Apantac KVM-SET-14 User manual

KVM-SET-14
APANTAC LLC, 10200 SW Allen BLVD, STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
KVM-SET-14
4K HDMI with USB
KVM Extenders
Over Gigabit Ethernet
Manual and Setup Guide
(Firmware A6.6.0.7, 01/09/2019)

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
1
COPYRIGHT and TRADEMARK
All rights reserved by APANTAC LLC, Porland, Oregon, USA. No part of this document may be
reproduced in any form or by any means without written permission from the product manufacturer.
Changes are periodically made to the information in this document. They will be incorporated in
subsequent editions. The product manufacturer may make improvements and /or changes in the
product described in this document at any time.
All the registered trademarks referred to this manual are belonging to their respective companies.
WARRANTY STATEMENT
Apantac LLC (herein after referred to as “Apantac”) warrants to the original purchaser of the
products manufactured by Apantac (the “Product,”) will be free from defects in material and
workmanship for a period of three (3) year from the date of shipment of the Product to the
purchaser.
If the Product proves to be defective during the three (3) year warranty period, the purchaser’s
exclusive remedy and Apantac’s sole obligation under this warranty is expressly limited, at
Apantac’s sole option, to:
(a) repair the defective Product without charge for parts and labor or,
(b) provide a replacement in exchange for the defective Product or,
(c) if after a reasonable time, is unable to correct the defect or provide a replacement Product
in good working order, then the purchaser shall be entitled to recover damages subject to
the limitation of liability set forth below.
Limitation of Liability
Apantac’s liability under this warranty shall not exceed the purchase price paid for the defective
product. In no event shall Apantac be liable for any incidental, special or consequential damages,
including without limitation, loss of profits for any breach of this warranty.
If Apantac replaces the defective Product with a replacement Product as provided under the
terms of this Warranty, in no event will the term of the warranty on the replacement Product
exceed the number of months remaining on the warranty covering the defective Product.
Equipment manufactured by other suppliers and supplied by Apantac carries the respective
manufacturer’s warranty. Apantac assumes no warranty responsibility either expressed or implied
for equipment manufactured by others and supplied by Apantac.

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
2
This hardware warranty shall not apply to any defect, failure or damage:
a) Caused by improper use of the Product or inadequate maintenance and care of the
Product;
b) Resulting from attempts by those other than Apantac representatives to install, repair, or
service the Product;
c) Caused by installation of the Product in a hostile operating environment or connection of
the Product to incompatible equipment;

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
3
Table of Contents
1.0 What’s in the Box.......................................................................................................... 4
2.0 Key Features ................................................................................................................. 4
3.0 Panels and Connectors.............................................................................................. 5
4.0 Configuraitons.............................................................................................................. 6
4.1 Setup Mode................................................................................................................... 6
4.2 Operation Mode............................................................................................................ 7
4.3 Network Configuration ............................................................................................... 8
4.4 Function Configurations............................................................................................. 9
4.5 Video Wall Configuration (Rx).................................................................................11
5.0 Installation...................................................................................................................13
5.1 USB and KM IP Installation......................................................................................14
6.0 External Software ......................................................................................................15

KVM-SET-14
4
1.0 What’s in the Box
The KVM Extenders can be sold in pairs (sets) or individually, depending on the
configuration of the system.
KVM-SET-14
•1 x KVM-IP-Tx-PL
•1 x KVM-IP-Rx-P
KVM-IP-Tx-PL
•1 x KVM-IP-Tx-PL
KVM-IP-Rx-P
•1 x KVM-IP-Rx-P
2.0 Key Features
–Based on Gigabit Ethernet Technology (IGMP and Jumbo frame)
–Transmitter has built-in HDMI looping input with POE
–Receiver with POE
–Support up to 170 meters point to point extension over CAT6
–Supports up to 100 meters when used with a GigE switch
–Supports HDMI inputs and output signals
–Suports point to point (Unicast), point to multi-point (Multicast) for audio/video
distribution
–Receivers has 4 USB ports that supports both HID and transparent USB (for
storage and tablets)
–Supports bi-directional stereo audio. Both embedded HDMI as well as external
stereo input
–Supports RS-232 commuication between Tx and Rx
–Built-in webpage for configuration
–Connection manager and video wall manager for Tx/Rx management
–Supports up to 4K/UHD@30Hz
–Advanced EDID management functionality. Built-in EDID, EDID ass through, copy
EDID and sharing EDID
–Built-in Scaler
–LED status indicators
–Plug and Play

