E-112 : ASSEMBLY GUIDE
Revision 3.0 - 06-02-2016

Assembly overview. . . . . . . . . . . . . . . . . . . . . . . ................2-3
1. Frame inspection . . . . . . . . . . . . . . . . . . . . . ...................4
2. Headset installation . . . . . . . . . . . . . . . . . . . . ..................5
3. Cable housing installation . . . . . . . . . . . . . . . . . . . . ..........6-7
4. Seatpost installation . . . . . . . . . . . . . . . . . . . . . . . . . ............8
5. Saddle adjustment . . . . . . . . . . . . . . . . . . . . . . . . ............9-10
6. Derailleur hanger adjustment. . . . . . . . . . . . . . . . . . . . . . . . ....11
7. Parts listing . . . . . . . . . . . . . . . . . . . . . .................... 12-14
For the warranty to be valid, the bicycle must be fully assembled by an authorized Argon 18 dealer. High-end components,
particularly carbon parts, need extra care when assembled. Those components must be installed using a calibrated torque
wrench to make sure every bolt is at the right torque setting to prevent damage.
E-112 : Table of contents

3. Cable housing installation
IMPORTANT NOTICE: It is easier to install the
cables and cable housings before the bearings.
1. Frame inspection 2. Headset installation
2
E-112 : Assembly overview
6. Derailleur hanger adjustment5. Saddle adjustment4. Seatpost installation

Images are for reference only. Proportions are not accurate.
4a
4f
2
4b
4c
2
4e 4g
4d
3
5
6
3a
3f
3b
3c
3d
3e
7. Parts listing
3
E-112 : Assembly overview

4
E-112 : 1. Frame inspection
Parts installed on the frame Description Screw Torque Detail
type Nm
1 Front derailleur hanger Screw (2) 3mm 4Nm Loctite
2 Rear derailleur hanger Screw (4) 3mm 4Nm Loctite
3 Bottle cage Screw (2) 4mm 3Nm Grease
4 Bottom bracket cover Screw (1) 5mm 2Nm Grease
When assembling a new frame, be sure to check if the following parts are assembled correctly.

Install the 3D headset (9) according
to the presst assembly guide. You
can choose from 3 dierent heights :
25mm, 15mm or 0mm.
5
E-112 : 2. Headset installation

1. Install the front and rear derailleur
cable housing starting at the head tube.
2. Install the rear brake cable housing
starting at the head tube.
For the derailleur and brake housing,
measure a sucient length of housing
to be able to turn the handlebar both
ways correctly.
See the table below for the cable housing
suggested length.
Suggested lengths of the cable housing
housing/size
Front brake
Rear brake
Front derailleur
Rear derailleur
Rear derailleur
(rear section)
58cm
136cm
140cm
140cm
40cm
60cm
138cm
142cm
142cm
40cm
62cm
140cm
144cm
144cm
40cm
64cm
142cm
146cm
146cm
40cm
XS S M L
6
E-112 : 3. Cable housing installation
2
1
A : barrel adjuster
B : metal cap
C : plastic cap
C
C
CC C
B
B
C
C
speed adjustment : C+A+C
Rear derailleur
Front derailleur
Rear brake
12h

Remove the cable guide and add a
plastic cap on each cable housing (front
and rear derailleur). Insert the plastic
cap into the cable guide, then x the
guide to the frame with the M5 screw.
7
E-112 : 3. Cable housing installation
4f

E-112 : 4. Seatpost installation
1. Make sure the clamp (4e) sits
correctly on the seat tube.
2. Insert the seatpost (6) on which
some carbon ber assembly gel has
been applied.
3. Position the seatpost at the desired
height and tighten evenly the two
screws to 6Nm.
8
3
4e
6Nm
GREASE
GREASE
CARBON FIBER
ASSEMBLY
COMPOSITE

E-112 : 5. Saddle adjustment
1. Install the saddle on the rocker (3f)
and slightly tighten the rail clamp (3e)
using a ball end hex key.
2. Tighten the upper screw of the rocker
clamp (3a) by keeping a space of 2
to 3mm between the aluminum and
carbon parts.
3. Adjust the angle of the saddle and
tighten the lower bolt of the rocker
clamp (3b).
4. Adjust the saddle oset and nalize
the tightening of the rail clamp (3c).
9
3b
3c
3d
3a
3f
3e
GREASE
8Nm
2-3mm
8Nm
GREASE
GREASE

E-112 : 5. Saddle adjustment
The 2waypost ASP-4000 can be ipped
to achieve a triathlon or a road position
(75°/78°).
The seat clamp oset can be set by
ipping the rail clamp (3d) and the
rocker (3f).
Road : -10mm to -15mm
Tri : +10mm to 15mm
10
3f
3f
3d
3d

E-112 : 6. Derailleur hanger adjustment
11
The front derailleur hanger can be
adjusted according to the front
derailleur angle to obtain an equal
curve between the derailleur and the
big chain ring. Once at the right angle,
use blue 242 Loctite and screw in at
6Nm.
LOCTITE
LOCTITE
4b

E-112 : 7. Parts listing
12
Images are for reference only. Proportions are not accurate.
4a
4f
2
4b
4c
2
4e 4g
4d
3
5
6
3a
3f
3b
3c
3d
3e

E-112 : 7. Parts listing
13
No. Name A18 SKU# Qty
# Frameset Parts
# Seat post with the following parts assembled
1 E-112 frame
2 E-112 fork 1
3 E-112 seat post (ASP-4000) 1
3a • Upper HexSocket screw (M6*20mm S) for rocker clamp 1
3b • Lower HexSocket screw (M6*20mm S) for rocker clamp 1
3c •HexSocket screws (M5*20mm S) 2
3d • Top rail clamp 1
3e • Rocker clamp 1
3f • Rocker 1
# Parts installed on the frame
4a Rear derailleur hanger with screws M4x7mmF - Model F 37831 1 set
4b Front derailleur hanger
with screws M5x16mmB & M5x16mmF - Model D 36197 1
4c Rear axel adjustment
round head Phillips screws M3x20mm and springs 37834 2
4d Screw for water bottle cage M5x16mmB 38234 2
4e Seat clamp alloy polish black with screws M5x20mmS 37834 1
4f Plastic BB cable guide
with screw M5x12mmS and nut M5x19mm 36194 1
4g FD cable guide with rivets 36659 1
# Also included with the frameset - shipped separately
5 Headset No. IS-2 6.5 + 3D with compressor TH-881-1 37859 1
6 3D headset tool 36165 1
