Arbor Technology EmNANO-i2300 User manual

1
EmNANO-i2300
User’s Manual
Version 1.2
COM Express®Mini Type 10
CPU Module
2017.04

- 2 -
This page is intentionally left blank.

- i -
Revision History
Version Release Time Description
1.0 August, 2014 Initial release
1.1 December, 2016 Updated the following sectons to the latest
spec:
• 1.3. Specifications
• 1.5. Ordering Information
• 2.2. Block Diagram
• 2.4 COM Express® Mini Type 10 AB Connector
• 2.6. Driver Installation Notes
• Chapter 3 - BIOS
1.2 April, 2017 8 x USB2.0ports(Port0~2 support USB2.0
only)

- ii -
This page is intentionally left blank.

- iii -
Contents
Table of Contents
Revision History .................................................................................i
Table of Contents .............................................................................iii
Preface................................................................................................v
Copyright Notice ..................................................................................... v
Declaration of Conformity ....................................................................... v
CE.................................................................................................... v
FCC Class A ................................................................................... vi
RoHS .............................................................................................. vi
SVHC / REACH ..............................................................................vii
Warning..................................................................................................vii
Replacing Lithium Battery ......................................................................vii
Technical Support ..................................................................................vii
Warranty................................................................................................viii
Chapter 1 - Introduction....................................................................1
1.1. The Product .....................................................................................2
1.2. About this Manual ............................................................................2
1.3.Specications...................................................................................3
1.4. Inside the Package ..........................................................................4
1.5. Ordering Information ........................................................................4
Chapter 2 - Getting Started...............................................................5
2.1. The Ultra-small COM Express®Mini Module ...................................6
2.2. Block Diagram..................................................................................7
2.3 Board Dimensions.............................................................................8
2.4 COM Express®Mini Type 10 AB Connector......................................9
2.5 Connectors Quick Reference.......................................................... 11
2.6. Driver Installation Notes.................................................................12
Chapter 3 - BIOS..............................................................................13
3.1. Main ............................................................................................... 15
3.2. Advanced .......................................................................................16
3.2.1.BootConguration ...............................................................17
3.2.2.PCIExpressConguration ..................................................17
3.2.3.USBConguration ...............................................................18
3.2.4.AudioConguration .............................................................18
3.2.5.LPSS&SCCConguration .................................................19
3.2.6.VideoConguration .............................................................20
3.2.7.SATAConguration..............................................................21
3.2.8. ACPI Table/Feature Control .................................................21
3.2.9. LM90 Thermal Sensor .........................................................22
3.2.10. SIO FINTEK71869E .........................................................22

- iv -
Contents
3.2.11. XR28V382 UART............................................................... 23
3.3. Security .......................................................................................... 24
3.4. Power.............................................................................................25
3.4.1 Advanced CPU Control......................................................... 26
3.5. Boot................................................................................................28
3.6. Exit .................................................................................................30

- v -
Preface
Preface
Copyright Notice
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright. All rights
are reserved. No part of this manual may be reproduced by any mechanical,
electronic, or other means in any form without prior written permission of the
manufacturer.
Declaration of Conformity
CE
The CE symbol on your product indicates that it is in compliance with the
directivesoftheUnionEuropean(EU).ACerticateofComplianceisavailable
by contacting Technical Support.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of shielded
cables. This kind of cable is available from ARBOR. Please contact your local
supplier for ordering information.
This product has passed the CE test for environmental specications. Test
conditions for passing included the equipment being operated within an
industrial enclosure. In order to protect the product from being damaged by ESD
(Electrostatic Discharge) and EMI leakage, we strongly recommend the use of
CE-compliant industrial enclosure products.
Warning
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.

- vi -
Preface
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the
interference at his own expense.
RoHS
ARBOR Technology Corp. certies that all components in its products are
in compliance and conform to the European Union’s Restriction of Use of
Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive
2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main purpose
of the directive is to prohibit the use of lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl
ethers (PBDE) in electrical and electronic products. Member states of the EU
are to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not contain
unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed
a maximum concentration value of 0.1% by weight or for cadmium exceed
0.01%byweight,perhomogenousmaterial.Homogenousmaterialisdenedas
a substance or mixture of substances with uniform composition (such as solders,
resins, plating, etc.). Lead-free solder is used for all terminations (Sn(96-96.5%),
Ag(3.0-3.5%) and Cu(0.5%)).