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
5
3.0 Panels and Connectors
KVM-IP-Tx-PL Transmittier (Tx)
Connector Description
1 Gigabit Ethernet Connect to Gigabit Ethernet switch or directly to RX.
2 HDMI in
Connect to HDMI Source, or use HDMI-to-DVI adapter cable for DVI
source.
3 HDMI Loopout Connect to HDMI local monitor
4 Line in
KVM-IP-Tx-PL supports both HDMI and 3.5mm audio. This 3.5mm input
audio will be extended to the Line Out of RX.
5 Line out This 3.5mm Line Out audio is extended from Microphone Input of RX.
6 USB-to-PC Connect this USB-B to PC for USB 2.0 Virtual HUB extension.
7 DC Power Input
DC9 ~ 32V Power input. KVM-IP-Tx-PL is equipped with POE. This is
an optional power input.
8 System LED (Green)
Link LED (Amber)
Green Blinking/Amber Off: System is starting up.
Green On/Amber Off:
System is ready, but TX/RX not connected.
Green On/Amber Blinking:
TX/RX connected, but waiting for HDMI
input.
Green On/Amber On: TX/RX connected, HDMI input is ready.
9 RS-232 (Phoenix) Provide Serial-over-IP function. (Pin assignment: TxD-RxD-GND)
10 IR Blaster Connect to external IR Transmitter
11 (Button 1)
Press and Hold at
Power ON until
Green
and Amber
LED
blinking
1. Reset to the Factory default settings.
2. Enter Setup and Firmware upgrade mode
in 192.168.0.88
12 (Button 2)
Short press Set to Video/Graphic mode.
Long press (3 sec.)
To Enable/Disable Anti-Dither.
Note:
For some ATI graphic cards with
Dithering function enabled, enabling Anti-
Dither achieves better video quality.
KVM-IP-Rx-P Receiver (Rx)
Connector Description
1 Gigabit Ethernet Connect to Gigabit Ethernet switch or directly to TX.
2HDMI Out This HDMI output connector supports HDMI 4K, 1080p output.
3 Mic. IN
Microphone Input; extended to Line Out of TX when TX/RX in Unicast
mode.
4 Line OUT
KVM-IP-Rx-P supports both HDMI and 3.5mm audio. This 3.5mm Line Out
can be set either from Line In or HDMI input source of TX.

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
6
5 DC Power Input
DC9 ~ 32V Power input. KVM-IP-Tx-PL is equipped with POE. This is an
optional power input.
6System LED
(Green) Link LED
(Amber)
Green Blinking/Amber Off:
System is starting up.
Green On/Amber Off:
System is ready, but TX/RX not connected.
Green On/Amber Blinking:
TX/RX connected, but waiting for HDMI input.
Green On/Amber On:
TX/RX connected, HDMI input is ready.
7 IR Receiver Remote Universal IR receiver (optional).
8 RS-232 (Phoenix) Provides Serial-over-IP function. (Pin assignment: TxD-RxD-GND)
9 Mode button
Short press Set to Video or Graphic mode.
Long press (3 sec.)
Enable/Disable Anti-Dither.
Note:
For some ATI graphic cards
with Dithering function enabled,
enabling Anti-Dither achieves
better video quality.
Press and Hold at Power ON until
Green
LED are blinking
Get and Use this RX’s EDID as the
system EDID (update TX EDID)
10 Link button
Short press
To enter Transmitter List OSD
menu, or TX/RX Setting OSD
menu.
Long press (3 sec.) Gets USB access right.
Press and Hold at Power ON until
Green and Amber
LED blinking
1. Reset to the Factory default.
2. Enter Setup and Firmware
upgrade mode in 192.168.0.88
11 USB 1.1 Host 2 USB-A ports for USB 1.1 devices like Keyboard, Mouse, Printer, …
12 USB 2.0 Host 2 USB-A ports for USB 2.0 devices like USB Disk, Touch Screen, …
4.0 Configuraitons
The Tx/Rx units have built-in web pages for Setup and Operation configurations
4.1 Setup Mode
1. Press and Hold the TX/RX’s [Button 1]/[Link] button and Power ON until Green and Amber LED
blinking then release the button. This will force TX/RX enter Setup mode.
2. Directly connect TX/RX to PC LAN port, set PC IP to 192.168.0.1, Net Mask 255.255.255.0.
3. Open PC’s Web Browser (we recommend Chrome) and enter 192.168.0.88 <Enter>
4. The Setup Mode Web page contains [System] tab with sub-tabs for [Version Information], [Update
Firmware], [Utilities], and [Statistics].
Reset to factory default (Setup Mode)
If the device settings are lost, you can reset the device back to the factory default:
1. Enter Setup Mode Web page [System] ---> [Utilities] ---> [Factory Default]
(The Factory default settings are shown on the label of the unit)
Firmware Upgrade (Setup Mode)
1. Enter Setup Mode Web page [System] ---> [Update Firmware] ---> navigate to the firmware file
(.bin) then click [Upload] to start firmware upgrade.
2. The firmware upgrade takes about 3 minutes, it will display “DONE Rebooting…” to indicate the
unit has been upgraded and rebooted.

