Argos Home Scandinavia 6423801 User manual

Page 1 of 21
Scandinavia
3 door robe w. mirror
Scandinavia 3 door robe w. mirror
1799mm
1070mm 530mm

Please sort out all parts before you begin to assemble the item.
This to make sure you always use the correct part.
Fittings contained in the Box.
Tools Needed.
A12 pcs. Cam - ø15 x 12mm B12 pcs. Bolt - ø6,5 x 24/11mm C4 pcs. Dowel - ø8 x 30mm
D40 pcs. Screw - ø3,5 x 12mm
H3 pcs.
O1 pcs. Hanging rail - ø16 x 636mm
S1 pcs. Joining strip - 1653mm
K3 pcs.
0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
MM
G30 pcs. Nail - 1,2 x 20mm
L4 pcs. Hanging rail cup
Knob
ø40 x 30mm
F3 pcs. Screw - ø3,5 x 35mm
J3 pcs. Screw - ø5 x 50mm
N9 pcs.
P9 pcs. Cross plate
Cup hinge
Magnet
Q4 pcs. Miniblock
Fittings A, B, C, D, E, F, G and J are shown in their actual dimensions.
M1 pcs.
Nail guide
E12 pcs. Screw - ø3,5 x 25mm
R1 pcs. Hanging rail
16 x 302mm
Hazard Warning !
Keep small components out of the reach of children.
Page 2 of 21Scandinavia 3 door robe w. mirror

Wooden parts contained in the box.
5
1 pcs.
Side, left
6
1 pcs.
Side, right
1
1 pcs.
Top
3
1 pcs.
Bottom
4
1 pcs.
Support Rail
8
1 pcs.
Door, right
11
2 pcs.
Back
2
2 pcs.
Plinth
Page 3 of 21Scandinavia 3 door robe w. mirror
7
1 pcs.
Divider
10
1 pcs.
Door w. mirror
9
1 pcs.
Door, left
1070 x 530mm
960 x 480mm
960 x 45mm
640 x 90mm
1785x498mm
1666x316mm
1710x488mm
1785x498mm
1666x316mm
1656x480mm
1666x316mm

No.3 "Shield Anchor" Wall Plug
Heavy Loads
For use with heavier loads such as TV
& HiFi Speakers and Satellite Dishes etc.
No.4 "Cavity Fixing" Wall Plug
For use with plaster board partitions or
hollow wooden doors.
No.5 "Cavity Fixing - Heavy Duty"
Wall Plug
For use when fitting or supporting heavy
loads such as shelving, wall cabinets,
coat racks.
IMPORTANT:
When drilling into walls always check that there are no
hidden wires or pipes etc. Make sure that the screws and
wall plugs being used are suitable for supporting your unit.
Consult a qualified tradesperson if you are unsure.
HINTS:
1) General Rule Always use a larger screw and wall plug if you are not sure.
2) Ensure you use the recommended drill bit to match the wall plug and hole size.
3) Ensure you drill the hole horizontally, do not force the drill or enlarge the hole.
4) Take extra care when drilling high walls, ceilings and ceramic tiles. Ensure the plug is fitting below the ceramic
tile to avoid splitting or cracking.
5) Ensure wall plugs are well fitted and are a tight fit in the drilled hole.
Types Of Walls
You can use one of the following types
of wall plug if your walls are made of
brick, breeze block, concrete, stone,
wood or plaster board.
No.1 "Standard" Wall Plug
General Wall Materials
These come in various sizes and are made
from plastic or sometimes wood fiber.
No.2 "General Purpose" Wall Plug
Aerated / Breeze Block
Generally aerated blocks should not be
used to support heavy loads, use a
specialist fitting in this case.
For light loads, a General Purpose Plug
can be used.
No.6 "Hammer Fixing" Wall Plug
For use with walls stuck with plaster
board. The hammer fixing allows it to
be fixed to the wall rather than the plaster
board. Always check the fixing is secure
to the retaining wall.
CARE & MAINTENANCE
SAFETY
Always check the fitting and
location to ensure your safety in
and around the home.
FITTING
From time to time check the fitting
to ensure the wall plugs or screws
do not become loose.
Wall Mounting & Fixings
A Guide to
Page 4 of 21
Scandinavia 3 door robe w.mirror

