ARJO HUNTLEIGH Maxi Transfer Sheet User manual

...with people in mind
Maxi Transfer Sheet
04.AK.01_6GB • September 2012
04.MT.00-GB_8 • 06/2018
INSTRUCTIONS FOR USE

WARNING
To avoid injury, always read this Instructions for Use and accompanied documents
before using the product.
Mandatory to read the Instructions for Use
Design Policy and Copyright
® and ™ are trademarks belonging to the ArjoHuntleigh group of companies.
© ArjoHuntleigh 2013.
As our policy is one of continuous improvement, we reserve the right to modify designs
without prior notice.The content of this publication may not be copied either whole or in
part without the consent of ArjoHuntleigh.

3
Contents
Foreword ...................................................................................4
Intended Use .............................................................................5
Safety Instructions .....................................................................6
Preparations ..............................................................................7
Parts Designation/Description ...................................................8
Maxi Transfer Sheet Size ..........................................................9
Allowed Combinations .............................................................10
To Apply/Change the Maxi Transfer sheet ..............................11
Loop Detachment ....................................................................12
Loop Attachment .....................................................................12
Stretcher Frame .......................................................................13
Horizontal Lateral Transfer ..................................................13
To Move the Patient Upwards in Bed ..................................15
To Weigh the Patient ...........................................................16
To Lift a Patient from the Floor ............................................18
Spreader Bars .........................................................................20
Lateral Transfer Between Adjacent Surfaces ......................20
To Move the Patient Upwards in Bed ..................................22
To Turn the Patient in Bed ...................................................24
To Apply/Remove an X-ray Image Plate ..............................26
Cleaning and Disinfection Instructions ....................................28
Care and Preventive Maintenance ..........................................29
Troubleshooting .......................................................................30
Technical Specifications ..........................................................31
Maxi Transfer sheet Label .......................................................32
ArjoHuntleigh Addresses .............................................Last page

4
Foreword
Thank you for purchasing ArjoHuntleigh
equipment.
Please read this Instructions for Use (IFU)
thoroughly!
ArjoHuntleigh will not be held responsible for any
accidents, incidents or lack of performance that occur as
a result of any unauthorized modification to its
products.
Customer Support
If you require further information, please contact your
local ArjoHuntleigh representative. The contact
information (ArjoHuntleigh Addresses) is listed on the
last page of this IFU.
Definitions in this IFU
Means: Safety warning. Failure to understand and obey
this warning may result in injury to you or to others.
•
Means: Failure to follow these instructions may cause
damage to all or parts of the system or equipment.
•
Means: This is important information for the correct use
of this system or equipment.
•
Means: This is information that will ease a certain task
in the work flow.
Means: The name and address of the manufacturer.
WARNING
CAUTION
NOTE
TIPS

5
Intended Use
The ArjoHuntleigh Maxi Transfer® sheet is intended
for use both as bed linen and as a sling/lifting device for
patients who are highly or totally dependent in hospital
care and nursing homes.
The Maxi Transfer sheet is intended:
• to be left under the patient instead of a bed linen,
• for lateral transfers,
• for reposition in bed,
• for weighing,
• for applying/removing X-ray image plates and
• lifting from floor.
The Maxi Transfer sheet must be operated by
appropriately trained caregivers with adequate
knowledge of the care environment, its common
practices and procedures in accordance with the
guidelines in this Instructions for Use (IFU).
The System
Only use the Maxi Transfer sheet together with
ArjoHuntleigh passive lift systems (loop attachments)
in accordance with the Allowed Combinations on
page 10 specified in this IFU.
Lift compatibility:
• Horizontal lateral transfer: use a stretcher frame.
• Lateral transfer between adjacent surfaces: use a
stretcher frame, a 4-point spreader bar or a 2-point
spreader bar.
• Moving patient up in bed: use a stretcher frame, a
4-point spreader bar or a 2-point spreader bar.
• Turning patient in bed: use a 2-point spreader or a
4-point spreader bar.
• Weighing: use a stretcher frame.
• For applying/removing X-ray plates: use a 4-point
spreader bar or a 2-point spreader bar.
• Lifting from floor: use a stretcher frame.
The patient weight must be lower than the lowest Safe
Working Load (SWL) for all products and accessories
used. See section Allowed Combinations on page 10.
The Maxi Transfer sheet should only be used for the
purposes specified in this IFU. Any other use is
prohibited.
Patient Assessment
ArjoHuntleigh recommends that facilities establish
regular assessment routines.
Caregivers shall assess each patient according to the
following criteria prior to use:
•TheMaxi Transfer sheet is intended for patients
who are highly or totally dependent and unable to
contribute with their own transfer and
repositioning.
• The patient’s weight must not exceed 272 kg/
600 lbs.
• The weight, girth and body shape of the patient
should be assessed in terms of potential risk for
the patient and the caregivers performing the
transfer/repositioning/lifting. The equipment
should be used with patients whose body shape
comfortably fit within the support surface of the
Maxi Transfer sheet.
• The number of caregivers and their positions
during the manoeuvre depend on:
- the assessment of the patient,
- the environment and
- the local working procedures for lifting,
transferring and repositioning the patient.
If these criteria are not met, an alternative equipment/
system shall be used.
If you have any questions regarding contraindication,
consult with the hospital for clinical assessment.
Expected Lifetime
The expected lifetime of the Maxi Transfer sheet is, unless
otherwise stated, two (2) years, based on use and laundry
every sixth (6th) day, subject to preventive maintenance
being carried out in accordance with the instructions in
this IFU.See sections Preparations on page 7 and Care
and Preventive Maintenance on page 29.