- vii -
Preface
SVHC / REACH
To minimize the environmental impact and take more responsibility to the earth
welive,ArborherebyconrmsallproductscomplywiththerestrictionofSVHC
(Substances of Very High Concern) in (EC) 1907/2006 (REACH --Registration,
Evaluation, Authorization, and Restriction of Chemicals) regulated by the
European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)
Warning
Single Board Computers and their components contain very delicate
Integrated Circuits (IC). To protect the Single Board Computer and its
components against damage from static electricity, you should always follow the
following precautions when handling it :
1. Disconnect your Single Board Computer from the power source when you
want to work on the inside.
2. Hold the board by the edges and try not to touch the IC chips, leads or
circuitry.
3. Use a grounded wrist strap when handling computer components.
4. Place components on a grounded antistatic pad or on the bag that comes
with the Single Board Computer, whenever components are separated from
the system.
Replacing Lithium Battery
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery type
recommended by the manufacturer.
Do not throw lithium batteries into the trash-can. It must be disposed of in
accordance with local regulations concerning special waste.
Technical Support
Ifyouhaveanytechnicaldifculties,pleasedonothesitatetocallore-mailour
customer service.
http://www.arbor-technology.com
E-mail:[e-mail]

- viii -
Preface
Warranty
This product is warranted to be in good working order for a period of two years
from the date of purchase. Should this product fail to be in good working order
at any time during this period, we will, at our option, replace or repair it at no
additional charge except as set forth in the following terms. This warranty does
notapplytoproductsdamagedbymisuse,modications,accidentordisaster.
Vendorassumes noliability for anydamages, lost prots,lost savings orany
other incidental or consequential damage resulting from the use, misuse of, or
inability to use this product. Vendor will not be liable for any claim made by any
other related party.
Vendors disclaim all other warranties, either expressed or implied, including but
notlimitedtoimpliedwarrantiesofmerchantabilityandtnessfora
particular purpose, with respect to the hardware, the accompanying product’s
manual(s) and written materials, and any accompanying hardware. This limited
warrantygivesyouspeciclegalrights.
Return authorization must be obtained from the vendor before returned
merchandise will be accepted. Authorization can be obtained by calling or
faxing the vendor and requesting a Return Merchandise Authorization (RMA)
number. Returned goods should always be accompanied by a clear problem
description.

- 1 -
1Chapter 1
Introduction
Chapter 1 - Introduction

- 2 -
Introduction
1.1. The Product
• Soldered onboard Intel®Atom E3800 series SoC processor
• Integrated Gigabit Ethernet
• 1 x DDI port, 1 x LVDS port
• 1 x USB 3.0 port, 8 x USB 2.0 ports, 2 x Serial port
• Support Dual Independent Displays
• Extended Operating Temp.: -20 ~ 70°C
1.2. About this Manual
This manual is intended for experienced users and integrators with hardware
knowledge of computers. If you are not sure about the description in this manual,
consult your vendor before further handling.
We recommend that you keep one copy of this manual for the quick reference
for any necessary maintenance in the future. Thank you for choosing ARBOR
products.

- 3 -
Introduction
1.3.Specications
Form Factor COM Express®Mini Type 10 CPU Module
CPU Soldered onboard Intel®Atom E3825 1.33GHz or E3845 1.91GHz
processor
Memory Soldered onboard 2GB DDR3L SDRAM
BIOS Insyde UEFI BIOS
Serial Port 2 x serial ports (RX/TX only, via LPC to UART EXAR XR28V382
USB Port*
1 x USB 3.0 port
8 x USB 2.0 ports(Port0~2 support USB2.0 only)
Expansion Interface
3 x PCIe x1 Gen2 lanes
SPI, and LPC (Low Pin Count) interface
Storage 2 x Serial ATA ports with 300MB/s HDD transfer rate
Ethernet Chipset 1 x Intel®i210IT GbE controller
Audio Interface HD audio link
VGA/LCD controller
Integrated Intel®Gen 7 Graphics
1 x Single Channel 24-bit LVDS port
1 x DDI port
I2C I2C Supported
Power Requirement
+5VSB, +12V
Power Input 12V/ 5V auto detect
Power Consumption 1.05A@+12V with E3825 (Typical, with PBN-9007)
Operating Temp. -20ºC ~ 70ºC (-4ºF ~ 158ºF)
Humidity 0 ~ 90%(non-condensing)
Dimension (L x W) 84 x 55 mm (3.30" x 2.16")

- 4 -
Introduction
1.4. Inside the Package
Before starting to install the single board, make sure the following items are
shipped:
1 x EmNANO-i2300 COM Express®Mini CPU Module
1 x Driver CD
1 x Quick Installation Guide
If any of the aforelisted items is damaged or missing, contact your vendor
immediately.
1.5. Ordering Information
EmNANO-i2300-E3825-2G-2S Intel®Atom™ E3825 COM Express Type 10 CPU module with
2G memory soldered on CPU module, 2 UART
EmNANO-i2300-E3845-2G-2S Intel®Atom™ E3845 COM Express Type 10 CPU module with
2G memory soldered on CPU module, 2 UART
HS-0660-F2-T Heat spreader with threaded standoffs 84x55x11mm
HS-0660-F2-NT Heat spreader without threaded standoffs 84x55x11mm
PBN-9007 COM Express®Mini evaluation carrier board (EPIC form factor)
CBK-05-9007-00
Cable Kit
1 x USB cable
1 x Serial port cable
1 x SATA cable
1 x SATA power cable
1 x PS/2 cable

