AQUAMAXX ConeS RC-3 User manual

www.aquamaxxaquariums.com
[email protected]
www.aquamaxxaquariums.com
AquaMaxx ConeS
RC-3 In-Sump
Protein Skimmer
User’s Manual

1Questions? Email [email protected]
                   
Footprint
Height Pump Motor
Pump Power Consumption
Recommended Water Level
Outlet Size
Top Clearance Required
Gallon
Rating
Chamber Diameter
Light Bioload
Heavy Bioload
15.3” x 9.4”
8”
23.8” Shark 3.0
27 Watts
1 1/2”
8-10”
Approx. 1/2”
Up to 270
gallons
Up to 450
gallons
AquaMaxx ConeS RC-3 In-Sump Protein Skimmer
            
1. Shark 2000 DC Pump
2. Pump Venturi
3. Pump Bracket
4. Pump-Stabilizing Plate & Screw
5. Pump Connector Pipe
6. Airline Tubing
7. Air Silencer
8. Bubble Plate / Diuser
9. Skimmer Body
10. Skimmer Base & Body Screws
11. Outlet Pipe
12. Adjustment Valve
13. Collection Cup
14. Elbow Drain

2Questions? Email [email protected]
Installation Guide
    
Press-t the venturi into the pump.
    
Connect the water outlet of the needlewheel pump to the skimmer body using the yellow silicone
tube.
    
Install the air silencer. Attach the air silencer to the skimmer body by nger-tightening the plastic
thumbscrew in a clockwise motion.

    
Connect the air silencer to the pump air intake using the yellow silicone air line tubing.
    
Attach the drain elbow to the collection cup, using a zip tie to secure if desired.
3Questions? Email [email protected]
Installation Guide

    
4Questions? Email [email protected]
Installation Guide
                                             
Ensure the o-ring is securely in place on the skimmer body, then install the collection cup by
twisting it clockwise onto the skimmer body.
O-ring

5Questions? Email [email protected]
Operation Guide
                
                
                                                             
                                            
As a starting point, it is recommended to adjust the water level within the skimmer body to where
the collection cup meets the neck.
It may require 2-4 weeks for the skimmer to reach optimal performance due to tiny amounts of
oil or remnant leftover from the manufacturing process. The skimmer’s performance may be
erratic during this period; be sure to allow ample time for the skimmer to break in prior to making
any major adjustments.
The recommended water level range for this skimmer is 8-10 inches. For proper performance of
the Quick-Precise adjustment valve, the water in your sump must not be any higher than 10”.
Use the Quick-Precise adjustment valve to alter the water level within the skimmer body.
Turning the valve counter-
clockwise will open the outlet
pipe, lowering the water level
within the skimmer body.
Turning the valve clockwise will
close the outlet pipe, raising the
water level within the skimmer
body.
                    
                       
        
          

6Questions? Email [email protected]
Operation Guide
         
Regular maintenance of the pump will ensure a long life and maximum performance. You can
clean the pump and its components by soaking in a general citric acid solution once every 3
months.
The collection cup should be cleaned frequently with a sponge and warm water.
                                                             
                                                                 
AquaMaxx warrants all AquaMaxx products to be free from manufacturing defects for one year from
the original purchase date when purchased through an authorized AquaMaxx retailer. This warranty
does not cover any damages caused by misuse, neglect, alterations or improper handling / transport /
maintenance / installation. Physical damages are not covered by warranty. AquaMaxx does not cover
personal injury, personal loss, or other damages associated with the use of our products. In order to
request warranty service, please email us at [e-mail]. A purchase receipt is
required for any warranty service. Products requiring warranty service must be returned to AquaMaxx.
You are responsible for the cost of shipping a warranty claim to AquaMaxx and any damages that may
occur during transit. Once a returned product has been inspected, it will be repaired or exhanged at
our discretion and returned to you. International and / or expedited shipping are not covered under
your AquaMaxx warranty.
       
