Argos Marlow 413/1212 User manual

MADE IN
BRITAIN
Dimensions
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: [e-mail] (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
Important - Please read these instructions fully before starting assembly
Marlow - 3 Door Mirror Robe
Assembly Instructions - Please keep for future reference
ALR3183
413/1212
418/9563
417/4619
Issue 1 - 01/07/15
Width - 130.8cm
Depth - 49.5cm
Height - 191.8cm

Safety and Care Advice
Important - Please read these instructions fully before starting assembly
• Warning: This unit weighs
approximately 89kgs.
Please lift with care.
• Check you have all the
components and tools listed on
pages 2 and 3.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Parts of the assembly will be
easier with 2 people.
• Make sure you have enough
space to layout the parts before
starting.
• Do not stand or put weight on
the product, this could cause
damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor (use opened
out unit carton).
1
Care and maintenance
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Safety note: It is
recommended that this unit is
secured to a wall using the
overbalance protector kit
supplied or, an alternative fixing
method of your choice.
• Dispose of all packaging
carefully and responsibly.
Top (DF3921)
(130.8 x 49.5cm)
Base (DF3922)
(119.4 x 45.9cm)
Large Shelf (DF3930B)
(79.7 x 45.9cm)
Small Shelf (DF3932)
(38.2 x 45.7cm)
Foot (D3090)
(10 x 5cm)
Large Rail (DF3742)
(79.7 x 11.9cm)
Small Rail (DF3926)
(38.2 x 11.9cm)
12
5 6
3
4
9
Components - Panels
Please check you have all the panels listed below
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: [e-mail] (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
Large Hanging Rail (FHR791)
(79.1cm long)
8
Small Hanging Rail (FHR376)
(37.6cm long)
7

Components - Panels
Please check you have all the panels listed below
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: [e-mail] (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
2
10 11 12
80%
Left Side (DF3918B)
(180.3 x 41.3cm)
Right Side (DF3919B)
(180.3 x 41.3cm)
Divider (DF3931)
(178.75 x 45.8cm)
Plain Door (DF3920)
(180 x 39.4cm) x 2
Mirror Door (DF3939)
(180 x 39.4cm)
(Mirror - SG27
175.5 x 38.8cm
Safety Back SAR)
Large Back (X1798-823)
(179.8 x 82.3cm)
Small Back (X1798-401)
(179.8 x 40.1cm)
14 15 16 17
Leg (DF3631)
(190.3 x 5cm) x 4
13

Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
Components - Fittings
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: [e-mail] (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
3
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
A B
D E F
G H I
G H I
L
C
Nail (F51) x 40
J K
38mm Screw (F81) x 36
Large locking
nut (F900) x 16
Metal dowel (F901) x 10 Wooden dowel (F22) x 19
19mm Screw (F461) x 4
M
40mm Screw (F910) x 9
Rail Holder
(F891) x 4
13mm Screw (F63) x 28
Handle (F449) x 2
Hinge plate
(F523) x 10 Hinge (F522) x 10
Strap Screw Washer x 2
Overbalance protector kit (F269) x 1
N
O P
Back holder (F276) x 6
*These can
also be round
Nail screw (F277) x 6
Large wooden dowel (F40) x 3
Q
Double metal dowel (F566) x 3
Tools required
Scissors / Rule / Hammer / Cross-head screwdriver / Square / Spirit level / Step ladder
Eye protection (when using a hammer or drill) / Electric drill (only use when drilling into walls)

Assembly Instructions
4
Step 1
Fit 2 legs to the left
side
Screw 2 legs to the
left side using 18
screws .
Note: The top of the
legs must be flush with
the top of the left side.
G
13
10
Step 2
Fit 2 legs to the right
side
Screw 2 legs to the
right side using 18
screws .
Note: The top of the
legs must be flush with
the top of the right side.
G
13
11
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
10
13
13
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
11
13
13