6
Safety Instructions
If the patient becomes agitated, stop transferring/
transporting and safely lower the patient onto a
secure surface.
WARNING
To avoid injury, first perform a patient assessment;
position, reposition, lift and transfer in accordance
with this assessment.
WARNING
To avoid injury, make sure the patient's head and
spine are supported during any manoeuvre.
WARNING
To avoid injury, if patient care requires the use of
tubes/ lines/drains, make sure these are being
safely handled in the lifting, repositioning and
transfer manoeuvre.
WARNING
To avoid injury, never leave the patient unattended
when the Maxi Transfer sheet is attached to the lift.
WARNING
To avoid the patient from falling, make sure that the
loops are securely attached before and during the
lifting process.
WARNING
To avoid injury, make sure that the Maxi Transfer
sheet is not attached to any other object than the
stretcher frame/spreader bar and that there is
clearance to perform the manoeuvre.

7
Actions Before First Use (8 steps)
1 Check all parts of the Maxi Transfer sheet, see
section PartsDesignation/Descriptiononpage 8.
If any part is missing or damaged - do NOT use
the Maxi Transfer sheet.
2 The packaging must be recycled according to
local regulations.
3 Read this Instructions for Use (IFU) thoroughly.
4 Use a permanent waterproof pen to enter the date
offirsttimeuseandthehospital/wardnameon the
Maxi Transfer sheet product label. See sections
Parts Designation/Description on page 8 and
Maxi Transfer sheet Label on page 32.
5 Wash and dry the product according to section
Cleaning and Disinfection Instructions on
page 28.
6 Find a place that is dry, out of sunlight and in
normal room temperature for storing the Maxi
Transfer sheet.
The Maxi Transfer sheet must be kept away from
sharp objects, corrosives and other things that can
cause damage to the product.
7 Choose a designated and accessible area where
the IFU must be kept.
8 Make sure to have a rescue plan ready in case of a
patient emergency.
NOTE
If you have any questions, please contact your
local ArjoHuntleigh representative for support
and service. The contact information
(ArjoHuntleigh addresses) is listed on the last
page of this IFU.
Before Every Use (4 steps)
1 Select the correct size of the Maxi Transfer sheet.
See section Maxi Transfer Sheet Size on page 9.
Before use with other patient, make sure the Maxi
Transfer sheet is laundered according to section
Cleaning and Disinfection Instructions on
page 28.
•.
Inspect the complete Maxi Transfer sheet
thoroughly for damage/deviationsbefore and after
every use according to section Care and
Preventive Maintenance on page 29.
If the Maxi Transfer sheet shows any damage/
deviation or if there is any uncertainty of its
condition - Do NOT use the product!
•
•
Check allowed combinations for the Maxi
Transfer sheet with stretcher frame/spreader bar
and lift. See Allowed Combinations on page 10.
Follow the lowest Safe Working Load (SWL) of
the total system.
2WARNING
To prevent cross contamination, always
follow the disinfection instructions in
this IFU.
3WARNING
To avoid injury, always make sure to
inspect the equipment prior to use.
4WARNING
To avoid injury, the Safe Working Load
(SWL) for all products and accessories
used must be higher than the patient
weight.
Preparations

