ARRI Lamphead TRUE BLUE User manual

TRUE BLUE
New Location & Studio Fresnels

2

3
ARRI |TRUE BLUE
THE EVOLUTION
Of Authentic ARRI TRUE BLUE Lighting
ARRI TRUE BLUES represent an unprecedented evolution
of the Studio and Location fixtures that have been popular
workhorses for over two decades. Following extensive
research and feedback from lighting professionals around
the world, combined with advances in technology, ARRI
has designed a series of six highly innovative lampheads
with over 30 newimprovements for studio and location
lighting. With reduced weight, compact size and maximum
light output TRUE BLUES set a newstandard for
professional lighting equipment.
New pressure die cast and extruded aluminum components
havereduced the overall weight of the TRUE BLUE fixtures
without anysacrifice in quality or durability. Many
components nowoffer greater strength and resistance to
corrosion.
ARRI’s cross cooling system* reduces lamp housing
temperature by 25% and lens temperature by 17%. With
special air channels built into the aluminum extrusion, a
constant stream of air passes around the Fresnel lens and
into the lamphead regardless of the tilt angle.
At the heart of the TRUE BLUE concept is a redesigned
stirrup and improved tilt lock. The stainless steel friction
disc locks the lamphead securely even with the largest
Chimera or other accessories. Tomakelamphead balance
even easier, the stirrup mounting slides and can be
adjusted to counterbalance all accessories. The new
extruded aluminum stirrup is stronger, lighter and less
bulky but still permits full fixture rotation. Its soft contour
makes it comfortable to carry.
The newStegmaier connector* and strain relief rotate to
allow the cable orientation to be quickly adjusted for
hanging or stand mounting. Improved barndoorsare
stronger,less susceptible to bending and a new hinge
design maintains constant tension that can be easily
adjusted.
Routine maintenance and repair are easier with fast, simple
access to all internal components. Cleaning is made
effortless with smooth lamp housing surfaces.
ARRI has redesigned these new lights down to the smallest
detail, offering lighting professionals better choices for
location and studio work. TRUE BLUE Fresnels from 1000
to 5000W include the T1, T2, T5, ST1, ST2 and ST5.
* Patent pending

4
We’ve named this component for its inventor and the principal designer of
ARRI TRUE BLUES. With this combination connector and strain relief, the
power cable can be quickly reoriented for stand mount or hanging fixtures.
In addition, the connector,along with ARRI’s new lampholder, allows us
to eliminate the interior terminal block.
Patent pending
Stegmaier Connector
ARRI’s cross cooling system moves a stream of air around the Fresnel lens
and through the lamphead. In addition, air is channeled through the
aluminum extrusion housing reducing lens temperature by 17% and housing
temperatures by 25%. Cross cooling allows ARRI TRUE BLUES to safely
operate at almost any tilt angle.
Patent pending
Cross Cooling
Modern fixtures use a wide variety of Chimeras, scrollers and other front
mounted accessories. Simply slide ARRI’sunique stirrup bracket to quickly
and easily adjust the fixture’s center of gravity.
*Due to the smaller size of the fixture, the sliding stirrup is not used on the T1.
Sliding Stirrup
ARRI’s new design creates a positive lock so there’s no slippage when using
heavy accessories. A stainless steel friction disc functions like a disc brake
allowing the lamphead to be completely locked off with a minimum of force.
* Due to the smaller size of the fixture, the friction disc tilt lock is not used
on the T1.
Tilt Lock