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
7
4.2 Operation Mode
The TX/RX can be configured in Operation Mode through an Ethernet Switch or direct connection.
To enter Operation mode Web page:
1. Set PC IP 10.0.1.1, Net Mask 255.0.0.0.
2. Open Browser (we recommend Chrome) then enter TX/RX IP: 10.xx.xx.xx
3. The TX/RX Web page are shown below. The TX contains 3 tab menus [System], [Network],
Functions], the RX contains 4 tab menus [System], [Video Wall], [Network], Functions]:
Firmware Upgrade (Operation Mode)
It is possible to do the firmware upgrade in Operation mode for TX/RX:
1. Enter Web page [System] ---> [Update Firmware] ---> navigate to the firmware file (.bin) then click
[Upload] to start firmware upgrade.
2. The firmware upgrade takes about 3 minutes, it will display “DONE Rebooting…” to indicate the unit
has been upgraded and rebooted.
TX/RX Compatibility Mode
From version 6.6.0.2 up, you can set 9525 TX/RX to be backward compatible with 950 or 9510. Enter
TX/RX Web page [System] ---> [Utilities] ---> [Compatibility mode] ---> select the mode from drop-down
menu: 1500 compatibility mode, 1510 compatibility mode, or 152x operation mode (default).
TX EDID selection
The TX provides flexible EDID selections:
Enter TX Web page [System] ---> [Utilities] --->[EDID]--->
select the EDID from the following 4 options:
Copy EDID from EDID Master. (Factory default)
(Enable this option will force the TX to get EDID from the
RX with EDID Master setting.)
Copy EDID from 1st connecting RX after powered On.
(Enable this option will force the TX to get EDID from the 1st connected RX.)
Copy EDID from RX IP.
(Enable this option to force TX to get EDID from a specific RX, enter RX’s IP here)
Resolution selection
You can also set TX with a specific Resolution from the drop-down menu.
The available resolutions are 1920 x 1200 60Hz, 1920 x 1080 60Hz, 1680 x 1050 60Hz, 1440 x 900
60Hz, 1366 x 768 60Hz, 1280 x 1024 60Hz, 1280 x 720 60Hz, 1024 x 768 60Hz, 720 x 480 60Hz.
Note: This Resolution EDID option will be overwritten by the RX EDID Master if:
1. The TX is set on Unicast.
2. The RX connection method is set on Direct Connection.

