Arbor Technology PBE-1702 User manual

- 1 -
4041170200120P
Quick Installation Guide
Version 1.2
PBE-1702
COM Express Type 6 Evaluation Board
Form Factor
COM Express
Evaluation Board
I/O
PCI Express x16/x1/x4,
SATA, USB, COM, LPT,
Mini-card
Video
Dual Channels LVDS,
Analog RGB , DVI,
Display Port
Ethernet
RJ-45 LAN Connector
If you have any technical difculties, please consult the user’s manual rst at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
nd out the answer.
http://www.arbor.com.tw
E-mail: [e-mail]
♦ Technical Support
Copyright® All Rights Reserved.
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Audio
ALC888 CODEC,
Line-in/ out, Mic-in,
7.1 + 2 Channel

- 2 -
Packing List
Before you begin installing your single board, please make sure that the following
materials have been shipped:
1 x PBE-1702 COM Express evaluation board
1 x Quick Installation Guide
COM Express Module Type Summary Features
COM Express supports seven pin-out Type apply to Basic and Extended form factors:
Module Type 1 and 10 supports single connector with two rows of pins (220 pins)
Module Type 2, 3, 4, 5 and 6 support two connectors with four rows of pins (440 pins)
Connector placement and most mounting holes have transparency between Form
Factors.
The differences amount the Module Types are summarized in table below:
Module Type 1 10 2 345 6
Connectors 1 1 2 2 2 2 2
Connector Rows A, B A, B A, B,
C, D
A, B,
C, D
A, B,
C, D
A, B,
C, D
A, B,
C, D
PCIe Lanes (max) 6 4 22 22 32 32 24
PCI Bus No No Yes Yes No No No
PATA - IDE No No Yes No Yes No No
LAN (Max) 1113131
Serial Ports No 0 / 2 No No No No 0 / 2
Muxed SDVO No No 0 / 2 0 / 2 0 / 2 0 / 2 No
Digital Display I/F No No No No No No 0 / 3
USB 3.0 Ports No No No No No No 0 / 4

- 3 -
Ordering Information
PBE-1702 COM Express evaluation board in ATX form factor
Cable Kit CBK-04-1702-00
Specications
Form Factor COM Express evaluation board in ATX form factor
I/O Chips Fintek F71869ED
Audio ALC888 CODEC, Line-in/out, Mic-in, 7.1 + 2 Channel
Serial ATA 4 x Serial ATA connectors
(depending on CPU module)
Serial Port 2 x COM ports
2 x Ultra COM ports (depending on CPU module)
Parallel Port 1 x SPP/EPP/ECP mode
KBMS Standard PS/2 keyboard and mouse
Universal Serial Bus 2 x USB 2.0 ports
4 x USB 3.0 ports (depending on CPU module)
LCD 1 x LVDS Dual Channel connector
VGA / Display Port Analog RGB connector / DisplayPort connector / DVI
connector
DIO 8-bit Digital Input/Output
Expansion Interface
1 x PCI Express x16 slot
2 x PCI Express x1 slots
1 x PCI Express x4 slot
2 x Mini-card sockets
All these expansion interfaces’ functions are depen-
dent upon CPU module.
Hardware Monitor Chip Integrated in F71869ED
Operation Temp. -20ºC~70ºC (-4ºF~158ºF)
Power Connector ATX connector
Dimension (L x W) 305 x 243 mm (12” x 9.6”)

- 4 -
Board dimensions
12
41
116.6
73
95
142.47
B110 A110
B1
A1
D110 C110
D1 C1
1
1
11
1 2 34
ON
ON
21
1
3
2
4
24
12
13
1
1
15
16
26
2
3
4
52
51
16
18
15 17
2
1
52
51
16 18
15 17
2
1
6
5
2
1
29
302
1
1
1
1
1
1
1
1
1
1
20
19
2
1 4
5
8
10
9
2 1
1
1
1
305
Unit: mm
243

