MPI Magnetostrictive Level Sensors
Installation Guide
For MPI-E, MPI-E Chemical, and MPI-R Intrinsically Safe
R
APG
Automation Products Group, Inc.
1025 W 1700 N Logan, UT 84321
www.apgsensors.com | phone: 888-525-7300 | email: [email protected]
Thank You
Thanks for purchasing an MPI series magnetostrictive level sensor from us! We appreciate your
business and your trust. Please take a moment to familiarize yourself with the product and this
manual before installation. If you have any questions, at any time, don’t hesitate to call us at 888-
525-7300.
1. Description
2. How To Read Your Label
3. Warranty
4. Dimensions
5. Installation Guidelines &
Instructions
6. Sensor and System Wiring
7. General Care
8. Repair Information
9. Hazardous Location Wiring
Table of Contents
5Installation Guidelines & Instructions
The MPI should be installed in an area--indoors or outdoors--which meets the following
conditions:
• Ambient temperature between -40°F and 185°F (-40°C to 85°C)
• Relative humidity up to 100%
• Altitude up to 2000 meters (6560 feet)
• IEC-664-1 Conductive Pollution Degree 1 or 2
• IEC 61010-1 Measurement Category II
• No chemical corrosive to stainless steel (such as NH3, SO2, Cl2, etc.) (Not applicable to plastic-
type stem options)
• Ample space for maintenance and inspection
Additional care must be taken to ensure:
• The probe is located away from strong magnetic elds, such as those produced by motors,
transformers, solenoid valves, etc.
• The medium is free from metallic substances and other foreign matter.
• The probe is not exposed to excessive vibration.
• The oat(s) t through the mounting hole. If the oat(s) does/do not t, it/they must be
mounted on the stem from inside the vessel being monitored.
• The oat(s) is/are oriented properly on the stem (See Figure 5.1 below). MPI-E oats will be
installed by the factory. MPI-R oats are typically installed by customer.
4Dimensions
NOTE: Scan the QR code to the right to see the full
user manual on your tablet or smartphone. Or visit
www.apgsensors.com/support to nd it on our website.
Part # 200339
Doc #9005625 Rev C
Each label comes with a full model number, a part number, and a serial number. The model
number for the MPI will look something like this:
The model number correlates with all the congurable options and tells you exactly what you have.
Compare the model number to the options on the datasheet to identify your exact conguration.
You can also call us with the model, part, or the serial number and we can help you.
You’ll also nd all hazardous certication information on the label.
SAMPLE: MPI-R5-ZY-P3SB-120-4D-N
The MPI series magnetostrictive level sensor provides highly accurate and repeatable level readings
in a wide variety of liquid level measurement applications. It is certied for installation in Class I,
Division 1, and Class I, Zone 0 hazardous areas in the US and Canada by CSA, and ATEX and IECEX
for Europe and the rest of the world.
1Description
2How To Read Your Label
3Warranty
MPI-E Housing Dimensions MPI-R Housing Dimensions
Figure 5.1
UP
Taper
This product is covered by APG’s warranty to be free from defects in material and workmanship
under normal use and service of the product for 24 months. For a full explanation of our Warranty,
please visit https://www.apgsensors.com/about-us/terms-conditions. Contact Technical Support to
receive a Return Material Authorization before shipping your product back.
Scan the QR code below to read the full explanation of our Warranty on your tablet or smartphone.
IMPORTANT: Floats must be oriented properly
on the stem, or sensor readings will be inaccurate
and unreliable. Untapered oats will have a sticker or
etching indicating the top of the oat. Remove sticker
prior to use.
ATEX Stated Conditions of Use:
• Under certain extreme circumstances, the non-metalic parts incorporated in the enclosure of
this equipment may generate an ignition-capable level of electrostatic charge. Therefore the
equipment shall not be installed in a location where the external conditions are conducive to
the build-up of electrostatic charge on such surfaces. In addition, the equipment shall only be
cleaned with a damp cloth.