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
8
4.3 Network Configuration
The TX/RX provides the following Network settings:
IP Setup (TX/RX)
Enter TX/RX Web page [Network] ---> [IP Setup]:
Select Auto IP, DHCP, Static.
Then enter device IP, Subnet Mask, Default Gateway.
Click [Apply].
Casting Mode (TX) (default Multicast)
TX can be set in Multicast or Unicast mode by entering TX
Web page [Network] ---> [Casting Mode]:
In Multicast mode, you can setup the following Multicast
address:
Multicast IP prefix (default 225.0.10)
Multicast IP address (prefixed with 225.0.10x.x)
Casting Mode Connection Methods (RX)
(default Multicast)
RX can be set in Multicast or Unicast mode by entering RX
Web page [Network] ---> [Casting Mode].
In Multicast mode, you can setup the Multicast IP prefix
and select the Connection Method from: First Available,
Multicast IP, OSD Transmitter List, and Direct Connection.
In Unicast mode, you can select the Connection Method
from First Available, OSD Transmitter List, TX IP and Direct
Connection.
First Available: the RX will connect to the first available TX when powered on.
Multicast IP 225.0.10x.xxx: the RX will connect to the TX with the same Multicast IP address.
OSD Transmitter List: the RX will display the available
Transmitters in OSD menu for user to select.
You can either select the “All Transmitters”, or using “-“ and
“,” for selecting TXs IP address range that are accessible for
this RX as the right screenshot.
TX IP: the RX will connect to this dedicated TX only.
Direct Connection: this setting enables RX to connect TX by
the same subnet, same Casting Mode, Jumbo Frame and
EDID Master will be automatically enabled.
Show TX Device name when connected (RX)
This feature enables RX to display the TX name (or IP) when connected. Default is enabled with
5 seconds.
Jumbo Frame (TX/RX)
The TX/RX Jumbo Frame must be enabled for the 4K input and output. (Default is Enabled)
Enter TX/RX Web page ---> [Network] ---> [Jumbo Frame] ---> Enable/Disable --->[Apply] ---> the unit
will save the setting and reboot automatically.
Note: TX/RX and Ethernet Switch must have Jumbo Frame enabled (at least 8K) to work properly for
4K HDMI.

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
9
4.4 Function Configurations
Device Name (TX/RX)
To set TX/RX Device name, enter TX/RX Web page ---> [Functions] ---> [Device Name] ---> enter
name (8 characters max) ---> [Apply] to save the Device Name.
K/M over IP (TX) ; KMoIP ports (RX)
The system supports both USB-over-IP and KM-over-IP for USB extension. The USB-over-IP works
as a 5-port Virtual HUB when TX is connected to PC; it is compatible with most kinds of USB
devices such as keyboard, mouse, Pen Drive, Touch Screen… etc.
The KM-over-IP is an HID emulation built for multiple RXs to share keyboard/mouse for one PC, it
takes one port of the 5 virtual ports. The KM-over-IP setting is different for TX and RX:
For TX: enter TX Web page ---> [Functions] ---> [USB over IP] ---> [Compatibility Mode] --->
check/uncheck [K/M over IP] to Enable/Disable ---> [Apply] (default: enabled).
For RX, enter RX Web page ---> [Functions] ---> [KMoIP ports] ---> check/uncheck 1, 2, 3, 4 to
Enable/Disable KM-over-IP ports (default: all disabled) ---> [Apply].
Hotkey (RX)
The RX supports Hotkey for OSD Menu. To choose the RX OSD Hotkey: enter RX Web page --->
[Functions] ---> [Hotkey] ---> select the Hotkey from the list: <Ctrl><Ctrl>, <Shift> <Shift>, <Alt> <Alt>,
or <Scroll> <Scroll> (default: Ctrl Ctrl).
Video over IP (TX)
Enter TX Web page ---> [Functions] ---> [Video over IP] --->
check/uncheck the following options:
[Enable Video over IP] (Default: Enabled)
[Video/Graphic Mode]: Select [Video Mode] for play smoothly. Select
[Graphic Mode] for static picture KVM application.
[Maximum Bit Rate]: The TX provides options of “Best Effort”, “200, 150, 100, 50, 10 Mbps for the
TX bandwidth selection. (default: Best Effort).
[Maximum Frame Rate]: This provides the maximum % of the TX frames rate capture up (default:
100%).
Video over IP (RX)
Enter RX Web page ---> [Functions] ---> [Video over IP] --->
check/uncheck the following options:
[Enable Video over IP] (Default Enabled).
[Enable Video Wall]: Enable this setting for the Video Wall output.
[Copy EDID from this Video Output]: Enable this setting to assign
this RX as the EDID Master.
[Scaler Output Mode]: Select the option of “Auto EDID”, “Pass Through”, “1080p60”, “1080p50”,
“1920x1200”, “Customize” (default Auto EDID)
[Timeout for detecting video lost]: Set the timeout period for the video lost detection (default 10
sec.)
[Turn off screen on video lost]: Enable this setting to stop the video output when video lost (default
Enabled)
USB over IP (TX/RX)
Enter TX/RX Web page ---> [Functions] ---> [USB over IP] ---> [Enable USB over IP] --->
check/uncheck to Enable/Disable (default Enable).