5
ARRI |TRUE BLUE
Sometimes simple and reliable is the best answer. The new ARRI spring
loaded Top Latch lifts and turns completely out of the way to load and
unload scrims and barndoors, then pivots back into its locked position.
Top Latch
Finally an easy solution to an old problem. Location crews need space in the
accessory bracket for up to four scrims; studio crews suffer from the light
leak this creates. Now TRUE BLUE accessory brackets quickly adjust for two
or four scrim use.
Adjustable Accessory Brackets
TRUE BLUE fixtures have been designed for serviceability with more common
parts across the line. Removing six universal Torx screws provides easy
access to all interior parts. TRUE BLUES require only three Torx drivers to
disassemble the complete fixture.
ARRI’s new aluminum extrusion makes cleaning fixtures easy and our new
paint process ensures that TRUE BLUES will look as great as they perform.
Maintenance
TRUE BLUE fixtures are
manufactured to the IP23 standard
and are suitable for indoor use or
outdoor use providing a degree of
protection against falling rain (up to
a60˚ angle from vertical).
IP23
NewARRI barndoorsuse a special alloywith a high strength-to-weight ratio.
Although lighter in weight, the leaves in our new design withstand bending
and deforming far better than traditional barndoors. In addition, leaves are
noweasily tightened to avoid slipping and the larger leaf design provides
better control and sharper cutoff.
Barndoors
The laser cut hexagonal safety mesh maximizes light transmission and is
tough enough to withstand location abuse.
Stainless Steel Lens Protection
Easy to carry, ARRI’s new aluminum extrusion stirrup is smooth, incredibly
strong and extremely lightweight.
Stirrup Contour

6
Cat. No. Description
551100 T1 1000W Fresnel, Stand Model
551101 T1 1000W Fresnel, Hanging Model
551102 T1 1000W Fresnel, Stand Model, Black
551103 T1 1000W Fresnel, Hanging Model, Black
551105 T1 1000W Fresnel, Pole Operated
551110 Four Leaf Barndoor
551115 Eight Leaf Barndoor
531120 Filter Frame
531130 Snoot
531150 7 3/4” Full Single Scrim
531151 7 3/4” Half Single Scrim
531152 7 3/4” Full Double Scrim
531153 7 3/4” Half Double Scrim
571712 Scrim Bag
853276 Safety Cable
571740 1800W Digital Dimmer
571197 Heavy Duty Case
Lamps
Code EGT EGR CP40
Watts 1000 750 1000
Volts 120 120 230
Color Temp (K) 3200 3200 3200
Approx. Life (hrs) 250 200 200
Specifications
Weight* 11.4 lbs. (5.2 kg)
Cable 23.0 ft. (7.0 m) cable with inline switch; Hanging model with 3.0 ft. (1.0 m) cable w/o switch
Lens Diameter 5.9” (150 mm) low expansion borosilicate Fresnel lens
Reflector Spherical specular high purity aluminum
Lampholder G22/38
Mounting Combination mount for 5/8” (16 mm) stand or 1 1/8” (28 mm) stand; Hanging model with
pipe clamp
Certification NRTL-US-C; CE; IP23
Photometric Data with EGT 1000W Lamp
Distance 10 ft. (3.0 m) 15 ft. (4.6 m) 20 ft. (6.1 m) 25 ft. (7.6 m) 30 ft. (9.1 m)
Spot Focus Beam Angle 8°
Footcandles 1634 726 409 261 182
Beam Diameter 1.4 ft. (0.4 m) 2.1 ft. (0.6 m) 2.8 ft. (0.9 m) 3.5 ft. (1.1 m) 4.2 ft. (1.3 m)
Medium Focus Beam Angle 30°
Footcandles 418 186 105 67 46
Beam Diameter 5.4 ft. (1.6 m) 8.0 ft. (2.4 m) 10.7 ft. (3.3 m) 13.4 ft. (4.1 m) 16.1 ft. (4.9 m)
Flood Focus Beam Angle 54°
Footcandles 194 86 48 31 22
Beam Diameter 10.2 ft. (3.1 m) 15.3 ft. (4.7 m) 20.4 ft. (6.2 m) 25.5 ft. (7.8 m) 30.6 ft. (9.3 m)
Spot Performance at any distance:
Footcandles (or lux) = 163,400 ÷ Distance2Beam Diameter = Distance x 0.14
Medium Performance at any distance:
Footcandles (or lux) = 41,800 ÷ Distance2Beam Diameter = Distance x 0.54
Flood Performance at any distance:
Footcandles (or lux) = 19,350 ÷ Distance2Beam Diameter = Distance x 1.02
*Stand Model
1000W Fresnel
T1
AVAILABLE SEPTEMBER 2008

