Argos Home Crystal 3ft Frame 697/0536 User manual

Crystal 3ft Frame
Dimensions
Width - 98.2cm
Depth - 198.7cm
Height - 120.2cm
Issue 1 - 25/06/10
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800
Assembly Instructions - Please keep for future reference 697/0536
697/0505

1
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• As you unpack and prepare
for assembly, clear an area for
assembly. The parts should be
placed on a carpeted or padded
area to protect them from
damage.
• Parts of the assembly will be
easier with 2 or 3 people.
• Do not discard any of the
packaging until you have
checked that you have all the
parts and pack of fittings.
• Only clean using a damp cloth
and mild detergent, do not use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• To ensure an easier assembly,
we strongly advise that all
fittings are only finger tightened
druing initial assembly. Only
upon completion of the
assembly should all fixing points
be fully tightened.

Components - Panels
Please check you have all the panels listed below
2
Side rail x 2
(192.2 x 9cm)
3
If you have damaged or missing components,
call the Customer Helpline:
0845 6400800
Headboard Frame
(98.2 x 76cm)
1
Headboard post x 2
(dia3.8 x 42cm)
4Slat x 12
(dia1.8 x 92cm)
5Final x 4
(9 x 5cm)
6
Footboard Frame
(98.2 x 90cm)
2

3
Please check you have all the fittings listed below
16mm Bolt x 4
Ruler - Use this ruler to help correctly identify the screws
A
Large plain washer x 8
E
42mm Bolt x 24
B
Small hex key x 1
H
30mm Bolt x 8
C
Large hex key x 1
I
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
                                 

Spring washer x 8
F
Small plain washer x 48
D
Nut x 24
G
Wrench x 1
J
Components - Fittings

4
Assembly Instructions
Step 1
Assemble headboard
Assemble headboard
posts 4to headboard
frame 1using bolts A
and secure tightly.
Assemble side rails
Three people are needed
here
Assemble side rails 3
to headboard posts 4
and footboard frame 2
using bolts C, spring
washers Fand large
plain washers E.
Note: Do not fully
tighten bolts.
Step 2
1
4
4
A
A
C
F
E
C
F
E
4
4
3
3
2

Step 3
Assembly Instructions
Assemble slats
Assemble slats to the
unit using bolts B, small
plain washers Eand
nuts G.
5
6into the
headboard frame and
footboard frame.
Note: Re-tighten all the
bolts.
Assembly is complete.
Step 4
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400800
5555555
5
5555
B
E
E
G
6
6
6
6
