Arbor Technology EmETXe-i87M2 User manual

Prelimanary
EmETXe-i87M2
Wide-temperature
COM Express®Basic
Type 6 CPU Module
User’s Manual
Version 1.0
2016.01
85

Prelimanary
Revision History
Version Date Description
1.0 2016/01 Initial release

- i -
Prelimanary
Preface iii
Copyright Notice................................................................iii
Declaration of Conformity ................................................iii
CE..........................................................................................iii
FCC Class A .........................................................................iii
RoHS.....................................................................................iv
SVHC / REACH.....................................................................iv
Warning ...............................................................................v
Replacing the Lithium Battery...........................................v
Technical Support ..............................................................v
Warranty .............................................................................vi
Chapter 1 - Introduction 1
1.1 The Product..................................................................2
1.2 About This Manual.......................................................2
1.3 Specifications ..............................................................3
1.4 Inside the Package ......................................................4
1.5 Ordering Information...................................................4
1.5.1 Optional Accessories.................................................5
1.6 The Installation Paths of CD Driver ...........................5
Chapter 2 - Board Overview 7
2.1 What Is “COM Express®”? ..........................................8
2.2 Board Dimensions.......................................................9
2.3 Block Diagram ...........................................................10
2.4 Connector Pin Denition ..........................................11
Chapter 3 - Installation & Maintenance 15
3.1 Installing the CPU Module on Carrier Board...........16
3.2 Installing the Heatsink ..............................................17
Chapter 4 - BIOS 19
4.1 Main ............................................................................20
4.2 Advanced....................................................................22
4.2.1 CPU Conguration ...................................................24
4.2.2 Trusted Computing...................................................25
Contents

- ii -
4.2.3 ACPI Settings............................................................25
4.2.4 AMT Conguration ...................................................25
4.2.5 Super IO Conguration............................................26
4.2.6 Hardware Monitor.....................................................27
4.2.7 S5 RTC Wake Settings .............................................28
4.2.8 SATA Conguration..................................................29
4.2.9 CSM Conguration...................................................30
4.2.10 USB Conguration .................................................31
4.2.11 Intel(R) Ethernet Connection I218-LM...................33
4.3 Chipset .......................................................................34
4.3.1 Display Control.........................................................35
4.3.2 Memory Conguration .............................................36
4.3.3 SB PCIe Conguration.............................................37
4.3.4 USB Conguration ...................................................38
4.3.5 HDAC Conguration.................................................39
4.3.6 LAN Conguration....................................................40
4.4 Boot ............................................................................41
4.5 Security ......................................................................42
4.6 Save & Exit .................................................................43
Appendix A: I/O Port Address Map ................................46
Appendix B: BIOS Memory Mapping .............................48
Appendix C: Interrupt Request Lines (IRQ) ..................49
Appendix D: Watchdog Timer (WDT) Setting................50
Content

- iii -
Prelimanary
Copyright Notice
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright.
All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Declaration of Conformity
CE
The CE symbol on your product indicates that it is in compliance with the
directives of the Union European (EU). A Certicate of Compliance is available
by contacting Technical Support.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of
shielded cables. This kind of cable is available from ARBOR. Please contact
your local supplier for ordering information.
This product has passed the CE test for environmental specications. Test
conditions for passing included the equipment being operated within an
industrial enclosure. In order to protect the product from being damaged by
ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the
use of CE-compliant industrial enclosure products.
Warning
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
Preface

- iv -
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference
that may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
RoHS
ARBOR Technology Corp. certies that all components in its products are in
compliance and conform to the European Union’s Restriction of Use of Haz-
ardous Substances in Electrical and Electronic Equipment (RoHS) Directive
2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main pur-
pose of the directive is to prohibit the use of lead, mercury, cadmium, hexava-
lent chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl
ethers (PBDE) in electrical and electronic products. Member states of the EU
are to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not contain
unintentional additions of lead, mercury, hex chrome, PBB or PBDB that ex-
ceed a maximum concentration value of 0.1% by weight or for cadmium exceed
0.01% by weight, per homogenous material. Homogenous material is dened
as a substance or mixture of substances with uniform composition (such as sol-
ders, resins, plating, etc.). Lead-free solder is used for all terminations (Sn(96-
96.5%), Ag(3.0-3.5%) and Cu(0.5%)).
SVHC / REACH
To minimize the environmental impact and take more responsibility to the
earth we live, Arbor hereby conrms all products comply with the restriction
of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH
--Registration, Evaluation, Authorization, and Restriction of Chemicals)
regulated by the European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)
Preface