7
ARRI |TRUE BLUE
Cat. No. Description
552100 ST1 1000W Studio Fresnel, Stand Model
552101 ST1 1000W Studio Fresnel, Hanging Model
552102 ST1 1000W Studio Fresnel, Stand Model, Black
552103 ST1 1000W Studio Fresnel, Hanging Model, Black
552105 ST1 1000W Studio Fresnel, Pole Operated
551210 Four Leaf Barndoor
551215 Eight Leaf Barndoor
531220 Filter Frame
531230 Snoot
531250 9” Full Single Scrim
531251 9” Half Single Scrim
531252 9” Full Double Scrim
531253 9” Half Double Scrim
571714 Scrim Bag
853276 Safety Cable
531510 Operating Pole for pole-op fixtures
571740 1800W Digital Dimmer
Lamps
Code EGT EGR CP40
Watts 1000 750 1000
Volts 120 120 230
Color Temp (K) 3200 3200 3200
Approx. Life (hrs) 250 200 200
Specifications
Weight* 16.5 lbs. (7.5 kg)
Cable 23.0 ft. (7.0 m) cable with inline switch; Hanging model with 3.0 ft. (1.0 m) cable w/o switch
Lens Diameter 6.9” (175 mm) low expansion borosilicate Fresnel lens
Reflector Spherical specular high purity aluminum
Lampholder G22/38
Mounting Combination mount for 5/8” (16 mm) stand or 1 1/8” (28 mm) stand; Hanging model with
pipe clamp
Certification NRTL-US-C; CE; IP23
Photometric Data with EGT 1000W Lamp
Distance 10 ft. (3.0 m) 15 ft. (4.6 m) 20 ft. (6.1 m) 25 ft. (7.6 m) 30 ft. (9.1 m)
Spot Focus Beam Angle 10°
Footcandles 1667 741 417 267 185
Beam Diameter 1.7 ft. (0.5 m) 2.6 ft. (0.8 m) 3.5 ft. (1.1 m) 4.4 ft. (1.3 m) 5.2 ft. (1.6 m)
Medium Focus Beam Angle 30°
Footcandles 409 182 102 65 45
Beam Diameter 5.4 ft. (1.6 m) 8.0 ft. (2.4 m) 10.7 ft. (3.3 m) 13.4 ft. (4.1 m) 16.1 ft. (4.9 m)
Flood Focus Beam Angle 54°
Footcandles 201 89 50 32 22
Beam Diameter 10.2 ft. (3.1 m) 15.3 ft. (4.7 m) 20.4 ft. (6.2 m) 25.5 ft. (7.8 m) 30.6 ft. (9.3 m)
Spot Performance at any distance:
Footcandles (or lux) = 166,725 ÷ Distance2Beam Diameter = Distance x 0.18
Medium Performance at any distance:
Footcandles (or lux) = 40,900 ÷ Distance2Beam Diameter = Distance x 0.54
Flood Performance at any distance:
Footcandles (or lux) = 20,050 ÷ Distance2Beam Diameter = Distance x 1.02
*Stand Model
ST1
1000W Studio Fresnel

