Aqua-Marina TOMAHAWK User manual

TOMAHAWK
User’s Guide
HIGH PRESSURE KAYAK/CANOE
For your own safety and that of your equipment, make sure to take the following
precautions.
Failure to follow warning notices and instruction may result in property damage,
serious injury or death.
WARNING
aquamarina.com
EN

2
GENERAL INFORMATION
SAFETY
Kayak sports can be very dangerous and physically demanding. The users of this
product should understand participating in paddle sports may involve serious injury or
death. Observe all applicable watercraft laws, and use common sense.
PLEASE KEEP THIS MANUAL IN A SECURE PLACE, AND HAND IT OVER TO THE NEW
OWNER WHEN YOU SELL THE CRAFT. RECORD THE “HULL IDENTIFICATION
NUMBER” (HIN) WHICH IS PRINTED ON THE KAYAK’S HULL IN THE FOLLOWING
BOX:
SAFETY CHECK LIST AND SAFETY WARNING
• It is the owner’s responsibility to carefully read the manual and instruct all users in
safe operation of this product.
• Retain owner’s manual for future reference.
• Get kayak instruction specific to this type of craft.
• Follow the instructions in the Owner’s Manual, including the data given on the
capacity plate. Uneven distribution of people or loads in the kayak could result in
danger.
• Use caution when stepping or climbing aboard the kayak. Step into the center of the
kayak for maximum stability.
• Always wear an approved Personal Flotation Device (Life Preserver).
• Wear a helmet when appropriate.
• DO NOT use in high wind, strong currents, open water or dangerous tides.
• DO NOT paddle in flood conditions.
• DO NOT use this product under the influence of alcohol or drugs.
• DO NOT overload or over inflate
• DO NOT exceed your paddling ability; be honest with yourself.
• Never tow from another boat or vehicle.
• Know and follow local water safety rules and boating regulations.
• Not a life saving device.
• Not for use by children without adult supervision.
• DO NOT drag your Aqua Marina over rocks or gravel if it can be avoided.
• DO NOT use compressors, CO2 or compressed air for inflation, only use Aqua Marina
recommended pumps.
• DO NOT sleep inside of your Aqua Marina while on the water.
• Bring a cell phone or other emergency contact device in a waterproof bag.
• DO NOT exceed the data given on the capacity plates.
• BEWARE OF OFFSHORE WINDS AND CURRENTS.
MANUFACTURER’S CERTIFICATION
AM kayak/canoe products are with reference to the ISO 6185 standard established by
International Organization for Standardization.
CN-ORP

3
MANUFACTURER’S RECOMMENDATION
The total number of persons and total weight shall not exceed the limits printed on the
kayak/canoe. Please refer to the kayak’s/canoe’s hull label for the actual specifications
of your product.
KAYAK/CANOE LABEL FORMAT
1. Country of origin
2. Maximum passengers
3. Manufacturer’s recommended maximum load capacity
4. Manufacturer’s recommended working pressure
5. Hull identification number (HIN)
6. Manufacturer’s name and address
= 128kg (282lbs)+
CN-ORP
Do not over inflate or use high pressure air compressor to inflate.
Inflate the chambers in sequence.
Ensure even distribution of person or loads in the KAYAK.
= 1 = 0
= 0.68bar / 10psi
DATE
aquamarina.com
AIR-K 375
TYPE Ⅲ(B)
D
BOAT MODEL
BOAT TYPE
DESIGN CATEGORY
ORIENTAL RECREATIONAL PRODUCTS (SHANGHAI) CO.,LTD
NO.1699 DAYE ROAD, WUQIAO, FENGXIAN, SHANGHAI,
201402, CHINA MADE IN CHINA
WARNING:
This is not a life saving device.
Use only under competent supervision.
Always use an approved life preserver.
Do not use in high wind, rapid currents, open water or dangerous tides.
Be familiar with area where you intended to use kayak.
Never allow diving into this product.
Never leave in or near the water when not in use.
Follow these rules to avoid drowning, paralysis or other serious injury:
● Not for use by children without adult supervison.
● Do not overload.
● Know and follow local water safety rules and regulations.
216
345