- v -
Prelimanary
Warning
Single Board Computers and their components contain very delicate
Integrated Circuits (IC). To protect the Single Board Computer and its
components against damage from static electricity, you should always follow
the following precautions when handling it :
1. Disconnect your Single Board Computer from the power source when you
want to work on the inside.
2. Hold the board by the edges and try not to touch the IC chips, leads or cir-
cuitry.
3. Use a grounded wrist strap when handling computer components.
4. Place components on a grounded antistatic pad or on the bag that comes
with the Single Board Computer, whenever components are separated from
the system.
Replacing the Lithium Battery
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery type
recommended by the manufacturer.
Do not throw lithium batteries into the trash-can. It must be disposed of in
accordance with local regulations concerning special waste.
Technical Support
If you have any technical difculties, please consult the user’s manual rst
at: http://www.arbor.com.tw
Please do not hesitate to call or e-mail our customer service when you still can-
not nd out the answer.
http://www.arbor.com.tw
E-mail:[e-mail]
Preface

- vi -
Warranty
This product is warranted to be in good working order for a period of two years
from the date of purchase. Should this product fail to be in good working order
at any time during this period, we will, at our option, replace or repair it at no
additional charge except as set forth in the following terms. This warranty does
not apply to products damaged by misuse, modications, accident or disaster.
Vendor assumes no liability for any damages, lost prots, lost savings or any
other incidental or consequential damage resulting from the use, misuse of,
or inability to use this product. Vendor will not be liable for any claim made by
any other related party.
Vendors disclaim all other warranties, either expressed or implied, including
but not limited to implied warranties of merchantability and tness for a
particular purpose, with respect to the hardware, the accompanying product’s
manual(s) and written materials, and any accompanying hardware. This limited
warranty gives you specic legal rights.
Return authorization must be obtained from the vendor before returned
merchandise will be accepted. Authorization can be obtained by calling or
faxing the vendor and requesting a Return Merchandise Authorization (RMA)
number. Returned goods should always be accompanied by a clear problem
description.
Preface

- 1 -
Prelimanary
Introduction
1Chapter 1
Introduction

- 2 -
Prelimanary
Introduction
1.2 About This Manual
This user’s manual provides general information and installation instructions
about the product. This user’s manual is intended for experienced users and
integrators with hardware knowledge of personal computers. If you are not
sure about any description in this booklet. Please consult your vendor before
further handling.
1.1 The Product
The EmETXe-i87M2 Series is a space-conscious CPU board of 125 mm x 95
mm to take up only small footprint in your system. By the architecture of Type 6,
the board has two high-performance connectors to promise stable data passing
rate. The soldered onboard Intel®5th Generation Core™ processor, along with in-
tegrated Intel®HD Graphics Gen 7.5 graphics chipset, bring Analog RGB, LVDS
and DDI solution for most CRT monitors or LCD video panels.
For system conguration, the board is supported by AMI UEFI BIOS. EmETXe-
i87M2 Series is an ideal choice for some demanding industrial control and data
communications by its signicant processing performance, low power consump-
tion and these features:
• Soldered onboard 5th Generation Intel®Core™ Processor
• Integrated Gigabit Ethernet
• Dual channels 24-bit LVDS, Analog RGB, and 3 x DDI ports
• Supports 3 independent displays
• ECC Memory supported
• Extended Operating Temp.: -40 ~ 85°C

- 3 -
Prelimanary
Introduction
1.3 Specifications
System
CPU Soldered onboard 5th Generation Intel®Core™ i7-5700EQ 2.0GHz
Memory 2 x DDR3L ECC SO-DIMM sockets, supporting 1600MHz up to
16GB SDRAM
Chipset Intel®PCH QM87
BIOS AMI®UEFI BIOS
Watchdog Timer 1~255 levels reset
I/O
USB Port
12 x USB ports:
- 8 x USB 2.0 ports
- 4 x USB 3.0 ports
Storage
4 x Serial ATA ports:
- 2 ports with 600MB/s HDD transfer rate
- 2 ports with 300MB/s HDD transfer rate
SATA RAID 0, 1, 5, 10 supported
Expansion Bus 1 x PCIe x16 Gen3 lanes
7 x PCIe x1 Gen2 lanes
Ethernet Chipset 1 x Intel®i218LM GbE PHY
Audio HD Audio link
Display
Graphics Chipset Integrated Intel®HD Gen 7.5
Graphics Interface
Analog RGB supports up to 1920x1200@60Hz
LCD: Dual Channels 24-bit LVDS up to 1920 x 1200
@60Hz (OEM request)
3 x DDI ports
Mechanical & Environmental
Power Requirement +12V, 5VSB
Power Consumption 1.13A@12V, 0.31A@5V, [email protected] with i7-5700EQ (Typical)
Operating Temp. -40 ~ 85°C (-40 ~ 185°F)
Operating Humidity 0% ~ 95% @ 60ºC (non-condensing)
Dimension (L x W) 125 x 95 mm (4.9” x 3.7”)