2000W Fresnel
T2
8
Cat. No. Description
551200 T2 2000W Fresnel, Stand Model
551201 T2 2000W Fresnel, Hanging Model
551202 T2 2000W Fresnel, Stand Model, Black
551203 T2 2000W Fresnel, Hanging Model, Black
551205 T2 2000W Fresnel, Pole Operated
551210 Four Leaf Barndoor
551215 Eight Leaf Barndoor
531220 Filter Frame
531230 Snoot
531250 9” Full Single Scrim
531251 9” Half Single Scrim
531252 9” Full Double Scrim
531253 9” Half Double Scrim
571714 Scrim Bag
853276 Safety Cable
531510 Operating Pole for pole-op fixtures
Lamps
Code CYX CXZ CYV CP41
Watts 2000 1500 1000 2000
Volts 120 120 120 230
Color Temp (K) 3200 3200 3200 3200
Approx. Life (hrs) 300 300 200 400
Specifications
Weight* 18 lbs. (8.2 kg)
Cable 23.0 ft. (7.0 m) cable with inline switch; Hanging model with 3.0 ft. (1.0 m) cable w/o switch
Lens Diameter 6.9” (175 mm) low expansion borosilicate Fresnel lens
Reflector Spherical specular high purity aluminum
Lampholder G22/38
Mounting 1 1/8” (28 mm) stand; Hanging model with pipe clamp
Certification NRTL-US-C; CE; IP23
Photometric Data with CYX 2000W Lamp
Distance 15 ft. (4.6 m) 20 ft. (6.1 m) 25 ft. (7.6 m) 30 ft. (9.1 m) 40 ft. (12.2 m)
Spot Focus Beam Angle 13°
Footcandles 930 523 335 232 131
Beam Diameter 3.4 ft. (1.0 m) 4.6 ft. (1.4 m) 5.7 ft. (1.7 m) 6.8 ft. (2.1 m) 9.1 ft. (2.8 m)
Medium Focus Beam Angle 30°
Footcandles 321 181 116 80 45
Beam Diameter 8.0 ft. (2.4 m) 10.7 ft. (3.3 m) 13.4 ft. (4.1 m) 16.1 ft. (4.9 m) 21.4 ft. (6.5 m)
Flood Focus Beam Angle 58°
Footcandles 135 76 49 34 19
Beam Diameter 16.6 ft. (5.1 m) 22.2 ft. (6.8 m) 27.7 ft. (8.4 m) 33.3 ft. (10.1 m) 44.3 ft. (13.5 m)
Spot Performance at any distance:
Footcandles (or lux) = 209,175 ÷ Distance2Beam Diameter = Distance x 0.23
Medium Performance at any distance:
Footcandles (or lux) = 72,200 ÷ Distance2Beam Diameter = Distance x 0.54
Flood Performance at any distance:
Footcandles (or lux) = 30,425 ÷ Distance2Beam Diameter = Distance x 1.11
*Stand Model

ST2
2000W Studio Fresnel
9
ARRI |TRUE BLUE
Cat. No. Description
552200 ST2 2000W Studio Fresnel, Stand Model
552201 ST2 2000W Studio Fresnel, Hanging Model
552202 ST2 2000W Studio Fresnel, Stand Model, Black
552203 ST2 2000W Studio Fresnel, Hanging Model, Black
552205 ST2 2000W Studio Fresnel, Pole Operated
552210 Four Leaf Barndoor
552215 Eight Leaf Barndoor
532220 Filter Frame
532230 Snoot
512250 13” Full Single Scrim
512251 13” Half Single Scrim
512252 13” Full Double Scrim
512253 13” Half Double Scrim
571716 Scrim Bag
853276 Safety Cable
531510 Operating Pole for pole-op fixtures
Lamps
Code CYX CXZ CYV CP41
Watts 2000 1500 1000 2000
Volts 120 120 120 230
Color Temp (K) 3200 3200 3200 3200
Approx. Life (hrs) 300 300 200 400
Specifications
Weight* 26.6 lbs. (12.1 kg)
Cable 23.0 ft. (7.0 m) cable with inline switch; Hanging model with 3.0 ft. (1.0 m) cable w/o switch
Lens Diameter 10” (250 mm) low expansion borosilicate Fresnel lens
Reflector Spherical specular high purity aluminum
Lampholder G22/38
Mounting 1 1/8” (28 mm) stand; Hanging model with pipe clamp
Certification NRTL-US-C; CE; IP23
Photometric Data with CYX 2000W Lamp
Distance 15 ft. (4.6 m) 20 ft. (6.1 m) 25 ft. (7.6 m) 30 ft. (9.1 m) 40 ft. (12.2 m)
Spot Focus Beam Angle 10°
Footcandles 1911 1075 688 478 269
Beam Diameter 2.6 ft. (0.8 m) 3.5 ft. (1.1 m) 4.4 ft. (1.3 m) 5.2 ft. (1.6 m) 7.0 ft. (2.1 m)
Medium Focus Beam Angle 30°
Footcandles 423 238 152 106 60
Beam Diameter 8.0 ft. (2.4 m) 10.7 ft. (3.3 m) 13.4 ft. (4.1 m) 16.1 ft. (4.9 m) 21.4 ft. (6.5 m)
Flood Focus Beam Angle 54°
Footcandles 202 114 73 50 28
Beam Diameter 15.3 ft. (4.7 m) 20.4 ft. (6.2 m) 25.5 ft. (7.8 m) 30.6 ft. (9.3 m) 40.8 ft. (12.4 m)
Spot Performance at any distance:
Footcandles (or lux) = 429,950 ÷ Distance2Beam Diameter = Distance x 0.18
Medium Performance at any distance:
Footcandles (or lux) = 95,200 ÷ Distance2Beam Diameter = Distance x 0.54
Flood Performance at any distance:
Footcandles (or lux) = 45,400 ÷ Distance2Beam Diameter = Distance x 1.02
*Stand Model

