Aplex ACS-2675C Box PC User manual

ACS-2675C User Manual
1
ACS-2675C Box PC
User Manual
Release Date Revision
Dec. 2011 V1.0
®2011 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: [phone] Fax: [phone] E-mail: [email protected] URL: www.aplex.com.tw

ACS-2675C User Manual
2
Warning!___________________________________
This equipment generates, uses and can radiate radio frequency energy and if not installed and
used in accordance with the instructions manual, it may cause interference to radio communications.
It has been tested and found to comply with the limits for a Class A computing device pursuant to
FCC Rules, which are designed to provide reasonable protection against such interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely
to cause interference in which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.
Disclaimer
This information in this document is subject to change without notice. In no event shall Aplex
Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising
from either the use or misuse of information in this document or in any related materials.
Electric Shock Hazard – Do not operate the machine with its back cover removed. There are
dangerous high voltages inside.

ACS-2675C User Manual
3
Packing List
Accessories (as ticked) included in this package are:
□AC power cable
□Driver & manual CD disc
□Other.___________________(please specify)
Safety Precautions
Follow the messages below to prevent your systems from damage:
◆Avoid your system from static electricity on all occasions.
◆ Prevent electric shock. Don‘t touch any components of this card when the card is
power-on. Always disconnect power when the system is not in use.
◆ Disconnect power when you change any hardware devices. For instance, when you
connect a jumper or install any cards, a surge of power may damage the electronic
components or the whole system.

ACS-2675C User Manual
4
Table of Contents______________________
Warning!…………………………………………………………………………….……..….2
Disclaimer………………………………………………………………….…………………2
Packing List…………………………………………………………………………………..3
Safety Precautions…………………………………………………………………………..3
Chapter 1 Getting Started
1.1 Specifications……………………………………….……………………..6
1.2 Dimensions………………………………...………………………….......7
1.3 Installation of HDD………………….…………………………….…..8
1.4 Installation of PCI Addon………..………………………………………..9
1.5 Brief Description…………………………………………………….……10
Chapter 2 Hardware
2.1 Mainboard………………..…….……………………………………..…..11
2.2 Installations…….…………………………………….…………………...12
2.2.1 Jumpers Setting and Connectors……...………..………………….....12
Chapter 3 BIOS Setup
3.1 Operations after POST Screen.............................................................32
3.2 BIOS SETUP UTILITY..........................................................................33
3.3 System Overview..................................................................................33
3.4 Advanced Settings............................................................................... 34
3.5 Advanced PCI/PnP Settings................................................................ 43
3.6 Boot Settings....................................................................................... 46
3.7 Security Settings.................................................................................. 48
3.8 Advanced Chipset Settings.................................................................. 49
3.9 Exit Options..........................................................................................56
Chapter 4 Installation of Drivers
4.1 Intel Chipset Driver.…………………………...…………………………59
4.2 Intel Graphics Media Accelerator Driver...……………………………..62
4.3 Intel 82574L LAN Device Driver………………………………………….66
4.4 Realtek ALC662 HD Audio Driver Installation…….………….…………69
4.5 Microsoft .NET Framework 3.5 Service Installation……………………71

ACS-2675C User Manual
5
Figures
Figure 1.1: ACS-2675C Dimensions……………………………………..…....7
Figure 1.2: Front View ……………………………………………………….10
Figure 1.3: Rear View………………………………………………………...10
Figure 2.1: Mainboard Dimensions…………………………………..…….....11
Figure 2.2: Jumpers and Connectors Location_ Board Top………………...12
Figure 2.3: Jumpers and Connectors Location_ Board Bottom…………....13