3
4
1
7
5
8
2
Page 5of 21Scandinavia 3 door robe w. mirror
Key diagram.
Function of cam & bolt.
Step 2:
Push the wooden Panel
with the attached Bolt onto
the other wooden Panel.
Step 4:
Tighten: Turn the Cam to
the Right.
Step 1:
Fix the Bolt to the
wooden Panel.
Step 3:
Place the Cam into the
Hole, arrow pointing
towards the Bolt.
134
2
9
10
11
11
6
2
S

1. Mounting the cross plates to the sides.
P
P
6 Pcs.
P
P
P
P
P
E
12 Pcs.
E
E
E
E
E
E
Fig. 1.1
2. Mounting the hanging rail cups to the sides.
Fig. 2.1
D
4 Pcs.
D
D
L
L
Page 6of 21Scandinavia 3 door robe w. mirror
L
2 Pcs.
Front
Front
Fix the cross plates
"P" to the sides "5"
and "6" using screws
"E" into the holes
indicated.
It is important that the
cross plates is placed
exactly as shown.
The short end of the
cross plates must
point towards the front
edge of the sides.
See fig. 1.1
6
Side, right
5
Side, left
Front
Short end
Long end
5
Side, left
6
Side, right
Fix the hanging rail cups
"L" onto the sides "5"
and "6" using screws
"D" into the pre-drilled
holes.
See fig. 2.1

3. Mounting the bolts to the sides.
4. Mounting the cross plates to the divider.
B
5 Pcs.
D
6 Pcs.
P
3 Pcs.
B
B
B
B
B
D
D
D
P
P
P
Page 7of 21Scandinavia 3 door robe w. mirror
Fig. 4.1
Screw the bolts "B"
into the holes
indicated on the sides
"5" and "6".
6
Side, right
5
Side, left
Fix the cross plates "P"
to the divider "7" using
screws "D".
It is important that the
cross plates is placed
exactly as shown.
The short end of the
cross plates must point
towards the front edge
of the divider.
See fig. 4.1
Holes = Back
7
Divider
NO Bolt here
Front
Long end
Short end
Front

5b. Mounting the hanging rail cup to the divider.
5a. Mounting the hanging rail cup to the divider.
D
D
2 Pcs.
L
1 Pcs.
L
D
Fig. 5a.1
Page 8 of 21 Scandinavia 3 door robe w. mirror
6. Mounting the bolt to the divider.
B
1 Pcs.
Fix the hanging rail cup
"L" onto the left hand
side of the divider "7"
using screws "D" into
the pre-drilled holes.
See fig. 5a.1
Fix the hanging rail cup
"L" onto the right hand
side of the divider "7"
using screws "D" into
the pre-drilled holes.
See fig. 5a.1
7
Divider
7
Divider
7
Divider
Screw the bolt "B" into
the hole indicated on
the divider "7".
L
1 pcs.
D
2 pcs.

7. Adding the dowels to the support rail.
8. Adding the miniblocks to the plinths.
9. Mounting the plinths to the bottom.
Q
4 Pcs.
C
4 Pcs.
Q
Q
C
C
C
Fig. 8.1
Page 9 of 21 Scandinavia 3 door robe w. mirror
10. Mounting the bolts to the top.
B
6 Pcs.
1
Top
B
B
B
B
B
4
Support Rail
2
2 Pcs.
Plinth
2
Plinth
2
Plinth
3
Bottom
Knock the dowels "C"
into the holes indicated
on the support rail "4".
Knock the miniblocks
"Q" into the holes
indicated on both the
plinths "2".
Fix the plinths "2" to
the bottom "3" using
the screws in the
miniblocks "Q".
Screw the bolts "B" into
the holes indicated on
the top "1".