8
Long
Middle
Short
Loop Lengths
5
1
4
2
3
Parts Designation/Description
1. Support Surface
The Maxi Transfer sheet has a patient side (support
surface) and a bed side but no defined head and foot
end.
Place the Maxi Transfer sheet on the bed with the
support surface upwards, towards the patient, and the
other side downwards, towards the mattress, so straps
are covered by the side valances.
The support surface provides the patient with support
during supine lifting, repositioning and transfer.
2. Side Valances
The side valances can be folded over the patient to give
increased warmth, comfort and dignity during the
transfer.
3. Reinforcements
The reinforcements are located where the support
surface meets the side valances. The reinforcements
must be placed in line with or outside the mattress edges
to avoid high pressure points on the patient.
4. Product Label
The product label is located on one of the side
valances.
5. Strap with Loops
The straps are attached along the reinforcements. Each
strap has three loop lengths to provide lift height
alternatives. Use the loop length that gives the best
patient support and comfort.
1 Support surface
2 Side valance
3 Reinforcement
4 Product label
5 Strap with loops

9
Maxi Transfer Sheet Size
The Maxi Transfer sheet must only be used with patients whose body shape comfortably fit within the support surface
of the Maxi Transfer sheet, choose Maxi Transfer sheet size accordingly.
Also make sure the Maxi Transfer sheet size is compatible with the bed it is placed upon in accordance with section
Allowed Combinations on page 9.
Sheet illustration Article
number SWL Product Description Measurement
MAA7000R 272 kg
(600 lbs)
Yellow and
purple straps
Support surface:
Width: 96 cm (38”)
Length: 244 cm (96”)
Side valance:
Width: 40 cm (16”)
Length: 244 cm (96”)
MAA7000W 272 kg
(600 lbs)
Green and
purple straps
Support surface:
Width: 125 cm (49”)
Length: 244 cm (96”)
Side valance:
Width: 40 cm (16”)
Length: 244 cm (96”)
Regular
Wide

10
Allowed Combinations
•
When deciding if a lift and stretcher frame/spreader bar is safe to use with the Maxi Transfer sheet, always comply
with the lowest SWL of the total system.
For example, the Maxi Move lift has a SWL of 227 kg (500 lbs), the stretcher frame has a SWL of 160 kg (352 lbs) and
the MAA7000R Maxi Transfer sheet has a SWL of 272 kg (600 lbs). This means the stretcher frame has the lowest
SWL, of maximum 160 kg (352 lbs), in this system.
No other products than the ones stated below are allowed to be used together with the Maxi Transfer sheet.
Ceiling Lift
Mobile Passive Lift
Bed
When selecting the Maxi Transfer sheet, the support surface should cover the full width and length of the bed mattress
and the side valances must not touch the floor.
WARNING
To avoid injury, the Safe Working Load (SWL) for all products and accessories used must be
higher than the patient weight.
Maxi Sky 600 272 kg (600 Ibs)
Stretcher frame 272 kg (600 Ibs)
2-point spreader bar 272 kg (600 Ibs)
Maxi Sky 2 272 kg (600 Ibs)
Stretcher frame 272 kg (600 Ibs)
2-point spreader bar 272 kg (600 Ibs)
4-point spreader bar 272 kg (600 Ibs)
Maxi Move 227 kg (500 Ibs)
Stretcher frame 160 kg (352 Ibs)
2-point spreader bar 227 kg (500 Ibs)
Maxi Transfer sheet Bed
Maxi Transfer sheet Regular,
MAA7000R 272 kg (600 Ibs)
Maximum width: 93 cm (36 5/8”),
Maximum length 220 cm (86 5/8”)
Maxi Transfer sheet Wide,
MAA7000W 272 kg (600 Ibs)
Maximum width: 122 cm (48”),
Maximum length 220 cm (86 5/8”)

