Asparion D700 User manual

Live
D700

1
en
Live
This guide shows you how to set up the D700 in Live. All pictures provided were taken
with Live 11 but it is also applicable to most other Live versions.
All files mentioned in this guide can be found on the USB drive, in the Asparion
Configurator installation folder or on our website.
If you are having trouble with anything in this guide, please contact us via our website
www.asparion.de/contact and we’ll immediately help you.
Step 1:
-Select the Live preset
How to select a preset is described in the main manual.

2
en
Step 2:
-Open Live
-Click on Options->Preferences…

3
en
Step 3:
-Set everything as shown below

4
en
Step 4: (optional)
-Live also has a Midi learn functionality. To do this click on MIDI
-Now you can click on a blue area. This will select the underlying control.
After that press a key on the D700. This will assign that key to the selected
control. Press MIDI again to save
If you are having trouble with this, you should have a look at the manual of your
DAW.

5
en
Step 5: (optional)
-If you would like to assign an encoder to a control in Live, it works the same
way as assigning a button but you should make sure to select Relative (Signed
Bit) in the lower left corner

6
en
Step 6: (optional)
-If you want to connect more than one extension, you should redo step 3 but
select D700 (Port 2) as MIDI Input and as MIDI Output and Mackie Control
XT
If there is only one D700 showing up, you need to enable the extensions first.
How you can do that is described in the main manual.

7
en
Hints:
-With the knobs Pan, EQ,Send and FX, you can assign a function to the
encoders
-In FX mode the different effects will be displayed first. Click an encoder to
assign the parameters of the respective effect to the encoders
-Press the Magic * button to switch to return channels

8
en
For more information
visit www.asparion.de
