ARGON18 GALLIUM PRO User manual

GALLIUM PRO: ASSEMBLY GUIDE
Revision 2.0 - 04-08-2016

Assembly overview. . . . . . . . . . . . . . . . . . . . . . . ................2-3
1. Frame inspection . . . . . . . . . . . . . . . . . . . . . ...................4
2. Headset installation . . . . . . . . . . . . . . . . . . . . ..................5
3. Cables & housing installation . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
4. Electronic drive-train specication . . . . . . . . . . ........ 10-13
5. Saddle adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15
6. Derailleur hanger adjustment. . . . . . . . . . . . . . . . . . . . . . . . ....16
7. Parts listing. . . . . . . . . . . . . . . . . . . . . . . . ................. 17-20
For the warranty to be valid, the bicycle must be fully assembled by an authorized Argon 18 dealer. High-end components,
particularly carbon parts, need extra care when assembled. Those components must be installed using a calibrated torque
wrench to make sure every bolt is at the right torque setting to prevent damage.
GALLIUM PRO: Table of contents

2. Headset installation 3. Cable housing installation
IMPORTANT NOTICE: It is easier to install the
cable housings before the bottom bracket, crank
& fork.
5. Seatpost installation 6. Derailleur hanger adjustment
2
GALLIUM PRO:Assembly overview
4. Electronic drive-train cable
routing specication
1. Frame inspection

3
GALLIUM PRO: Assembly overview
2
3b 3c
3e
3d
3b
3f
20
3a
4d 4i 7 6
4f
4e
4a
4g
5a 5b 5c 5d 4j
4c
4h
4b
3
Images are for reference only. Proportions are not accurate.
7. Parts Listing

Parts installed on the frame Description Screw Torque Detail
type Nm
1 Seatpost, Ø 27.2mm Seatpost Carbon paste
2 Front derailleur hanger Screw 3mm 3Nm Loctite
3 Rear derailleur hanger Screw (2) 3mm 4Nm Loctite
4 Bottle cage Screw (4) 4mm 3Nm Grease
5 Seatpost collar Clamp 4mm 6Nm Grease
6 Rear derailleur cable stopper Screw (2) 2mm 2Nm Loctite
7 Bottom bracket cable guide Screw 5mm 3Nm Grease
When assembling a new frame, be sure to check if the following parts are assembled correctly.
4
GALLIUM PRO: 1. Frame inspection

Install the 3D headset (6) according
to the presst assembly guide. You
can choose from 3 dierent heights :
25mm, 15mm or 0mm.
5
GALLIUM PRO: 2. Headset installation
6

6
GALLIUM PRO: 3. Cables & housing installation
1. Install the front and rear derailleur
cable starting at the head tube.
2. Install the rear brake cable starting
the head tube.
For the derailleur and brake housing,
measure a sucient length of housing
to be able to turn the handlebar both
ways correctly.
2
1
A : barrel adjuster
B : metal cap
C : plastic cap
B
B
C
C
C
C
C
speed adjustment : C+A+C

7
GALLIUM PRO: 3. Cables & housing installation
Rear brake cable housing
Remove the cable stopper (4g) near the seat collar.
Font section: Mesure the necessary cable housing to ensure a proper
rotation of the handlebar. Insert the cable trough the shifter, then insert
the cable and the housing with a ferrule in the head tube.
Rear section: With a magnet, get the rear brake cable out of the frame,
and pass it trough the rear cable stopper. Measure the rear housing
correctly to avoid interference with the rider’s left leg. Fix the cable to
the brake according to the brake manufacturer assembly guide.
4g

8
GALLIUM PRO: 3. Cable & housing installation
Front and rear derailleur: Pass
the two cables inside the frame
starting from the top tube
until they come out under the
bottom bracket.
Pass both cables into the cable
guide (4d). Make sure the
5mm screw is set to 1.5 Nm.
For a Di2 conguration, use
the bottom bracket dedicated
cover for electric shifting (4i).
It’s better to install the cables
before installing the bottom
bracket and crank. 4d
4i

9
GALLIUM PRO: 4. Electronic drive-train specication
The Di2 cable routing can be achieved easily using this
simple trick: use a brake cable and a metal cable end to
x the Di2 cable. For more information on Shimano Di2
electronic system installation, go to : http://si.shimano.com.
