Asko T754CW User manual

Dear Customer,
Thank you for choosing this quality product from ASKO. We hope it will
meet your expectations and fulfill your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality, and
high quality. These are key characteristics of all our products and the
reason they are greatly appreciated throughout the world.
To ensure that you get the most out of your new machine, we recommend
that you read the operating instructions before using the machine. The
operating instructions also contain information on how to avoid damaging
the environment.
Operating Instructions
Tumble dryer
ASKO T754C W
WARNING: Read the instructions before using the machine.

2Customer Care Center
1-800-898-1879
www.askona.com
Contents
Before using your machine for the first
time 3
Important safety instructions 4
Grounding instructions 5
Packing material 6
Disposal 6
Child safety 7
General 7
Description of the tumble dryer 8
Advice and tips before you tumble dry 9
Materials that can be tumble dried 9
Materials that should not be tumble dried 9
Static electricity 9
Operating instructions 10
Sort your fabrics 10
Press the main power switch until the
display lights. 10
Open the door, load the items, and then
close the door 10
Select the program 11
Selecting Options 13
Press the Start button 14
Drying program finished 14
Care and maintenance instructions 15
Cleaning the lint filter 15
Cleaning the condenser 16
Cleaning the outside of the machine 17
Troubleshooting 18
The machine will not start 18
The machine loses all power during a
program 18
Drying takes too long 18
Error messages 18
Technical information 19
Technical data 19
Service and guarantee 20
Limited Warranty – Residential
Appliances 20
Installation instructions 23
Installation 23
Electrical installation 23
Reversing the door 24
Follow these instructions: 25
Original instructions

3
Customer Care Center
1-800-898-1879
www.askona.com
Before using your machine for the first time
Laundry labels
Certain materials are not suitable for tumble
drying. Always check and follow the instructions
on each item's laundry label. You can find more
information in the Advice and tips before you
tumble dry chapter.
NOTE!
When starting the tumble dryer for the first time
or after a long period without use, you may hear
a slight thumping noise. This noise is completely
normal and will disappear after a few loads.
Do you need this Use&Care Guide in Spanish? Log on to www.askona.com/customer-care to
download. ¿Necesita esta Instrucciones de uso y cuidado en español? Entre en www.askona.com/
customer-care. y descárguesela.

4Customer Care Center
1-800-898-1879
www.askona.com
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE
WARNING!
WARNING - To reduce the risk of fire,
electric shock, or injury to persons
when using your appliance, follow basic
precautions, including the following:
• Read all instructions before using the
appliance.
• Your dryer is intended solely for
household use.
• Do not wash or dry articles that have
been previously cleaned in, washed
in, soaked in, or spotted with gasoline,
dry-cleaning solvents, cooking
oils, other flammable or explosive
substances as they give offvapors
that could ignite or explode.
• Do not allow children to play on or
in the appliance. Children should be
closely supervised when near the
appliance.
• Before the appliance is removed from
service or discarded, remove the door
to the drying compartment.
• Do not reach into the appliance if the
drum is moving.
• Do not install or store this appliance
where it will be exposed to the
weather.
• Do not tamper with controls.
• Do not attempt to repair or replace
any part of the appliance or perform
any servicing unless specifically
recommended in this guide.
• Do not use fabric softeners or dryer
sheets unless the manufacturer gives
written assurance that the product will
not damage a tumble dryer.
• Do not heat dry items containing
vinyl, plastic, foam rubber or similarly
textured rubberlike materials,
fiberglass, or wool unless the label
specifies “washable”.
• Clean the lint filter before or after each
load.
• Keep the area around the exhaust
opening and adjacent surrounding
areas free from the accumulation of
lint, dust and dirt.
• The interior of the machine should be
cleaned periodically by an authorized
ASKO service agent.
• Do not place items exposed to
cooking oils in your dryer. Items
contaminated with cooking oils may
contribute to a chemical reaction that
could cause a load to catch fire.
• Electrical installation, if required, must
be done by a licensed electrician.
• Do not operate appliance while away
from the home.
• Do not heat dry items that have been
dry-cleaned.
• The dryer is made and marked to
facilitate recycling. When it is no
longer useful, contact your local refuse
collection service for advice on how
to properly dispose of the dryer for
purposes of recycling.
• Damaged power cables should
only be replaced by a certified
professional.
• Provide sufficient ventilation,
otherwise smoke from open fires or
fumes from equipment burning other
fuels can be drawn into the room.
•
Important safety instructions