11
Follow these 4 Steps
Refer to local safe patient handling and pressure ulcer prevention
guidelines when preparing the bed.
1 Adjust the bed to an ergonomic height, flat position and
apply the brakes.
2 Remove the existing bed linen and apply the Maxi Transfer
sheet. Make sure the Maxi Transfer sheet does NOT touch
the floor. (See Fig. 1)
If the patient is already on the bed, remove existing bed
linen and apply the Maxi Transfer sheet. Use the preferred
local technique for application, for example:
Log-roll: Make sure the bed side rail is raised or another
caregiveris positioned onthe side towardswhich the patient
is turned. (See Fig. 2 & 3)
Unravel: Use ArjoHuntleigh sliding aids. See respective
sliding aid IFU.
3 Check that:
•theMaxi Transfer sheet is aligned with the head end of
the bed and extra fabric extends below the foot end of
the bed, to enable the patient to be moved upwards in
bed several times,
• the pair of straps in the middle (yellow or green) comes
approximately in line with the patient’s trochanter
major/ below pelvis,
•theMaxi Transfer sheet is centred under the patient/ on
the mattress,
• the reinforcements are in line with or outside the
mattress edges,
• the side valances cover the straps on both sides of the
bed without touching the floor,
• the support surface is clear of straps and has no creases,
• the straps and side valances do not interfere with other
equipment (e.g. lines, tubes, drains, wires and bed
components),
• the pillow is placed on the Maxi Transfer sheet and
• the possible chucks pad is placed on the Maxi Transfer
sheet.
4 Make sure the patient is positioned safely and comfortably.
(See Fig. 4)
NOTE
Bed in this IFU refers to stretcher, trolley, gurney or
other receiving surface
To Apply/Change the Maxi Transfer sheet
Fig. 2, remove patient an
Fig. 3, on bed not under pat.
Fig. 1
Fig. 2
Fig. 3
Fig. 4

12
Loop Detachment
Follow these 3 Steps
The illustration is an example of a hook with latch. The spreader
bar or stretcher frame might be of a different design.
1 Place the loop over the latch.
2 Pull the loop down to force the latch to open.
3 Make sure the latch closes completely with the loop inside
the hook. (See Fig. 1)
NOTE
• Make sure to align coloured straps so that
both sides match each other in order to
distribute the patient weight evenly, e.g.
yellow strap in-line with yellow strap.
• The loop length alternatives on the straps can
be used to adjust the patient’s position and
comfort, for example shorter loops at the
head end and longer loops at the hip.
• If the patient is not centred on the
Maxi Transfer sheet, select longer loop
lengths on the side closest to the patient and
shorter loop lengths at the other side.
Method 1 (2 Steps)
1 Press the latch open.
2 Remove the loop.
Method 2 (2 Steps)
The illustrations are examples of a hook with latch. The spreader
bar or stretcher frame might be of a different design.
1 Pull one side of the loop over the hook and latch.
(See Fig. 1)
2 Pull down the loop. (See Fig. 2)
Fig. 1 Latch
Hook
Loop Attachment
Fig. 1
Hook
Latch
Fig. 2

13
Stretcher Frame
Horizontal Lateral Transfer
Follow these 15 steps
To transfer the patient, use a stretcher frame. (See Fig. 1)
For lift instructions, see respective lift IFU.
1 Adjust the patient bed to an ergonomic height, flat position
and apply the brakes. Place the lift nearby.
2 Adjust the receiving bed to flat position and equal height,
applythe brakes and raise the side rail on the side the patient
is moved towards.
3 Position the patient’s arms on top of the patient’s body.
4 Position the stretcher frame along the length of the patient,
with the centre above the patient’s navel. (See Fig. 2)
5 To access the straps, place the side valances on top of the
patient's body or along both sides of the patient. (See Fig. 2)
6 Lower the stretcher frame to enable the straps to be
attached. Caregiver should always hold on to the stretcher
frame to avoid swinging movements. (See Fig. 3)
7Attach all the straps.
All seven pairs of straps shall be attached to the five pairs of
hooks. Attach the first and last two pairs of straps, to the
first and last pairs of hooks. (See Fig. 4)
Use the loop lengths that give the best patient support and
comfort.
Make sure the side rail furthest away on the receiving bed is
raised or another caregiver is present.
continue with the steps on the next page
NOTE
Bed in this IFU refers to stretcher, trolley, gurney or
other receiving surface.
8WARNING
To avoid injury, make sure there is another
caregiver present by the bed and/or raise the
side rail on the side the patient is moved
towards.
Fig. 1
Fig. 2
Fig. 3
Fig. 4