• The enclosure is manufactured from Aluminum. In rare cases, ignition sources due to impact
and friction sparks could occur. This shall be considered during installation.
Installation Instructions:
• If your sensor’s stem and oats t through the mounting hole, carefully lower the assembly
into the vessel, then secure the sensor’s mounting option to the vessel.
• If the oats do not t, mount them on the stem from inside the vessel being monitored. Then
secure the sensor to the vessel.
• For sensors with oat stops, refer to the assembly drawing included with the sensor for oat
stop installation locations.
Electrical Installation Instructions:
• Remove the housing cover of your MPI.
• Feed system wires into MPI through conduit openings. Fittings must be UL/CSA Listed for CSA
installation and IP65 Rated or better.
• Connect wires to MPI terminals. Use crimped ferrules on wires, if possible.
• Replace housing cover.
See Sensor and System Wiring Diagrams (section 6) for Modbus wiring examples.
MPI-E Chemical Housing Dimensions
4.21”
3.74”
7.32-7.44”
6.53-6.65”
5.00”
4.25”
5.71”
4.92”
Ø 0.27”
3/4” NPT
1/2” NPT
2.38”
4.94”
4.15”
GND
SCREW
ZERO
REFERENCE
3/4” NPT
1/2” NPT
Housing
Connection
Location
Note:
For dual dimensions, large
housing dimensions are
above small housing
dimensions.
5.00”
4.25”
5.71”
4.92”
Ø 0.27”
4.21”
3.74”
6.84” - 6.97”
6.05” - 6.18”
3/4” NPT
1/2” NPT
1.90”
4.94”
4.15”
GND
SCREW
ZERO
REFERENCE
3/4” NPT
1/2” NPT
Housing
Connection
Location
Note:
For dual dimensions, large
housing dimensions are
above small housing
dimensions.
5.71"
4.92"
5.00"
4.25"
2x
.27"
3/4" NPT
1/2" NPT
4.29"
3.70"
9.30"
8.51"
Min. 12"
Max. 153"
S1 Dead-Band
S2 Dead-Band
ZERO
REFERENCE
2.00"
3.50"
Float Ref.
Float Options
H & K
4.29"
3.70"
9.30"
8.51"
ZERO
REFERENCE
Note:
for dual dimensions,
large housing dimensions
are above small housing
dimensions.
3/4” NPT
1/2”NPT
6Sensor and System Wiring Diagrams
IMPORTANT: Refer to section 9 for Hazardous Location Wiring.
NOTE: For APG Modbus programming instructions, please see MPI
user manual. APG Modbus software can be downloaded from www.
apgsensors.com/support.
MPI-E/R Intrinsically Safe Modbus System Wiring MPI-E/R Intrinsically Safe Modbus System Wiring with RST-6001
IMPORTANT: MPI level sensor MUST be installed according to drawing 9005491
(Intrinsically Safe Installation Drawing for Hazardous Areas) in section 9 to meet listed
approvals. Faulty installation will invalidate all safety approvals and ratings.
DANGER: WARNING -- EXPLOSION HAZARD -- SUBSTITUTION OF COMPONENTS MAY
IMPAIR INTRINSIC SAFETY;
AVERTISSEMENT -- RISQUE D’EXPLOSION -- LA SUBSTITION DE COMPOSANT PEUT
AMELIORER LA SECURITE INTRINSIQUE.
DANGER: WARNING -- EXPLOSION HAZARD -- DO NOT DISCONNECT EQUIPMENT
UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NON-
HAZARDOUS;
AVERTISSEMENT -- RISQUE D’EXPLOSION -- AVANT DE DECONNECTER L’EQUIPEMENT,
COUPER LE COURANT OU S’ASSURER QUE L’EMPLACEMENT EST DESIGNE NON
DANGEREUX.
DANGER: OPEN CIRCUIT BEFORE REMOVING COVER or KEEP COVER TIGHT WHILE
CIRCUITS ARE ALIVE;
AVERTISSEMENT -- COUPER LE COURANTAVANT D’ENLEVER LE COUVERCLE, ou GARDER
LE COUVERCLE FERME TANT QUE LES CIRCUITS SONT SOUS TENSION.
7General Care
Your level sensor is very low maintenance and will need little care as long as it was installed
correctly. However, in general, you should periodically inspect your MPI unit to ensure the stem
is free of any heavy buildup that might impede the movement of the oat(s). If sediment or other
foreign matter becomes trapped between the stem and oat(s), detection errors can occur.
If you need to remove the oats(s) from the stem of your MPI, be sure to note the orientation of the
oat(s) prior to removal. This will help ensure proper re-installation of the oat(s).
Also, ensure that the housing cover is snuggly secured. If the cover becomes damaged or is
misplaced, order a replacement immediately.
8Repair Information
If your MPI level sensor needs repair, contact us via email, phone, or online chat on our website. We
will issue you a Return Material Authorization (RMA) number with instructions.
• Phone: 888-525-7300
• Email: [email protected]
• Online chat at www.apgsensors.com