- 5 -
2Chapter 2
Getting
Started
Chapter 2 - Getting Started

- 6 -
Getting Started
2.1. The Ultra-small COM Express®Mini Module
EmNANO-i2300 is a COM Express®Mini Type 10 module. 55 mm x 84 mm is
the smallest in ARBOR’s COM Express®product lineup, next to the Basic size
(125 mm x 95 mm) and Compact size (95mm x 95mm) form factors.
The connector difference between Standard COM Express Mini type 10 and
EmNANO-i2300 is tabulated as below:
Module Type Type 10 EmNANO-i2300
Connectors 1 1
Connector Rows A, B A, B
PCIe Lanes (max) 4 3
LAN (Max) 1 1
Serial Ports (Max) 2 1
DDI0 (Max) 1 1
LVDS Channel A 1 1
USB 2.0 Ports (Max) 8 8
USB 3.0 Ports (Max) 2 1

- 7 -
Getting Started
2.2. Block Diagram
DDR3L 1066 / 1333MHz (up to 4GB) Onboard DDR3L
2GB SDRAM
5 x USB 2.0 Ports（Support USB1.1/2.0）
1 x USB2.0 USB Hub
GL854G-MSGAA
SPI I/F BIOS ROM
SPI 8MB
1 x DDI port
3 x PCIe x 1
LPC I/F
I2C
HD Audio
3 x USB 2.0 Ports(Support USB2.0 only)
1 x USB 3.0 Port
SATA0, 1
SER0
1 x PCIe x 1 GbE LAN
Giga LAN
Intel i210
1 x LVDS Single Channel 24-bit
Connector AB
Intel®
Atom
Bay
Trail-I
E3825
1.33GHz/
E3845
1.91GHz
1 x eDP NXP
PTN3460

- 8 -
Getting Started
2.3 Board Dimensions
E C A
1
1
14
47.00
4.00
76.00
2.00
Ø2.7
29.21
44.00
84.00
55.00
4.00
Unit:mm

- 9 -
Introduction
2.4 Connector Pin Assignment
Note: A pin with a remark “(N/C)“ is a pin that the signal isn’t available on this board while the
 remarkbeyondthebracketdeliverstheconsortium-specieddenition.
B1 GND GND A1
B2 GBE0_ACT# GBE0_MDI3- A2
B3 LPC_FRAME# GBE0_MDI3+ A3
B4 LPC_AD0 GBE0_LINK100# A4
B5 LPC_AD1 GBE0_LINK1000# A5
B6 LPC_AD2 GBE0_MDI2- A6
B7 LPC_AD3 GBE0_MDI2+ A7
B8 LPC_DRQ0#(N/C)
GBE0_LINK# (N/C)
A8
B9
LPC_DRQ1# (N/C) GBE0_MDI1- A9
B10 LPC_CLK GBE0_MDI1+ A10
B11 GND GND A11
B12 PWRBTN# GBE0_MDI0- A12
B13 SMB_CK GBE0_MDI0+ A13
B14 SMB_DAT
GBE0_CTREF (N/C)
A14
B15 SMB_ALRERT# SUS_S3# A15
B16 SATA1_TX+ SATA0_TX+ A16
B17 SATA1_TX- SATA0_TX- A17
B18 SUS_STAT# SUS_S4# A18
B19 SATA1_RX+ SATA0_RX+ A19
B20 SATA1_RX- SATA0_RX- A20
B21 GND GND A21
B22 USB_SSTX0- USB_SSRX0- A22
B23 USB_SSTX0+ USB_SSRX0+ A23
B24 PWR_OK SUS_S5# A24
B25
USB_SSTX1- (N/C) USB_SSRX1- (N/C)
A25
B26
USB_SSTX1+ (N/C) USB_SSRX1+ (N/C)
A26
B27 WDT (N/C) BATLOW# A27
B28 AC_SDIN2 (N/C) ATA_ACT# A28
B29 AC_SDIN1 AC_SYNC A29
B30 AC_SDIN0 AC_RST# A30
B31 GND GND A31
B32 SPKR AC_BITCLK A32
B33 I2C_CK AC_SDOUT A33
B34 I2C_DAT BIOS_DIS0# A34
B35 THRM# THRMTRIP# A35
B36 USB7- USB6- A36
B37 USB7+ USB6+ A37
B38 USB_4_5_OC# (N/C) USB_6_7_OC# (N/C) A38
B39 USB5- USB4- A39
B40 USB5+ USB4+ A40
B41 GND GND A41
B42 USB3- USB2- A42
B43 USB3+ USB2+ A43
B44 USB_0_1_OC# (N/C) USB_2_3_OC# (N/C) A44
B45 USB1- USB0- A45
B46 USB1+ USB0+ A46
B47 EXCD1_PERST# VCC_RTC A47
B48 EXCD1_CPPE# EXCD0_PERST# A48
B49 SYS_RESET# EXCD0_CPPE# A49
B50 CB_RESET# LPC_SERIRQ A50
B51 GND GND A51
B52 RSVD (N/C) RSVD (N/C) A52
B53 RSVD (N/C) RSVD (N/C) A53
B54 SD_CMD (N/C) SD_DATA0 (N/C) A54
B55 RSVD (N/C) RSVD
(N/C)
A55