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
10
Serial over IP (TX/RX)
Enter TX/RX Web page ---> [Functions] ---> [Serial over IP] --->
Enable/Disable (default: Enable).
--->[Operation Mode]
Select options of Type 1, Type 2, Type 1 guest mode, Type 2
guest mode (default: Type 2).
Note: Type 1 is mainly for Unicast application where user can
dynamically link with any target RX.
Type 2 is mainly for Multicast application where TX RS-232 will
link with all of connected RXs (default).
Type 1 guest mode is similar to type 1 but using PC to link with
RX’s RS-232.
Type 2 guest mode is similar to type 2 but using PC to link with RX’s RS-232.
For details, please refer to “How to Use RS232 over IP” manual.
---> [Baudrate Setting for Type 2]
Select Baudrate, Data bits, Parity, Stop bits. (default 115200, 8-n-1)
Audio Output (RX)
If the TX’s input audio is in HDMI, you can route the audio output on Line Out of the RX: Enter RX
Web page ---> [Functions] ---> [Audio Output] ---> check “HDMI Audio De-Embedder”. Click [Apply]
to save the setting and reboot. (default Disabled)
IR over IP (RX)
It is possible to assign the IR signal routing path: Enter RX Web page --->
[Functions] ---> [IR over IP] ---> Enable IR over IP (default Enabled)
[IR Assignment]: Select IR routing path from the following 3
[Video Source TX]: Send the IR signals to the video source TX.
[VWall Manager (TX: )]: Send the IR signals to the TX which is assigned by
the VWall Manager software.
[TX IP: ]: Send the IR signals to the manually assigned TX.
Multi-Screen Setting (TX/RX)
The system supports Multi-Screen feature. Each Main TX/RX
can be assigned with 2nd, 3rd, 4th TX/RX IP. When the Main RX
switches to a new Main TX, its associated RXs will also be
switched to the new TX’s associated TXs automatically.
Enter TX/RX Web page ---> [Functions] ---> [Multi-Screen Setting]
---> then enter IP address for the associated 2nd, 3rd, 4th TX/RX IP.
Mirror (RX)
When the “Mirror” option is enabled, the associated RXs will connect to the same TX as the Main
RX is connecting. This splitter function enables multiple RXs to display the same TX.

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
11
4.5 Video Wall Configuration (Rx)
The HDMI over IP Receiver comes with Video-Wall feature for broadcasting one video stream to multiple screens in a
grid. You can setup the Video-Wall either by using OSD (On Screen Display) or the Web page.
For the OSD setup and operation, please refer to “HDMI over IP Video-Wall OSD Quick Setup Guide”.
The following section provides information for the Web page setup.
Video-Wall Basic Setup
Enter RX Web page ---> [Video Wall] ---> [Basic Setup].
Bezel and Gap Compensation
Enter the value for OW (Outside Width), OH (Outside
Height), VW (View Width), VH (View Height) in 0.1mm
unit ---> [Apply].
Wall Size and Position Layout
Select the value for Vertical Monitor Count, Horizontal
Monitor Count, Row Position, Column Position from the
drop-down menu ---> [Apply].
Stretch and Rotation Preferences
[Preferences] ---> [Stretch Type]: Select ”Fit In” or “Stretch
Out” ---> [Apply]
[Clockwise Rotate]: Select 0, 180, 270 --> [Apply]
Note:
Fit In: Stretches or compresses the broadcast screen to
fill the whole wall.
Keep Aspect: keeps strict picture aspect ratio. If there is
a mismatch, some image may fall beyond screen edges.
Show OSD
To identify the screen, check the “Show OSD” and select the device then click [Apply] button.