IMPORTANT: All repairs and adjustments of the MPI level sensor must be made by the
factory. Modifying, disassembling, or altering the MPI is strictly prohibited.
Power
Supply
+8-24 Vdc
GND Use Shielded Cable
120 Ω terminating resistor
may be necessary for long
cable runs.
V+
B (TX-)
A (TX+)
Sensor 1
GND
V+
B (TX-)
A (TX+)
Sensor 2
GND
V+
B (TX-)
A (TX+)
Sensor 3
GND
Server
Device
RS-485 A (TX+)
RS-485 B (TX-)
MPI Sensor MPI Sensor MPI Sensor
Note: When connecting MPI
sensors to your system, reversing
A and B connections may be necessary
if sensors do not communicate with
Modbus Server device.
120 Ω terminating resistor across A & B
terminals of last or only sensor, if necessary.
For installations without IS barriers only.
Wiring T’s must be located on
controller/supply side of IS barriers.
See Hazardous Installation
Drawing for Intrinsically Safe
installation requirements.
Otherwise, wire directly.
See Hazardous Installation
Drawing for Intrinsically Safe
installation requirements.
Otherwise, wire directly.
See Hazardous Installation
Drawing for Intrinsically Safe
installation requirements.
Otherwise, wire directly.
Power
Supply
+8-24 Vdc
GND Use Shielded Cable
Equivalent 120 Ω
terminating resistor
internal to RST-6001
USB to computer
with APG Modbus
software
RST-6001
Modbus
Controller
V+
B
A
Sensor 1
GND
V+
B
A
Sensor 2
GND
V+
B
A
Sensor 3
GND
A
B
-5V
MPI sensor
+5V
MPI sensor MPI sensor
Note: An independent +8-24 Vdc
power supply is required when using
an RST-6001 Modbus Controller. The
RST-6001 can only supply ±5 Vdc, not
the +8-24 Vdc required by the MPI.
Wiring T’s must be located on
controller/supply side of IS barriers.
120 Ω terminating resistor across A & B
terminals of last or only sensor, if necessary.
For installations without IS barriers only.
See Hazardous Installation
Drawing for Intrinsically Safe
installation requirements.
Otherwise, wire directly.
See Hazardous Installation
Drawing for Intrinsically Safe
installation requirements.
Otherwise, wire directly.
See Hazardous Installation
Drawing for Intrinsically Safe
installation requirements.
Otherwise, wire directly.
MDI
Modbus Address: Server
Controling: Sensor 1
MPI Sensor
Modbus Address: 1
Hazardous Area
Zone 1
Zone 0 or Zone 1
MDI
Modbus Address: Server
Controling: Sensor 1
MPI Sensor
Modbus Address: 1
Hazardous AreaNon-hazardous Area
Approved
IS Barrier
Passive Control Equipment
Modbus: Sniffer
Sniffing: MDI
Zone 1
Zone 0 or Zone 1
MPI - MDI Use Case Diagram MPI - MDI with Passive Controller Use Case Diagram
IMPORTANT: Only the combustion gas detection performance of the instrument has been
tested.
DANGER: WARNING -- POTENTIAL ELECTROSTATIC CHARGING HAZARD - CLEAN ONLY
WITH A DAMP CLOTH;
AVERTISSEMENT -- DANGER DE CHARGE ELECTROSTATIQUE POTENTIEL - NETTOYER
SEULEMENT AVEC UN CHIFFON HUMIDE.
9Hazardous Location Wiring
Form 9000063 Rev C
APPROVALS DATE
FINISH
MATL
APVD
CHKD
DRWN
SIZE
A
CAGE CODE PART NO DOCUMENT NO REV
SHEET OF
CONTRACT
888.525.7300
Logan, Utah USA
1025 West 1700 North
APPROVEDDATECHANGE ORDERDESCRIPTIONREVZONE
REVISIONS
CAGE CODE DOCUMENT NO SHEET REV
52797 9005491 1 B
-- B See Change Order CO-3982 06/01/2020 A. Fullmer
C. Chidester
S. Hutchins
R. Barson
6/5/2018
8/29/2018
8/29/2018
B
12
for Hazardous Locations
Intrinsically Safe Installation Drawing
MPI Series
PROPRIETARY AND CONFIDENTIAL
LOGAN, UTAH AND MAY NOT BE
USED, REPRODUCED, PUBLISHED, OR
IN ANY WAY DIRECTLY OR INDIRECTLY
THIS DRAWING IS THE PROPERTY OF
AUTOMATION PRODUCTS GROUP, INC.
DISCLOSED TO OTHERS WITHOUT
IF LOANED, IT IS SUBJECT TO RETURN
UPON DEMAND AND MAY NOT BE USED
WRITTEN CONSENT OF THE COMPANY.
DETRIMENTAL TO THE COMPANY. 9005491VARIOUS
A
B
VIN
GND
Vmax (or Ui) = 28V
Unclassified Location
Imax (or Ii) = 280mA
Pi = 850mW
Ci = 0.374uF
Li = 3.50uH
Associated Apparatus
Voc (or Uo) ≤ Vmax (or Ui)
Hazardous Location
Class I, Zone 0, AEx ia IIB T4 Ga
Isc (or Io) ≤ Imax (or Ii)
Po ≤ Pi
Ca (or Co) ≥ Ci + Ccable
La (or Lo) ≥ Li + Lcable
with Entity Parameters
Ex ia IIB T4 Ga, Ta -40°C to 85°C
- Installation must be in accordance with NEC Articles 504 and 505.
Class I, Division 1, Groups C,D T4
52797
MPI - RS485 RTU
RS485-
V+
V-
RS485+