5
Customer Care Center
1-800-898-1879
www.askona.com
Important safety instructions
CAUTION!
During the program, the back of the
dryer will get very hot. Let the machine
cool completely before touching the
back.
WARNING!
This appliance must be properly
grounded.
Grounding instructions
A) Grounding instructions for a
grounded, cord-connected appliance
In the event of malfunction or
breakdown, grounding will reduce the
risk of electric shock by providing a path
of least resistance for electric current.
This appliance (Canadian market only)
is equipped with a cord having an
equipment-grounding conductor and
a grounding plug. The plug must be
plugged into an appropriate outlet that
is properly installed and grounded in
accordance with all local codes and
ordinances.
WARNING!
Improper connection of the equipment-
grounding conductor can result in a risk
of electric shock. Check with a qualified
electrician or service representative
or personnel if you are in doubt as
to whether the appliance is properly
grounded. Do not modify the plug
provided with the appliance (Canadian
market only). If it will not fit the outlet,
have a proper outlet installed by a
qualified electrician.
To reduce the risk of fire, this appliance
must be exhausted outdoors or the
equivalent. Do not exhaust into a
chimney, wall, ceiling or concealed
space in a building.

6Customer Care Center
1-800-898-1879
www.askona.com
Important safety instructions
B) Grounding instructions for a
permanently connected appliance:
This appliance must be connected to
a grounded metal, permanent wiring
system, or an equipment-grounding
conductor must be run with the circuit
conductors and connected to the
equipment-grounding terminal or lead on
the appliance.
NOTE!
This manual does not cover every
possible condition and situation that
may occur. Use common sense and
caution when installing, operating, and
maintaining any appliance.
Installation
See the separate installation instructions.
Packing material
Please sort waste materials in
accordance with local guidelines.
Disposal
This machine is manufactured and
labeled for recycling. In order to prevent
personal injury, the machine must be
made inoperable after deciding to take it
out of service. Contact your municipality
for information about where and how
your machine can be recycled correctly.
WARNING!
This product may contain chemicals
known to the state of California to cause
cancer or reproductive harm.

7
Customer Care Center
1-800-898-1879
www.askona.com
General
WARNING!
Do not allow children to play with the
tumble dryer.
• If the door is opened when a program
is running, the garments may be very
hot, with a risk of burn injuries.
• The tumble dryer does not start
automatically when the door is closed
(if a child pulls the door shut from the
inside, for example).
Child safety

8Customer Care Center
1-800-898-1879
www.askona.com
Description of the tumble dryer
1. Main power switch
2. Panel
3. Serial number tag and rating plate
4. Lint filter
5. Outer door
6. Condenser
4 52
13
6