5000W Fresnel
T5
10
Cat. No. Description
551500 T5 5000W Fresnel, Stand Model
551501 T5 5000W Fresnel, Hanging Model
551502 T5 5000W Fresnel, Stand Model, Black
551503 T5 5000W Fresnel, Hanging Model, Black
551505 T5 5000W Fresnel, Pole Operated
552210 Four Leaf Barndoor
552215 Eight Leaf Barndoor
532220 Filter Frame
532230 Snoot
512250 13” Full Single Scrim
512251 13” Half Single Scrim
512252 13” Full Double Scrim
512253 13” Half Double Scrim
571716 Scrim Bag
853276 Safety Cable
531510 Operating Pole for pole-op fixtures
531530 6K Dimmer (120V/50-60Hz)
Lamps
Code DPY CP29
Watts 5000 5000
Volts 120 230
Color Temp (K) 3200 3200
Approx. Life (hrs) 500 500
Specifications
Weight* 27.7 lbs. (12.6 kg)
Cable 10.0 ft. (3.0 m) cable with inline switch; Hanging model with 3.0 ft. (1.0 m) cable w/o switch
Lens Diameter 10” (250 mm) low expansion borosilicate Fresnel lens
Reflector Spherical specular high purity aluminum
Lampholder G22/38
Mounting 11/8” (28 mm) stand; Hanging model with pipe clamp
Certification NRTL-US-C; CE; IP23
Photometric Data with DPY 5000W Lamp
Distance 20 ft. (6.1 m) 25 ft. (7.6 m) 30 ft. (9.1 m) 40 ft. (12.2 m) 50 ft. (15.2 m)
Spot Focus Beam Angle 15°
Footcandles 1207 772 536 302 193
Beam Diameter 5.3 ft. (1.6 m) 6.6 ft. (2.0 m) 7.9 ft. (2.4 m) 10.5 ft. (3.2 m) 13.2 ft. (4.0 m)
Medium Focus Beam Angle 30°
Footcandles 603 386 268 151 96
Beam Diameter 10.7 ft. (3.3 m) 13.4 ft. (4.1 m) 16.1 ft. (4.9 m) 21.4 ft. (6.5 m) 26.8 ft. (8.2 m)
Flood Focus Beam Angle 53°
Footcandles 301 192 134 75 48
Beam Diameter 19.9 ft. (6.1 m) 24.9 ft. (7.6 m) 29.9 ft. (9.1 m) 39.9 ft. (12.2 m) 49.9 ft. (15.2 m)
Spot Performance at any distance:
Footcandles (or lux) = 482,600 ÷ Distance2Beam Diameter = Distance x 0.26
Medium Performance at any distance:
Footcandles (or lux) = 241,125 ÷Distance2Beam Diameter = Distance x 0.54
Flood Performance at any distance:
Footcandles (or lux) = 120,275 ÷ Distance2Beam Diameter = Distance x 1.0
*Stand Model

