/s
brass
s/s
function cartridge
body jets
one way joint ABS
s/sfixing bar
brass
brass
handle plate cover brass
21 hand shower ABS
22 hand shower hlolder ABS
23 flexible hose s/s
valve cap
ABS

PERFECTION IS OUR TRADITION™
pg. 2
For any questions or concerns contact
our dedicated technical support team
at 305-614-4070.
BEFORE YOU START
Screwdriver Channel Locks
Adjustable Wrench Allen key
Goggles
Teflon tape
Recommended Items
ATTENTION: Please read all instructions thoroughly
including all warnings, attentions and notes before
beginning installation.

LEVEL
PERFECTION IS OUR TRADITION™
pg. 3
SPEC
DRAWING
SP-AZ056
Perfection is our Tradition™
Material:
Finish: Black
Handles: 3
Jets: 3
Shower: 2.99” x 6.535”
Sprayer: 60” reach
Weight: 14.74 lbs
Height: 64.96”
Supply: 1/2” connections
Flow: 2.5 gpm
Features
Heavy Rain™ Showerhead
Acu-Stream™ high pressure body jets
Euro-Grip™ hand held sprayer
Rhino Alloy™ certified materials
18.90
7.87
64.96

Figure A
INSTALLATION (SETUP)
PERFECTION IS OUR TRADITION™
pg. 4
Before drilling any holes for the shower panel brackets, ensure there are no hidden cables or
pipelines aligned with the desired drilling position.
Drill the two holes for the top bracket 1” apart at the desired height.
Drill the two holes for the bottom bracket 1” apart at approximately 45” below the top bracket.
IMPORTANT
Step A
Step A.2
Ø 6mm Drill
1 INCH

Figure B
INSTALLATION (SETUP)
PERFECTION IS OUR TRADITION™
pg. 5
Insert the wall anchors into the pre-drilled holes as shown in Figure B.
Place the shower panel brackets aligned with the drilled holes and using a Philips screw-
driver tighten the screws to secure the brackets.
Step B
Step C
Figure C

Figure 1
INSTALLATION (HANDSHOWER)
PERFECTION IS OUR TRADITION™
pg. 6
Insert the shower wand holder through the pre-drilled hole on the shower panel.
Install the water supply hose for the shower wand onto the holder, as shown.
Make sure all O-rings are inserted to prevent leakage.
Once the shower panel is fully installed and hung on the bracket, you can install the shower
wand hose to the holder connection.
Step 1A
Step 1B
Step 1C
Step 1D

Figure 2
INSTALLATION (HANDSHOWER)
PERFECTION IS OUR TRADITION™
pg. 7
Finally, install the shower wand to the hose, as shown.Step 2A
1 Setting
Hand
Shower
3 Setting
Hand
Shower
or

Figure 4
INSTALLATION (WALL MOUNTING)
PERFECTION IS OUR TRADITION™
pg. 8
Screw the cold and hot water from the shower panel to the supply lines in the wall.
Carefully hang the shower panel on the secured mounting brackets as shown in Figure 4.
Step 4A
Step 4B
Hot
Cold

pg. 9
CARE AND MAINTENANCE
ANZZI®products are crafted with superior quality standards and workmanship and are engineered to
stand the test of time. However, that does not mean the product can be neglected and will need some
care and cleaning.
It is recommended to use regular soap and hot water along with a non-abrasive cloth or sponge to
regularly clean the product. This avoids any nasty build up or deposits which would be tougher to
remove.
If you feel the use of stronger cleaning solutions or chemicals is necessary always test the cleaning
solution or chemical on an inconspicuous area before applying to the entire surface.
Wipe all surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and
dry any overspray that lands on nearby surfaces.
DO NOT ALLOW THE CLEANER TO SOAK.
Following these simple principles will ®product will remain as lustrous and
stun-ning as the day it was first received. ENJOY!