- 4 -
Prelimanary
Introduction
1.4 Inside the Package
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x EmETXe-i87M2 COM Express CPU Module
1 x Driver CD
1 x Quick Installation Guide
If any of the above items is damaged or missing, contact your vendor
immediately.
1.5 Ordering Information
EmETXe-i87M2-5700EQ 5th Generation Intel®Core i7-5700EQ 2.0GHz/QM87
WT COM Express®CPU module

- 5 -
Prelimanary
Introduction
1.5.1 Optional Accessories
HS-87M2-C1 Cooler (125x95x40mm)
PBE-1702 COM Express® Type 6 evaluation carrier board (ATX form factor)
CBK-04-1702-00
Cable Kit
1 x SATA cable
2 x COM-port cables
1 x USB cable
1.6 The Installation Paths of CD Driver
Windows 7
Driver Path
Chipset \EmETXe-i87M2\Chipset\Chipset_10.1.1.7
Graphic
32bit: \EmETXe-i87M2\Graphic\32bit\Intel® Graphics Driver
Production Version 15.40.8.4281
64bit: \EmETXe-i87M2\Graphic\64bit\Intel® Graphics Driver
Production Version 15.40.8.64.4281
Audio 32bit: \EmETXe-i87M2\Audio\32bit
64bit: \EmETXe-i87M2\Audio\64bit
Ethernet \EmETXe-i87M2\Ethernet\20_0_CD
ME \EmETXe-i87M2\ME\ME9.0_5M_V9.0.13.1402
USB 3.0 \EmETXe-i87M2\USB3.0\Intel_USB_3.0_Driver_3.0.5.69
The CPU module supports Windows 7 and 8.1 Find the necessary drivers on
the CD that comes with your purchase. For different OS, the driver installation
may vary slightly, but generally they are similar. Find the drivers on CD by the
following paths:

- 6 -
Board Overview
Prelimanary
Windows 8.1
Driver Path
Chipset \EmETXe-i87M2\Chipset\Chipset_10.1.1.7
Graphic
32bit: \EmETXe-i87M2\Graphic\32bit\Intel® Graphics Driver Production
Version 15.40.8.4281
64bit: \EmETXe-i87M2\Graphic\64bit\Intel® Graphics Driver Production
Version 15.40.8.64.4281
Audio 32bit: \EmETXe-i87M2\Audio\32bit
64bit: \EmETXe-i87M2\Audio\64bit
Ethernet \EmETXe-i87M2\Ethernet\20_0_CD
ME \EmETXe-i87M2\ME\ME9.0_5M_V9.0.13.1402

- 7 -
Board Overview
2Chapter 2
Board Overview

- 8 -
Board Overview
Prelimanary
2.1 What Is “COM Express®”?
With more and more demands on small and embedded industrial boards, a
multi-functional COM (Computer-on-Module) surfaces as a great solution.
COM Express®supports seven pin-out types applying to Basic and Extended
form factors:
Module Type 1 and 10 support single connector with two rows (220 pins).
Module Type 2, 3, 4, 5 and 6 support two connectors with four rows (440 pins).
EmETXe-i87M2 Series is a Type-6 module.
Difference between Standard Type 6 and EmETXe-i87M2 Series is listed
as below:
Module Type Standard Type 6 EmETXe-i87M2 Series
Connectors 2 2
Connector Rows A, B, C, D A, B, C, D
PCIe Lanes (Max) 24 23
LAN (Max) 1 1
Serial Ports (Max) 2 0
Digital Display I/F
(Max) 3 3
USB 3.0 Ports (Max) 4 4
Row AB provides pins for PCI Express, SATA, LVDS, LCD channel, LPC
bus, system and power management, VGA, LAN, and power and ground
interfaces.
Row CD provides SDVO and legacy PCI and IDE signals next to additional
PCI Express, LAN and power and ground signals. The COM are targeted at
following applications:
• Retail & Advertising
• Medical
• Test & Measurement
• Gaming & Entertainment
• Industrial & Automation
• Military & Government
• Security

