Argos Lima User manual

MADE IN
BRITAIN
Dimensions
Width - 79.5cm
Depth - 39cm
Height - 51cm
Lima - Corner TV Unit
Assembly Instructions - Please keep for future reference
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 01/07/14
Important - Please read these instructions fully before starting assembly
276/4296
ALR3075

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 14kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: If there is any
chance of this unit being pulled
over by children etc. it is
recommended that the unit is
secured to a wall using suitable
fixings (not supplied).
• Dispose of all packaging
carefully and responsibly.
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
Note: If required the next page
can be cut out and used as
reference throughout the
assembly. Keep this page with
these instructions for future
reference.

Components - Panels
Please check you have all the panels listed below
2
1
3
80%
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Upright (D1319A)
(477 x 280mm)
Plinth (D1320A)
(721 x 96mm)
Top (D1315A)
(795 x 391mm)
Horizontal (D1318A)
(721 x 352mm) x 2
4
2
5
6Drawer Front (D1913A)
(717 x 200mm)
Left Drawer Side (W454LH)
(200 x 115mm)
Right Drawer Side (W454RH)
(200 x 115mm)
Drawer Base (T454)
(700 x 197mm)
Side (D1912A)
(477 x 230mm) x 2
Drawer Back (W454)
(689 x 115mm)
97
8
10

Please check you have all the fittings listed below
Tools required
3
Components - Fittings If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A
Wooden dowel (F22) x 2
B
Metal dowel (F901) x 14
C
D E
Large locking
nut (F900) x 12
F
G
Rule Scissors Hammer
Eye protection
(when using a
hammer or drill)
Cross-head
screwdriver
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
Small metal dowel (F893) x 4
Hollow core
locking nut
(F892) x 4
45mm Screw (F65) x 4
Small locking
nut (F3) x 2
I
19mm Screw (F461) x 2
H
Knock-in Peg (F171) x 4
M
Drawer runner (F307) x 2
J K
9mm Screw (F74) x 2 9mm Screw (F73) x 4
L
Handle (F306) x 1

Assembly Instructions
4
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Step 1
B
Prepare the drawer
front
Screw 2 metal dowels
into the holes shown on
the back of the drawer
front .
Note: Tighten metal
dowels up fully against
the panel.
B
6B
B
G
G
Prepare the drawer
sides
Insert a small locking
nut into the hole
shown on the left drawer
side and right drawer
side .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
G
7
8
Step 2
G
7
8
Note: Due to the manufacturing process, the holes for the
locking nut can be on either surface of the drawer sides.
Step 3
Attach the drawer
sides to the drawer
front
Push the left drawer side
. and right drawer side
. onto the back of the
drawer front .
Turn the small locking
nuts on the left
drawer side and right
drawer side .
Note: Turn the locking
nuts clockwise to
secure panels - more
than 1/2 a turn.
7
8
6
G
G
7
8
Note: The locking nuts can be on
either surface of the drawer sides.
Make sure that the small groove
is on the inside, as shown.
B
B
G
6
6
7
8
Small groove

H
H
Assembly Instructions
5
Step 4
6
7
Attach the handle
Attach the handle to
the drawer front
using 2 screws .
L
I
Step 6
6
Fit the drawer base
Slide the drawer base
down the grooves in the
drawer sides and
and down into the
groove in the drawer
front .
Step 5
Fit the drawer back
Fit the drawer back
between the drawer
sides and .
Make sure that the
drawer base fits into
the groove in the drawer
back .
Hold the drawer back
in position and tap the
knock-in pegs
through the holes in the
drawer sides and .
10
7 8
6
9
7 8
10
9
9
H
7 8
8
I
6
I
7
8
H
H
6
10
9
L

Assembly Instructions
6
Step 7
Prepare the left side
a: Place a runner
onto one of the sides .
Slide back the top of
runner and use the 2nd
hole from the front to fit
the 1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the side .
c: Screw 5 metal
dowels into the side
. .
Push 2 hollow core
locking nuts into the
side , making sure
that they are flush
against the panel’s
surface.
Using a hammer, tap in
the pin on the hollow
core locking nut .
Note: The pin should be
tapped in flush with the
top surface of the hollow
core locking nut .
D
DD
K
M
K
M
3
K
M
K
D
B
B
B
B
B
D
3
3
3
front edge
K
M
back edge
K
M
a:
b:
c:
B
3
D
3
D
D
3