- 5 -
Jumpers/ Connectors Quick Reference
Jumpers
Label Description
JPWOK1 Carrier Board Power OK Selection
J5VSB1 CPU Midule 5VSB Power Selection
JPSON1 Force ATX Power Supply Power On
JTPM1
Select TPM Module Special Command
JBL2 LVDS1 Brightness Control Level and Mode Selection
JBL1 LVDS1 Brightness Control Source Selection
JWDT1 Watch Dog Source Selection
JINV1 LVDS1 Inverter Power Selection
JVLCD1 LVDS Panel Voltage Selection
JBLON1 LCD Backlight On Control Mode
SW1 BIOS boot selection
JBAT1 Clear CMOS
JAUDIO1 Audio Codec I/O Power Selection

- 6 -
Connectors
Label Function
COM1~2 RS-232 Serial Ports
LPT1 Parallel Port Connector
TPM1 Trusted Platform Module Connector
DIO1 Digital I/O Connector
ATX1 ATX Power Connector
ATX12V1 ATX +12V Connector
CPUF1 CPU Fan Power Connector
SATA1~4 Serial ATA Connectors
DP1~2 Display Port Connector
INV1 LCD Inverter Connectors
LVDS1 LVDS LCD Panel Connectors
JFRT1 Switches and Indicators Connector
RES1 Reset Button / Connector
PSON1 Power On Button / Connector
CON1~2 CPU Module Ultra Serial Ports (Only RX and TX)
MC1~2 PCI Express Mini-card Sockets
SYSF1 System Fan Power Connector
PCIE1~2 PCIE ×1 Slots
PCIE3 PCIE ×4 Slot
PCEG1 PCIE Graphic ×16 Slot
AUDIO1 HD AUDIO Connector
LAN1 RJ-45 & Double Stack USB Connector
USB1~2 Double Stack USB Type A Connectors (support USB 3.0, depending
on CPU module)
VGA1 Analog RGB & DVI-D Display Connector
KBM1 PS/2 Keyboard & Mouse Connector

- 7 -
Jumpers
B110
A110
B1
A1
D110
C110
D1
C1
1
1 11
1 2 34
ON
ON
21
1 3
2 4
24
12
13 1
1
15
16
26
2
3
4
52
51
16
18
15 17
2
1
52
51
16 18
15 17
2
1
6
5
2 1
29 302
1 1
1
1
1
1
1 1
1
1
20
19
2
1 4
5
8
10
9
2
1
JPWOK1
1
JPSON1
3
J5VSB1
2
JTPM1
4
JBL1
6
JBL2
5
JINV1
8
SW1
11
JBAT1 12
JAUDIO113
JWDT1
7
JVLCD1
9
JBLON1
10
1
1
1

- 8 -
Connectors
B110
A110
B1
A1
D110
C110
D1
C1
1
1 11
1 2 34
ON
ON
21
1 3
2 4
24
12
13 1
1
15
16
26
2
3
4
52
51
16
18
15 17
2
1
52
51
16 18
15 17
2
1
6
5
2 1
29 302
1 1
1
1
1
1
1 1
1
1
20
19
2
1 4
5
8
10
9
2
1
COM1
14 COM2 15 LPT1 16 TPM1
17 DIO1
18
ATX1
19
ATX12V1
20
CPUF1
21
SATA1
22
SATA4
23
SATA3
24
SATA2
25
DP1
26
DP2
27
LVDS1
28
INV1
29
RES1
31
POSN1
32
CON2
33
CON1
34
MC2
35
MC1
36
SYSF137
PCIE3 38
PCIE2 39
PCEG140
PCIE141
AUDIO142
LAN143
USB2 44
JFRT1
30
1
1
1
USB1 45
VGA146
KBM147