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
12
Video-Wall Advanced Setup
The Advanced Setup can be used for special effects
which are not included in Basic Setup. There are two
steps in advanced setup:
Step 1: Choose one or more target RXs to apply
setup to.
Step 2: After the targets are selected, changes can
be applied in Step 2.
Reset to Basic Setup:
Reset the target(s) to the setting of “Basic Setup”.
Stretch Type:
Fit In: Stretch the full screen to the whole wall.
Keep Aspect: keeps picture aspect ratio; some image
may spill off screen if needed.
Clockwise Rotate:
0: No rotate
180: clockwise rotate 180 degrees
270: clockwise rotate 270 degrees
Screen Layout (Row x Column):
Define the Video Wall size, select the Row and
Column count from the drop-down menu.
Row Position:
Set the Row position for the selected target RX.
(Rows start from 0)
Column Position:
Set the Column position for the selected target RX.
(Columns start from 0)
Horizontal Shift (Left, Right):
Shift target screen horizontal to left or right in 1 pixel
units.
Vertical Shift (Left, Right):
Shift target screen vertically up or down in 1 pixel
units.
Horizontal Scale Up
Scale up the target screen horizontally, by pixels (1/column count).
Vertical Scale Up
Scale up the target screen vertically (1/row count).

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
13
5.0 Installation
1. The factory default Connection Method for RX is “First Available”, and TX is in Multicast mode
with its default Multicast IP (shown on the label). This means all TXs will send packets with their
default Multicast IP (225.0.10x.xxx), and all RXs will find the first available TX for connection.
2. Use a CAT6 UTP cable (straight, EIA 568B) to directly connect TX/RX as a pair connection, or
connect to IGMP enabled Gigabit Ethernet switch for many-TXs-to-many RXs installation.
Note: Each TX comes with individual factory default Multicast IP which is shown on the unit
label.
3. Connect TX/RX to video source/screen by HDMI cable.
4. The TX factory default setting for EDID is “Copy EDID from EDID Master”, please use either step
4.1 or 4.2 to assign a RX as the EDID Master.
You can change TX to use the EDID from the 1st connected RX, or from a specific RX by step 4.3
or 4.4.
Or you can use the TX built-in EDID as step 4.5:
4.1 Press and hold the [Mode] button of the specific RX unit and power ON until Green LED
blinking then releasing the [Mode] button, this RX will be assigned as EDID Master (RX’s
Green LED will blink, then steady ON, and Amber LED Off to indicate it is ready and waiting
for connecting with TX). Then power ON other RX units sequentially.
4.2 Refer page 7, enable “Copy EDID from this Video Output” to assign a specific RX as EDID
Master.
4.3 Refer page 5, enable “Copy EDID from 1st connecting RX” to set TX EDID from the first
connected RX.
4.4 Refer page 5, enable “Copy EDID from RX IP” to set TX EDID from a specific RX.
4.5 To use TX built-in EDID for specific Resolution, refer to page 5 “Resolution Selection”.
5. The following start-up messages will be displayed during RX powered on:
FW: 02-Jan-2019 A6.6.0.7 (Firmware date and version)
Local IP: 10.0.34.38 (RX’s IP address)
MAC: 0020FExxxxxx (RX’s MAC address)
Connection Method: First Available
Remote IP: 10.0.x.x / 225.0.x.x (Connecting target TX IP / Multicast IP)
6. If the input source is 4K, please refer to page 6 to enable TX/RX Jumbo Frame setting, and set
Ethernet Switch Jumbo Frame with minimum 8K bytes to get the best video quality.
7. Attach HDMI/DVI source to the TX’s HDMI In. Then power ON the TX unit, the Green LED will
blink then go steady ON to indicate ready and waiting for connecting with RX.
8. As long as TX/RX connection established, both TX and RX Amber LED will start to blink,
indicating waiting for video input source (Green LED is ON).
9. If you are using PC as video source, check that the correct screen EDID is shown on PC graphic
control panel.
10. Activate video with audio source, then check if all RXs are correctly displaying. In this step, both
Green and Amber LED should be ON to indicate the unit is ready and video source is also ready.