Assembly Instructions
7
Step 8
Prepare the right side
a: Place a runner
onto one of the sides .
Slide back the top of
runner and use the 2nd
hole from the front to fit
the 1st screw .
b: Slide the runner
back the other way and
fit the 2nd screw into
the corresponding hole
in the side .
c: Screw 5 metal
dowels into the side
. .
Push 2 hollow core
locking nuts into the
side , making sure
that they are flush
against the panel’s
surface.
Using a hammer, tap in
the pin on the hollow
core locking nut .
Note: The pin should be
tapped in flush with the
top surface of the hollow
core locking nut .
D
DD
M
3
K
M
K
K
D
B
B
B
B
B
D
3
3
3
a:
b:
c:
B
3
D
3
D
D
3
K
Front edge
K
M
Back edge
K
M
M

Assembly Instructions
8
Step 9
Step 10
Prepare the top
Screw 2 metal dowels
into the top .
Screw 4 small metal
dowels into the holes
on the top .
Note: Tighten metal
dowels up fully against
the panels.
B
BB
E
E
E
E
E
1
B
1
E
1
Join the top to a side
Attach the top to the
right side .
Note: You will need to
slide the 2 small metal
dowels into the top of
the 2 hollow core locking
nuts .
Insert a screwdriver into
the 2 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
E
D D
1
3
1
3
E
D
D
Prepare the 2
horizontals
Insert 4 large locking
nuts into each
horizontal .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
C
C
C
C
C
2
C
2
x 2
Step 11

Assembly Instructions
9
Step 12
Step 13
Fit the other
horizontal
Push the other
horizontal onto the
right side .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the horizontal .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
2
3
C
2
C
2
3
Fit a horizontal
Push a horizontal
onto the right side .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the horizontal .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
2
3
2
3
C
2
C
C
C
A
A
10mm
A
Prepare the plinth
Tap 2 wooden dowels
into the plinth .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
Insert 2 large locking
nuts into the plinth
. .
A
5
C
5
5
Step 14

Assembly Instructions
Step 15
Step 16
5
3
Fit the plinth
Push the plinth onto
the right side .
Use a screwdriver to
tighten the large locking
nut fitted to the plinth
. .
Note: Turn the large
locking nut as far as it
will go - more than 1/2 a
turn.
5
3
C
5
C
Note: Support the plinth
until the side has been
fitted in the next step.
Fit the other side
Push the left side
onto the assembly.
Insert a screwdriver into
the 2 hollow core locking
nuts and turn the nuts
inside as far as they will
go.
Use a screwdriver to
tighten the 5 large
locking nuts fitted to
the 2 horizontals and
the plinth .
3
D
C
2
53
2
2
5
Step 17
C
C
Prepare the upright
Insert 2 large locking
nuts into the upright
. .
Note: The arrow on the
locking nuts must point
towards the hole in the
edge of the panel.
4
C
4
10

Assembly Instructions
11
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
and quote the reference numbers on the component pages.
Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW
Step 18
ALR3075
Fit the upright
Push the upright onto
the top .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the upright .
Note: Turn the large
locking nuts as far as
they will go - more than
1/2 a turn.
Screw through the 4
holes in the upright
and into the back edge
of the 2 horizontals
using screws .
Stand the unit up.
4
1
4
1
C
4
C
2
4
F
F
F
F
F
2
2
J
J
2nd threaded
hole
M
J
Step 19
Fit the drawer
Slide both of the runners
. forward and locate
the drawer sides and
. between them, lining
up the holes in the
drawer wrap with the
2nd 'threaded' holes in
the runners .
Working from the inside
of the drawer, insert 2
screws through the
drawer sides and out into
the 2nd threaded hole in
the runner.
Assembly is complete
M
J
7
8
Note: Do not overtighten the screws.
If they catch on the runner you may
need to loosen them slightly.
M
7
8
