Armedica AM-SX Series User manual

This manual has been prepared for the owners and operators of the
ARMEDICA™ AM-SX Series Hi-Lo Treatment Tables, and contains
installation instructions, precautionary instructions and
maintenance procedures for the following model numbers:
AM-SX and AM-BAX1000, 1060, 1072,
2000, 3000, 3500, 4000, 4500, 5000, 5400
ISO 13485
FM 50089 .
Made in the U.S.A

AM-SX SERIES HI-LO TREATMENT TABLES
Armedica Treatment Tables are intended to be used as physical therapy supports for patients during
clinician attended physical therapy related diagnosis, treatment, and monitoring. The table is
equipped with a vertical table height adjustment actuator and casters for mobile transport.
Patients are not to be left unattended.
INSTALLATION
1. Remove all packaging material from the table.
2. There is no assembly required on the ARMEDICA™ AM-SX Series Treatment Tables.
3. Plug the power cord into a properly grounded 100-240VAC 50/60Hz outlet and follow the procedure outlined in
the precautionary Instructions.
4. The tables are equipped with 4-total lock swivel casters for maximum stability.
5. The motors are equipped with a thermal cutout that protects them from overheating.
PRECAUTIONARY INSTRUCTIONS
1. Read, understand and practice the precautionary instructions in this manual. Be aware of the
limitations and the hazards associated with the ARMEDICA™ Treatment Tables.
2. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to other devices in the vicinity. However,
there is no guarantee that interference will not occur in any particular installation. If this equipment does cause
harmful interference to other devices, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving device.
- Increase the separation between the equipment.
- Connect the equipment into an outlet on a circuit different from that to which the
other device(s) are connected.
- Consult the manufacturer or field service technician for assistance.
3. Always make certain all 4 casters are locked prior to patient use.
4. Always use both hands when changing the angle of any section of the
table.
5. Never change the angle of any section, except motorized sections, when the patient’s weight is on that
section.
6. Never place your hands or feet nor the patient’s hands or feet near any of the working mechanisms
of the table when raising or lowering the table.
7. Never leave patient unattended.
OPERATING INSTRUCTIONS
To adjust the height of the ARMEDICA™ Treatment Tables, a low voltage foot switch or hand switch is used to
activate the electric motor assembly. The up and down activators are clearly indicated by decals.
Duty cycle is Intermittent 1min.on/ 9min.off
TABLE SECTION ADJUSTMENTS
The sections of the ARMEDICA™ Treatment Tables are raised by lifting them with both hands. The locking
mechanism holds them securely at any angle. To lower a section, hold it in one hand and release the locking
mechanism by rotating the lever with the other.
The AM-SX 4000 is equipped with an automatic spring return.
CAUTION: When lowering any of the table sections, make certain that your hands cannot come in contact with the
board supports.
CAUTION: When adjusting the non-motorized sections with the patient on the table, be sure that the patient’s
weight is not on the section you are going to adjust.
CAUTION: To adjust the arm rest on the 3-piece head section loosen knob while holding arm rest. Raise or lower
the arm rest to the desired position and tighten knob.
1