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
14
5.1 USB and KM IP Installation
11. Connects TX USB-B to PC, OS will detect a Generic USB 2.0 Virtual Hub Device.
12. The system can support both “USB-over-IP” and “KM-over-IP”.
The USB-over-IP works as a Virtual 5-port HUB when connected to TX, it is compatible with
most kinds of USB devices such as keyboard, mouse, Pen Drive, Touch Screen, etc.
The KM-over-IP means the USB port will work as an HID device only for keyboard/mouse
emulation. It is not necessary to gain USB access right for the KM-over-IP port. The TX (PC) can
be shared with multiple RXs for keyboard/mouse access in KM-over-IP mode.
13. There are 4 USB-A ports on the RX. The factory default setting for the TX is both USB-over-IP
and KM-over-IP enabled, all 4 RX USB ports are USB-over-IP enabled and KM-over-IP disabled.
14. There are 2 methods to gain the access rights for a USB-over-IP port:
14.1 Long press (3 sec.) the RX [Link button].
14.2 Press “U” key to toggle during Transmitter List OSD menu.
The RX display “Requesting USB” to indicate starting USB-over-IP connection, and
message of “Starting USB” will be displayed if it successfully gained the USB access rights.
Meanwhile, the previous USB Master unit will show an OSD message of “USB Stopping”.
RX OSD Transmitter List by [Link] button
The RX supports OSD Transmitter List menu by short-pressing the RX’s [Link] button as the
below left screenshot. Short press the button to move the highlight arrow to select the TX, the
RX will connect to the selected TX after 3 seconds.
Long-pressing the [Link] button for 3 seconds will enter Simple Configuration OSD menu as the
below right screenshot. Press the [Link] button to move the highlight arrow to the setting to
change. You can change Casting Mode, Maximum bit rate for TX, and Hotkey Setting,
Connection Method and ON/OFF for RX:
RX OSD Transmitter List by Hotkey
The RX supports OSD Transmitter List menu by pressing
<hotkey> <hotkey> with maximum 8 Transmitters will be
shown, as shown in the screenshot on the right. The top 2
lines are the current TX and RX IP or name. You can select the
TX using the↑↓keys and <Enter>, or 1 ~ 8 key to immediately
connect to the target TX.
Press U to request (or release) USB-over-I P.
Press F5 to refresh Transmitter List.
Press F8 to switch in between Name/IP/OSD modes.
Press V to enter Video-Wall configuration.
Press W to send the current display to other RX or RXs with VWall ID. To end the OSD, press
<ESC>
RX OSD Hotkey selection Sub-Menu
From the Simple Configuration OSD menu, press [Link] button to move the highlight arrow to
[Hotkey Setting]. Wait a few seconds, the sub-menu will show up with 4 possible selections: “Ctrl
Ctrl”, “Shift Shift”, “Alt Alt”, or “Scroll Scroll”. Press [Link] button again to move the highlight arrow
to the desired selection. The RX unit will be re-booted.
RX OSD Connection Method Sub-Menu
From the Simple Configuration OSD menu, press [Link] button to move the highlight arrow to

KVM-SET-14
APANTAC LLC, 10200 SW ALLEN BLVD STE C, BEAVERTON, OR 97005
[e-mail], TEL: [phone], FAX: [phone]
15
[Connection Method]. Wait a few seconds, either Multicast or Unicast Connection Method sub-
menu will show up depending on the RX’s Casting mode.
The Multicast RX supports 4 possible connection methods: First Available, Multicast IP, OSD
Transmitter List, and Direct Connection.
The Unicast RX supports 4 possible connection methods: First Available, OSD Transmitter List,
Dedicated TX IP, and Direct Connection.
Press the [Link] button to move the highlight arrow to the desired Connection Method and wait a
while to confirm the selection.
6.0 External Software
The system provides Windows-based Connection Manager and Video-Wall Manager software for
the TX/RX connection and Video-Wall management. Please refer to the Connection Manager and
Video Wall Manager Guide for further details.