Fig. 11.1
11. Mounting the magnets to the top.
12. Assembling the bottom to the divider.
13. Adding the support rail to the divider.
J
3 Pcs.
Fig. 12.1
D
6 Pcs.
A
1 Pcs.
7
Divider
7
Divider
3
Bottom
3
Bottom
J
J
D
DD
H
H
H
Page 10 of 21 Scandinavia 3 door robe w. mirror
Front edge H
3 Pcs.
Fix the magnets "H" to
the top "1" using screws
"D" into the pre-drilled
holes.
It is important that the
magnetic part points
towards the front edge of
the top. See fig. 11.1
Fix the divider "7" to the
bottom "3" using
screws "J".
Make sure to turn the
bottom as shown. The
chamfered edge should
point towards the front.
See fig 12.1
Chamfer = Front
4
Support rail
Press the support rail "4"
onto the divider "7".
See page 4 "Function of
the cam & bolt".
Place the cam "A" into
the hole indicated, arrow
pointing towards the
divider / bolt.
Tighten:
Turn the cam to the right.
1
Top

14. Adding the side to the plinths and the support rail.
15. Adding the right hand side to the plinths.
7
3
A
3 Pcs.
A
2 Pcs.
A
3
5
7
Page 11 of 21 Scandinavia 3 door robe w. mirror
Press the side "5" onto
the plinths "2" and the
support rail "4".
See page 4 "Function of
the cam & bolt".
Place the cams "A" into
the holes indicated,
arrows pointing towards
the side / bolt.
Tighten:
Turn the cams to the
right.
Press the side "6" onto the
plinths "2".
See page 4
"Function of the
cam & bolt".
Place the cams "A" into
the holes indicated,
arrows pointing towards
the side / bolt.
Tighten:
Turn the cams to the right.
5
Side, left
2
Plinth
4
Support rail
A
6
Side, right
2
Plinth

A
6 Pcs.
1
Top
7
Divider
A
A
A
A
16. Assembling the top to the sides.
Page 12 of 21 Scandinavia 3 door robe w. mirror
6
Side, right
5
Side, left
Lower the top "1" onto
the sides "5" and "6" and
the divider "7".
See page 4 "Function of
the cam & bolt".
Place the cams "A" into
the holes indicated,
arrows pointing towards
the top / bolt.
Tighten:
Turn the cams to the
right.

17. Adding the back to the carcass.
Fig. 17.4
Fig. 17.2
90a
Fig. 17.1
Fig. 17.3
Fig. 17.5
M
G
G
G
G
G
M
4
3
11
Back
Page 13 of 21 Scandinavia 3 door robe w. mirror
Place the back "11" into
the rabbet of the top "1"
and the side "6".
Ensure there is NO GAP
between the side and the
back, NOR between the
top and the back.
Fasten the back with
nails "G" along the top.
Use the nail guide "M" -
see fig. 17.4
The angle between the
top and the side must be
90 degrees. Fig. 17.2
To accomplish this,
ensure there is NO GAP
between the side and the
back.
Fasten the back along
the side and the bottom.
Use the nail guide as
shown in fig. 17.5.
Rabbet = Back
Rabbet = Back
1
Top
6
Side, right
5

Fig. 18.1
18. Adding the back and the joining strip to the carcass.
S
11
11
90a
fig. 18.2
Fig. 18.3
D
2 Pcs.
11
Back
11
4
1
1
11 1
G
14 Pcs.
D
G
G
G
G
G
Page 14 of 21 Scandinavia 3 door robe w. mirror
Place the joining strip
"S" onto the back.
See fig. 18.1
Place the back into the
rabbet of the top "1" and
the side "5".
Ensure there is NO GAP
between the side and the
back, NOR between the
top and the back.
Fasten the back along
the top. Use the nail
guide - see page 12, fig.
17.4.
Ensure there is NO GAP
between the side and the
back.
Fasten the back along
the side and the bottom.
Use the nail guide - see
page 12, fig. 17.5
Fix the back onto the
support rail "4" using
screws "D".
See fig. 18.3
5
S
Joining strip