4
PART LIST
AIR-K
Durable rubber carry handle
D-rings for seat and footrest
connection
Integrated drain valve x 2
High pressure recessed valve for
quick and easy inflation and deflation
a
c
Safety grab handlesb
d
EVA footpad provides grip and
comfort
e
f
g
Slide-in kayak fin x 2
Extended water splash guard
bow design
Deck shield
j
Zip backpacki
Adjustable footrest
(AIR-K 375 x 1, AIR-K 440 x 2)
hp
k
l
m
Durable high-back seat
(AIR-K 375 x 1, AIR-K 440 x 2)
n
Repair patch
o
Wrench
Velcro for removable high-back seat
i
j
o
km
p
n
Double-action pump, Inflation hose
ab
ce
e
e
l
e
dg
h
h
f
b
b
c
f
b
a
g
a

PART LIST
Durable rubber carry handle
D-rings for seat connection
Integrated drain valve x 2
High pressure recessed valve for
quick and easy inflation and deflation
a
c
Safety grab handlesb
d
EVA footpad provides grip and
comfort
e
f
g
Durable high-back seat x 3
Repair patch
j
Double-action pump, Inflation hosei
Zip backpackh
k
l
mWrench
n Transparent hose
Velcro for removable high-back seat
Slide-in kayak fin x 2
5
AIR-C
i
l
n
jm
k
a
a
b
b
ceeee e
d
g
gg
h
f
b
c
b
f
a

6
Model
375 cm
(12’4”)
AIR-K
375
AIR-K
440
AIR-C
72 cm
(28”) 1128 kg (282 lbs)
16.6 kg
(36.6 lbs)
0.68 bar
(10 psi)
440 cm
(14’5”)
78 cm
(31”) 2210 kg (462 lbs)
20.3 kg
(44.8 lbs)
0.68 bar
(10 psi)
478 cm
(15’8”)
88 cm
(35”) 3260 kg (573 lbs)
24.7 kg
(54.5 lbs)
0.68 bar
(10 psi)
Length Width Max.
Passenger Net Weight Max.
air pressure
SPECIFICATIONS
B
INSTRUCTION FOR ASSEMBLING AND DISASSEMBLING
UNFOLD THE KAYAK / CANOE FROM THE PACKAGING BOX
Locate a clean and smooth space to unfold the Aqua Marina Tomahawk kayak/canoe
and lay it out flat.
A
HIGH PRESSURE VALVE
NOTE: Deck Shield Set-up
Max. Loading
Capacity
Step 2
Step 1
Step 1
AIR-K

INFLATE THE KAYAK/CANOE
Inflate the inflatable keels (for AIR-C only), side chambers and air floor in
sequence as shown in the picture.
1. Attach the pressure gauge and the pump hose to the gauge housing on the pump
and secure it tightly. The pump can be switched between double action mode and
single action mode.
2. HIGH PRESSURE VALVE
Unscrew the valve cap, push button in and turn it clockwise to make sure that the
valve is in the “Pin Out” position.
KEEL AIR VALVE (AIR-C)
Open external cap and pull firmly to extend out. Start pumping air into the
inflatable keel by sliding the pump piston up and down for ONLY ONE ROUND.
3. Inflate the drop-stitch air chambers to the maximum air pressure (10 psi/ 0.68 bar).
TIP: If the pump piston starts to squeak, apply some lubrication oil on the piston shaft.
7
MAXIMUM OF 10PSI FOR THIS PRODUCT. DO NOT OVER INFLATE
BEYOND 10PSI. THIS WILL VOID YOUR WARRANTY.
HIGH PRESSURE VALVE KEEL AIR VALVE
DOUBLE
ACTION
SINGLE
ACTION
Step 3
Step 2
Step 2
Step 1 Step 1
AIR-C

