Argos PAT88V3FP User manual

HARTLEBURY TRADING ESTATE, HARTLEBURY, WORCS DY10 4JB
Patio Deck Kit 8’ X 8’
Should you require any additional guidance with the assembly of your arbour please contact our technical help line
on 0844 248 9853 between the hours of 8:30am and 5:00pm Monday-Friday.
Thank you for choosing this deck kit from the U.K.’s largest manufacturer of timber garden products. In order to gain the most benefit from it, please
note the following :
1) Please take time to read the assembly instructions carefully before erecting the deck, and check all parts prior to assembly. Neither refunds nor
replacements can be offered if the product is incorrectly assembled.
2) In line with your statutory rights, please check all parts prior to assembly, as assembly of damaged parts may be deemed to be acceptance and this may
effect the remedies you are entitled to. If the product is not constructed in accordance with the instructions or is altered in anyway (eg painted), the
manufacturer cannot be held liable for any resulting damage.
3) All holes should be pre-drilled in order to prevent wood from splitting.
4) Please take care to keep all plastic bags and small parts away from children to minimise the risk of suffocation.
5) This product is pressure treated to ensure longevity of all timber components and protect against rot. This may leave a colour difference in some parts
that will even out as the moisture contents stabilises.
Important : Assembly of this deck requires two
people.
Assembly should take approximately ½ a day.
Fixings Included
60mm
Components Included
VDB24BI (QTY 28)
PAT88V3FP
DRILL POZI DRIVE SCREWDRIVER
TAPE MEASURE
Required Tools : (Not Supplied )
SPIRIT LEVEL
Step 1
Repeat along this side with 60mm screws
Issue 0112
40mm
HANDRAIL SUPPORT
FSDDPTR (QTY 4)
HANDRAIL LONG
FSDHRPTR (QTY 2)
BALUSTER
BAL900BI (QTY 44)
UPRIGHTS
NDP9595BI (QTY 3)
448
448
448
448
448
2400
2440
1358
2400mm
100mm
6
8
Note that 8 of the boards
are used to make the base.
Fix using 24 x 60mm screws.
VDB24BI
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
SAW
MUST PRE DRILL
DECK PROFILE
60mm x 2
60mm x 2
60mm x 2
60mm x 2
60mm x 2
60mm x 2
2400
MUST PRE DRILL
70mm
36
8
PAT88V3FP
457
448
457
448
457
448
457
448
457 60mm
50mm
320

Step 2
IMPORTANT : PRIOR TO PROCEEDING PLEASE MEASURE DIAGONALS. BOTH DIAGONALS MUST BE EQUAL IN
ORDER TO ENSURE THE DECK IS SQUARE.
Step 3
Position uprights ( ) As shown on top of the boards to the outside edge of the deck. Secure
using 2 x100mm bolts for each.
NDP9595BI
Issue 0112
50mm x 2
50mm x 2
50mm x 2
50mm x 2
50mm x 2
50mm x 2
50mm x 2
50mm x 2
50mm x 2
50mm x 2
50mm x 2
50mm x 2
Fix using 24 x 50mm screws.
MUST PRE DRILL
MUST PRE DRILL
50mm

Position the rest of the Deck boards ( ) Equally spacing them across the entire deck.
Secure to each supporting deck board using 2x50mm screws on each,
VDB24BI
Step 4
Issue 0112
Fix using 216 x 50mm screws
50mm

2248mm
2305mm
765
50
Position a handrail support
( ) on top of the
blocks. You will need to cut
down the rail supports and
handrail to the sizes shown
on the assembly below in
order for them to fit between
the uprights. Secure the
support either end with
1x70mm screw
DR7028BI Cut 4 balusters you have
already trimmed to 785mm
and place these on top of
the supports. Secure using
2 x 60mm screws one at the
top and one at the bottom of
the trimmed batten.
Position the second correctly sized Handrail
support onto the trimmed battens and secure in
the same manner as the bottom Hand Rail
Support.
Attach the correctly sized Handrail to the top
using 4 x 40mm screws evenly space across
each Handrail.
Attach the remaining Baluster’s (BAL900BI) evenly across each Handrail assembly. Secure using
1x50mm screw top and bottom. Make sure the gaps are evenly spaced but the gaps are no greater
than 99mm.
Step 5
Step 6
Cut 50mm off four of the
balusters ( ).
Attach the 50mm block to
the outer edge of the
uprights on top of the
decking. Secure using
1x60mm screw for each.
BAL900BI
Issue 0112
70mm
60mm
40mm
785
50mm
Fix using 80 x 50mm screws
93mm
93mm
93mm
93mm