9
Customer Care Center
1-800-898-1879
www.askona.com
Advice and tips before you tumble dry
Here are some tips that may help you before
you begin tumble drying.
Have the clothes been spun?
Items to be tumble dried should be spun at 1000
rpm or faster. Higher spin speeds save energy
and reduce drying time.
Materials that can be tumble dried
This symbol means that the material is
suitable for tumble drying. Fabrics best suited
to tumble drying are cotton fabrics, terry cloth,
and synthetic fibers. Garments will be softer and
lighter when tumbled than when hung out to dry.
NOTE!
The tumble dryer does not cause any significant
wear on fabrics. The lint trapped in the lint filter
consists of dust and fiber residues formed when
the items are used.
Materials that should not be tumble
dried
This symbol means that the material is not
suitable for tumble drying. Certain materials
may melt or become a fire hazard if exposed to
heat and others can lose their shape or shrink.
And do not tumble dry
• materials labeled "Do not dry near heat".
• garments that have been dry-cleaned at
home.
• plastic foam.
• fiberglass material.
• wool must not be tumble dried due to the risk
of piling.
Static electricity
To reduce the risk of static electricity in the
laundry after tumble drying, you can:
• Use fabric softener when washing.
• Wait five minutes after the drying program
ends before opening the door and removing
the laundry from the dryer.
NOTE!
You can stop the tumble dryer by pressing the
Stop button for three seconds or by opening the
door. In both cases the program is stopped and
starts from the beginning if restarted.
If you do not want to restart the program,
immediately remove all laundry and spread it
out to allow the heat to dissipate.

10 Customer Care Center
1-800-898-1879
www.askona.com
WARNING!
To reduce the risk of electric shock or injury
to persons, read the "Important Safety
Instructions" section before operating this
appliance.
Below are step-by-step instructions to help you
achieve the best possible tumble drying results.
1Sort your fabrics
You will achieve the most uniform drying
results if the items are made of the same
type of material. Close zippers and fasten
buttons or belts; sort the items and adjust load
and temperature.
Do not overload the drum!
Overloading the dryer will result in poor drying
results and wrinkling.
2Press the main power switch
until the display lights.
NOTE!
Power on
Press the on/offbutton for min. 1 sec and max.
5 sec.
Power off
Press the on/offbutton for min. 5 sec.
If the ON/OFF command is not correctly
accepted by the machine, wait min. 8 sec before
any further press.
3Open the door, load the items,
and then close the door
Make sure that objects e.g. detergent
dispensing balls, have been removed from the
laundry. They could melt and cause damage to
the dryer or the laundry.
To save energy, always observe the maximum
load for each programme (see Program chart).
Operating instructions

11
Customer Care Center
1-800-898-1879
www.askona.com
4Select the program
Operating instructions
Guidelines as to what specific
programs can be used for:
Auto Heavy
Program with the maximum temperature. This
program is for items that are particularly difficult
to dry, such as jeans with very thick seams.
NOTE!
Knitted fabrics in particular are prone to
shrinkage. Use the Auto Normal, Auto Delicate,
or Auto Iron Dry programs for these items.
Stretch clothes back into shape immediately
after drying.
Auto Normal and Auto Delicate
These programs end automatically when the
load is dry. The Auto Normal program leaves
the laundry slightly more dry than Auto Delicate.
Auto Iron Dry
This program shuts offthe heat once the load is
just damp enough for ironing or pressing.
Timed Dry
The most suitable program time depends
on what you intend to do with the items after
tumble drying them. Use trial and error to find
out what works best. When you use Timed Dry
to tumble dry a load of mixed fabrics, some of
the garments may remain damp. Tumble dry
any damp garments for a further 30 minutes
or so using the Timed Dry program. Select the
desired time by pressing the Delayed Start
button. A program time between 30 minutes and
3 hours can be selected and each button press
changes the time by 15 minutes.
NOTE!
When using the Timed Dry program with a
program time that is too long, the garments
can become "over-dry". This can cause items
to shrink or wrinkle and feel rough to the touch.
Synthetic materials can also become charged
with static electricity.
Air Fluff
Use the Air Fluffprogram when you just want to
refresh, air out, or soften up items.
Select the desired time by pressing the Delayed
Start button. A program time between 15
minutes and 3 hours can be selected and each
button press changes the time by 15 minutes.
Select a program by turning the program selector. An LED lights next to the selected program. Use the
option buttons to select any options.
/
Program selector
Options buttonsMain power switch
Start Stop
Display window