SEAT INSTALLATION
1. Attach the seat to the kayak/canoe floor with Velcro. It is important to place the
seat in the right place to evenly balance the boat when in the water. A solo
paddler should be slightly aft of the boat’s center. With two paddlers, the
heavier one should sit toward the rear.
2. Once seat position is confirmed, connect the seat straps to the D-rings by using
seat strap buckles. Attach the upper straps to the D-rings forward of each seat.
NOTE: AIR-C is designed for 2-3 users. Seat position could be easily adjusted by
clipping strap buckles to different D-rings, and strap buckles may be clipped to
the same D-ring if needed. Please refer to above seat position layout for reference
when there are 2 or 3 users.
8
C
D
KAYAK FIN INSTALLATION
Turn the kayak/canoe over and slide the kayak fin into the fin box. It only slides in
facing one way. Slide in the push-in pin into the groove until it clicks into the position.
FOR 2 USERS
FOR 3 USERS

KAYAK/CANOE DEFLATION
1. Clear any water or debris out of the valve areas.
2. HIGH PRESSURE VALVE
Open the valve cap first. Slowly press down on the valve stem to start letting air
out of the kayak/canoe. There will be an initial burst of air, but that will slow
down very quickly. Once the air flow has slowed down, press the valve stem all
the way down and turn it clockwise to lock it into the “OPEN” position.
KEEL AIR VALVE (AIR-C)
Open external cap and pull firmly to extend out. Start to deflate by using the
transparent hose (come with the repair kit bag), or by simply squeezing the
bottom of the valve.
KAYAK/CANOE FOLDING STEPS
1. Remove all the accessories from the kayak/canoe: seats, paddles, kayak fins, etc.
For AIR-K, remember to remove the Deck Shield before folding.
2. Make the first fold from the bow. Continue folding towards the valves tightly,
forcing out any remaining air as you go.
3. Fold the boat all the way to the end to push all the air out. Then unfold one fold.
Fold stern back and place bow folds on top of stern.
9
E
HIGH PRESSURE VALVE KEEL AIR VALVE
NOTE: Please avoid bending the molded keels.
NOTE:
Remove Deck
Shield first.
AIR-K

10
INSTRUCTION FOR CARE AND STORAGE
The kayak/canoe is made of the highest quality materials and is with reference to
ISO 6185 standards. Altering the construction of the kayak/canoe will endanger
your own safety, safety of the occupants and void the limited warranty! There is
very little that you have to do to keep your kayak/canoe in good condition for many
years.
• Clean your kayak/canoe after a trip to prevent damage from sand, salt water or
sun exposure. Most dirt can be removed with a garden hose, a sponge and mild
soap. Make sure the kayak/canoe is completely dry before being stored . Use as
few cleaning agents as possible, do not discharge waste agents into water, and
clean your kayak/canoe preferably on land.
• The products may be stored inflated, but do not place any heavy or sharp objects
on it. Hanging the kayak/canoe is not recommended.
• Open all air valves and deflate kayak/canoe completely. Remove all the
accessories from the kayak/canoe.
• The kayak/canoe storage bag is designed to allow you to get your kayak/canoe
into the bag as easily as possible with minimal folds.
• Store your kayak/canoe in a dry room.
• Take protection method to keep your kayak/canoe away from rodents or other
vermin, as they may bite the product.
• The room temperature shall be maintained between 0°C (32°F) and 40°C
(104°F).
F
ZIP BACKPACK
• Perfect for storing & carrying
KAYAK/CANOE
• Side pockets are designed for
pump and paddle
G