- 10 -
Introduction
B56 RSVD (N/C) RSVD
(N/C)
A56
B57 SD_WP (N/C) GND A57
B58 PCIE_RX3+ (N/C) PCIE_TX3+ (N/C) A58
B59 PCIE_RX3- (N/C) PCIE_TX3- (N/C) A59
B60 GND GND A60
B61 PCIE_RX2+ PCIE_TX2+ A61
B62 PCIE_RX2- PCIE_TX2- A62
B63 SD_CD# (N/C) SD_DATA1 (N/C) A63
B64 PCIE_RX1+ PCIE_TX1+ A64
B65 PCIE_RX1- PCIE_TX1- A65
B66 WAKE0# GND A66
B67 WAKE1# SD_DATA2 (N/C) A67
B68 PCIE_RX0+ PCIE_TX0+ A68
B69 PCIE_RX0- PCIE_TX0- A69
B70 GND GND A70
B71 DDI0_PAIR0+
LVDS_A0+ / eDP_TX2+
A71
B72 DDI0_PAIR0-
LVDS_A0- / eDP_TX2-
A72
B73 DDI0_PAIR1+
LVDS_A1+ / eDP_TX1+
A73
B74 DDI0_PAIR1-
LVDS_A1- / eDP_TX1-
A74
B75 DDI0_PAIR2+
LVDS_A2+ / eDP_TX0+
A75
B76 DDI0_PAIR2-
LVDS_A2- / eDP_TX0-
A76
B77
DDI0_PAIR4+ (N/C) LVDS_VDD_EN / eDP_VCC_EN
A77
B78
DDI0_PAIR4- (N/C) LVDS_A3+ A78
B79
LVDS_BKLT_EN/ eDP_BKLT_EN LVDS_A3- A79
B80 GND GND A80
B81 DDI0_PAIR3+
LVDS_A_CK+ / eDP_TX3+
A81
B82 DDI0_PAIR3-
LVDS_A_CK- / eDP_TX3-
A82
B83
CKLVDS_BKLT_CTRL / DP_BKLT_CTRL LVDS_I2C _CK / eDP_AUX+
A83
B84 VCC_5V_SBY
LVDS_I2C_DAT / eDP_AUX-
A84
B85 VCC_5V_SBY SD_DATA3 (N/C) A85
B86 VCC_5V_SBY RSVD (N/C) A86
B87 VCC_5V_SBY
RSVD / eDP_HPD(NC)
A87
B88 BIOS_DIS1# PCIE0_CK_REF+ A88
B89 DDI0_HPD PCIE0_CK_REF- A89
B90 GND GND A90
B91
DDIO_PAIR5+ (N/C) SPI_POWER A91
B92
DDIO_PAIR5- (N/C) SPI_MSIO A92
B93
DDIO_PAIR6+ (N/C) SD_CLK (N/C) A93
B94
DDIO_PAIR6- (N/C) SPI_CKL A94
B95
DDI0_DDC_AUX_SEL SPI_MOSI A95
B96
USB_HOST_PRSNT (N/C) TPM_PP (N/C) A96
B97 SPI_CS# TYPE10# A97
B98
DDI0_CTRLCLK_AUX+ SER0_TX A98
B99
DDI0_CTRLCLK_AUX- SER0_RX A99
B100 GND GND A100
B101 FAN_PWMOUT(N/C) SER1_TX A101
B102 FAN_TACHIN(N/C) SER1_RX A102
B103 SLEEP# LID# A103
B104 VCC_12V VCC_12V A104
B105 VCC_12V VCC_12V A105
B106 VCC_12V VCC_12V A106
B107 VCC_12V VCC_12V A107
B108 VCC_12V VCC_12V A108
B109 VCC_12V VCC_12V A109
B110 GND GND A110