19. Mounting the cup hinges to the doors.
Fig. 19.1
D
18 Pcs.
N
9 Pcs.
N
D
N
D
N
D
N
D
N
D
N
D
N
D
N
D
D
N
Page 15 of 21 Scandinavia 3 door robe w. mirror
Lower the cup hinges
"N" into the holes
indicated on the doors
"8", "9" and "10".
Fix the hinges using
screws "D".
Fig. 19.1
8
Door, right
9
Door, left
10
Door w. mirror

Fig.
1
2
3
20.2
20. Mounting the doors to the carcass.
Page 16 of 21 Scandinavia 3 door robe w. mirror
10
Fig. 20.1
When placing the doors,
the magnet catches
MUST point upwards.
Step 1
Place the adjustment
hole of the cup hinge at
the level of the fixing
screw. Push the cup
hinge towards the cross
plate - placing the fixing
screw in the wider part
of the adjustment hole.
It is very IMPORTANT to
catch ALL of the fixing
screws.
Step 2
Push the door / cup
hinge inwards - placing
the fixing screw in the
narrow end of the
adjustment hole.
Step 3
Tighten the fixing
screws of ALL of the
cross plates.
Cross plate
Fixing screw
Adjustment
hole
Adjusting
screw

21. Mounting the knobs & adding the hanging rails.
K
3 Pcs.
F
3 Pcs.
FF
K
K
Page 17 of 21 Scandinavia 3 door robe w. mirror
KF
Fig. 21.1
Fig. 21.2
Lower the hanging rails
"O" and "R" into the
hanging rail cups "L".
Fix the knobs "K" to
the doors using
screws "F".
O
Hanging rail
R
Hanging rail

22a. Adjusting the doors from side to side.
Fig.
12
3
4
22a.1
Page 18 of 21 Scandinavia 3 door robe w. mirror
MAKE SURE THE
WARDROBE IS PLACED
ON A PLANE SURFACE
BEFORE YOU BEGIN
ADJUSTING THE HINGES.
Step 1
Loosen the fixing screw.
Step 2
To adjust the door away
from the side (towards the
other door / the centre) -
turn the adjusting screw
to the right.
Step 3
To adjust the door
towards the side (away
from the other door / the
centre) - turn the
adjusting screw to the
left.
Step 4
Either continue
adjustment on page 18 -
step 2 - or tighten the
fixing screws of ALL of
the cross plates.
Fixing screw
Adjusting
screw
Adjusting
screw
Cross plate
Fixing screw

Fig.
1
2
3
22b.1
22b. Adjusting the doors forwards or backwards.
Page 19 of 21 Scandinavia 3 door robe w. mirror
Step 1
Loosen the fixing screw.
Step 2
Push the cup hinges / the
door back OR forth to
adjust. The doors should
level with the front edge
of the sides.
Step 3
Tighten the fixing screws
of ALL of the cross
plates.
Fixing
screw
Adjustment hole
Cross plate
Fixing
screw

22c. Adjusting the doors up or down.
Fig.
1
2
3
22a.1
Page 20 of 21Scandinavia 3 door robe w. mirror
Step 1
Loosen the two screws
"E"/"D" of each cross
plate, BUT ONLY as
much as it will allow the
cross plate to move up
and down.
Step 2
Adjust the cross plate /
the door.
Step 3
Tighten the screws
"E"/"D" of ALL of the
cross plates.
"E"/"D"
Cross Plate
"E"/"D"
"E"/"D"