CAUTION: Make sure that each armrest on the 3-piece head section is locked securely in position before the
patient places any weight on it.
CAUTION: When locking the rolling section of the AM-SX 4000 in position, make sure the lock plunger is fully
engaged in one of the slots.
MAINTENANCE
The ARMEDICA™ AM-SX Series Treatment Tables are equipped with a maintenance free electric motor. The
moving parts of the table should have a drop of oil placed on them approximately every six months.
When lubricating the slide block track use a food grade grease.
Frequently check to make certain that all hardware (nuts, bolts, etc.) are properly adjusted and securely fastened.
In the event it becomes necessary to replace the foot switch, hand switch or the power cord, make certain that the
plug is properly installed and the locking tabs on the motor snaps in place.
The vinyl cover should be cleaned with mild soap and water and the table frame wiped with a dry cloth to remove
dust and lint when necessary.
SYMBOLS AND INDICATORS
Attention: Consult accompanying documents.
Type B Equipment: “An adequate degree of protection against electric shock is provided, particularly
regarding leakage currents and reliability of the protective earth connection.”
The grounding pin located on the power supply cable is for functional use only, and is present for
EMI/ EMC purposes. The product is Class II equipment and does not rely on this grounding means for safety.
TROUBLESHOOTING
MOTOR DOESN’T WORK.
A. Check to see if motor is plugged into electrical outlet, and the power cord is properly plugged into the motor.
B. Make sure the electrical outlet has power.
C. Check hand switch or foot switch to be sure it is plugged in correctly.
D. Thermal cutout may have activated. Allow the motor to cool.
E. In the event there is a failure of the motor, the motor must be returned to Armedica Mfg. Corp. The motor must
be serviced by the manufacturer. Contact Armedica Mfg. Corp. prior to returning any parts or products to
obtain return authorization.
MOTOR SPECIFICATIONS Lumbar section (AM-SX3000 & AM-SX5000 models)
Magnetic Corp., Olney, Illinois 62450 Magnetic Corp., Olney, Illinois 62450
Model MAX 72-A200415A1001-000. Model MAX 30-B050265A10M0-000
Rated Voltage and Frequency. Rated Voltage and Frequency 24Vdc 60HZ
100-240Vac, 50-60Hz. w/24VDC output Current 5A
Current 3.2A/1.6A Duty cycle: on/off Int. 1 min. / 9 min.
Model MAX 74-A200415A1001-000.
Rated Voltage and Frequency.
100-240Vac, 50-60Hz
Current 3.2A/1.6A
UL CORD SET 140-355
Duty cycle: on/off Int. 1 min. / 9 min.
Transport and storage
Ambient temperature: 0°– 40° C
Relative humidity: 5% - 85%, including condensation
Atmospheric pressure: 700hPa to 1060hPa
2

1000 1060 2000 3000 3500 4000
1072 5000 5400 4500
118856 BASE FRAME SX PNTD 1 1 1 1 1 1
218862 SX CASTER LEG ASSY W/HOLES PNTD 2 2 2 2 2 2
318875 ARM SX-BA DUAL LIFT PNTD 1 1 1 1 1 1
418776 ARM AM-SX PWR SINGLE LIFT UNPNTD 1 1 1 1 1 1
513879 BUSH SX BRZ .5015x.628x1/4" OILITE 4 4 4 4 4 4
613855 ROD SX 1/2x8-1/8 X PIVOT PLTD 1 1 1 1 1 1
702176 SCREW BTN HD SOC 3/8-16X3/4 8 8 8 8 8 8
802198 SCREW BTN HD SOC 1/2-13x3/4 4 4 4 4 4 4
902340 SX SLIDE BLOCK PLAS 4 4 4 6 4 4
10 03072 CASTER SWIVEL LOK TENTE 4 4 4 4 4 4
11 02715 SCREW SET #12-24x1/2 SOC HD 8 8 8 8 8 8
12 02665 SCREW BTN HD SOC 7/16-14x1 4 4 4 4 4 4
13 02663 WASHER LOC 7/16" INTERNAL TOOTH PLT 4 4 4 4 4 4
14 02664 NUT ACORN 7/16-14 NICKEL PLATED 4 4 4 4 4 4
15 02196 CAP AXEL NUT STYLE 1/2" 2 2 2 2 2 6
16 03595 MOTOR MAX74 8KN 120-240VAC 1 1 1 1 1
17 03106 SWITCH FT MAX74 8000N 1 1 1 1 1
18 03113 SWITCH HAND MAX65 (OPTIONAL)
19 02012 BOLT SHLDR M10x30 2 2 2 4 2 2
20 02092 NUT NYLOCK M8-1.25 HEAVY 2 2 2 4 2 2
21 18770
BASE FRAME SX-BA PNTD(BA option only)
1 1 1 1 1 1
22 18772 BAR FT SWITCH SX-BA BASE PNTD 2 2 2 2 2 2
23 02646 BOLT SHLDR 1/2x1-1/4 2 2 2 2 2 2
24 02645 BOLT SHLDR 1/2x1 2 2 2 2 2 2
25 19020 PLATE FRMD SWITCH MNT ASSEMBLED 1 1 1 1 1 1
26 02252 SCREW PAN HD PHIL 10-24x1/2 2 2 2 2 2 2
27 02207 WASHER SEALED #10x1/2 GALV STEEL 2 2 2 2 2 2
28 03192 STRAIN RELIEF FT RAIL SWTCH COVER 1 1 1 1 1 1
29 02265 SHT MTL AM-BA SIDE SHIELD PNTD 2 2 2 2 2 2
30 02647 SPACER PLAS .251 ODx..152 IDx.156 8 8 8 8 8 8
31 03191 SWITCH LIMIT ROLLER FT RAIL E13-00K 4 4 4 4 4 4
32 02077 NUT NYLOCK 6-32 4 4 4 4 4 4
33 02528 SPACER PLAS .775 ODx.515 IDx.250 RL 4 4 4 4 4 4
34 03263 TERMINAL BLOCK 12 POLE 22-10GA 350V 1 1 1 1 1 1
35 02076 SCREW PAN HD PHIL 6-32x1/2 1 1 1 1 1 1
36 02165 WASHER NYLON .518 IDx1"ODx.08 2 2 2 2 2 3
37 02100 NUT NYLOCK 1/4-20 2 2 2 2 2 14
38 02140 WASHER 1/4 2 2 2 2 2 6
39 02538 SCREW BTN HD SOC 1/4-20x3/4 2 2 2 2 2 2
40 03429 SPRING COMPRSSN 3/4x1-5/8 ZINC PLTD 2 2 2 2 2 2
41 02657 PLUG RD 1"ODx14-20 GA BLK 4 4 4 4 4 4
42 02662 SPACER PLAS .620 ODx .504 IDx 13/16 2 2 2 2 2 2
43 02312 FRM SX TOP 1 PC PNTD 1
44 14823 BD UPH SX100 27X76 W/FACE HOLE 1
45 14855 BD UPH AMSX CHANGING TABLE 25x60 1
46 14851 BD UPH SX CHNG TBL 25x72 1
47 02045 SCREW HX HD CAP 1/4-20x1 8 8 12 14 16 26
48 02310 FRM SX3500 11GA TOP PNTD 1 1
49 02308 FRM SX HD SHT MTL PNTD 1 1 1 1
50 18877 ROD SX 1/2"RDx8 HD SEC SPPT PLTD 2 2 2 2
51 13867 ROD SX 1/2x15-1/8 HD PVT SPPT PLTD 1 1 1 1
52 03040 SPRING TORSION LESS BEND LEFT 1 2 2 1
53 03030 SPRING TORSION LESS BEND RIGHT 1 2 2 1
PARTS LIST
ITEM
NO.
PART
NO.
DESCRIPTION
QUANTITY
3