CANOE PADDLE ASSEMBLY (*Optional for AIR-C)
1. Join the 2 shafts together and easily adjust the shaft length by using the clamp
system.
2. Clamp to secure the length and reduce any play.
3. To disassemble, reverse the assembly steps.
Blade Shaft Shaft
H
PADDLE ASSEMBLY
KAYAK PADDLE ASSEMBLY (*Optional for AIR-K)
1. Place the blade piece into the shaft by unlocking the microlock. Snap it into
place and secure the microlock into the shaft hole.
2. Join the 2 shafts together by securely snapping the shaft pieces into place.
3. To disassemble, reverse the assembly steps.
Note: It’s not necessary to detach the paddle blades from the shafts.
Shaft ShaftBlade Blade
NOTE: Always drain the water left in the paddle shaft after each use.
11

12
OPTIONAL ACCESSORIES
I
12V ELECTRIC PUMP FOR INFLATABLE WATER SPORT ITEMS
PSI/BAR
10.89
J
HOW TO FIX A LEAKING VALVE
open
close
open
close
1. Inflate your kayak/canoe up to the max air
pressure
2. Stick your valve wrench down inside of
valve and turn clockwise to tighten the
valve back down onto the kayak/canoe
1. Completely deflate your kayak/canoe
2. Undo the dust cap and insert the valve wrench into the valve and
twist counterclockwise to remove the valve
A. Try to tighten the valve
B. Re-install or replace a valve

13
NOTE: Correctly use the wrench by pressing it with
one hand on top.
open
close
3. Check the rubber ring to make sure that it is in the correct position,
tight around the valve and there is no debris in the way
4. Be sure the pin spring is functioning properly and there are no cracks
along the edges
5. Ensure there are no strings from the drop stitching material
6. Note the bottom piece of the valve is not attached to anything
7. Fit the valve back into your kayak/canoe
8. Align all the threads and twist to tighten
9. Once the valve is hand tight, use the valve wrench to seal completely
Rubber Ring

LEAK DETECTION AND REPAIR
14
K
A leaking valve is rare, but if you do find a leak, turn to after-sales service center
for a replacement valve. To locate a leak, we recommend mixing soap and water
in a spray bottle, spray around the valve. If you see bubbles forming, check your
valve seating and base and be sure the valve insert is screwed tight. If the
kayak/canoe is losing air and all the valves are good, it probably has a small
puncture.
Small punctures can be repaired easily and permanently. Spray soap water
around the kayak/canoe until air bubbles become visible and mark the position
of the leak.
1. Punctures less than 1/8”in size can be repaired simply without a patch.
Deflate your kayak/canoe, then clean and dry the area to be repaired. Apply a
small drop of glue to cover the puncture, and let it dry 12 hours.
2. Cut a piece of repair material large enough to overlap the damaged area by
approximately 1.5cm (1/2”), and round off the edges.
3. Apply glue to the under side of the patch and around the area to be repaired.
Too much glue will interfere with a proper repair.
4. Allow adhesive to become tacky for 2-4 minutes, and then start at one corner
and work outward, carefully apply the patch to the repair area using very firm
pressure. Rub the entire patch area and the edges of the patch using very firm
pressure. Allow to cure for at least 12 hours before inflating and using.