12 Customer Care Center
1-800-898-1879
www.askona.com
Operating instructions
Program chart
Here we present the energy and time consumption of a few different programs. The table shows the
effect of using different spin speeds when washing the load. Consumption can vary depending on
room temperature, humidity, load, variations in the power supply, and selected options.
For the consumption values given below, the requirements are as follows:
Temperature of intake air: 73 °F (23 °C)
Moisture content of intake air: 55 %
Drying temperature: Normal
Heater output: 2500W
Program Material Load Spin speed (rpm) Energy consumption,
approx. (kWh)
Program time,
approx. (min)
Auto Heavy Cotton, linen 1/1 800 4.5 2:00
1000 4.2 1:50
1400 3.7 1:40
1600 3.5 1:35
Auto Normal Cotton, linen 1/1 800 4.3 1:50
1000 3.9 1:45
1400 3.4 1:30
1600 3.2 1:25
Wrinkle-resistant, polyester/cotton 1/2 1000 2.0 1:00
Auto Delicate Cotton, linen 1/1 800 4.2 1:50
1000 3.92 1:40
1400 3.3 1:25
1600 2.8 1:15
Wrinkle-resistant, polyester/cotton 1/2 1000 1.41 0:40
Auto Iron Dry Cotton, linen 1/1 800 4.1 2:05
1000 3.50 1:45
1400 2.8 1:30
1600 2.2 1:10

13
Customer Care Center
1-800-898-1879
www.askona.com
Operating instructions
5Selecting Options
By selecting options, you can
tailor a drying program to suit your
requirements. The available options depend on
the selected program. Once you have started
the program, the options you selected are saved
for the next time you use the same program.
Temperature Low
You can select Temperature Low with all
programs except Air Fluffand Timed Dry.
• Select Temperature Low by pressing the
button next to the symbol.
• The lamp next to the button lights when
Temperature Low is selected.
Time saver
You can select Time saver with all programs
except Air Fluff. The program is shortened by
about 12 minutes.
• Press the button next to the symbol.
• The lamp next to the button lights when
Temperature Saver is selected.
Anti Wrinkle
This option means that the drum will rotate for
three seconds per minute for two hours after the
drying program has finished. If you are unable
to remove the items immediately after the
program has finished, this option prevents the
garments from remaining in the same position
and becoming wrinkled. Cannot be selected
with the Air Fluffprogram.
• Select Anti Wrinkle by pressing the button
next to the symbol.
• The lamp next to the button lights when Anti
Wrinkle is selected.
Delayed Start
Select a program and then press Delayed
Start. Press the button to select a delayed start
of 1 to 24 hours. The lamp next to the button
lights when this option is activated. Next, press
Start and the machine will count down 1 hour
at a time and start after the selected delay.
To cancel Delayed Start, press and hold Stop
for three seconds. Delayed Start cannot be
selected with Timed Dry or Air Fluff.

14 Customer Care Center
1-800-898-1879
www.askona.com
Operating instructions
6Press the Start button
Remaining drying time
An estimate of the remaining drying time
will be shown on the display a few minutes after
the drying program starts. 1:35 means that it will
take approximately 1 hour and 35 minutes for
the load to dry.
The actual remaining time may be longer than
the estimated time shown on the display. The
remaining time is then shown as 0:15 until the
laundry is sufficiently dry. If you selected Time
saver, the display will show 0:05 instead.
You can stop the tumble dryer by pressing the
Stop button or by opening the door. In both
cases the program is stopped and starts from
the beginning if restarted.
NOTE!
The program will not be affected if you change
the program selector after the program has
started.
7Drying program finished
The text "End" is shown on the display for
2 minutes. The machine then turns off.
NOTE!
• Clean the lint filter in the outer door after
each load. See the Care and maintenance
instructions chapter.
To install the automatic drain hose, please see
the section titled Installation
WARNING!
If the lint filter becomes clogged, the machine’s
automatic overheating cut-out may be triggered.
Clean the filter, wait until the machine has
cooled, then try starting it. If it still does not start:
Call the Customer Care Center.
Once drying has finished
Remove the clothes and close the door to
prevent small children from climbing into the
machine.