14
9 Slightly lift the patient to tension the straps:
• pay attention to tubes, drains, lines etc. if any,
• make sure all loops are securely attached and the patient
lays fully supported and comfortably in the
Maxi Transfer sheet and
• make sure the Maxi Transfer sheet is not attached to
any other object than the stretcher frame and that there is
clearance to perform the manoeuvre.
10 If an adjustment is needed, lower the patient until he/she is
supported by the bed:
• adjust the stretcher frame balance (See Fig. 5) (A) by
shifting the balance to the part carrying the most of the
weight and/or
• detach the straps and rearrange to different hooks or
select different loop lengths.
Continue to lift and transfer the patient to the receiving bed.
(See Fig. 6 and Fig. 7)
12 Lower the patient to the receiving bed.
13 Before detaching the loops make sure that (See Fig. 8):
• the patient's body weight is fully supported by the bed
• the straps are no longer in tension.
Detach all loops and move the lift away from the patient.
15 Make sure:
• the patient is positioned safely and comfortably,
• there are no creases or straps under the patient and
• the reinforcements of the Maxi Transfer sheet are
positioned outside the edges of the mattress.
11 TIPS
If using a ceiling lift, move the beds instead of the lift
to avoid moving the patient during the transfer.
14 WARNING
To avoid injury, make sure all loops are detached
from the hooks before removing the lift.
A
Horizontal
Fig. 5
Fig. 6
Fig. 7
Fig. 8

15
To Move the Patient Upwards in Bed
Follow these 11 steps
To weigh the patient, use a stretcher frame. (See Fig. 1)
For lift instructions, see respective lift IFU.
1 Adjust the bed to an ergonomic height, flat position and
apply the brakes. Place the lift nearby.
2 Position the patient’s arms on top of the patient’s body.
3 Lower the stretcher frame to enable the straps to be
attached. Caregiver should always hold on to the stretcher
frame to avoid swinging movements.
4 Position the stretcher frame along the length of the patient,
with the centre above the patient’s navel. (See Fig. 2)
5 Use the loop lengths that give the best patient support and
comfort. Attach all the straps.
All seven pairs of straps shall be attached to the five pairs of
hooks. (See Fig. 3)
If needed, to enhance attachment of the loops, tilt the head
end of the bed upwards.
6 Slightly lift the patient to tension the straps:
• pay attention to tubes, drains, lines etc. if any,
• make sure all loops are securely attached and the patient
lays fully supported and comfortably in the
Maxi Transfer sheet and
• make sure the Maxi Transfer sheet is not attached to any
other object than the stretcher frame and that there is
clearance to perform the manoeuvre.
7 Move the patient upwards in bed. (See Fig. 4)
8 Lower the patient onto the bed.
9 Before detaching the loops make sure that:
• the patient’s body weight is fully supported by the bed
• the straps are no longer in tension.
Detach all loops and move the lift away from the patient.
11 Make sure:
• the patient is positioned safely and comfortably,
• there are no creases or straps under the patient and
• the reinforcements of the Maxi Transfer sheet are
positioned outside the edges of the mattress.
10 WARNING
To avoid injury, make sure all loops are detached
from the hooks before removing the lift.
Fig. 1
Fig. 2
Fig. 3
Fig. 4

16
To Weigh the Patient
Follow these 12 steps
To weigh the patient, use a stretcher frame. (See Fig. 1)
For lift instructions, see respective lift IFU.
1 Adjust the bed to an ergonomic height, flat position and
apply the brakes. Place the lift nearby.
2 Position the patient’s arms on top of the patient’s body.
3 Position the stretcher frame along the length of the patient,
with the centre above the patient’s navel. (See Fig. 2)
4 Lower the stretcher frame to enable the straps to be
attached. Caregiver should always hold on to the stretcher
frame to avoid swinging movements.
5Attach all the straps.
All seven pairs of straps shall be attached to the five pairs of
hooks. Attach the first and last two pairs of straps, to the
first and last pairs of hooks. (See Fig. 3)
Use the loop lengths that give the best patient support and
comfort.
6 Slightly lift the patient to tension the straps:
• pay attention to tubes, drains, lines etc. if any,
• make sure all loops are securely attached and the patient
lays fully supported and comfortably in the
Maxi Transfer sheet and
• make sure the Maxi Transfer sheet is not attached to
any other object than the stretcher frame and that there
is clearance to perform the manoeuvre.
7 Lift the patient until the Maxi Transfer sheet carries the full
weight of the patient. (See Fig. 4)
8 The patient’s weight is shown on the scale display. See
respective lift or scale IFU. Be aware that the indicated
weight will also include the weight of the Maxi Transfer
sheet. See section Technical Specifications on page 31 for
the weight of the Maxi Transfer sheet
continue with the steps on the next page
Fig. 1
Fig. 2
Fig. 3
Fig. 4

17
9 Lower the patient onto the bed.
10 Before detaching the loops make sure that:
• the patient’s body weight is fully supported by the bed
• the straps are no longer in tension.
Detach all loops and move the lift away from the patient.
12 Make sure that (See Fig. 5):
• the patient is positioned safely and comfortably,
• there are no creases or straps under the patient and
• the reinforcements of the Maxi Transfer sheet are
positioned outside the edges of the mattress.
11 WARNING
To avoid injury, make sure all loops are detached
from the hooks before removing the lift.
Fig. 5