Front
edge
C
C
C
C
Assembly Instructions
5
Step 3
10mm
C
A
I
D
I
D
K
Prepare the left side
Screw 5 metal dowels
into the left side .
Note: Tighten the metal
dowels up fully against
the panels.
Tap 2 wooden dowels
into the left side .
Note: Wooden dowels
must not stick out from
the edge by more than
10mm or they may
damage other panels.
To fit the rail holder ,
screw through the top
hole with screw and
into the mark hole drilled
in the left side . Make
sure that it is fitted
straight, in line with the
panel edges and then fit
another screw using
the lower hole.
Fit 3 hinge plates onto
the left side , making
sure that the slot is
facing towards the front
edge.
A
10
C
10
D
I
I
10
K
10
K
Step 4
Prepare the right side
Use the same fittings you
used for the left side to
prepare the right side .
11
10
K
K
K
A
A
A
A
I
I
D
11
A
A
A
II
D
K
K
K
A
AFront
edge
A

Finished
front edge
C
C
Assembly Instructions
6
Step 5
K
K
K
K
I
I
D
C
C
Prepare the divider
a: Tap 4 wooden dowels
. into the divider .
To fit the rail holder ,
screw through the top
hole with screw and
into the mark hole drilled
in the divider . Make
sure that it is fitted
straight, in line with the
panel edges and then fit
another screw using
the lower hole.
Fit 4 hinge plates onto
the divider , making
sure that the slot is
facing towards the
finished front edge.
Turn the divider over
b: Fit another rail holder
. , through the top hole
with screw and into
the mark hole drilled in
the divider . Make
sure that it is fitted
straight, in line with the
panel edges and then fit
another screw using
the lower hole.
C12
D
I
K
I
12
D
I
I
12
12
a:
b:
Turn the divider over
12
12
I
I
D
Finished
front edge

Finished
front edge
12
Finished
front edge
Assembly Instructions
7
Step 6
C
Prepare the base
Insert 4 large locking
nuts into the base .
Note: The arrow on the
locking nut must point
towards the hole in the
edge of the panel.
Tap 4 wooden dowels
into into the base .
B
BB
B
C
B2
C
2
6
Finished
front edge
C
B
B
C
B
B
C
C
2
Fit the base to the
divider
Attach the base to
the divider using 2
screws .
F
F
Finished
front edge
2
Step 7
Step 8
Step 6
2
12
F
A
A
Prepare the foot
Tap a wooden dowel
into the foot .
C
9
9
9
Prepare the small
shelf
Insert 4 large locking
nuts into the small
shelf .
Tap 2 wooden dowels
into small shelf .
B
6
C
6

Finished
front edge
C
Assembly Instructions
8
Step 9
Q
N
a:
c:
Fit the small shelf
a: Position the small
shelf up against the 4
holes in the divider .
b: Tap 2 double metal
dowels through the
divider and into the
small shelf until they
‘’bottom out’’.
Tap 2 large wooden
dowels through the
divider and into the
small shelf until they
‘’bottom out’’.
c: Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the small shelf .
6
6
12
12
Q
N
B
12
6
6
6
12
Q
b:
N
Q
N
B
Prepare the small rail
Insert 2 large locking
nuts into the small rail
. .
Tap a wooden dowel
into small rail .
B
4
C
4
Step 10
B
Finished
front edge

Assembly Instructions
9
Step 11
Step 12
Step 6
A
A
Prepare the foot
Tap a wooden dowel
into the foot .
C
9
9
9
Fit the right side
Note: To make the
assembly easier, place
polystyrene blocks from
the packaging
underneath the base and
divider panels to raise
the assembly.
Push the right side
onto the assembly.
Use a screwdriver to
tighten the 5 large
locking nuts fitted to
the base , the small
rail and the small
shelf .
Q
N
a:
Fit the small rail
a: Position the small rail
. up against the 2
holes in the divider .
b: Tap a double metal
dowel through the
divider and into the
small rail until it
‘’bottoms out’’.
Tap a large wooden
dowel through the
divider and into the
small rail until it
‘’bottoms out’’.
c: Use a screwdriver to
tighten the large locking
nut fitted to the small
rail .
4
4
12
12
Q
N
B
12
4
4
b:
c:
12
4
Note: Support the
small rail until the
right side has been
fitted in the next step.
11
B
2
4
6
11
2
4
6
Polystyrene
block
Polystyrene
block