15
Customer Care Center
1-800-898-1879
www.askona.com
Care and maintenance instructions
Cleaning the lint filter
The lint filter must be cleaned after each load.
1. Lift the filter from the holder in the door.
2. Open the lint filter. Push against the edge
with your thumb as shown in the figure.
3. Open the inner filter as shown in the figure.
4. Use your hand or a soft cloth to remove the
lint from all sides of the filter. If necessary,
use a damp sponge and a small amount of
washing-up liquid dish soap to remove any
deposits. Dry the filter thoroughly with a
towel.
NOTE!
Clean the surface of the lint (fluff) filter after
each drying program.
5. To close the lint filter, follow the reverse order
of steps used for opening. Then, replace the
filter by sliding it back into the door. Close the
lint filter before closing the door.

16 Customer Care Center
1-800-898-1879
www.askona.com
Cleaning the condenser
The condenser should be cleaned at least three
times a year. If you have pets, the condenser
must be cleaned more frequently.
1. Turn offthe tumble dryer with the main power
switch and open the outer door.
2. Remove the Toe kick.
3. Open the condenser panel by turning the two
knobs.
4. Remove the condenser and rinse the ribs
clean with a sink spray nozzle or a garden
hose with attached spray nozzle. Do not
poke around in the rib gaps as you may
damage the condenser. Do not use pointed
metal objects when cleaning.
NOTE!
Do not clean the condenser in a dishwasher.
5. Wipe any lint from the channel in front of
the condenser and inside the condenser
compartment. Use a cotton rag to remove
any lint from the drain hole at the front edge
of the compartment.
NOTE!
It is quite normal for water to collect in the
channel in front of the condenser.
6. Replace the condenser with the handle
facing down as illustrated.
7. Reattach the toe kick.
Care and maintenance instructions

17
Customer Care Center
1-800-898-1879
www.askona.com
Care and maintenance instructions
NOTE!
Clean the filters after each drying.
Do not replace the filters if they are damp or
wet. Damp or wet filters could cause operational
faults.
NOTE!
The dryer should never be operated without
the filters in place, or with damaged filters as
excessive amount of accumulated fibres from
the fabric could cause malfunction or failure of
the dryer.
Cleaning the outside of the machine
Clean the outside of the machine and the
program panel with a mild cleaner. Do not use
solvents, as these can damage the machine. Do
not hose down or spray the machine with water.
NOTE!
Do not allow dust to accumulate around the
machine. Keep the area around the tumble
dryer clean and cool; dust, heat, and moisture
prolong drying times.

18 Customer Care Center
1-800-898-1879
www.askona.com
Troubleshooting
The machine will not start
Check:
• that the door is properly closed.
• that the main power switch is on.
• that the Delayed Start option has not been
selected. To cancel Delayed Start, press the
Stop button for three seconds.
• that any plug is connected.
• that the house fuses or circuit breaker have
not been tripped.
• that the overheating cut-out has not been
triggered.
The machine loses all power during a
program
The overheating cut-offshuts offthe tumble
dryer if the temperature is too high, caused by
lint clogging the lint filter, for instance.
• Clean the lint filter.
• Check that the condenser is clean. Clean it
if necessary. See the Care and maintenance
instructions chapter.
• Wait until the machine has cooled, then try
starting it. If it still does not start: Call the
Customer Care Center.
Drying takes too long
• Check that the lint filter is not blocked. See
the Care and maintenance instructions
chapter.
• Check that the condenser is not blocked.
See the
• Care and maintenance instructions chapter.
• Prolonged drying times may also be due to
the tumble dryer being located in a confined
area or in a room that is too small, causing
the air to become too hot.
• Make sure that the tumble dryer has access
to more cold air, open doors and/or windows,
for example.
Error messages
If F30 is flashing on the display, the maximum
permitted program time has been reached.
Check that the lint filter and the condenser are
not blocked. See the Care and maintenance
instructions chapter.