1000 1060 2000 3000 3500 4000
1072 5000 5400 4500
54 13865 TUBE SXDT 3/4x6 LOCK SLEEVE PLT 1 1 1 2
55 02553 BUSH PLAS FLNG .687ODx.510 ID 2 4 4 4
56 02196 CAP AXEL NUT STYLE 1/2" 4 6 4
57 13877 ROD SX 1/2x13.5 HD SEC PVT PLTD 1 1 1 1
58 02534 PIN SPRING 3/16x3/4 2 2 4 4
59 13946 ROD 1/2x11-13/16 BNT SX LK PLTD 2 2 2 2
60 03464 CAP PLAS TUBE BLK .500x3 2 2 4 2
61 02543 PIN SPRING 3/16x1-1/2 2 2 4 2
62 02165 WASHER NYLON .518 IDx1"ODx.08 2 2 2
63 18787 BRKT LOCK SX 3PC HD SUPPT PLTD 2 2 2 2
64 02170 PIN SPRING 3/16x1 2 2
65 02339 SX LOCK TAB 2 2 4
66 02036 SCREW BTN HD SOC 1/4-20x3/8 S.S. 2 2 4 4
67 14826 BD UPH 200 BODY 27" 1
68 14835 BD UPH SX HD 27" WIDE 1 1 1 1
69 18866 SX MID LIFT FRAME ASSY PNTD 1
70 18869 FRAME SX3000 MID LIFT FOOT PNTD 1
71 18900 ARM MIDLIFT CNTR WELDED PNTD 1
72 18902 HINGE MIDLIFT FT BD PLTD 1
73 03154 MOTOR MAX30 4000Nx50MM 24VDC 1
74 13884 ROD 1/2x20-1/4 SXML TOP PIVOT PLTD 1
75 13026 ROD 1/2x23 THD'D FT SEC LK PLATED 1
76 13871 ROD SX FT SPPT W/BEND PLTD 222
77 18127 BRKT LOCK SUPPORT PLATED 2
78 28354 SX FT SEC SPPT PVT PLTD 222
79 02135 NUT HX FIN JAM 1/2-13 2 2
80 03070 KNOB WING 1/2X13 ID 2 2
81 14836 BD UPH SX 3000 CTR 27" WIDE 1
82 14837 BD UPH SX 3000/5000 FOOT 27" WIDE 1
83 02037 SCREW BTN HD SOC 1/4-20x1 444
84 03038 SWITCH CONTROL MNTD PWR MAT 2
85 18854 HANDL LOC BAR BENT AMSX DRIL PLT 2
86 02503 RETAINER RING 1/2 EXTERNAL 226
87 02063 SCREW HX WASHER HD #10x3/4 4 4
88 02327 HINGE BENT 2.5x4 2 2
89 14711 BD UPH SX 3500 CTR 27" WIDE 1
90 14713 BD UPH SX 3500 FT 27" WIDE 1
91 02318 FRM SX TOP TRACTION PNTD 1
92 18851 FRM SX ROLLER W/CHANNEL PNTD 1
93 12743 BAR SX 1/8x1.5x7-5/8 TX ELBOW PNTD 2
94 13869 ROD SX 1/2x14.563 TX RLLR AXLE PLTD 2
95 02330 WHEEL SX TRACTION ROLLER FRM 4
96 18879 ROD SXDT THD'D FT LOCK BAR PLTD 2
97 02060 SCREW FLT HD PHIL 1/4-20x1/2 6
98 02332 ANGLE SX RLLR FRM LOCK MNT PNTD 1
99 13875 BAR SX 5/16HXx23-7/8 RLLR LOCK PLTD 1
100 02501 SCREW PAN HD PHIL 10-32x1/2 4
101 03029 LATCH SOUTHCO 1
102 02089 NUT NYLOCK 10-32 4
103 02185 SCREW FLT HD PHIL 1/4-20x2 2
104 03084 NUT ROUND FLANGED 1/4-20x7/8 BARREL 2
105 02120 NUT HX FIN 1/4-20 4
106 03027 SPRING EXTNSN DECOMP .490x8x.060 2
PARTS LIST
ITEM
NO.
PART
NO.
DESCRIPTION
QUANTITY
4

