Event Lighting TSUNAMI-IP User manual

TSUNAMI-IP
Outdoor LED Tilt Moving Head
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications
within this manual are subject to change without notice. Event Lighting assumes no liability or
responsibility for any errors or omissions. Please consult Event Lighting for any clarification or
information regarding this item.
Version: 1 (1 September 2022)

2
www.event-lighting.com.au
Safety Instructions
Warning
• Do not open this device, there is no user-serviceable parts inside. Risk of electric shock.
• Do not look at the light source when the device is on.
Caution: This unit's housing may be hot during and after operation.
• Install this device in a location with adequate ventilation, at least 50 cm from adjacent
surfaces.
• Do not leave any flammable material within 50 cm of this unit while operating or connected to
power.
• Use a safety chain when mounting this device overhead.
• This product is rated IP65, meaning it is protected against dust and water jets from all
directions. Do not operate this device in any location where excessive heat or water beyond
the IP65 specification may affect it.
• Do not operate this device if the housing, lenses, or cables appear damaged.
• Do not connect this device to a dimmer or rheostat.
• ONLY connect this device to a grounded and protected circuit.
• ONLY use the hanging bracket to carry this device.
• In case of a serious operating problem, stop using immediately.
• The maximum ambient temperature is 40° C. Do not operate this device at higher
temperatures.
Power Input and Power Linking
This device has an auto-switching power supply that works with input voltage range of 100~240 VAC,
50/60 Hz.
Link up to a maximum of 8A. Do NOT exceed this.
Product Installation
• This fixture can be mounted in many orientations provided each individual fixture is secured by
the use of correct mounting bracket.
• Use a safety chain when mounting this device overhead.

3
www.event-lighting.com.au
Dimensions
Lux Chart

4
www.event-lighting.com.au
Menu Operation
Menu – Move up a level.
Up – Move selection up one item.
Down – Move selection down one item.
Enter – Select / Move down a level.
Menu
Level 1
Level 2
Description
DMX Address
001-512
Set DMX address
DMX Channel
Mode
7 Channel Mode
7 channel DMX mode
14 Channel Mode
14 channels DMX mode
42 Channel Mode
42 channels DMX mode
Dimmer Mode
Dimmer Mode 1
Dimmer Mode 2
Dimmer Mode 3
Dimmer Mode 4
Dimmer Mode 5
Dimmer Curve
Dimmer Curve 1
Dimmer Curve 2
Dimmer Curve 3
Dimmer Curve 4
Manual Colour
Tilt
000-255
Tilt Fine
000-255
Aura Dimmer
000-255
Aura Strobe
000-255
Aura Red
000-255
Aura Green
000-255
Aura Blue
000-255
Aura Macro
000-255
Aura Macro Colour
000-255
Aura Macro Speed
000-255
White Dimmer
000-255
White Strobe
000-255
White Macro
000-255
White Macro
Speed
000-255
Language
English

5
www.event-lighting.com.au
Chinese
Display
Normal
Reverse
Flip 180°
Backlight
On
Always on
30s
Off after 30 seconds of inactivity
DMX Fail
Blackout
Blackout when DMX signal lost
Hold
Keep last DMX value when DMX signal
lost
Factory Settings
No
Yes
Reset to factory settings
System Info
RDM UID
Version
Software Version
DMX Channel
Current DMX channel mode
Run time
Total usage time
User time
Time since power on
Temperature
Current temperature
DMX Chart
This fixture is controlled by the universal DMX 512 protocol. The DMX address is the first channel
used to receive instructions from the external controller. For independent control, each fixture must
be assigned a unique address for each of its control channels. For example, this device has three
channel modes: 7/14/42, if it’s set to 7 channel mode, and there are several fixtures need to be
independently controlled, we just simply address first fixture at 1, and second fixture at 8, third one
at 15, etc. !
• If multiple fixtures have the same DMX address, they will behave synchronically. !
• Display will flash when no DMX signal is received. !
Mode/Channel
Min
DMX
Max
DMX
7
Ch
14
Ch
42
Ch
Function
Description
1
1
1
Tilt
0
255
Tilt Movement
2
2
Tilt Fine
0
255
Tilt Fine Movement
2
3
3
Beam Dimmer
0
255
Strobe Dimmer, 0-100%
3
4
4
Beam Mode
0
5
No Strobe
6
42
Strobe Mode 1
43
85
Strobe Mode 2
86
128
Strobe Mode 3
129
171
Strobe Mode 4
172
214
Strobe Mode 5
215
255
Strobe Mode 6

6
www.event-lighting.com.au
5
5
Beam Duration
0
255
0-3 sec
6
6
Beam Macro
0
15
No Macro
16
57
Strobe Macro 1
58
99
Strobe Macro 2
100
141
Strobe Macro 3
142
183
Strobe Macro 4
184
225
Strobe Macro 5
226
255
Strobe Macro 6
4
7
7
Plate Red
0
255
Red Dimmer, 0-100%
5
8
8
Plate Green
0
255
Green Dimmer, 0-100%
6
9
9
Plate Blue
0
255
Blue Dimmer, 0-100%
7
10
10
Plate Strobe
0
9
No Strobe
10
255
Strobe, slow to fast
11
11
Plate Macro
0
4
No Macro
5
9
Plate Macro 1
10
14
Plate Macro 2
15
19
Plate Macro 3
…
…
…
250
254
Plate Macro 50
255
255
Plate Macro 51
12
12
Plate Macro colour
0
255
Plate Macro colour
13
13
Plate Macro Speed
0
255
Plate Macro Speed
14
14
Reserved
0
255
Reserved
15
Beam Section 1
0
255
Beam Section 1 dimmer, 0-100%
16
Beam Section 2
0
255
Beam Section 2 dimmer, 0-100%
17
Beam Section 3
0
255
Beam Section 3 dimmer, 0-100%
18
Beam Section 4
0
255
Beam Section 4 dimmer, 0-100%
19
Plate Section 1 Red
0
255
Plate Section 1 Red dimmer, 0-100%
20
Plate Section 1
Green
0
255
Plate Section 1 Green dimmer, 0-
100%
21
Plate Section 1 Blue
0
255
Plate Section 1 Blue dimmer, 0-100%
…
…
…
…
…
40
Plate Section 8 Red
0
255
Plate Section 8 Red dimmer, 0-100%
41
Plate Section 8
Green
0
255
Plate Section 8 Green dimmer, 0-
100%
42
Plate Section 8 Blue
0
255
Plate Section 8 Blue dimmer, 0-100%

7
www.event-lighting.com.au
Technical Specifications
Photometrics
• Light Source:
o RGB: 480x SMD5050 0.5W 3-in-1 LEDs
o Strobe: 144x 5W White LEDs
• Beam Angle: 117°
• Output:1,800 lux @ 5m
• LED Lifespan: 50,000 hours
Effects
• Dimming: 0~100%
• Strobe: 0.3-20 Hz
Movement
• 8 / 16 – bit movement
• Tilt: 270°
Power
• Input Voltage: 100~240V AC, 50/60 Hz
• Power Consumption: 1,000 W
• Connection: True1 in/out
Control
• Protocol: DMX512
• Operation Modes: DMX, auto, manual, sound active, master/slave
• DMX Channels: 7/14/42
• Interface: 3-pin XLR in & out
• Display: 4-button 2.4-inch LCD control panel
• Cooling: Fan
Housing
• Materials: Metal & Flame retardant ABS
• Finishing: Matte black
• IP rating: IP65
• Net Weight: 12 kg
Warranty
Please refer to your local dealer or please contact Event Lighting Pty Ltd.