- 9 -
Board Overview
2.2 Board Dimensions
The following illustration shows the dimension of EmETXe-i87M2 Series, with
the measurements in width, depth, and height called out.
2
6
12
45.35
9.2
Ø2.6*Ø6.5
44176
4
48.46
87
95
125
55.68
30.88
71.12
430
70.64
79.53
COM Express CD Connector
COM Express AB Connector
Unit: mm

- 10 -
Board Overview
Prelimanary
2.3 Block Diagram
4 x USB 3.0
DDI1
(eDP)
DDI2 (DVI)
6 x PCIex1
LPC I/F
1 x PCIex16 (Gen3)
Dual Chnnels
24-bit LVDS
NXP
PTN3460
eDP to LVDS
transmitter
DDR3L W/ ECC-1600MT/s 2 x ECC SO-DIMM
DDR3L sockets
8 GPIO
SPI Bus
SPI Bus
SMBus
1 x PCIex1 GbE
Intel I218LM
GbE PHY
Analog RBG
8 x USB 2.0 Ports
SATA0, 1(6Gb/s) / 2,3(3Gb/s)
HD Audio Link
Connector CD
Connector AB
DMI2
(x4)
FDI
SPI BIOS
SMBus Fintek
F75111
Soldered
onboard
5th Gen Intel®
Core
Processor
(Broadwell-H)
DDI3 (DP)
DDI1 (DP)
(Alternative, Default)
(OEM request)
Intel®
QM87
Lynx Point
PCH
ATMEL
AT97SC3204
TPM

- 11 -
Board Overview
2.4 Connector Pin Denition
2
1
4445
BEBD AB
BFBE
1
203 204
72
74
71
73
12
203
204
72
74
71
73
12
98 7 6 5 432 1
1011121314
P
N
M
L
K
J
H
G
F
E
D
C
B
A
COM Express CD Connector
SO-DIMM Socket
COM Express AB Connector
2
1
4445
BEBD AB
BFBE
1
203 204
72
74
71
73
12
203
204
72
74
71
73
12
98 7 6 5 432 1
1011121314
P
N
M
L
K
J
H
G
F
E
D
C
B
A
COM Express CD Connector
SO-DIMM Socket
COM Express AB Connector
Top Side
Bottom Side
Being a most commonly-used Type 6, the EmETXe-i87M2 Series features two
board-to-board connectors on bottom side.