1000 1060 2000 3000 3500 4000
1072 5000 5400 4500
107 02073 SCREW FLT HD PHIL 1/4-20x1-1/2 2
108 14840 BD UPH SX4000 18x27 THORACIC 1
109 14841 BD UPH SX4000 13x27 LUMBAR 1
110 14842 BD UPH SX4000 27x31 FOOT 1
111 03125 KNOB "T" SPRNG LOAD PULL PIN 1/4DIA 3
112 02111 NUT HX FIN JAM 5/16-18 2
113 28038 BRKT MACH STND MNT SX PNTD 1
114 12751 PLATE SX 1/8x6-1/2 STND LOCK PLTD 1
115 02050 SCREW HX HD CAP 5/16-18x1-3/4 2
116 02162 SPACER PLAS .33 IDx.565 ODx.56 2
117 02105 NUT NYLOCK 5/16-18 2
118 03008 PLUG 1x1-1/2 6
119 18494 STAND MACHINE PIVOT BA PAINTED 1
120 03015 PLUG 1x2x14GA 1
121 02090 NUT NYLOCK 1/2-13 1
122 14508 BD PLY 400 ADAPT FORMICA 3/4x10 1
SIDE RAILS
123 18991 FRAME SX SIDE RAIL LEFT PNTD 1 1 1
124 18993 FRAME SX SIDE RAIL RIGHT PNTD 1 1 1
125 18995 BRKT SIDE RAIL PIVOT MNT LR PNTD 1 1 1
126 18980 BRKT SIDE RAIL PIVOT MOUNT RR PNTD 1 1 1
127 18998 BRKT SIDE RAIL PVT LOCK MNT LF PNTD 1 1 1
128 18982 BRKT SIDE RAIL PVT LOCK MNT RF PNTD 1 1 1
129 14859 BD UPH SX CHNG TBL SIDE RAIL 2 2 2
130 02037 SCREW BTN HD SOC 1/4-20x1 4 4 4
131 02045 SCREW HX HD CAP 1/4-20x1 8 8 8
132 02104 WASHER 1/4" INTERNAL TOOTH LOCK 4 4 4
133 02657 PLUG RD 1"ODx14-20 GA BLK 4 4 4
134 02190 WASHER FENDER 1/4IDx1-1/4OD 2 2 2
135 02036 SCREW BTN HD SOC 1/4-20x3/8 S.S. 2 2 2
136 03126 KNOB SPRNG LOAD PULL PIN 3/8 DIA 2 2 2
3-PIECE HEAD SECTION
137 02553 BUSH PLAS FLNG .687ODx.510 ID 222
138 03464 CAP PLAS TUBE BLK .500x3 222
139 13910 BAR RD 1/2x11-13/16 SX 3PC HD PLTD 222
140 18783 BAR RD 1/2x11-13/16 SX 3PC HD PLTD 111
141 12300 BAR 1/4x1x1 AM100 RAIL SPCR UNPLTD 666
142 03010 PLUG 1x1x14GA 444
143 18779 BRKT ARM REST RIGHT PNTD 111
144 18787 BRKT LOCK SX 3PC HD SUPPT PLTD 222
145 02339 SX LOCK TAB 222
146 02036 SCREW BTN HD SOC 1/4-20x3/8 S.S. 222
147 03167 KNOB 5/16-18 1/2" L BLACK 1 3/4" 222
148 02196 CAP AXEL NUT STYLE 1/2" 222
149 18877 ROD SX 1/2"RDx8 HD SEC SPPT PLTD 222
150 02165 WASHER NYLON .518 IDx1"ODx.08 222
151 13908 BAR RD 1/2x12 SX 3PC HD PLTD 111
QUANTITY
OPTIONAL ACCESSORIES AVAILABLE ON SOME MODELS
PARTS LIST
ITEM
NO.
PART
NO.
DESCRIPTION
5

