APW Wyott Design Features
PRODUCT: QUANTITY: ITEM#:
Model: CW-3A W-43V W-43VCE
MODEL CW-3A COUNTERTOP COOKER
Classic Countertop
12” x 27” Cooker & Warmers
W-43V (Warmer)
• 28.5 t. capacity.
• Element configuration provides even heat distribution.
• Heavy-duty stainless steel for long life.
• Easy to clean.
• Infinite control with a Bimetal thermostat backup.
• Great for buffets, serving lines, back bars or
back-of-the-house.
• Knob Guards.
CW-3A (Cook & Serve)
• Wet usage 100°F to 212°F (38°C to 100°C); recommended.
• Heavy-duty stainless steel for long life.
• Thermostatically controlled.
Options
• Adapter Plates
2 holes for two 11 t. insets (56639)
3 holes for three 7 t. insets (56638)
4 holes for four 4 t. insets (56640)
Designed Smart.
• Utilizes counter display space more efficiently.
• CW-3A and the W-43V have 35% more display
capacity with extended 27-inch length vs. standard
20-inch models.
• Both models have uni ue “serpentine shaped” heating
elements that evenly distribute heat throughout the
unit.
• Provided with insulation to protect interior parts and
countertops from heat build-up.
• Able to utilize W-43V warmer in wet or dry
applications. CW-3A should be ran wet.
• CW-3A is ideal for thawing frozen soup and then
holding thawed soup at NSF-safe serving temperatures.
• CW-3A includes a knob guard.
Built Solid.
Built to Last
• Exterior constructed with heavy-duty stainless steel for
excellent durability.
• Steel “element support” stabilizes heating elements
and reflects heat toward food.
• Interior liner formed out of tough stainless steel.
Reliability backed by t e Industry’s Best Warranty
• These APW Wyott Warming E uipment
products are backed by a 1-year Parts
and Labor warranty, including our
“Enhanced Warranty” service that
replaces new units with certain product
issues through the convenience of direct
factory shipments.
• Certified by the following agencies:
*
*230V model only
Rev. 1/1/2003

PRODUCT: QUANTITY: ITEM#:
World Class Support
World Class Sales Support to assist you with finding the right
solution to your operation’s needs. Call Customer Service at
(800) 527- 2100 or Fax your re uest to 1-[phone].
For more information about APW Wyott’s World Class Support and
High Performance E uipment, look us up on the Internet at
www.APWwyott.com
Most Extensive Service System in the Industry! APW Wyott
has two levels of service support for your needs:
• Direct Service Hot Line to Service Department, call
[phone].
•
To find the Registered Service Technician in your area, call
Automated Service Hot Line at [phone].
Model: CW-3A W-43V W-43VCE
PRODUCT SPEC F CAT ONS
Construction:
Stainless steel housing and liner pan, fiberglass
insulation.
Dimensions:
W-43V: 9 1/8” H x 1411⁄16 " W x 295⁄8 " D
(23.2 cm x 37.3 cm x 75.2 cm)
CW-3A: 101⁄8
" H x 1411⁄16 ” W x 295⁄8 ” D
(25.7 cm x 37.3 cm x 75.2 cm)
Electrical nformation:
Each unit is e uipped with a 60”, three wire grounded
power cord which terminates with a standard three
pronged male plug. The 120V unit uses a NEMA 5-15P
plug. The 230V unit uses a 10 Amp Euro plug. The
208V and 240V units use a NEMA 6-15P plug.
Electrical Specifications:
W-43V: 120V, 1500W, 12.5 Amps
W-43VCE: 230V, 1375W, 6 Amps
240V, 1500V, 6.25 Amps
CW-3A: 120V, 1800W, 15 Amps
230V, 1375W, 6 Amps
208V, 1800W, 15 Amps
Capacity:
W-43V: 28.5 t. (26.9L)
CW-3A: 28.5 t. (26.9L)
Both accept (1) 12”x20”x6” deep pan and one
1/3 size pan or (2) 2/3 size pans or four 1/3 size pans.
Ship Weight:
W-43V: 30 lbs. (13.6 kg)
CW-3A: 30 lbs. (13.6 kg)
F.O.B./ Dallas, TX
Model CW-3A Cooker & W-43V Warmer
Classic Countertop
12” x 27” Cooker & Warmers
(Millimeters in Parent esis)
CW-3A
AND
W-43V
CW-3A
W-43V
11 15/16" [303]
14 11/16" [373]
26 7/8"
[683]
10 1/8"
[257]
9 1/8"
[232]
6 1/4"
[159]
29 5/8"
[752]
Rev. 1/1/2003 #1502
