APW Wyott HFW-1 User manual

PRODUCT: QUANTITY: ITEM #:
Models: ¨HFW-1 ¨HFW-2 ¨HFW-3 ¨HFW-4 ¨HFW-5 ¨HFW-6 (“D” after model # designates drain)
Bid Specifications
Standard Features
Options
Hot Food Wells
Top Mount w/EZ-Lock
APW Wyott Foodservice Equipment Company · 729 Third Ave., Dallas, TX 75226
[phone] · [phone] · Fax [phone] · www.apwwyott.com· [email protected]
Rev. 3/20/2008
Top Mount w/EZ-Lock
Heavy-duty Top mount insulated Rectangular Drop-In Food
Well designed for installation in metal or wood countertops.
Hot Food Well is designed to accommodate standard size
steamtable pans. Well is constructed of deep-drawn 20 ga.
Type 304 stainless steel, above countertop with 20 ga. alu-
minized outer housing with sides and bottom fully insulated.
Units shipped with drain are provided with stainless steel
1/2” NPT drain welded to bottom of pan provided with
removable screen. Unit is heated by a tubular heating ele-
ment shaped in serpentine fashion for even heat distribution
to pan base.
Element is mounted under well and secured by aluminized
deflector shield for maximum efficiency. Unit standard with
APW Wyott E-Z Locks on all four exterior sides for easy
installation. The units feature complete UL construction
including electrical conduit, bezel and control box.
• 20ga.Deep-drawnType304stainlesssteelwellpans.
• Stainlesssteeldraincoupling.
• UnitsmaybeusedWETorDRY(Wetoffersbestresult)
• Easyaccesstoheatingelements
• Compacthousing—overalldepth8-11/16”and111/2”
over all drain manifold
• Largeindicatingpilotlight
• Multipleunitscanbe
• Simplifiedconstructionreducesinstallationtimeand
significantly reduces on-site electrical and plumbing costs
• Unitizedelectricalwiringforsinglepowerhookup
• Individualinfinitecontrols
Reliability backed by APW Wyott’s
Warranty
•Backedbya1yearparts&laborwarranty.
•FoodWellsareCertifiedbythefollowingagencies:
• Factoryassembled¾manifolddrains-screens
provided
• Thermostaticcontrol(effective26”)
• Leveroperateddrainvalve(56360)
• Threephase(Specify)
• Withoutdrain(Noletteraftermodel#designatesno
drain)
• Withdrain(“D”aftermodel#designatesdrain)
See reverse side for product specifications.
HFW-6 not CSA approved

Hot Food Wells
Top Mount w/EZ-Lock
PRODUCT: QUANTITY: ITEM #:
Models: ¨HFW-1 ¨HFW-2 ¨HFW-3 ¨HFW-4 ¨HFW-5 ¨HFW-6 (“D” after model # designates drain)
APW Wyott Foodservice Equipment Company · 729 Third Ave., Dallas, TX 75226
[phone] · [phone] · Fax [phone] · www.apwwyott.com· [email protected]
Rev. 3/20/2008
# 1404
*APW Wyott reserves the right to modify specifications or discontinue models without incurring obligation.
