APW Wyott W-46V User manual

R
SANITATION
NSF/ANSI 4
Phone: [phone]
Fax: [phone]
Toll Free: [phone]
Website: www.apwwyott.com
E-mail: [email protected]
INSTALLATION
AND
OPERATING
INSTRUCTIONS
1
APW WYOTT
729 Third Avenue
Dallas, TX 75226
R
Models: W-46V.......... (120V, 1150W - Warmer w/Hanger 81000100)
W-46V-NH....(120V, 1150W - Warmer No Hanger 81000200)
WENDY’S
HOT TOPPING WARMER 4/3 x 1/2 - 4 PAN HOLDER i
P/N 79900002 10/07
INTENDED FOR OTHER
THAN HOUSEHOLD USE
This equipment has been engineered to provide you with year-round dependable service when used
according to the instructions in this manual and standard commercial kitchen practices.
Initial heating of appliance may generate smoke or fumes and must be done in a well ventilated area.
Overexposure to smoke or fumes may cause nausea or dizziness.
WARNING: Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury or death. Read the Installation, Operating and
Maintenance Instructions thoroughly before installing or servicing this equipment. !!
RETAIN THIS MANUAL FOR FUTURE REFERENCE
APPLIANCE MUST BE KEPT CLEAR OF COMBUSTIBLES AT ALL TIMES

2
OWNER'S INFORMATION
General Installation
1. Always clean equipment thoroughly before first use. (See general cleaning instructions.)
2. Check rating label for your model designation & electrical rating.
3. Locate equipment on level counter and plug into a grounded outlet so that the plug is
accessible. (See individual description for electrical loads.) On units bearing the CE
marking the appliance must be connected by an earthing cable to all other units in the
complete installation and hence to an independent earth connection.
General Operating Instructions
1. All foodservice equipment should be operated by trained personnel.
2. Do not allow your customers to come in contact with any surface labeled "CAUTION
HOT.”
3. Where applicable, do not cook, warm or hold food directly in liner pans (well pans). Always
use steam table pans/insets, etc.
4. Never hold food below 150°F (66°C)
General Cleaning Instructions
1. NEVER clean any electrical unit by immersing it in water. Unplug unit before surface
cleaning. NEVER POUR COLD WATER INTO DRY HEATED UNITS.
2. Always clean equipment thoroughly before first use. Clean unit daily. Except where noted on
charts: Use warm, soapy water. Mild cleansers & PLASTIC scouring pads may be used to
remove baked-on food & water scale.
3. Unplug all units before cleaning or servicing. All service should be performed by an APW
authorized service agency.
4. Do not use chlorides or chloride-based products in this unit. Always clean equipment before
first use. Clean unit daily. Use warm, soapy water. Rinse thoroughly to remove all residue.
Chlorides, chloride-based products and improper cleaning may cause corrosion and pitting.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY VOID UNIT WARRANTY.
ITEM Page
Owner's Information 2
General Installation 2
General Operating Instructions 2
General Cleaning Instructions 2
General Troubleshooting 3
Specifications 3
Installation 3
Operations 3
Cleaning 3
Service Information 3
Dimensions 4
Wiring Diagram 5
Parts List w/Exploded View 6
Warranty 8
TABLE OF CONTENTS

3
GENERAL TROUBLESHOOTING
Always ask & check:
1. Is the unit plugged in?
2. Check circuit breaker.
3. Is power switch on & pilot light glowing?
4. Check rating label. Are you operating unit on proper voltage?
If the supply cord is damaged, it should only be replaced by an identical supply cord.
If the above checks out, and you still have problems, call an APW authorized service agency.
SPECIFICATIONS
Installation:
Follow General Instructions on previous page.
W-46V Hot Topping Warmer 4/3 X 1/2 - 4 Pan Holder............................120 volt outlet - 10 amp
load.
Operations:
Follow General Operating Instructions on previous page.
1. Add hot water (120° - 140°) to well pan: W-46V, uses 1.5 quarts (1.4 liter).
2. Turn rocker switch to “ON” position and preheat for 10 minutes.
3. Place four (4) inset pans into unit then place refrigerated toppings into inset pans.
4. Internal thermostat will automatically keep unit at correct temperature.
Cleaning:
Daily Cleaning
1. Refrigerate remaining product.
2. Follow General Cleaning Instructions on previous page.
SERVICE INFORMATION
IF A SHORTAGE OR A PROBLEM CALL - in the USA 1-888-279-7493
PLEASE FOLLOW THESE INSTRUCTIONS:
A. ON ALL CALLS YOU WILL NEED TO GIVE THE FOLLOWING INFORMATION.
1. Name and title of person calling
2. Phone number of person calling
3. Business name
4. Street address
5. City, State, Zip
6. Model Number (from serial plate)
7. Serial Number (from serial plate)
8. Date purchased (if serial number indicates date of manufacture is over 13 months
old you will be asked to supply proof of purchase)
9. Purchased from
i