- 12 -
Board Overview
Prelimanary
COM Express AB Connector (bottom side)
B1 GND (FIXED)
B2 GBE0_ACT#
B3 LPC_FRAME#
B4 LPC_AD0
B5 LPC_AD1
B6 LPC_AD2
B7 LPC_AD3
B8 LPC_DRQ0#
B9 LPC_DRQ1#
B10 LPC_CLK
B11 GND (FIXED)
B12 PWRBTN#
B13 SMB_CK
B14 SMB_DAT
B15 SMB_ALERT#
B16 SATA1_TX+
B17 SATA1_TX-
B18 SUS_STAT#
B19 SATA1_RX+
B20 SATA1_RX-
B21 GND (FIXED)
B22 SATA3_TX+
B23 SATA3_TX-
B24 PWR_OK
B25 SATA3_RX+
B26 SATA3_RX-
B27 WDT
B28 AC_SDIN2
B29 AC_SDIN1
B30 AC_SDIN0
B31 GND
B32 SPKR
B33 I2C_CK
B34 I2C_DAT
B35 THRM#
B36 USB7-
B37 USB7+
B38 USB_4_5_OC#
B39 USB5-
B40 USB5+
B41 GND
B42 USB3-
B43 USB3+
B44 USB_0_1_OC#
B45 USB1-
B46 USB1+
B47 EXCD1_PERST#
B48 EXCD1_CPPE#
B49 SYS_RESET#
B50 CB_RESET#
B51 GND
B52 PCIE_RX5+
B53 PCIE_RX5-
B54 GPO1
B55 PCIE_RX4+
GND (FIXED) A1
GBE0_MDI3- A2
GBE0_MDI3+ A3
GBE0_LINK100# A4
GBE0_LINK1000# A5
GBE0_MDI2- A6
GBE0_MDI2+ A7
N/C A8
GBE0_MDI1- A9
GBE0_MDI1+ A10
GND (FIXED) A11
GBE0_MDI0- A12
GBE0_MDI0+ A13
GBE0_CTREF A14
SUS_S3# A15
SATA0_TX+ A16
SATA0_TX- A17
SUS_S4# A18
SATA0_RX+ A19
SATA0_RX- A20
GND (FIXED) A21
SATA2_TX+ A22
SATA2_TX- A23
SUS_S5# A24
SATA2_RX+ A25
SATA2_RX- A26
BATLOW# A27
ATA_ACT# A28
AC_SYNC A29
AC_RST# A30
GND A31
AC_BITCLK A32
AC_SDOUT A33
BIOS_DISABLE0# A34
THRMTRIP# A35
USB6- A36
USB6+ A37
USB_6_7_OC# A38
USB4- A39
USB4+ A40
GND A41
USB2- A42
USB2+ A43
USB_2_3_OC# A44
USB0- A45
USB0+ A46
VCC_RTC A47
EXCD0_PERST# A48
EXCD0_CPPE# A49
LPC_SERIRQ A50
GND A51
PCIE_TX5+ A52
PCIE_TX5- A53
GPI0 A54
PCIE_TX4+ A55
B56 PCIE_RX4-
B57 GPO2
B58 PCIE_RX3+
B59 PCIE_RX3-
B60 GND
B61 PCIE_RX2+
B62 PCIE_RX2-
B63 GPO3
B64 PCIE_RX1+
B65 PCIE_RX1-
B66 WAKE0#
B67 WAKE1#
B68 PCIE_RX0+
B69 PCIE_RX0-
B70 GND
B71 LVDS_B0+
B72 LVDS_B0-
B73 LVDS_B1+
B74 LVDS_B1-
B75 LVDS_B2+
B76 LVDS_B2-
B77 LVDS_B3+
B78 LVDS_B3-
B79 LVDS_BKLT_EN
B80 GND
B81 LVDS_B_CK+
B82 LVDS_B_CK-
B83
CKLVDS_BKLT_CTRL
B84 VCC_5V_SBY
B85 VCC_5V_SBY
B86 VCC_5V_SBY
B87 VCC_5V_SBY
B88 BIOS_DIS1#
B89 VGA_RED
B90 GND
B91 VGA_GRN
B92 VGA_BLU
B93 VGA_HSYNC
B94 VGA_VSYNC
B95 VGA_I2C_CK
B96 VGA_I2C_DAT
B97 SPI_CS#
B98 RSV2
B99 RSV1
B100 GND
B101 FAN_PWMOUT
B102 FAN_TACHIN
B103 SLEEP#
B104 VCC_12V
B105 VCC_12V
B106 VCC_12V
B107 VCC_12V
B108 VCC_12V
B109 VCC_12V
B110 GND
PCIE_TX4- A56
GND A57
PCIE_TX3+ A58
PCIE_TX3- A59
GND A60
PCIE_TX2+ A61
PCIE_TX2- A62
GPI1 A63
PCIE_TX1+ A64
PCIE_TX1- A65
GND A66
GPI2 A67
PCIE_TX0+ A68
PCIE_TX0- A69
GND A70
LVDS_A0+ A71
LVDS_A0- A72
LVDS_A1+ A73
LVDS_A1- A74
LVDS_A2+ A75
LVDS_A2- A76
LVDS_VDD_EN A77
LVDS_A3+ A78
LVDS_A3- A79
GND A80
LVDS_A_CK+ A81
LVDS_A_CK- A82
LVDS_I2C_CK A83
LVDS_I2C_DAT A84
GPI3 A85
RSV4 A86
RSV3 A87
PCIE0_CK_REF+ A88
PCIE0_CK_REF- A89
GND A90
SPI_POWER A91
SPI_MISO A92
GPO0 A93
SPI_CLK A94
SPI_MOSI A95
TPM_PP A96
TYPE10# A97
(N/C)SERR0_TX A98
(N/C)SERR0_RX A99
GND A100
(N/C)SERR1_TX A101
(N/C)SERR1_RX A102
LID# A103
VCC_12V A104
VCC_12V A105
VCC_12V A106
VCC_12V A107
VCC_12V A108
VCC_12V A109
GND A110