ACS-2675C User Manual
6
Chapter 1 System
1.1 Specifications
Specs
ACS-2675C
CPU Intel Socket P Core 2 Duo 45nm Processor, up to P8600 2.4GHz
FSB1066/800/667MHz
System Chipset Intel GM45 + Intel ICH9M-E
System Memory 2 x 204 Pin DDR3 SO-DIMM slot, up to 8GB 800/1066 SDRAM
External I/O Port Rear Side:
 2 x DB-9 RS-232 COM1/2
 1 x DB-15 VGA
 1 x HDMI
 2 x RJ45 GbE LAN
 4 x USB 2.0
 1 x Mic-in, Line-Out
 1 x DC Power input 3 Pin terminal block connector
 1 x Additional terminal block for switch
 2 x LED Indication
Front Side:
 1 x Power on/off
 1 x 5 Pin terminal block for GPIO (option)
 1 x RS-232 COM4
 1 x RS-422/485 COM3, default RS-485
 2 x USB 2.0
Expansion Slots 2 x PCI / 1 x PCI + 1 x PCIe x1 for option
Storage  2 x 2.5" SATA HDD Space
 1 x CF Slot (External)
Power Supply DC 9~32V
Construction / Color Aluminum Molding Heat sink + Steel Chassis / Silver
Mounting Wall mount
Dimensions 268(W)x195(H)x125.7(D) mm
Operating Temperature 0~50 °C
Storage Temperature -20~60 °C
Storage Humidity 10%~90%@ 40℃, non-condensing
Certificate CE / FCC Class A

ACS-2675C User Manual
7
1.2 Dimensions
Figure 1.1: Dimensions of the ACS-2675C

ACS-2675C User Manual
8
1.3 Installation of HDD
Step 1
There are 9 screws
to deal with when enclosing
or removing the chassis.
Step 2
Get the HDD screwed to the bracket with the
four screws as shown by the arrows in the
picture.
Connect the cable to the HDD as shown in the
picture, making sure the red stripe of the cable
is rightly positioned
Step 3
That’s how it should look after it has been
installed.

ACS-2675C User Manual
9
1.4 Installation of PCI Addon
Step 1
There are 2 screws to deal with when enclosing
or removing the chassis.
Step 2
Now slide the addo
n into the PCI slot, making
sure the golde
n part faces the slot. When the
part that is
interfaced together come into the
right contact, slightly push the addon into the rail
of the slot.
After sliding the addon into the PCI expansion
slot, get the one screws
as circled tightened to
finish the connection.
Step 3
To finish the job, just fasten the 2 screws as
shown in the picture.

ACS-2675C User Manual
10
1.5 Brief Description of the ACS-2675C
The ACS-2675C is a Fan-less High-efficiency Thermal Solution and ultra-compact standalone Box PC,
powered by an Intel Core 2 Duo with 45nm, up to P8600 2.4GHz, and supporting 6 x USB 2.0 ports, 4
x COM Ports, 1 x VGA, 1 x HDMI, support PCI or PCIe Expansion, 2 x SATA HDD space, 1 x external
CF slot, 9-32V wide-ranging power input etc. It is ideal for kiosks, POS systems, airport terminal
controllers, digital entertainments, etc. and running factory operations from small visual interface and
maintenance applications to large control process applications. The ACS-2675C works very well along
with any of our Display Monitor series and it absolutely can provide an easy way to perform control
and field maintenance.
Figure 1.2: Front View of ACS-2675C
Figure 1.3: Rear View of ACS-2675C

ACS-2675C User Manual
11
Chapter 2 Hardware
2.1 Mainboard
Figure 2.1: Mainboard Dimensions

ACS-2675C User Manual
12
2.2 Installations
ASB-M801 is a Mini-ITX industrial motherboard developed on the basis of Intel GM45 and
ICH9M, which provides abundant peripheral interfaces to meet the needs of different customers. Also,
it features dual 1000M LAN port, 6-COM port and one Mini PCIE configuration. To satisfy the special
needs of high-end customers, PC104+ port (capable of adjusting IO voltage) richer extension
functions. The product is widely used in various sectors of industrial control.
2.2.1 Jumpers Setting and Connectors
Figure 2.2: Jumpers and Connectors Location_ Board Top

ACS-2675C User Manual
13
Figure 2.3: Jumpers and Connectors Location_ Board Bottom
1. JP2:
(2.0mm Pitch 1X2 Pin Header),ATX Power and Auto Power on jumper setting.
JP2
Mode
Open ATX Power
Close Auto Power on
(Default)
2. RTC/SRTC:
(2.0mm Pitch 1X2 Pin Header)CMOS clear jumper, CMOS clear operation will
permanently reset old BIOS settings to factory defaults.
RTC/SRTC
CMOS