Finished
front edge
Assembly Instructions
10
Step 13
B
B
C
Finished
front edge
3
Prepare the large rail
Insert 2 large locking
nuts into the large rail
. .
Tap a wooden dowel
into large rail .
B
3
C
3
B
B
B
B
5
Finished
front edge
Prepare the large
shelf
Insert 4 large locking
nuts into the large
shelf .
Tap 2 wooden dowels
into large shelf .
B
5
C
5C
C
Step 14
Fit the right side
Push the large shelf
onto the divider .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the large shelf .
Step 15
5
12
B
5
5
12
Polystyrene
block

Assembly Instructions
11
Step 16
Step 17
Fit the left side
Push the left side
onto the assembly.
Use a screwdriver to
tighten the 5 large
locking nuts fitted to
the base , the large
rail and the large shelf
. .
12
Fit the large rail
Push the large rail
onto the divider .
Use a screwdriver to
tighten the 2 large
locking nuts fitted to
the large rail .
3
12
B
3
3
Note: Support the
large rail until the left
side has been fitted
in the next step.
10
B
2
3
5
10
2
3
5

Assembly Instructions
12
Step 18
Step 19
F
2
C
C
Prepare the foot
Tap a wooden dowel
into the foot .
C
9
9
9
9
Fit the foot
Push the foot onto
the base and secure
it using screw .
Step 20
2
9
F
F
F
Finished
front edge
F
F
F
Fit the top
Attach the top to the
sides and and the
divider using the 6
screws .
F
1
10
12
11
F
1
10
12
11

yy
yy
xx
xx
Assembly Instructions
13
Step 21
Fit the 2 back panels
a: Square up the unit by
making sure that
measurement x:x equals
y:y.
Place the small back
and large back ,
coloured surface facing
down, onto the unit as
shown.
Make sure that the 2
backs are pushed up
tight against each other
and that they meet in the
centre of the divider’s
back edge.
b: Nail around the
outside edges of the 2
backs.
Note: Do not nail where
the 2 backs meet.
c: Push the nail screws
. through the back
holders and tap them
down between the small
back and large back
. and into the back
edge of the divider .
Keep tapping the nail
screws in until the
back holders dig into
the small and large back.
Carefully stand the
unit up for the next
step.
16
17
E
O
P
16
17
12
O
P
Note: If ever you need to take
the backs off to dismantle the
unit, the nail screws can be
taken out using a screwdriver.
O
P
The measurement from top corner X to bottom corner X must be
equal to the measurement from top corner Y to bottom corner Y
a:
Note: These can
also be round
PO +
c:
O
P
16
17
P
b:
E
16
17
Warning: The
unit is heavy.
Lift with care.

Assembly Instructions
14
Step 22
87
D
Fit the hanging railS
Push the 2 hanging rails
. and into the rail
holders .
7 8
D
8
7

Assembly Instructions
15
Step 23
Prepare the 2 plain
doors
Push fit 3 hinges into
each of the 2 plain doors
. .
Secure each hinge with
2 screws .
Note: Before securing
with the screws, make
sure that the hinges are
positioned at 90 degrees
with the edge of the
door.
I
L
14
Step 24
Prepare the mirror
door
Push fit 4 hinges into
the mirror door .
Secure each hinge with
2 screws .
Note: Before securing
with the screws, make
sure that the hinges are
positioned at 90 degrees
with the edge of the
door.
I
L
15
L
I
I
90
L
x 2
L
I
I
L
I
I
8
L
I
I
L
I
I
L
I
I
L
I
I
Warning:
Glass! Handle
with care
15