1000 1060 2000 3000 3500 4000
1072 5000 5400 4500
3-PIECE HEAD SECTION
152 18785 FRAME SX 3 PC HD SEC PNTD 111
153 18781 BRKT ARM REST LEFT PNTD 111
154 14774 BD UPH SX 3 SEC ARM 222
155 14773 BD UPH SX 3 SEC HD 111
5400 CRESENT HEAD SECTION
156 02553 BUSH PLAS FLNG .687ODx.510 ID 222
157 13910 BAR RD 1/2x11-13/16 SX 3PC HD PLTD 222
158 13894 BAR RD 1/2 DIAx7-1/4 SX 3PC HD PLTD 111
159 18944 TUBE LOCKING SX 3PC HD PLTD 111
160 18898 TUBE LOCK SPPT SX 2PC HD PLTD 111
161 18951 FRAME SX 2PC HEAD SECTION PNTD 111
162 03464 CAP PLAS TUBE BLK .500x3 222
163 02165 WASHER NYLON .518 IDx1"ODx.08 222
164 03040 SPRING TORSION LESS BEND LEFT 111
165 02196 CAP AXEL NUT STYLE 1/2" 444
166 02534 PIN SPRING 3/16x3/4 222
167 02548 KNOB W/STEM 1/4-20x1 222
168 02045 SCREW HX HD CAP 1/4-20x1 444
169 14767 BD UPH SX CRESCENT ARM REST 111
170 14762 BD UPH SX HD 3 PC 111
BAR ACTIVATION BOX
171 02478 PLATE FORMED SWITCH MOUNT 9-3/8 1 1 1 1 1 1
172 03190 TERM INSUL NYLON FEMALE 22-18GA .25 8 8 8 8 8 8
173 03283 CABLE MAX65 FT BAR CONTROL 2.55M 1 1 1 1 1 1
174 02475 PLT COVER FORMED 1-3/8x4-1/2x9-1/2 1 1 1 1 1 1
175 02265 SHT MTL AM-BA SIDE SHIELD PNTD 2 2 2 2 2 2
176 03193 RIVET PLAS PUSH FT RAIL COVER BLK 2 2 2 2 2 2
MID-LIFT MOTOR
177 03596 MOTOR MAX72 8KN 120-240VAC W/OUTPUT 1
PARTS LIST
QUANTITY
ITEM
NO.
PART
NO.
DESCRIPTION
OPTIONAL ACCESSORIES AVAILABLE ON SOME MODELS
6