ST5
5000W Studio Fresnel
11
ARRI |TRUE BLUE
Cat. No. Description
552500 ST5 5000W Studio Fresnel, Stand Model
552501 ST5 5000W Studio Fresnel, Hanging Model
552502 ST5 5000W Studio Fresnel, Stand Model, Black
552503 ST5 5000W Studio Fresnel, Hanging Model, Black
552505 ST5 5000W Studio Fresnel, Pole Operated
552510 Four Leaf Barndoor
552515 Eight Leaf Barndoor
532520 Filter Frame
532530 Snoot
532550 15 1/2” Full Single Scrim
532551 15 1/2” Half Single Scrim
532552 15 1/2” Full Double Scrim
532553 15 1/2” Half Double Scrim
571716 Scrim Bag
853276 Safety Cable
531510 Operating Pole for pole-op fixtures
531530 6K Dimmer (120V/50-60Hz)
Lamps
Code DPY CP29
Watts 5000 5000
Volts 120 230
Color Temp (K) 3200 3200
Approx. Life (hrs) 500 500
Specifications
Weight* 33.9 lbs. (15.4 kg)
Cable 10.0 ft. (3.0 m) cable with inline switch; Hanging model with 3.0 ft. (1.0 m) cable w/o switch
Lens Diameter 11.8” (300 mm) low expansion borosilicate Fresnel lens
Reflector Spherical specular high purity aluminum
Lampholder G22/38
Mounting 11/8” (28 mm) stand; Hanging model with pipe clamp
Certification NRTL-US-C; CE; IP23
Photometric Data with DPY 5000W Lamp
Distance 20 ft. (6.1 m) 25 ft. (7.6 m) 30 ft. (9.1 m) 40 ft. (12.2 m) 50 ft. (15.2 m)
Spot Focus Beam Angle 12°
Footcandles 1469 940 653 367 235
Beam Diameter 4.2 ft. (1.3 m) 5.3 ft. (1.6 m) 6.3 ft. (1.9 m) 8.4 ft. (2.6 m) 10.5 ft. (3.2 m)
Medium Focus Beam Angle 30°
Footcandles 627 401 279 157 100
Beam Diameter 10.7 ft. (3.3 m) 13.4 ft. (4.1 m) 16.1 ft. (4.9 m) 21.4 ft. (6.5 m) 26.8 ft. (8.2 m)
Flood Focus Beam Angle 61°
Footcandles 246 157 109 61 39
Beam Diameter 23.6 ft. (7.2 m) 29.5 ft. (9.0 m) 35.3 ft. (10.8 m) 47.1 ft. (14.4 m) 58.9 ft. (18.0 m)
Spot Performance at any distance:
Footcandles (or lux) = 587,500 ÷ Distance2Beam Diameter = Distance x 0.21
Medium Performance at any distance:
Footcandles (or lux) = 250,850 ÷Distance2Beam Diameter = Distance x 0.54
Flood Performance at any distance:
Footcandles (or lux) = 98,375 ÷ Distance2Beam Diameter = Distance x 1.18
*Stand Model

www.arri.com
Specifications are subject to change without notice. © 2008 ARRI Inc. RP-3/2008/5000 aMintDesign
ARRI Inc.
617 Route 303 Blauvelt NY, 10913-1109
Tel.[phone] Fax[phone]
www.arri.com
ARRI Inc.
600 N. Victory Blvd. Burbank CA, 91502-1639
Tel.[phone] Fax[phone]
www.arri.com
ARRI Inc.
2385 Stirling Road Ft. Lauderdale FL, 33312-6608
Tel.[phone] Fax[phone]
www.arri.com
ARRI Canada LTD.
415 Horner Avenue, Unit 11 Etobicoke, Ontario M8W 4W3,
Canada
Tel.[phone] Fax[phone]
www.arrican.com
