AQUAMAXX Cone-S Q Series User manual

www.aquamaxxaquariums.com
[email protected]
www.aquamaxxaquariums.com
Cone-S Q Series
In-Sump Protein
Skimmer
User’s Manual

1Questions? Email [email protected]
AquaMaxx ConeS Q Series In-Sump Protein Skimmer
                          
 
Footprint
Height
Gallon
Rating
Motor
Light Bioload
Medium Bioload
Heavy Bioload
6.7” x 9.5”9.5” x 5.9” 8.7” x 11.5” 10.7” x 13.4” 16.6” x 13”
19.3”19.6” 19.7” 19.7”
Shark 2.0Shark 1.5 Shark 3.0 Shark 6.0
Approx.
200 gallons
Approx.
110 gallons
Approx.
350 gallons
Approx.
450 gallons
Up to 130
gallons
Up to 80
gallons
Up to 240
gallons
Up to 300
gallons
Up to 250
gallons
Up to 140
gallons
Up to 420
gallons
Up to 550
gallons
22.9”
Shark 7.0
Approx.
650 gallons
Up to 450
gallons
Up to 760
gallons
                   
                  
                 
Collection
Cup
Drain
Tube
Air
Silencer
Adjustment
Valve
Outlet
Pipe
Pump Base
Plate
Airline
Tubing
Pump
Venturi
Bubble
Plate
Diuser
Skimmer
Body
Skimmer
Base
O-Ring
In order to remove residual
residue leftover from the
manufacturing process, it is
recommended to clean all
skimmer components prior
to use by soaking them in
warm water.
                 
                    
         

Installation Guide
      
                                                              
    
    
    
2Questions? Email [email protected]
Center and press-t the bubble plate base into the pump outlet,
nger-tightening the outlet thumbscrew clockwise to secure.
Remove the top of the bubble plate assembly by twisting its
central thumbscrew in a counter-clockwise motion.
The venturi is press-t into the pump body and can be removed by pulling gently with a twisting
motion. Take care when handling so that you do not damage the venturi inlet pipes.
                              
                              
Replace the bubble plate lid and position it so that the area
without bubble diusers sits directly above the pump outlet.
Once in the correct position, nger-tighten the bubble plate’s
central thumbscrew clockwise to secure it into place.

3Questions? Email [email protected]
Installation Guide
    
    


                               
                                                                
Turn the ve thumbscrews underneath the
skimmer base counter-clockwise to detach
the skimmer body.
With the venturi side facing away from the
skimmer’s outlet pipe, position the pump into
the base plate notches and secure by twisting
the two base plate thumbscrews in a clockwise
motion.
Ensure the pump power cord is seated within
the guide channel prior to placing the skimmer
body back onto its base.
Secure the skimmer body to its base by nger
tightening the thumbscrews in an alternating
pattern.









4Questions? Email [email protected]
Installation Guide
    
    
                     
            
Push the press-t venturi into the pump
outlet through the opening in the skimmer
body.
Attach the air silencer to its mount by nger-
tightening its central thumbscrew in a clockwise
motion.
Connect one end of the yellow
air line tubing to the bottom pipe
on the air silencer.
The second venturi inlet is designed for ozone, which is optional. If you
choose not to use the ozone inlet, be sure to keep it covered with the
included rubber cap.
Connect the other end of the yellow airline tubing to
one of the air inlets located on the pump venturi.

5Questions? Email [email protected]
Installation Guide
    
                             
Connect the silicone drain tube to the outlet pipe
on the bottom of the collection cup.
If desired, use a zip tie to further secure the drain
tube.
                                
              
Ensure the o-ring is securely in place on the
skimmer body.
Install the collection cup by twisting it clockwise
onto the skimmer body.
O-ring

6Questions? Email [email protected]
Operation Guide
                 
                
The pump must be completely submerged underwater when in use. Running the pump dry or in
too low of a water level will damage the pump.
Turning the knob counter-
clockwise will open the outlet
pipe, causing the water level
within the chamber to drop.
Generally, opening the
valve will lead to wetter
skimmate that is light in
color.
As a starting point, it is recommended to adjust the water level within the skimmer body to where
the collection cup meets the neck.
                   
 
Required Water Level 7-8”7-8” 8-9” 8-9” 8-9”
For proper performance of the quick-precise adjustment valve, the water in your sump must not be
any higher than the following levels:
Turning the quick-precise adjustment knob will change the water level within the skimmer body
chamber.
Turning the knob clockwise
will close the outlet pipe,
causing the water level
within the chamber to rise.
Generally, closing the valve
will lead to drier skimmate
that is dark in color.

7Questions? Email [email protected]
Operation Guide
                    
It may require 2-4 weeks for the skimmer to reach optimal performance due to tiny amounts of
oil or remnant leftover from the manufacturing process. The skimmer’s performance may be
erratic during this period; be sure to allow ample time for the skimmer to break in prior to making
any major adjustments.
         
Regular maintenance of the pump will ensure a long life and maximum performance. You can
clean the pump and its components by soaking in a general citric acid solution once every 3
months.
The collection cup should be cleaned frequently with a sponge and warm water.
                                                            
                                                                      
AquaMaxx warrants all AquaMaxx products to be free from manufacturing defects for one year from
the original purchase date when purchased through an authorized AquaMaxx retailer. This warranty
does not cover any damages caused by misuse, neglect, alterations or improper handling / transport /
maintenance / installation. Physical damages are not covered by warranty. AquaMaxx does not cover
personal injury, personal loss, or other damages associated with the use of our products. In order to
request warranty service, please email us at [e-mail]. A purchase receipt is
required for any warranty service. Products requiring warranty service must be returned to AquaMaxx.
You are responsible for the cost of shipping a warranty claim to AquaMaxx and any damages that may
occur during transit. Once a returned product has been inspected, it will be repaired or exhanged at
our discretion and returned to you. International and / or expedited shipping are not covered under
your AquaMaxx warranty.
       