19
Customer Care Center
1-800-898-1879
www.askona.com
Technical data
Height: 33 1/2'' (850 mm)
Width: 23 1/2'' (597 mm)
Depth: 23 7/8" (606 mm)
Weight (net): 97 lb (44 kg)
Cylinder volume: 29,6 gal (112 l)
Max. drying capacity: 15 lb (7 kg)
Speed: 50-55 rpm
Rated power: See serial number tag and rating plate.
Drum material: Stainless steel
Outer casing material: Powder-coated and hot-galvanized sheet steel or stainless steel.
Setup Stacking or freestanding
Technical information

20 Customer Care Center
1-800-898-1879
www.askona.com
Service and guarantee
Limited Warranty – Residential
Appliances
ASKO Distribution North America, LLC.
(“ASKO”) warrants to the original purchaser
(the “ASKO Customer”) of the ASKO product
(the “ASKO Product”), who purchased the
ASKO Product from a distributor, dealer,
manufacturer’s representative or other seller
who has been authorized by ASKO, that this
ASKO Product is free of defects in materials
and/or workmanship, subject to the terms
and conditions set forth herein. This Limited
Warranty covers parts and labor, except as set
forth in this Limited Warranty. Service must
be provided by an authorized ASKO service
company. YOUR SOLE AND EXCLUSIVE
REMEDY UNDER THIS LIMITED WARRANTY
SHALL BE PRODUCT REPAIR AS PROVIDED
HEREIN. This Limited Warranty is valid only
when the ASKO Product is used in the country
in which it was purchased. Proof of original
purchase date is required to obtain service
under this Limited Warranty.
Residential ASKO Products Used
Exclusively for Household/Personal
Purposes:
Two (2) Years limited Warranty – Any warranty
service claims for residential ASKO Products
must be filed with ASKO within two (2) years
from date of purchase. Service will be provided
during normal business hours.
Residential ASKO Products Not Used
Exclusively for Household/Personal
Purposes or used Commercially or
used in Marine, Mobile or Aeronautical
Applications:
One (1) Year limited Warranty – Any warranty
service claims for ASKO Products not used
exclusively for household and personal use, or
used commercially or used in marine, mobile,
or aeronautical applications must be filed with
ASKO within one (1) year from date of purchase.
Service will be provided during normal business
hours.
ITEMS EXCLUDED FROM WARRANTY
This limited warranty does not cover:
1. Replacement parts or repair labor if the
ASKO Product is used in a manner that is
inconsistent with published user or operator
instructions and/or installation instructions.
2. Service calls to correct the installation of the
ASKO Product, to instruct you on how to use
the ASKO Product, to replace or repair house
fuses, or to correct house wiring or plumbing.
3. Consumable items and parts, such as filters.
4. Damage resulting from accident, alteration,
misuse, abuse, negligence, fire, flood, acts
of God, improper use, improper installation,
installation not in accordance with electrical
or plumbing codes, or use of products not
approved by ASKO, as well as any attempted
repair by other than authorized ASKO service
companies.
5. Cosmetic damage, including scratches,
dents, chips or other damage to the
finish of the ASKO Product, unless such
damage results from defects in materials or
workmanship and is reported to ASKO within
5 days from date of purchase.
6. Pickup and delivery. The ASKO Product is
intended to be repaired in your home.
7. Repairs to parts or systems resulting from
unauthorized modifications made to the
ASKO Product.
8. Expenses for travel and transportation for
product service if the ASKO Product is
located in a remote area where service by
an authorized ASKO service company is not
available.
9. The removal and reinstallation of the ASKO
Product if it is installed in an inaccessible
location or is not installed in accordance with
ASKO’s published installation instructions.
10.Replacement parts or repair labor on ASKO
Products with original model/serial numbers
that have been removed, altered or cannot
be easily determined.