ACS-2675C User Manual
14
Open NORMAL
(Default)
Close 1-2 Clear CMOS
Procedures of CMOS clear:
a) Turn off the system and unplug the power cord from the power outlet.
b) To clear the CMOS settings, use the jumper cap to close pins1 and 2 for about 3
seconds then reinstall the jumper clip back to pins open.
c) Power on the system again.
d) When entering the POST screen, press the <F1> or <DEL> key to enter CMOS Setup
Utility to load optimal defaults.
e) After the above operations, save changes and exit BIOS Setup.
3. BAT1 :
(1.25mm Pitch 1X2 box Pin Header) 3.0V Li battery is embedded to provide power for
CMOS.
Pin# Signal
Name
Pin1
VBAT
PIN2 Ground
4. DCIN:
(5.08mm Pitch 1x3 Pin Connector),DC9V ~ DC32V System power input connector。
Pin# Power
Input
Pin1 DC+9V~32
V
Pin2 Ground
Pin3
Ground
Power Mode
Location
(5.4.4.)
Location
(5.4.5.)
Location (5.4.6.)
ATX

ACS-2675C User Manual
15
DCIN ATX12V
AT
(Default)
input
DC9~32V
output
DC 12V
NC
5. ATX12V:
(2x2 Pin Connector),DC12V System power output connector.
Pin# Power
output
Pin1 Ground
Pin2 Ground
Pin3 DC+12V
Pin4 DC+12V
6. ATX (option):
(2.0mm Pitch 1X3 box Pin Header), connect PSON and 5VSB and Ground
signal,support ATX Power model. Reserved.
Pin# Signal Name
Pin1 ATX PSON
PIN2 ATX Ground
PIN3 ATX 5VSB
7. CPU1:
(Socket P), installing the CPU Socket.

ACS-2675C User Manual
16
8. CPU_FAN1/SYS_FAN1:
(2.54mm Pitch 1x3 Pin Header),Fan connector, cooling fans can be connected directly
for use. You may set the rotation condition of cooling fan in menu of BIOS CMOS Setup.
Pin#
Signal Name
1 Ground
2
VCC
3 Rotation
detection
Note:
Output power of cooling fan must be limited under 5W.
9. SODIMM1/SODIMM2:
(SO-DIMM 204Pin socket), DDRIII memory socket, the socket is located at the Top of the board
and supports 204Pin 1.5V DDRIII 800/1066MHz FSB SO-DIMM memory module up to
8GB.
10. CRT1:
(CRT DB15 Connector ),Video Graphic Array Port, provide high-quality video output.
they can not work at the same time for CRT1 and VGA1.
11. VGA1:
(CRT 2.0mm Pitch 2X5 Pin Header), Video Graphic Array Port, Provide 2x5Pin cable
to VGA Port, they can not work at the same time for CRT and VGA1.
Signal Name Pin# Pin# Signal Name
CRT_RED
1
2
Ground
CRT_GREEN 3 4 Ground
CRT_BLUE
5
6
VGA_EN
CRT_H_SYN 7 8 CRT_DDCDAT

ACS-2675C User Manual
17
C
A
CRT_V_SYNC 9 10 CRT_DDCCL
K
12. INVERTER1:
(2.0mm Pitch 1x6 box Pin Header), Backlight control connector for LVDS1.
Pin# Signal Name
1
+DC12V
2 +DC12V
3
Ground
4 Ground
5
BKLT_EN
6 BKLT_CTRL
Note:
Pin6 is backlight control signal, support DC or PWM mode, mode select at BIOS CMOS
menu.
13. LVDS1:
(1.25mm Pitch 2x20 Connector), For 18/24-bit LVDS output connector, Fully supported
by Intel GM45 chipset, the interface features dual channel 18/24-bit output.
Signal Name Pin# Pin# Signal Name
VDD5
2
1
VDD5
Ground 4 3 Ground
VDD33
6
5
VDD33
LB_D0_N 8 7 LA_D0_N
LB_D0_P
10
9
LA_D0_P
Ground 12 11 Ground
LB_D1_N
14
13
LA_D1_N
LA_D1_P 16 15 LA_D1_P
Ground
18
17
Ground
LB_D2_N 20 19 LA_D2_N