- 9 -
JPWOK1: Carrier Board Power OK
Selection (1)
Connector type: 2.54mm pitch 1×3 pin header.
Pin Power Button
1-2 from carrier board power
ok out (default)
23 1
2-3 always high
23 1
JBL2: LVDS1 Brightness Control
Level and Mode Selection (5)
Connector type: 2.00mm pitch 2×3 pin header.
Pin Brightness Control Source
1-3 5V PWM mode control
(default)
65
2
1
65
2
1
65
2
1
65
2
1
3-5 3.3V PWM mode control
65
2
1
65
2
1
65
2
1
65
2
1
2-4 5V DC level control
65
2
1
65
2
1
65
2
1
65
2
1
4-6 0V DC level control
65
2
1
65
2
1
65
2
1
65
2
1
JINV1: LCD Inverter Voltage
Selection (8)
The voltage of inverter could be selected by
JINV1 in +5V or +12V.
Connector type: 2.54mm pitch 1×3 pin header.
Pin Voltage
1-2 +5V
23 1
2-3 +12V (default)
23 1
Jumpers
J5VSB1: CPU Module 5VSB Power
Selection (2)
Connector type: 2.54mm pitch 1×2-pin header.
Pin CPU Module 5VSB Power
1-2 Short 5VSB (default) 1 2
Open No Standby power 1 2
JPSON1: Force ATX Power Supply
Power On (3)
Connector type: 2.54mm pitch 1×2-pin header.
Pin AT/ATX Mode Select
Short AT mode 1 2
Open ATX Mode (default) 1 2
JTPM1: Select TPM Module Special
Command (optional)(4)
Connector type: 2.54mm pitch 1×2-pin header.
Pin TPM Physical Presence
Short Presence 1 2
Open Not Presence 1 2
JBL1: LVDS1 Brightness Control
Source Selection (6)
Connector type: 2.54mm pitch 1×3 pin header.
Pin Brightness Control Source
1-2 CPU module (default)
23 1
2-3 carrier Super I/O
23 1
JWDT1: Watch Dog Source Selection
(7)
Connector type: 2.54mm pitch 1×3 pin header.
Pin Source
1-2 carrier Super I/O (default)
23 1
2-3 CPU module
23 1

- 10 -
JBLON1: LCD Backlight On Control
Mode (10)
Connector type: 2.54mm pitch 1×3 pin header.
Pin Mode
1-2 0V low ON
23 1
2-3 5V high ON (default)
23 1
SW1: BIOS Boot Selection (11)
Function 1 2
Boot from CPU module SPI Flash
ON
21
ON
21
ON
21
ON
21
Boot from CPU module SPI Flash
ON
21
ON
21
ON
21
ON
21
Boot from Carrier Board SPI Flash
ON
21
ON
21
ON
21
ON
21
Boot from CPU Module SPI Flash
ON
21
ON
21
ON
21
ON
21
JBAT1: CMOS Setup (12)
Connector type: 2.54mm pitch 1×3 pin header.
Pin Mode
1-2 keep CMOS (default)
23 1
2-3 clear CMOS
23 1
JAUDIO1: AUDIO Voltage Selection
(13)
The voltage of AUDIO could be selected by
JAUDIO1 in +1.5V or +3.3V.
Connector type: 2.54mm pitch 1×3 pin header.
Pin Voltage
1-2 +3.3V (default)
23 1
2-3 +1.5V
23 1
JVLCD1: LVDS Panel Voltage
Selection (9)
The voltage of LVDS panel could be selected
by JVLCD1 in +5V or +3.3V.
Connector type: 2.54mm pitch 1×3 pin header.
Pin Voltage
1-2 +5V
23 1
2-3 +3.3V (default)
23 1

- 11 -
Connectors
COM1, 2: RS-232 Serial Ports (14,
15)
Connector type: 2.54mm pitch 2×5 box
header.
Pin Desc. Pin Desc.
12
910
1DCD# 2RXD
3 TXD 4DTR#
5 GND 6 DSR#
7RTS# 8 CTS#
9 RI# 10 NC
LPT1: Parallel Port Connector (16)
Connector type: 2.00mm pitch 2×13 box
header.
Pin Desc. Pin Desc.
14
26
1
13
1STB# 14 AFD#
2PTD0 15 ERROR#
3 PTD1 16 INIT#
4PTD2 17 SLIN#
5 PTD3 18 GND
6 PTD4 19 GND
7PTD5 20 GND
8 PTD6 21 GND
9 PTD7 22 GND
10 ACK# 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SELECT 26 NC (Key)
TPM1: Trusted Platform Module
Connector (optional) (17)
Connector type: 2.54mm pitch 2×10 pin
header.
1
2
20
19
Pin Description Pin Description
1LPC_CLK 2GND
3 LFRAME# 4NC (Key)
5 RESET# 6 5V
7LAD3 8 LAD2
9 +3.3V 10 LAD1
11 LAD0 12 GND
13 SMB_CLK 14 SMB_DATA
15 +3.3VSB 16 SERIRQ
17 GND 18 NC
19 PD# 20 LDRQ#
DIO1: Digital I/O Connector (18)
DIO1 is a 8-bit GPIO connector.
Connector type: 2.54mm pitch 2×5 pin header.
Pin Desc. Pin Desc.
12
10
9
1DIO1 2DIO2
3 DIO3 4DIO4
5 DIO5 6 DIO6
7DIO7 8 DIO8
9 +5V 10 GND

