ARJO HUNTLEIGH Maxi Sky 2 User manual

4
Connect the sling loops or
clips to the spreader bar.
1
Place the sling around the
patient. For sling with head
support make sure it extends
to top of patient’s head.
2
Approach the lift. Place spreader
bar at shoulder level and close
enough to attach shoulder
straps.
Attach and secure the
clip at the lug before
patient is lifted.
3
Place attachment
loop on the hook.
Make sure that the
safety latch is
closed.
Clip sling Loop sling
For the DPS spreader bar and clip sling,
tilt the spreader bar to attach the leg
clips.
56
Raise the patient.
8
Lower until no tension. Detach
loops or clips.
Move the patient.
7
001-15772-EN Rev 0 • 05/2020 • Page 1/4
QUICK REFERENCE GUIDE - USE
Maxi Sky 2
Transfer from seated position

4
Connect the sling loops or clips to
the spreader bar.
Attach shoulder straps then leg
straps.
1
Place and centre the sling
under the patient. For sling
with head support make
sure it extends to top of
patient’s head.
2
Position lift over the patient. Attach and secure the
clip at the lug before
patient is lifted.
3
Place attachment
loop on the hook.
Make sure that the
safety latch is
closed.
Clip sling Loop sling
5
Raise patient.
6
Move the patient. Lower patient onto new location.
7 8
When the patient's body weight is fully
supported, detach the loops or clips.
001-15772-EN Rev 0 • 05/2020 • Page 2/4
Transfer from supine position

1
Place sling under the patient and
position the lift over the patient.
1
Place sling under the patient and
position the lift over the patient.
3
Attach as many sling loops as
possible from one side to the
spreader bar. Start with the
loops at the head end.
4
Raise until hips are
supported and move
up.
2
Loop sling
Lower patient onto new
location and detach all loops.
5
Attach as many sling loops
as possible to the spreader
bar. Start with the loops at
the head end.
3
2
Loop sling
Lower until no tension and
disconnect all loops.
54
Raise until patient is rolled
into wanted position.
Place attachment
loop on the hook.
Make sure that the
safety latch is
closed.
Place attachment
loop on the hook.
Make sure that the
safety latch is
closed.
001-15772-EN Rev 0 • 05/2020 • Page 3/4
Repositioning - move up in bed
Repositioning - bed turning

1
Place sling under the patient, make sure
to identify head end of sling.
2
Position lift over the patient.
4
Lower stretcher frame carefully and align
centre of frame with patients navel.
Attach all sling loops.
5
Raise and move the patient away
from the bed.
3
Loop sling
Place attachment
loop on the hook.
Make sure that the
safety latch is
closed.
ArjoHuntleigh AB
Hans Michelsensgatan 10
211 20 Malmö, Sweden
www.arjo.com 001-15772-EN Rev 0 • 05/2020 • Page 4/4
Transfer patient in supine position
6
Transfer the patient.
7
Lower patient onto new location
and detach all loops.
8
Move frame away from the patient.
