INTRODUCTION：
Congratulations on your selection of the ARISTEL DV-22 SOHO System!
ARISTEL DV-22 is a state-of-the-art communication system that offers you unique features,
flexibility and superb service in your office or in your home.
ARISTEL DV-22 system’s digital technology extends well beyond handling just
conventional phone calls. Computers, paging systems, fax machines, sensors, modems,
door phones and even door latches can be connected and controlled through this unique
system which is designed to suit your requirements today and grow with your business
tomorrow.
The available capacity is 3-6 CO lines, 8-16 station ports together with a RS-232 port.
Multi-function card ports such as door phone port, paging port, external music port, sensor
and a switch are all powerful options to enhance your communication system.
This manual will provide you with detailed instructions and procedures for the successful
installation of the ARISTEL DV-22 SOHO system. Please read this entire section before
proceeding with the actual installation.
In case you have any other questions, please phone Aristel Tech Support.
Aristel Networks Pty Ltd
3

System Installation Manual
Digital Key Telephone System
22
DV
1. System Summary
1.1 Hardware Configuration
zSystem capacity：308~616
zSystem Control：Stored Program Control (SPC)。
z”A-SERIES ” ASIC IC
6A
zSMT interface agglutinate technology
zStationary trough interface installation, Main systematic and Internal/External Lines
independent of each other
1.2 System Software
zBuilt-in programming：Store in ROM
zSystem Operation programming：Store in RAM
zSoftware Security Element：Watch Dog
zProgramming security：Back up by “Li-Battery”
zKey phone operation security：Error operation recovery protection program.
zExtension Error Action Protection：Extension error action protection mode
1.3 Safety Conformity
zFCC、CE、AUSTEL、TAS、SIRIM
zInternal/External Lines Short Circuit Protection
zPower Mingled Dispatch Restraint
zLightning Protection
zPower Fluid Transformation : AC110 ~ AC240
zKEY PAD Endurance：1,000,000 Times
Aristel Networks Pty Ltd
4

System Installation Manual
Digital Key Telephone System
22
DV
2. Hardware Configuration
2.1 System Specifications
The system uses fixed slot design - all expansion cards have to connect to designated
slots.
5
DV-22 Basic Capacity
Expansion
Capacity Max. Capacity
CO Line 3 3 6
Key Telephone 8 6 / 8 16
Single Line Telephone 0 1 / 2 / 4 / 8 8
Door Phone Connection 0 1 1
Relay Interface 0 1 1
Sensor Interface 0 1 1
Auto Attendant 0 1 / 2 2
RS232 for SMDR 0 1 1
Speed Dial set 1000 0 1000
1 1 2
Power Failure Telephone interface
Virtual Extensions 16 - 16
Aristel Networks Pty Ltd

System Installation Manual
Digital Key Telephone System
22
DV
2.2 ELECTRICAL SPECIFICATIONS
Input AC Voltage AC110~240V
Key Telephone 1~2 W
6
Door Phone 0.5 W
Power
Consumption Maximum 40 W
System Power Back-Up Battery 4 ~ 5 Hour (24 V 7AH)
CO Line 1.5K Ωmax.
Key Telephone 40 Ωmax.
Loop
Resistance Door Phone 40 Ωmax.
Outgoing Dialing Tone / Pulse
Dialing Signal Intercom Dialing Tone / Pulse / Digital
CO Line/Key Telephone 2 wires
Door Phone 2 wires
Relay Switch 2 wires
Wiring
Installation
External Music/paging 2 wires
Type SPDT
Relay Switch Contact Capacity 120V × 7A max.
System Dimension (mm, W×D×H) 310 ×205 ×70 mm
Key Telephone Dimension (mm) 200L ×180W ×75H mm
0
Working Temperature 0 C ~ 45 0C (32 0F ~ 113 0F)
Working Humidity 10% ~ 90% relative non-condensing
Aristel Networks Pty Ltd

System Installation Manual
Digital Key Telephone System
Aristel Networks Pty Ltd
7
22
DV
2.3 KEY TELEPHONE SPECIFICATION
Model DKP70X DKP73 DKP51 DKP53
Flexible DSS Key 10 Keys 20 Keys 20 Keys 20 Keys
9
LCD (16 × 2) … Large LCD Large LCD
9999
Handsfree Dialing
9999
Direct Intercom dialing
9999
Optical hook switch
Dual Color LED
indicator 10 Keys 20 Keys 20 Keys 20 Keys
Digital Volume Control 8 levels 8 levels 8 levels 8 levels
Short-circuited
Protection 9999
99
Handsfree Conversation ... …
9999
One-Touch Paging
9999
Last outgoing Redial
Calculator …
999
Individual Speed Dial 20 sets 20 sets 20 sets 20 sets
Different Ringing
Frequencies 9 selections 9 selections 9 selections 9 selections

