Amersham - Solid Pine Large TV Unit
724/7196
Dimensions
Width - 120cm
Depth - 44cm
Height - 50cm
Issue 2 - 08/08/18
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800
Important – Please read these instructions fully before starting assembly
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.
1
Care and maintenance
Use an appropriate furniture
polish for natural wood
furniture and a dry cloth to
clean the product.
Avoid placing the furniture in
direct sunlight as this will cause
the timber to prematurely age.
From time to time check
that there are no loose
screws on this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre.
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Parts of the assembly will be
easier with 2 people.
Dispose of all packaging
carefully and responsibly.
This product has been produced
from natural timber; you may
notice some variation in the grain
and colour of different component
parts which is normal for furniture
produced using natural wood and
is not the result of any
manufacturing fault.
The product has been treated
with a wax and oil finish to
prevent dirt ingress and preserve
moisture.
On unpacking the
furniture you may notice an
odour due to this treatment;
this will disappear once the
furniture is unpacked and
assembled after a period of time.
This process may leave some
staining on the packaging
material; please take care to
ensure this does not transfer
to clothing or carpeted surfaces
during assembly.
underside
1Top panel (120 x 44cm)
top
top
Components - Panels
Please check you have all the panels listed below
2
2Base panel (114.4 x 40.4cm)
3Back panel (116,2 x 40cm)
4Front frame x 2 (103.6 x 6.5cm)
5Right front frame (48 x 9.2cm)
6Left front frame (48 x 9.2cm)
Right side panel (48 x 42cm)
7
Left side panel (48 x 42cm)
8
Middle wall panel x 2
(37.5 x 40.4cm)
9
Shelf (36.4 x 40.4cm)
10
11 Door x 2 (30.4 x 30.4cm)
12 Block x 4 (10 x 2cm)
Wooden dowel x 20 14mm Screw x 26
22mm Bolt x 2 Metal dowel x 12
Locking
nut x 12
Door
hinge x 4
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more
fittings may be supplied than are required.
Ruler - Use this ruler to help correctly identify the screws
0510 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170
Tools required
Phillips screwdriver
(medium & large)
Eye protection
(when using a
hammer or glue)
Small
hammer
Ruler/tape
measure
2m
3
Components - Fittings If you have damaged or missing components,
call the Customer Helpline: 03456 400 800
G
A
D
J
E
H
B
K
C
F
I
L
M N
Door
handle x 2
Clip x 2 Plug x 2
35mm Screw x 16
40mm Screw x 4
Metal
bracket x 1
Nail x 20
Door
spacer x 1
Step 2
Step 1
Fixing right front frame
to the right side panel
(Two people required for
an easier assembly).
a: Insert right side panel
into right front frame
through joints.
c: Fix front frame through
blocks using screws
.
Assembly Instructions
4
Fixing left front frame
to the left side panel
(Two people required for
an easier assembly).
a: Insert left side panel
into left front frame
through joints.
c: Fix front frame through
blocks using screws
.
Note:
Before fixing
blocks into
place it is important to
ensure that the slot and
groove of parts and
are fully pushed together
and lined up correctly at
the top and bottom.
b: Place blocks
between the two marks as
shown. First fix to the side
panel using screws .
Note:
Before fixing
blocks into
place it is important to
ensure that the slot and
groove of parts and
are fully pushed together
and lined up correctly at
the top and bottom.
b: Place blocks
between the two marks as
shown. First fix to the side
panel using screws .
a: b: c:
Yes!No!
a: b: c:
Yes!No!
7
5
12
C
C
7
7
5
5
12
12
C
C
12
7
5
12
12
Attention: correct
position of panel.
Top
12
12
Attention: correct
position of panel.
Top
8
6
12
6
C
C
8
6
12
8 6
12
C
C
12
8
Assembly Instructions
5
Step 3
Step 4
F
Fitting Metal dowels.
Screw metal dowels
into right side panel ,
left side panel and top
panel .
Insert metalNote:
dowels as far as
shown.
Do not over tighten.
Insert dowels into the
indicated parts.
A
F
1
F
F
F
F
F
F
8
7
1
7
8
2x
78
and
10
2
9
A
A
A
A
A
A
A
Assembly Instructions
6
Fit shelf into the
holes on middle wall
panels .
Important!
Shelf must be
positioned as shown in
the picture.
Step 5
Step 6
Fixing base panel.
With help, fit middle wall
panels to the base
panel then fix it using
screws .
Do not over tighten
screws.
9
9
10
10
9
D
D
D
D
2
2
10
2
D
9
9
9
Assembly Instructions
7
Insert front frames
into the holes on left side
panel .
Step 7
Step 8
Fixing base panel.
With help, fit base panel
to the left side panel.
Insert 2 locking nuts
into base panel where
shown.
Use a screwdriver to turn
locking nuts clockwise
to lock.
Do not over tighten.
G
G
G
G
8
4
4
4
8
G
G
8
2
2
2
Assembly Instructions
8
Step 9
Step 10
Fix metal bracket in
the base panel and
bottom front frame
using screws as
shown.
L
B
Fixing right side panel.
With help, place right side
panel properly
ensuring dowels and front
frames are all fit into their
holes at the same time.
Insert 2 locking nuts
into base panel where
shown.
Use a screwdriver to turn
locking nuts clockwise
to lock.
Do not over tighten.
G
G
G
G
4
B
B
7
G
G
2
7
2
4
2
L
L
Assembly Instructions
9
Step 11
Fixing top panel.
Important:
With help, carefully
stand the product upright.
With help, fit top panel
to the cabinet.
Insert locking nuts8
side p sinto anel and
middle wall panels where
shown.
Use a screwdriver to turn
locking nuts clockwise
to lock.
Do not over tighten.
1
Step 12
G
G
Fitting hinges to doors.
Attach hinges in the
pre marked holes on
doors using screws
as shown.
B
B
2x
I
I
I
1
G
G
G
G
G
GG
I
11
11