2
2327
11
18
19
20
31
20
22
19
35
18
30
29
24
28
21 4
AMSX BASE ONLY
32177
7

21
25 23
40
39
38
37 41
22
25
32
24
36
35
34
33
29
27
26
28
31 30
AM-BAX BASE
BAR ACTIVATION OPTION
8

82
81
68
5
78
83
80
79
78
76
75
12
74
56
84 9
11
19
20
73
64
57
66
65
54 58
55 63
60
50
51
49
47
59
4
8
AM-SX 3000/5000
AM-BAX 3000/5000
9

21
23 8
222324
26
45
46
27 57
29
28 34
30
31
32
44
43 38
37 41
39
33
36
50
8
5
40
42
AM-SX 2000
AM-SX 1000 AM-SX 1060 AM-SX 1072
10

AM-SX 3500
AM-BAX 3500
28
27
26
30
33
31
1
13
32
5
19
9
12
54
25
21
66
17
34
54
55
20
59 8
5
57
50
56
51
49
22
47
11

78
83
80
79
76
96 2
110
109
88
112
65
102
86
94
100
101
99
98
97
94
111
95
47
105
106
52
61
1
93
36
54
62
51
58
57
50
49
15
59
55
53
5
68
8
108
104
63
103
37
107
87
66
64
60
AM-SX 4000/4500
AM-BAX 4000/4500
122
38
47
120
111
119
7
7
121
117
118
37
12
9
116
115
36
12

1
2
133
4
131
128
135
136
134
129
127
3
130 132
141
138
139
137
140
143
147
142
144
145
148
149
150
146
151
152
153
154
155
154
3-PIECE HEAD SECTION
5400 CRESENT HEAD SECTION
157
162
156
160
166
159
164
163
158 165
170
161
168
169
167
GUARD RAILS
13

28
173
34
171
31
30
32
172
176
174
26
27
175
35
OPEN
CLOSED
OPTIONAL BAR ACTIVATION SWITCH BOX
FOR AM-BAX MODELS
14

BLUEBLUE
2x LIGHT BLUE (HAND SWITCH)
PURPLE
PURPLE
GRAYGRAY
GRAY GRAY
GRAY
PURPLE
CORD TO MOTOR
DOWN
UP
2x ORANGE (HAND SWITCH)
2x LIGHT GREEN (HAND SWITCH)
DARK BLUE
BLACK
DARK GREEN
AM-BAX 3000/5000
CORD TO
HAND SWITCH
CORD TO
HAND
SWITCH
GRAY GRAY
AM-BAX BAR ACTIVATION WIRING DIAGRAM
15

16

ARMEDICA™ MANUFACTURING CORP.
LIMITED WARRANTY
ARMEDICA™ Manufacturing Corp. warrants that the AM-SX Series treatment tables are free from defects in
material and workmanship. This warranty shall remain in effect for 18 months from the date of original
consumer purchase of the product. If the product fails to function during the warranty period due to a defect in
material or workmanship, ARMEDICA™ Manufacturing Corp. or the selling Dealer will repair or replace the
table without charge within a 30 day period from the date on which the table is returned to ARMEDICA™
Manufacturing Corp. or the selling Dealer. ARMEDICA™ Manufacturing Corp. has a policy of continuous
improvement that may result in changes to specifications at any time.
THIS WARRANTY DOES NOT COVER
1. Replacement parts or labor furnished by anyone other than ARMEDICA™, Selling Dealer or approved
ARMEDICA™ Service Agent.
2. Any failure of the table during the warranty period if the failure is not caused by a defect in material or
workmanship or if the failure is caused by unreasonable use, including the failure to provide reasonable
and necessary maintenance.
ARMEDICA™ MANUFACTURING CORP. IS NOT LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGE TO PROPERTY OR BUSINESS.
To obtain service under this warranty, please do the following:
1. A written claim should be sent to ARMEDICA™ Manufacturing Corp., P.O. Box 880, Greenwood, AR.
72936-0880 or the selling Dealer.
2. The table must be returned to ARMEDICA™ Manufacturing Corp. or the selling Dealer.
3. This warranty gives you specific legal rights and you may have other rights, which vary from state to
state
ARMEDICA™ does not authorize any person or dealer to create for it any other obligations or liabilities in
connection with the sale of the tables. Any representation or agreement not contained in this warranty
shall be void.
PN-03409 REV G. 10/31/2019
SX SERIES MANUAL
17