System Installation Manual
Digital Key Telephone System
Aristel Networks Pty Ltd
8
22
DV
2.4 System Model Description
Model No. Description
MAIN SERVICE UNIT, consisting of (Plastic Cabinet + D4MBUA+A7PWUA)D4-308K
D4PWUA POWER UNIT
MOTHER BOARD UNIT, consisting of (3 CO Lines + 8 Digital Key Stations Ports)D4MBUA
MOTHER BOARD UNIT, consisting of (3 CO Lines + 8 Digital Key Stations Ports), with
RS-232 interface.
D4MBUB
CO Trunk CARD, consisting of 3 CO LinesD4TKUB
Key Station Card, consisting 8 Digital Key Station Ports.D4DLUB
HYBRID STATION UNIT, consisting of 6 Digital Key Station+2 SLT Station port)D4HYUB
SLT STATION CARD, consisting of 8 SLT Station PortsD4SLUB
SLT STATION CARD, consisting of 4 SLT Station PortsD4SLCC
SLT STATION CARD, consisting of 1 SLT Station PortsD4SLCD
VOICE SERVICE CARD, consisting of 2 Voice Channels (60 seconds)D4VSCA
VOICE SERVICE CARD, consisting of 1 Voice Channel (60 seconds)D4VSCB
VOICE SERVICE CARD, consisting of 2 Voice Channels (60 seconds) with Fax Detection
function
D4VSCC
MULTI FUNCTION CARD, consisting of (1 Sensor + 1 Relay + 1 Door Phone Port)D4MFCA
MULTI FUNCTION CARD, consisting of 1 Door Phone PortD4MFCB
D1CIDC FSK/DTMF CLI INTERFACE

System Installation Manual
Digital Key Telephone System
Aristel Networks Pty Ltd
9
22
DV
zPrivate Line
2.5 System Features List zProgramming Help List
z2 Pages of DSS Keys Remote Programming
z5 Different Trunk Access Codes Remote Relay Control
z9 Different Incoming Ringing Frequencies Security/Fire Alarm System
zAccount Code zSingle Digit Dialing
Auto Attendant Station Loud Bell
zAuto Accessing Trunk Station Message Details Report
(SMDR)
zAutomatic Answer (Intercom)
Automatic Call Distribution (ACD) zSystem Alarm
zAutomatic Transfer zToll Restriction
Baby Listening zTone/Pulse Dialing
Caller’s Number Identification zTrunk Grouping
zCall Limit Time Duration Trunk Loud Bell
zCall Park zTrunk Queuing
zCall Split
zConsole Grouping
zDate/Time Setting
zDay/Night Schedule
zDirect Intercom Dialing
zDirect Inward Station Access (DISA)
Door Phone Connection
Door Switch Control
Environment Monitor Means the optional function.
Fax Call Detection
zFlexible Function Key Assignment
zForced Account Code
zHeadset Function
zHot Line
zIllegal Outgoing Prohibit
zIntercom Busy Reminder
zIncoming Hunting
zIncoming Paging
zIntercom Hunting
zInternal/External Music Source
zInternal/External Paging
zKey Station Short Protection
zLightning Protection
zMessage Waiting
zName Speed Dialing (Phone Book)
zOne Touch Operation
zPower Failure Telephone

System Installation Manual
Digital Key Telephone System
Aristel Networks Pty Ltd
10
22
DV
2.6 Station Features List Handsfree Conversation
z16×2 Dot-Matrix LCD Display zHold/Exclusive Hold
z5 Different NumbersAuto Redial zLast Outgoing Redial
z9 Different Ringing Frequencies on Key Station zMacro Key Setting
zAdjustable LCD Angle zMessage Text
zBuilt-In Calculator Function (25 Buttons LCD
Phone) zMonitor
zOverride
zCall Forward/Call Follow Me zPage/Be Paged
zCall Forward To Individual Speed Dial zStation Lock/Unlock
zCall Pick Up zStation Name Setting
zCall Transfer zStation Operation Help List
zCamp On
zDay/Night Service Indication
zDigital Volume Control (8 Levels)
zDo Not Disturb means the optional function.
zDual-Color/Tri-Status BLF Indication
DSS Console
zHandsfree Dialing