- 12 -
ATX12V1: ATX +12V Connector
(20)
ATX +12V voltage is for CPU Processor. If this
connector is not connected, system cannot
boot up.
Connector type: 12V 4-pin power connector.
Pin Desc. Pin Desc.
1
3
2
4
2GND 1GND
4+12V 3 +12V
ATX1: ATX Power Connector (19)
Connector type: Standard 24-pin Power
Connector.
113
1224
Pin Desc. Pin Desc.
13 +3.3V 1+3.3V
14 NC 2 +3.3V
15 GND 3 GND
16 PS-ON 4 +5V
17 GND 5 GND
18 GND 6 +5V
19 GND 7GND
20 NC 8 PW-OK
21 +5V 9 +5VSB
22 +5V 10 +12V
23 +5V 11 +12V
24 GND 12 +3.3V
CPUF1, SYSF1: Fan Power
Connectors (21, 37)
The fan must be a +12V fan.
Connector type: 2.54mm pitch 1×3 wafer one
wall connector.
Pin Description
1
2
3
1GND
2+12V
3 Fan_Detect
SATA1, 2, 3, 4: Serial ATA
Connectors (22, 23, 24, 25)
Support high speed transfer rates and SATA
RAID function.
Connector type: Standard 7-pin SATA
Connector.
Pin Description
1GND
2TX+
3 TX-
4GND
5 RX-
6 RX+
7GND
INV1: LCD Inverter Connectors (29)
Connector type: 2.00mm pitch 1×5 box wafer
connector.
Pin Description
1
2
3
4
5
1+12V
2GND
3 Backlight on/off
4Brightness control
5 GND
DP1, 2: Display Port Connector
(26, 27)
Pin Description Pin Description
1LANE0+ 2GND
3LANE0- 4 LANE1+
5 GND 6 LANE1-
7LANE2+ 8 GND
9LANE2- 10 LANE3+
11 GND 12 LANE3-
13 AUX_EN# 14 GND
15 AUX+ 16 GND
17 AUX- 18 HPD
19 RTN_PWR 20 PWR

- 13 -
JFRT1: Switches and Indicators
Connector (30)
It’s a connector for system indicators that
provide computer activities’ light indication and
for switches to change the computer status.
Connector type: 2.54mm pitch 2×8 pin header.
1
216
15
Pin Description Pin Description
1Power LED+ 2PWRBTN+
3 Power LED- 4PWRBTN-
5 Power LED- 6 RESET+
7HDD LED+ 8 RESET-
9 HDD LED- 10 SPEAKER+
11 SMBCLK 12 SPEAKER+
13 SMBDATA 14 SPEAKER-
15 GND 16 SPEAKER-
LVDS1: LVDS LCD Panel
Connectors (28)
The connector supports up to 24-bit dual
channel.
Connector type: DF-13-30DP-1.25V.
Pin Desc. Pin Desc.
1
2930
2
2VDD* 1VDD*
4TX2CLK+ 3 TX1CLK+
6 TX2CLK- 5 TX1CLK-
8 GND 7GND
10 TX2D0+ 9 TX1D0+
12 TX2D0- 11 TX1D0-
14 GND 13 GND
16 TX2D1+ 15 TX1D1+
18 TX2D1- 17 TX1D1-
20 GND 19 GND
22 TX2D2+ 21 TX1D2+
24 TX2D2- 23 TX1D2-
26 GND 25 GND
28 TX2D3+ 27 TX1D3+
30 TX2D3- 29 TX1D3-
*Note: VDD could be selected by JVLCD1 in
+5V or +3.3V.
MC1, 2: PCI Express Mini-card
Sockets (35, 36)
52
51
16
18
15
17
2
1
Mini-Card
Socket
CON1, 2: Ultra Serial Ports (33, 34)
Connector type: 2.54mm pitch 1×5 pin header.
Pin Description
1
2
3
4
5
1+3.3V
2 NC
3 RX
4GND
5 TX
PCIE1, 2: PCI Express x1 Slots (39,
41)
Pin Description Pin Description
B1 +12V A1 PRSNT1
B2 +12V A2 +12V
B3 +12V A3 +12V
B4 GND A4 GND
B5 SMCLK A5 JTAG2
B6 SMDAT A6 JTAG3
B7 GND A7 JTAG4
B8 +3.3V A8 JTAG5
B9 JTAG1 A9 +3.3V
B10 +3.3VAUX A10 +3.3V
B11 WAKE# A11 PWRGD
B12 RSVD A12 GND
B13 GND A13 REFCLK+
B14 PCIE_TX+ A14 REFCLK-
B15 PCIE_TX- A15 GND
B16 GND A16 PCIE_RX+
B17 PRSNT2 A17 PCIE_RX-
B18 GND A18 GND