Assembly Instructions
16
Step 25
Fit doors and handles
Note: The easiest way to
attach each door and
. is to fit the top hinge
first, then align and fit the
other hinges.
a: Push the hinge
onto the front part of the
hinge plate .
The recess at the bottom
of screw B goes into the
slot in the hinge plate.
b: Keep the hinge
FLAT against the hinge
plate as you slide it
across as far as it will go.
Tighten screw A.
c: The hinge must be
flat against the hinge
plate prior to any
adjustment.
d: The hinge must
NOT be AT AN ANGLE
to the hinge plate
when assembled.
This would indicate that
the recess at the bottom
of screw B had not
located in the slot in the
hinge plate and the hinge
would not be secure.
Remove the hinge from
the hinge plate and then
re-assemble being
careful to follow
instructions a-c.
e: Attach a handle to
each of the 2 plain doors
. using screws .
L
L
L
K
K
K
L
K
J
H
14
14
a: b:
c: d:
K
L
K
K
B
K
L
L
L
A
L
K
B
e:
H
H
J
14
14
15
Warning:
Glass! Handle
with care
15
J

Assembly Instructions
17
Step 26
b:
c:
d:
a:
Adjust the doors if
needed
a: Before adjusting the
doors, use a spirit level
to check the base (or
top) of the unit is level,
front-to-back and
side-to-side in the 3
positions shown.
Use suitable packing
pieces (not supplied) to
make the unit level
BEFORE making any
adjustment to the hinges,
as shown.
b: Height adjustment.
Loosen screws A on
hinge plates and move
door up or down as
required.
Retighten screw A.
c: Forward and Back
adjustment.
Loosen screw B on hinge
plate and move door in
or out as required.
Retighten screw B.
d: Sideways
adjustment.
To move door ‘out’
loosen screw C.
To move door ‘in’ tighten
screw C.
A
A
B
C

Assembly Instructions
18
Step 27
Fit the overbalance
protector
To prevent possible
overbalancing we
recommend that this unit
is secured to a suitable
wall by fitting of the
overbalance protector kit
. to the unit, or an
alternative fixing method
of your choice.
Wall fixings are not
supplied as they will
need to suit the wall
type.
Note: Take care when
drilling the wall that you
do not drill into any
pipes, wires etc.
If in doubt, consult an
expert.
M
M
WALL
Wall fixing
(not supplied)
Screw
(not supplied)
Washer
Strap
M
Strap
Washer
Screw
TOP OF UNIT
M

Assembly Instructions
19 ALR3183
Step 28
Assembly is complete
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: [e-mail] (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
IMPORTANT INFORMATION ABOUT THIS PRODUCT
This product complies with the requirements of BS 7449:1991 and has been manufactured by
DECORATIVE PANELS FURNITURE LTD, TEESSIDE INDUSTRIAL ESTATE,
THORNABY-ON-TEES, CLEVELAND, TS17 9LT .
The product code for this unit and the item code(s) for the glass components are listed in the Assembly
Instructions along with a description of the type of glass used. All clear/tinted glass complies with the
requirements of BS 6206 Class A. All mirrors comply with the requirements of BS 6206 Class C. If the
glass component contained in this unit is chipped or broken consult the furniture manufacturer, retailer,
or agent with regard to obtaining a manufacturing specification and shape for replacement glass
quoting the unit description and batch number or date of manufacture.
Do not place very hot or very cold items against or in close proximity to glass surface(s) unless
adequately thick insulating material is used to prevent such items coming in contact with the glass.
Do not strike the glass with hard or pointed items.
Do not sit or stand upon horizontal glass surfaces.
When cleaning glass panels use a damp cloth or leather with washing up liquid or soft soap if
necessary - do not use washing powders or any other substance containing abrasives since these
substances scratch glass.
If stated in the instruction leaflet, it is essential that this unit is fixed to a wall.
KEEP THESE INSTRUCTIONS FOR FUTURE USE