System Installation Manual
Digital Key Telephone System
22
DV
3. Equipment Requirement:
3.1 Preparation:
Survey the capacity of system and telephone.
Survey the wiring and terminals.
Carefully study and follow this manual before installation.
3.2 Environment Requirement:
Input Voltage：AC110~240V
System Power Back-up Battery：Connect with DC24V power source to the battery
back-up interface to ensure a continuous supply of power during a power failure.
3.3 Cable Requirement：
CO Line：2 wires
Key Telephone：2 wires
SLT：2 wires
Door Phone：2 wires
Relay Switch / Sensor：2 wires
External Paging / External music：2 wires
3.4 Notice:
The main unit should be installed in a clean, dry, dust-free and secure location. Place at
least 10cm above the ground to avoid vibration.
Install in a well ventilated environment and away from direct sunlight.
Install main unit in the center position of the extensions to shorten the distance between
main unit and extensions.
The power supply must be independent from the others. And keep away from high
frequency sources and noise to avoid interference from EMI.
Aristel Networks Pty Ltd
11

System Installation Manual
Digital Key Telephone System
22
DV
Use three-aperture outlet. (Include ground connection)
Install lightning rod ground wire to ensure stability of system.
Use twin wire to avoid noise and interference when the wiring is too long.
Keep away from the power cord and interference source. Otherwise, it’s necessary to
use segregated wire and install a ground wire.
Aristel Networks Pty Ltd
12

System Installation Manual
Digital Key Telephone System
22
DV
4. DV-22 PCB AND CABINET LAYOUT
4.1 DV-22 SYSTEM DIAGRAM
Figure 1: DV-22 Diagram
1. System Dimension：306 x 205 x 70mm
2. System AC Input：110~240VAC
3. External Backup Battery Input : 24VDC
Aristel Networks Pty Ltd
13

System Installation Manual
Digital Key Telephone System
Aristel Networks Pty Ltd
14
22
DV
4.2 D4PWUA – Full Range Power Adaptor
Figure 2: DV-22 power adaptor D4PWUA front view
1. AC Input：110~240VAC Full range
2. DC Output：28VDC

System Installation Manual
Digital Key Telephone System
22
DV
4.3 D4MBUB(C) (Mother Board Unit)
1
3
2
5
7
4
6
8
9
10
13
14
11
15
12
Figure 3: DV-22 Mother board Unit (D4MBUB)
1. CPU
2. System Software EEPROM
3. System Software RAM backup battery Switch
4. System Software RAM backup battery
5. Key phone port connector
6. Trunk port connector
7. D4VSCA card connector
8. Standard card expansion connector
9. D4PWUA power adapter connector
10. D4MFCA/D4MFCB Multi-function card connector
11. D4TKUA trunk expansion connector
12. System working Indicator
13. Music on hold Switch (Internal/ External)
14. The volume controller of the Internal Music on hold
15. Battery Reverse Protect Fuse: 2A/250V
Aristel Networks Pty Ltd
15

System Installation Manual
Digital Key Telephone System
22
DV
4.4 D4TKUB (Trunk Unit)
2
1
Figure 4: DV-22 CO Trunk Card Unit (D4TKUB)
1. For D4MBUB connection.
2. RJ-12 Connectors for CO Line Connection
NOTE：D4TKUB（CO Trunk CARD）consists of 3 CO Lines
REFER TO PAGE 23 FOR CONNECTION DETAILS
Aristel Networks Pty Ltd
16

System Installation Manual
Digital Key Telephone System
22
DV
4.5 D4DLUB（Key Station Card）
2
1
Figure 5: DV-22 Key Station Card Unit (D4DLUB)
1. For D4MBUB connection.
2. Quick-Connector Module for Key phone connection,（Use 2-wire T/R）, including 4
sets of 6 wires RJ-12 Connector.
NOTE：D4DLUB（Key Station Card）consists of（8 Digital Key Station Ports）
REFER TO PAGE 24 FOR CONNECTION DETAILS
Aristel Networks Pty Ltd
17

System Installation Manual
Digital Key Telephone System
22
DV
4.6 D4SLCC (SLT Station Card)
2
1
Figure 6: DV-22 SLT Station Card Unit (D4SLCC)
1. For D4MBUB connection.
2. Quick-Connector Module for Single Line phone connection（Use 2-wire T/R）,
including 2 sets of 6-wire RJ-12 connector.
NOTE：D4SLCC (SLT Station Card) consists of 4 SLT Station Ports.
D4SLCD (SLT Station Card) consists of 1 SLT Station Port.
Aristel Networks Pty Ltd
18

System Installation Manual
Digital Key Telephone System
22
DV
4.7 D4HYUB（Hybrid Station Unit）
1 2
Figure 7：DV-22 Hybrid Station Unit
1. For D4MBUB connection.
2. Quick-Connector Module for Key Station Wiring, or Single Line Telephone (Use
2-wire T/R), including 4 sets of 6-wire RJ-12 connector.
NOTE：D4HYUB (Hybrid Station Unit) consists of 6 Digital Key Station + 2 SLT
Station ports.
Aristel Networks Pty Ltd
19