Other manuals for MPI-E

1

This manual suits for next models

2

Other APG Accessories manuals

APG VBL Series User manual

APG

APG VBL Series User manual

APG IRU-2 4 Series User manual

APG

APG IRU-2 4 Series User manual

APG MPI-F Series User manual

APG

APG MPI-F Series User manual

APG B Series User manual

APG

APG B Series User manual

APG MPX User manual

APG

APG MPX User manual

APG RPM Series User manual

APG

APG RPM Series User manual

APG MPX User manual

APG

APG MPX User manual

APG FLR Series User manual

APG

APG FLR Series User manual

APG LPU-2127 User manual

APG

APG LPU-2127 User manual

APG MPXI-F Series User manual

APG

APG MPXI-F Series User manual

APG LPU-2428 User manual

APG

APG LPU-2428 User manual

APG LPU-2127 User manual

APG

APG LPU-2127 User manual

APG MPX Series User manual

APG

APG MPX Series User manual

APG PT-500 Series User manual

APG

APG PT-500 Series User manual

APG RPM Series User manual

APG

APG RPM Series User manual

APG MPX Series User manual

APG

APG MPX Series User manual

APG MPX-E User manual

APG

APG MPX-E User manual

APG MNU IS Series User manual

APG

APG MNU IS Series User manual

APG PWS Series User manual

APG

APG PWS Series User manual

APG MPX-T User manual

APG

APG MPX-T User manual

Popular Accessories manuals by other brands

Baumer UNAM 18P7903/S14 quick start guide

Baumer

Baumer UNAM 18P7903/S14 quick start guide

SPL Creon manual

SPL

SPL Creon manual

Eaton GFX Installation and operation manual

Eaton

Eaton GFX Installation and operation manual

ASL INTERCOM DANS01 installation guide

ASL INTERCOM

ASL INTERCOM DANS01 installation guide

PCB Piezotronics 105C02/NC Installation and operating manual

PCB Piezotronics

PCB Piezotronics 105C02/NC Installation and operating manual

Mobicool C40AC operating manual

Mobicool

Mobicool C40AC operating manual

Ryan Mechatronics CHIMU user manual

Ryan Mechatronics

Ryan Mechatronics CHIMU user manual

GE Monogram ZXR7510 installation instructions

GE

GE Monogram ZXR7510 installation instructions

Rockwell Automation Allen-Bradley VisiSight R42KC installation instructions

Rockwell Automation

Rockwell Automation Allen-Bradley VisiSight R42KC installation instructions

Endress+Hauser CUS 5 Installation and operating instructions

Endress+Hauser

Endress+Hauser CUS 5 Installation and operating instructions

Kogan KAPB10KALBA user guide

Kogan

Kogan KAPB10KALBA user guide

Sherlock Hones VTag instruction manual

Sherlock Hones

Sherlock Hones VTag instruction manual

CS Instruments VA 570 instruction manual

CS Instruments

CS Instruments VA 570 instruction manual

ALTAI C1N Configuration manual

ALTAI

ALTAI C1N Configuration manual

Kasanova AIR000004-5 instruction manual

Kasanova

Kasanova AIR000004-5 instruction manual

IFM OY4**S Series operating instructions

IFM

IFM OY4**S Series operating instructions

ABB CMS-12xLA installation manual

ABB

ABB CMS-12xLA installation manual

Oypla Leisure 4003 user manual

Oypla Leisure

Oypla Leisure 4003 user manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