15
The warranty is valid only when this product is used for normal recreational activities
and does not cover products used in rental or school operations
AM will make the final warranty determination, which may require inspection and/or
photos of the equipment, which clearly show the defect(s). If necessary, this
information must be sent to the AM distributor in your country with prepaid
postage. Product can be returned only if a return authorization number is given in
advance by the AM distributor. The return authorization number must be clearly
labeled on the outside of the package, or it will be refused
If a product is deemed to be defective by AM, the warranty covers the repair or
replacement of the defective product only. AM will not be responsible for any costs,
losses, or damages incurred as a result of loss or misuse of this product
This warranty does not cover damage caused by misuse, abuse, neglect, normal
wear and tear including, but not limited to, punctures, damage due to excessive
heat exposure, damage caused by improper handling and storage, damage caused
by use in waves or shore break, kayak/canoe breakage caused by filling or crashing
in surf conditions, or damage caused by anything other than defects in material and
workmanship
This product must not be modified and/or fitted with a motor except AM BlueDrive
power fin
This product must not be used in excess of the manufacturers recommended
maximum load capacity
This warranty is void if any unauthorized repair, change or modification has been
made to any part of the equipment
The warranty for any repaired or replacement equipment is good from the date of
the original purchase only
The original purchase receipt must accompany all warranty claims. The name of the
retailer and date of purchase must be clear and legible
There are no warranties that extend beyond the warranty specified here in
THIS PRODUCT IS DESIGNED IN ACCORDANCE WITH STANDARDS
FOR A SPECIFIC USE. ANY MODIFICATIONS OR
TRANSFORMATIONS HIGHER THAN THAT INDICATED BY THE
MANUFACTURER COULD RESULT IN SERIOUS RISKS FOR THE
USER AND WILL VOID THE WARRANTY.
WARNING
WARNING
AM warrants this product to be free from major defects in material
or workmanship to the original purchaser for a period of ONE (1)
YEAR from the date of purchase. This warranty is subject to the
following limitations
1
YEARYEAR
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.

TOMAHAWK
Guide de l'utilisateur
CANÖE/KAYAK HAUTE PRESSION
Pour votre propre sécurité et celle de votre équipement, veillez à prendre les
précautions suivantes.
Si vous ne suivez pas les avertissements et les instructions, vous pourrez être
exposé à des dommages matériels et des blessures graves ou même la mort.
ATTENTION
aquamarina.com
FR

2
INFORMATIONS GÉNÉRALES
SÉCURITÉ
Les sports de kayak peuvent s’avérer être très dangereux et physiquement exigeants.
Les utilisateurs de ce produit doivent comprendre que la pratique de sports de pagaie
peut entraîner des blessures graves, voire la mort. Respectez toutes les lois applicables
aux embarcations et faites preuve de bon sens.
VEUILLEZ CONSERVER CE MANUEL DANS UN LIEU SÛR ET LE REMETTRE AU
NOUVEAU PROPRIÉTAIRE LORS DE LA VENTE DE L’EMBARCATION. ENREGISTREZ
LE “NUMÉRO D'IDENTIFICATION DE LA COQUE” (HIN), IMPRIMÉ SUR LA COQUE
DU KAYAK, DANS LA BOÎTE SUIVANTE:
LISTE DE VERIFICATION DE SECURITE ET AVERTISSEMENT DE SECURITE
• Il est la responsabilité du propriétaire de lire attentivement le manuel et d’instruire
tout utilisateur pour utiliser ce produit en toute sécurité.
• Conservez le manuel d’utilisation pour un usage ultérieur.
• Obtenez les instructions des sports à pagayespécifiques à ce type d’embarcation.
• Suivez les instructions du Manuel du Propriétaire, y compris les données situées sur la
plaque indiquant les capacités. La répartition inégale des personnes ou des charges
dans le bateau peut engendrer une situation dangereuse.
• Soyez prudents lorsque vous embarquez à bord du Kayak. Entrez par le centre du
Kayak pour une stabilité maximale.
• Portez toujours un Dispositif Personnel Flottant approuvé (Gilet de Sauvetage).
• Portez un casque si nécessaire.
• Ne pas utilisezdans legrand vent, les courants forts, le large ou les marées
dangereuses.
• Ne pas pagayez en casd’inondations.
• Ne pas utilisezce produit sous l’emprise de l’alcool ou de la drogue.
• Ne pas surchargezou tropgonflez.
• Ne dépassez pas vos capacités à pagayer, soyez honnêtes avec vous-même.
• Ne jamais remorquez par des autres bateaux ou véhicules.
• Connaissez et suivez les règles locales de sécurité et de navigation.
• Ce n’est pas un dispositif de sauvetage.
• Ne pas pour utilisation par des enfants sans surveillance d’un adulte.
• NE PAS dépassez les données indiquées sur les plaques de capacité.
• FAITES ATTENTION AUX VENTS ET COURANTS EN MER.
• BEWARE OF OFFSHORE WINDS AND CURRENTS.
ATTESTATION DU FABRICANT
Les canoës / kayaks AM sont conformes à la norme ISO 6185 établie par l'Organisation
internationale de normalisation.
CN-ORP