W-46V & W-46V-NH HOT TOPPING WARMER - DIMENSIONS
4
8.736
w/Hanger
81000100
7.380
No Hanger
81000200
12.970
30.792
w/Hanger
81000100
29.821
No Hanger
81000200
10.729 15.200
B. FOR SHORTAGE - SUPPLY THE ABOVE INFORMATION AND FULLY EXPLAIN WHAT IS
MISSING. It will be sent immediately - prepaid via UPS or equivalent. (Next Day Air or
Priority shipments available at customer's expense)
C. FOR EQUIPMENT PROBLEMS - IF WITHIN ONE YEAR FROM THE DATE OF PURCHASE
THIS UNIT FAILS TO FUNCTION.
Contact the Authorized Service Distributor to service the equipment on site. If the
problem is covered under warranty, the parts and labor will be billed to the
factory.
INSTRUCTIONS AND PROCEDURES MUST BE FOLLOWED OR THE WARRANTY IS VOID.
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this manual for the life of the equipment. For
Warranty Service and/or Parts, this information is required.
Model Number Serial Number Date Purchased

W-46V & W-46V-NH HOT TOPPING WARMER - WIRING DIAGRAM
Brown
Blue
Blue
White or Blue Wire From Cord
Black or Brown Wire From Cord
Green Wire From Cord
SSR Relay
Temperature Control Black
Red
Red
K Thermocouple
12
3
4+
+
-
-
Com
115
230
Yellow
4
5
6
7
8
9
9
Element
Switch
Main Power
6
8
10
120V Single Phase
4
5
7
5

6
ITEM P/N DESCRIPTION QUANTITY
PARTS LIST w/EXPLODED VIEW - W-46V & W-46V-NH HOT TOPPING WARMER
Note: When ordering, ALWAYS specify Part #, Model #, Serial #,Voltage/Phase & type of Gas. 79900003 9/07
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
81000101
81000102
81000103
81000110
81000109
81000111
81000112
81000118
89025
70101088
81000014
70444800
81000113
89164
81000119
81000120
81000114
54418
88933
89032
81000122
69148
88948
89050
86284
81000014
85211
89101
55947
86280
81000121
81000156
Weld Assembly, 1/2 x 4/3 Well w/Drain, Nipple, StudsI
Wrapper Assembly
Bottom Cover
Cover, Control Panel
Bracket, Terminal Block
Bottom Cover
Mounting Bracket, 1/2 x 4/3 Warmer (Used on hanger model only)I
Bracket, Mounting Strip (Used on hanger model only)
Nut, Speed 10-24 Pal Zinc
Nipple, ½" NPT X 1.25" Brass
Valve, Drain
Switch, Rocker On-Off
Grommet, PVC, Sealing, Lip Style
Screw, 1/4-20 X 5/8 Hex Sl Nck Pl (Used on hanger model only)
Heat Transfer Plate, Single Element
Element Cover, Single Element
Element, 1150W
Element Cover Bracket
Rivet,1/8 X 1/4 Aluminum
Screw, 10-32 x 3/8
Control, Solid State, 115/230VAC Input, 24VDC Output, 190-198° Fixed
Relay, Solid State 50A 280V Out, 3-32VDC In
Screw 6-32 X 3/4 Pan Hd
Screw 6/32 X 1/2 Pan Hd
Screw, 8-32 X 1/4 Phil Pan Type 23 Zink
Handle
Housing Bearing Plated
Bushing Strain Relief
Cord Set
Probe, "K” Thermocouple
O-Ring, 1/2 X 7/8 Buna-n #310
Bracket, On/Off Switch
1
1
1
1
1
1
1
1
14
1
1
1
1
6
1
1
1
5
10
4
1
1
4
2
18
1
1
1
1
1
1
1

7
W-46V HOT TOPPING WARMER - EXPLODED VIEW
“B”“B”
“A”“A”
28
29
26 31
32
12
13 8
7
1
14
2
DETAIL “A”DETAIL “A”
27
30
3
10
11
16
17
18
19
16
15
9
DETAIL “B”DETAIL “B”
4
23
24
25
5
6
20
21
22
Note: When ordering, ALWAYS specify Part #, Model #, Serial #,Voltage/Phase & type of Gas. 79900003 9/07