18
To Lift a Patient from the Floor
Follow these 20 steps
To lift the patient from the floor, use a stretcher frame (See Fig. 1)
For lift instructions, see respective lift IFU.
1 Make a clinical assessment of the patient (follow local rou-
tine).
2 Place a pillow under the patient’s head. (See Fig. 2)
3 Make sure the patient is accessible for the lift. If needed,
move the patient using a sliding aid. See respective sliding
aid IFU.
4 Place a bed nearby and apply its brakes.
5 Apply the Maxi Transfer sheet, centred, underneath the
patient.
6 Move the pillow so it is on top of the Maxi Transfer sheet.
7 Position the patient’s arms on top of the patient’s body.
8 Position the lift sideways with the lift legs wide open.
Always pay attention to the patient’s head.
Positiononeliftlegnear the head and the other lift leg under
the patient’s knees. (See Fig. 3)
9 Make sure the stretcher frame is positioned along the length
of the patient.
10 Apply the brakes on the lift.
11 Lower the stretcher frame to enable the straps to be
attached.
12 Attach all the straps.
All seven pairs of straps shall be attached to the five pairs of
hooks. Attach the first and last two pairs of straps, to the
first and last pairs of hooks (See Fig. 4).
Use the loop lengths that give the best patient support and
comfort.
continue with the steps on the next page
NOTE
Bed in this IFU refers to stretcher, trolley, gurney or any
other receiving surface.
Fig. 1
Fig. 2
Fig. 3
Fig. 4

19
13 Slightly lift the patient to tension the straps:
• make sure all loops are securely attached and the patient
lays fully supported and comfortably in the
Maxi Transfer sheet and
• make sure the Maxi Transfer sheet is not attached to
any other object than the stretcher frame and that there
is clearance to perform the manoeuvre.
14 Continue to lift.
15 Release the brakes on the lift and transfer the patient to the
bed.
16 Lower the patient onto the bed. (See Fig. 5)
17 Before detaching the loops make sure that:
• the patient’s body weight is fully supported by the bed
• the straps are no longer in tension.
Detach all loops and move the lift away from the patient.
19 Change the Maxi Transfer sheet, which has been on the
floor, to prevent contamination. See section To Apply/
Change the Maxi Transfer sheet on page 11.
20 Make sure (See Fig. 6):
• the patient is positioned safely and comfortably,
• there are no creases or straps under the patient and
• the reinforcements of the Maxi Transfer sheet are
positioned outside the edges of the mattress.
18 WARNING
To avoid injury, make sure all loops are detached
from the hooks before removing the lift.
Fig. 5
Fig. 6

20
Spreader Bars
Lateral Transfer Between Adjacent Surfaces
Follow these 15 steps
To transfer the patient, use one of the following spreader bars
(See Fig. 1):
• 2-point spreader bar (A)
• 4-point spreader bar (B)
For lift instructions, see respective lift IFU.
1 Adjust the patient bed to an ergonomic height, flat position
and apply the brakes. Place the lift nearby.
2 Adjust the receiving bed to flat position and equal height,
applythe brakes and raise the side rail on the side the patient
is moved towards.
3 Position the patient’s arms on top of the patient’s body.
4 Position the:
•4-point spreader bar across the patient, with the centre
above the patient’s navel. Place the wider part towards
the patient’s shoulders and the narrow part towards the
patient’s hip.
•2-point spreader bar across the patient, with the centre
above the patient’s navel. (See Fig. 2)
5 To access the straps, place the side valances on top of the
patient's body or along both sides of the patient. (See Fig. 2)
6 Lower the spreader bar to enable the straps to be attached.
Caregiver should always hold on to the spreader bar to
avoid swinging movements. (See Fig. 3)
7 Use the loop lengths that give the best patient support and
comfort. Use all hooks.
If needed, to enhance attachment of the loops, tilt the head
end of the bed upwards. Attach the straps from the top of the
head to the knees, use a minimum of five straps on each
side
continue with the steps on the next page
NOTE
Bed in this IFU refers to stretcher, trolley, gurney or
other receiving surface.
NOTE
If the patient’s heels are outside the Maxi Transfer
sheet, place a sliding aid under the patient’s heels,
to avoid high shear force.
Fig. 1
A
B
Fig. 2
Fig. 3