3
RECOMMANDATION DU FABRICANT
Le nombre total de personnes qui peuvent embarquer et le poids total ne doivent pas
dépasser les limites imprimées sur le canoë/kayac. Veuillez vous reporter à l’étiquette
de la coque du canoë/kayak pour connaître les vraies spécifications de votre produit.
PRÉSENTATION DE L'ÉTIQUETTE DU CANÖE/ KAYAK
1. Pays d’origine
2. Nombre maximal de passagers
3. Capacitésde charge maximale recommandée par le fabricant
4. Pression de service recommandée par le fabricant
5. Numéro d’identification de la coque (NIC)
6. Nom et adresse du fabricant
= 128kg (282lbs)+
CN-ORP
Do not over inflate or use high pressure air compressor to inflate.
Inflate the chambers in sequence.
Ensure even distribution of person or loads in the KAYAK.
= 1 = 0
= 0.68bar / 10psi
DATE
aquamarina.com
AIR-K 375
TYPE Ⅲ(B)
D
BOAT MODEL
BOAT TYPE
DESIGN CATEGORY
ORIENTAL RECREATIONAL PRODUCTS (SHANGHAI) CO.,LTD
NO.1699 DAYE ROAD, WUQIAO, FENGXIAN, SHANGHAI,
201402, CHINA MADE IN CHINA
WARNING:
This is not a life saving device.
Use only under competent supervision.
Always use an approved life preserver.
Do not use in high wind, rapid currents, open water or dangerous tides.
Be familiar with area where you intended to use kayak.
Never allow diving into this product.
Never leave in or near the water when not in use.
Follow these rules to avoid drowning, paralysis or other serious injury:
● Not for use by children without adult supervison.
● Do not overload.
● Know and follow local water safety rules and regulations.
216
345

4
LISTE DES PIÈCES
AIR-K
Poignée de transport robuste en
caoutchouc
Anneaux en D pour la connexion du
siège et du repose-pied
2 valves de vidange intégrées
Valve encastrée haute pression pour
gonflage et dégonflage rapides et faciles
a
c
Poignées de sécuritéb
d
Le repose-pied EVA offre adhérence
et confort
e
f
g
2 ailerons de kayak coulissants
Protection contre les éclaboussures
d'eau, de conception en arc
Bouclier de pont
j
Sac à dos à fermeture éclairi
Repose-pieds réglable
(AIR-K 375 x 1, AIR-K 440 x 2)
hp
k
l
m
Siège robuste avec dossier haut
(AIR-K 375 x 1, AIR-K 440 x 2)
n
Kit de réparations
o
Clé
Velcro pour siège amovible avec
dossier haut
i
j
o
km
p
n
Pompe à double action, tuyau de
gonflage
ab
ce
e
e
l
e
dg
h
h
f
b
b
c
f
b
a
g
a

LISTE DES PIÈCES
Poignée de transport robuste en
caoutchouc
Anneaux en D pour la connexion du
siège
2 valves de vidange intégrées
Valve encastrée haute pression
pourgonflage et dégonflage rapides
et faciles
a
c
Poignées de sécuritéb
d
Repose-pieds EVA offrnt adhérence
et confort
e
f
g
3 sièges robustes avec dossier haut
Kit de réparations
j
Pompe à double action, tuyau de
gonflage
i
Sac à dos à fermeture éclairh
k
l
mClé
nTuyau transparent
Velcro pour siège amovible avec
dossier haut
2 ailerons de kayak coulissants
5
AIR-C
i
l
n
jm
k
a
a
b
b
ceeee e
d
g
gg
h
f
b
c
b
f
a