ACS-2675C User Manual
18
LB_D2_P
22
21
LA_D2_P
Ground 24 23 Ground
LB_CLK_N
26
25
LA_CLK_N
LB_CLK_P 28 27 LA_CLK_P
Ground
30
29
Ground
DS_DDC_DATA
32 31 LVDS_DOC_CLK
Ground
34
33
Ground
LB_D3_N 36 35 LA_D3_N
LB_D3_P
38
37
LA_D3_P
NC 40 39 NC
14. HDMI:
(HDMI 19P Connector), High Definition Multimedia Interface connector.
15. BT1:
POWER on/off Button, They are used to connect power switch button. The two pins
are disconnected under normal condition. You may short them temporarily
to realize system startup & shutdown or awaken the system from sleep
state.
16. JCOM1:
(2.0mm Pitch 2x3 Pin Header),COM1 jumper setting, pin 1~6 are used to select
signal out of pin 9 of COM1 port.
JP3 Pin# Function
Close 1-2 COM1 RI (Ring Indicator)
(default)
Close 3-4 COM1 Pin9=+5V
(option)
Close 5-6 COM1 Pin9=+12V
(option)
17. COM1:
(Type DB9),Rear serial port, standard DB9 Male serial port is provided to make a
direct connection to serial devices. COM1 port is controlled by pins No.1~6 of
JCOM1,select output Signal RI or 5V or 12v, For details, please refer to description of
JCOM1.

ACS-2675C User Manual
19
Pin#
Signal Name
1 DCD# (Data Carrier Detect)
2
RXD (Received Data)
3 TXD (Transmit Data)
4
DTR (Data Terminal Ready)
5 Ground
6
DSR (Data Set Ready)
7 RTS (Request To Send)
8
CTS (Clear To Send)
9
JCOM1 select Setting
18. COM2:
(Type DB9),Rear serial port, standard DB9 Male serial port is provided to make a
direct connection to serial devices.
Pin# Signal Name
1
DCD# (Data Carrier Detect)
2 RXD (Received Data)
3
TXD (Transmit Data)
4 DTR (Data Terminal Ready)
5
Ground
6 DSR (Data Set Ready)
7
RTS (Request To Send)
8 CTS (Clear To Send)
9
RI (Ring Indicator)
19. COM5:
(2.0mm Pitch 2X5 Pin Header),COM5 Port, standard RS232 ports are provided. They
can be used directly via COM cable connection.
Signal
Name
Pin# Pin# Signal Name

ACS-2675C User Manual
20
DCD
1
2
RXD
TXD 3 4 DTR
Ground
5
6
DSR
RTS 7 8 CTS
RI
9
10
NC
20. JCOM6:
(2.0mm Pitch 1x3 Pin Header) COM6 setting jumper, pin 1~3 are used to select signal
out of pin 10 of COM6 port.
JP1 Pin#
Function
Close 1-2
COM5 Pin10=+5V (default)
Close 2-3
COM5 Pin10=+12V (option)
21. COM6:
(2.0mm Pitch 2X5 Pin Header), COM6 Port, standard RS232 ports are provided. They
can be used directly via COM cable connection. COM6 port is controlled by pins
No.1~3 of JCOM6,select output Signal 5V or 12v, For details, please refer to
description of JCOM6.
Signal
Name
Pin# Pin# Signal Name
DCD 1 2 RXD
TXD
3
4
DTR
Ground 5 6 DSR
RTS
7
8
CTS
RI 9 10 JCOM6
select Setting
22. USB4/USB5/USB6/USB7:
(Double stack USB type A), Rear USB connector, it provides up to 4 USB2.0 ports,
speed up to 480Mb/s.
23. LAN1/LAN2:
(RJ45 Connector), Rear LAN port, Two standard 10/100/1000M RJ-45 Ethernet ports
are provided. Used Intel 82574L chipset, LINK LED (green) and ACTIVE LED (yellow)