APW WYOTT EQUIPMENT LIMITED WARRANTY
APW Wyott Foodservice Equipment Company warrants it's equipment against defects in materials and workmanship, subject to the
following conditions:
This warranty applies to the original owner only and is not assignable.
Should any product fail to function in its intended manner under normal use within the limits defined in this warranty, at the option of
APW Wyott such product will be repaired or replaced by APW Wyott or its Authorized Service Agency. APW Wyott will only be
responsible for charges incurred or service performed by its Authorized Service Agencies. The use of other than APW Wyott
Authorized Service Agencies will void this warranty and APW Wyott will not be responsible for such work or any charges associated
with same. The closest APW Wyott Authorized Service Agent must be used.
This warranty covers products shipped into the 48 contiguous United States, Hawaii, metropolitan areas of Alaska and Canada. There
will be no labor coverage for equipment located on any island not connected by roadway to the mainland.
Warranty coverage on products used outside the 48 contiguous United States, Hawaii, and metropolitan areas of Alaska and Canada
may vary. Contact the international APW Wyott distributor, dealer, or service agency for details.
Time Period
One year for parts and one year for labor, effective from the date of purchase by the original owner. The Authorized Service Agency
may, at their option, require proof of purchase. Parts replaced under this warranty are warranted for the un-expired portion of the
original product warranty only.
Exceptions
*Gas/Electric Cookline: Models GCB, GCRB, GF, GGM, GGT, CHP-H, EF, EG, EHP. Three (3) Year Warranty on all
component parts, except switches and thermostats. (2 additional years on parts only. No labor on second or third year.)
*Broiler Briquettes,
*Heat Strips: Models FD, FDL, FDD, FDDL. Two (2) Year Warranty on element only. No labor second year.
*Glass Windows, Doors, Seals, Rubber Seals, Light Bulbs:
In all cases, parts covered by extended warranty will be shipped FOB the factory after the first year.
Portable Carry In Products
Equipment weighing over 70 pounds or permanently installed will be serviced on-site as per the terms of this warranty. Equipment
weighing 70 pounds or under, and which is not permanently installed, i.e. with cord and plug, is considered portable and is subject to
the following warranty handling limitations. If portable equipment fails to operate in its intended manner on the first day of
connection, or use, at APW Wyott's option or its Authorized Service Agency, it will be serviced on site or replaced.
From day two through the conclusion of this warranty period, portable units must be taken to or sent prepaid to the APW Wyott
Authorized Service Agency for in-warranty repairs. No mileage or travel charges are allowed on portable units after the first day of use.
If the customer wants on-site service, they may receive same by paying the travel and mileage charges. Exceptions to this rule: (1)
countertop warmers and cookers, which are covered under the Enhanced Warranty Program, and (2) toasters or rollergrills which have
in store service.
Exclusions
The following conditions are not covered by warranty:
*Equipment failure relating to improper installation, improper utility connection or supply and problems due to
ventilation.
*Equipment that has not been properly maintained, calibration of controls, adjustments, damage from improper cleaning
and water damage to controls.
*Equipment that has not been used in an appropriate manner, or has been subject to misuse or misapplication, neglect,
abuse, accident, alteration, negligence, damage during transit, delivery or installation, fire, flood, riot or act of god.
*Equipment that has the model number or serial number removed or altered.
If the equipment has been changed, altered, modified or repaired by other than an Authorized Service Agency during or after the
warranty period, then the manufacturer shall not be liable for any damages to any person or to any property, which may result from the
use of the equipment thereafter.
This warranty does not cover services performed at overtime or premium labor rates. Should service be required at times which
normally involve overtime or premium labor rates, the owner shall be charged for the difference between normal service rates and such
premium rates. APW Wyott does not assume any liability for extended delays in replacing or repairing any items beyond its control.
In all cases, the use of other than APW Wyott Authorized OEM Replacement Parts will void this warranty.
This equipment is intended for commercial use only. Warranty is void if equipment is installed in other than commercial application.
Water Quality Requirements
Water supply intended for a unit that has in excess of 3.0 grains of hardness per gallon (GPG) must be treated or softened before
being used. Water containing over 3.0 GPG will decrease the efficiency and reduce the operation life of the unit.
Note: Product failure caused by liming or sediment buildup is not covered under warranty.
“THE FOREGOING WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES EXPRESSED OR IMPLIED
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSES
AND CONSTITUTES THE ENTIRE LIABILITY OF APW WYOTT. IN NO EVENT DOES THE LIMITED WARRANTY
EXTEND BEYOND THE TERMS STATED HEREIN.”
9/05
Rock Grates, Cooking Grates, Burner Shields, Fireboxes: 90 Day Material Only. No Labor.
90 Day Material Only. No Labor.
8