- 14 -
PCEG1: PCI Express x16 Slot (40)
Pin Description Pin Description
B1 +12V A1 PRSNT1
B2 +12V A2 +12V
B3 +12V A3 +12V
B4 GND A4 GND
B5 SMCLK A5 JTAG2
B6 SMDAT A6 JTAG3
B7 GND A7 JTAG4
B8 +3.3V A8 JTAG5
B9 JTAG1 A9 +3.3V
B10 +3.3VAUX A10 +3.3V
B11 WAKE# A11 PWRGD
B12 RSVD A12 GND
B13 GND A13 REFCLK+
B14 PEG_C_TX0+ A14 REFCLK-
B15 PEG_C_TX0- A15 GND
B16 GND A16 PEG_RX0+
B17 PRSNT2 A17 PEG_RX0-
B18 GND A18 GND
B19 PEG_C_TX1+ A19 RSVD
B20 PEG_C_TX1- A20 GND
B21 GND A21 PEG_RX1+
B22 GND A22 PEG_RX1-
B23 PEG_C_TX2+ A23 GND
B24 PEG_C_TX2- A24 GND
B25 GND A25 PEG_RX2+
B26 GND A26 PEG_RX2-
B27 PEG_C_TX3+ A27 GND
B28 PEG_C_TX3- A28 GND
B29 GND A29 PEG_RX3+
B30 RSVD A30 PEG_RX3-
B31 PRSNT2 A31 GND
B32 GND A32 RSVD
B33 PEG_C_TX4+ A33 RSVD
B34 PEG_C_TX4- A34 GND
B35 GND A35 PEG_RX4+
B36 GND A36 PEG_RX4-
B37 PEG_C_TX5+ A37 GND
B38 PEG_C_TX5- A38 GND
B39 GND A39 PEG_RX5+
B40 GND A40 PEG_RX5-
B41 PEG_C_TX6+ A41 GND
B42 PEG_C_TX6- A42 GND
B43 GND A43 PEG_RX6+
B44 GND A44 PEG_RX6-
B45 PEG_C_TX7+ A45 GND
B46 PEG_C_TX7- A46 GND
B47 GND A47 PEG_RX7+
B48 PRSNT2 A48 PEG_RX7-
B49 GND A49 GND
B50 PEG_C_TX8+ A50 RSVD
B51 PEG_C_TX8- A51 GND
B52 GND A52 PEG_RX8+
B53 GND A53 PEG_RX8-
B54 PEG_C_TX9+ A54 GND
B55 PEG_C_TX9- A55 GND
B56 GND A56 PEG_RX9+
B57 GND A57 PEG_RX9-
B58 PEG_C_TX10+ A58 GND
B59 PEG_C_TX10- A61 GND
B60 GND A62 PEG_RX10+
B61 GND A61 PEG_RX10-
B62 PEG_C_TX11+ A62 GND
B63 PEG_C_TX11- A63 GND
B64 GND A64 PEG_RX11+
B65 GND A65 PEG_RX11-
B66 PEG_C_TX12+ A66 GND
B67 PEG_C_TX12- A67 GND
B68 GND A68 PEG_RX12+
B69 GND A69 PEG_RX12-
B70 PEG_C_TX13+ A70 GND
B71 PEG_C_TX13- A71 GND
B72 GND A72 PEG_RX13+
B73 GND A73 PEG_RX13-
B74 PEG_C_TX14+ A74 GND
B75 PEG_C_TX14- A75 GND
B76 GND A76 PEG_RX14+
B77 GND A77 PEG_RX14-
B78 PEG_C_TX15+ A78 GND
B79 PEG_C_TX15- A79 GND
B80 GND A80 PEG_RX15+
B81 PRSNT2 A81 PEG_RX15-
B82 RSVD A82 GND

- 15 -
AUDIO1: HD AUDIO Connector (42)
Azalia Audio supports 7.1-channel audio.
Connector type: 2 × triple stack audio jacks
(Stereo ø3.50).
Blue: Line In
Green: Line Out
Pink: MIC In
Orange: CET/LEF
Black: Surround
Gray: Side-SUR
PCIE3: PCI Express x4 Slot (38)
Pin Description Pin Description
B1 +12V A1 PRSNT1
B2 +12V A2 +12V
B3 +12V A3 +12V
B4 GND A4 GND
B5 SMCLK A5 JTAG2
B6 SMDAT A6 JTAG3
B7 GND A7 JTAG4
B8 +3.3V A8 JTAG5
B9 JTAG1 A9 +3.3V
B10 +3.3VAUX A10 +3.3V
B11 WAKE# A11 PWRGD
B12 RSVD A12 GND
B13 GND A13 REFCLK+
B14 PCIE_TX0+ A14 REFCLK-
B15 PCIE_TX0- A15 GND
B16 GND A16 PCIE_RX0+
B17 PRSNT2 A17 PCIE_RX0-
B18 GND A18 GND
B19 PCIE_TX1+ A19 NC
B20 PCIE_TX1- A20 GND
B21 GND A21 PCIE_RX1+
B22 GND A22 PCIE_RX1-
B23 PCIE_TX2+ A23 GND
B24 PCIE_RX2- A24 GND
B25 GND A25 PCIE_RX2+
B26 GND A26 PCIE_RX2-
B27 PCIE_TX3+ A27 GND
B28 PCIE_TX3- A28 GND
B29 GND A29 PCIE_RX3+
B30 NC A30 PCIE_RX3-
B31 NC A31 GND
B32 GND A32 NC
LAN1: RJ-45 & Double Stack USB
Connector (43)
This connector supports USB 2.0 ×2 and
Gigabit RJ-45 Etherner Connector.
Connector type: RJ-45 + double stack USB
type A connector.
LED LED
LAN
USB
USB
8 7 6 5 4 3 2 1
1 2 3 4
1 2 3 4
USB1, 2: Double Stack USB Type A
Connectors (44, 45)
Connector type: double stack USB 3.0 type A
connector.
USB
USB
1 2 3 4
1 2 3 4
KBM1: PS/2 Keyboard & Mouse
Connector (47)
Standard PS/2 Keyboard & Mouse connector
Connector type: double stack 6-pin mini DIN.
Pin Description
78
9
1112
10
Keyboard
(Purple)
12
3
56
4
Mouse
(Green)
1KB Data
2 NC
3 GND
4+5V
5 KB Clock
6NC
7MS Data
8NC
9 GND
10 +5V
11 MS Clock
12 NC

- 16 -
VGA1: Analog RGB & DVI-D
Display Connector (46)
Connector type: VGA: D-Sub 15-pin female.
DVI-D: DVI-D female.
Analog RGB
DVI-D
1
18
17 24
5
1115
Analog RGB Connector
Pin Description Pin Description
1 Red 9 +5V
2Green 10 GND
3Blue 11 Reserve
4 Reserve 12 DDC_Data
5 GND 13 Horizontal Sync
6Red Return
(GND)
14 Vertical Sync
7Green Return
(GND)
15 DDC_Clock
8Blue Return
(GND)
DVI-D Connector (only supports single
channel)
Pin Description Pin Description
1TMDS Data 2- 13 NC
2TMDS Data 2+ 14 +5V
3TMDS Data 2/4
shield 15 GND (for +5V)
4 NC 16 Hot plug detect
5NC 17 TMDS Data 0-
6 DDC clock 18 TMDS Data 0+
7DDC data 19 TMDS Data 0/5
shield
8NC/Analog
vertical sync 20 NC
9 TMDS Data 1- 21 NC
10 TMDS Data 1+ 22 TMDS clock
shield
11 TMDS Data 1/3
shield 23 TMDS clock+
12 NC 24 TMDS clock-
