ASRock Industrial iBOX 1300/D4 Series User manual

iBOX 1200 Series
User Manual
Version 1.0
Published June 2022
iBOX 1300/D4 Series
User Manual

Version 1.0
Published April 2023
Copyright©2023 ASRock Industrial Inc. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or translated
in any language, in any form or by any means, except duplication of documentation by the
purchaser for backup purpose, without written consent of ASRock Industrial Inc.
Products and corporate names appearing in this documentation may or may not be
registered trademarks or copyrights of their respective companies, and are used only for
identication or explanation and to the owners’ benet, without intent to infringe.
Disclaimer:
Specifications and information contained in this documentation are furnished for
informationa l use only and subject to change wit hout notice, and should not be
constructed as a commitment by ASRock Industrial. ASRock Industrial assumes no
responsibility for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock Industrial does not provide
warranty of any kind, either expressed or implied, including but not limited to the implied
warranties or conditions of merchantability or tness for a particular purpose.
In no event shall ASRock Industrial, its directors, ocers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for loss of
prots, loss of business, loss of data, interruption of business and the like), even if ASRock
Industrial has been advised of the possibility of such damages arising from any defect or
error in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
ASRock Industrial’s Website: https://www.asrockind.com

Replaceable batteries
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS
CAUTION (or Warning)
Hot surface
Do not touch
e equipment intended only for use in a Restricted Access Area.
DIN Rail/Wall Mount: M3x5mm Screws (for securing the mounting bracket(s) to the chassis)
VESA Mount: M4x6mm Screws (for securing the VESA bracket to the monitor)
is product should be connected by means of a power cord to a socket-outlet
with earthing connection.
e terms HDMI®and HDMI High-Denition Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI Licensing LLC in the United States and other
countries.

Contact Information
If you need to contact ASRock Industrial or want to know more about ASRock Industrial,
you’re welcome to visit ASRock Industrial’s website at https://www.asrockind.com; or you
may contact your dealer for further information.
ASRock Industrial Incorporation
Email: Info_i[email protected]

Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Product Specications 2
1.3 Block Diagram 4
Chapter 2 Product Overview 5
2.1 Front View 5
2.2 Rear View 6
2.3 Inside View 7
Chapter 3 Hardware Installation 8
3.1 How to Remove the Bottom Case 8
3.2 How to Install the WiFi Module 9
3.3 How to Remove the M.2 SSD and the Bracket 10
3.4 How to Install the M.2 SSD 11
3.5 How to Install the 2.5-inch Hard Drive 12
3.6 How to Install the Memory Modules (DDR4) 15
3.7 How to Install the VESA Bracket 16
3.8 How to Install the Wall Mounting Brackets 18
3.9 How to Install the Din Rail Mounting Bracket (Optional) 20
Chapter 4 Motherboard 21
4.1 Motherboard Layout 21

4.2 Motherboard Specications 22
4.3 Onboard Headers and Connectors 24
4.4 Installation of ROM Socket 27
4.5 Expansion Slots (M.2 Slots) 28
Chapter 5 UEFI Setup Utility 29
5.1 Introduction 29
5.1.1 UEFI Menu Bar 29
5.1.2 UEFI Menu Bar 30
5.1.3 Navigation Keys 31
5.2 Main Screen (Advanced Mode) 32
5.3 Advanced Screen 33
5.3.2 Chipset Conguration 37
5.3.3 Storage Conguration 39
5.3.4 Super IO Conguration 41
5.3.5 AMT Conguration 42
5.3.6 ACPI Conguration 44
5.3.7 USB Conguration 45
5.3.8 Trusted Computing 46
5.4 Hardware Health Event Monitoring Screen 49
5.5 Security Screen 50
5.6 Boot Screen 51
5.7 Exit Screen 53

Chapter 6 Software Support 54
6.1 Install Operating System 54

iBOX 1300/D4 Series
PB 1
English
Chapter 1 Introduction
1.1 Package Contents
• iBOX 1300/D4 Series
• 1 x SATA 1 to 1 Power Cable
• 4 x HDD Screws (M3x4)
• 1 x WiFi Module Screw
• 1 x Screw for M.2 slot
• 1 x Bracket for M.2 2280 support
• 1 x 19V/90W Power Adapter
• 1 x VESA Mount Bracket & Screw Package (by request)
• Din Rail Kit & Screw Package (by request)
• Wall Mount Kit & Screw Package
• Quick Installation Guide
Because the hardware specications might be updated, the content of this documentation
will be subject to change without notice.
If any items are missing or appear damaged, contact your authorized dealer.

2 3
English
1.2 Product Specications
Memory
Technology
Capacity
Socket
Dual Channel DDR4 3200 MHz
64GB (32 GB per DIMM)
2 x 260-pin SO-DIMM
Graphics
Controller
HDMI
DisplayPort
MultiDisplay
Intel® Iris®XeGraphics for i7/i5 CPU
Intel®UHD Graphics for i3 CPU
HDMI 2.0b
Max resolution up to 4096x2160@60Hz
DisplayPort 1.4a, DP++
Max resolution up to 4096x2160@60Hz
Quad-Display (Included 2 outputs from Type-C)
Processor System
CPU
Chipset
BIOS
iBOX-1365UE/D4 (i7-1365UE, 2P+8E)
iBOX-1335UE/D4 (i5-1335UE, 2P+8E)
iBOX-1315UE/D4 (i3-1315UE, 2P+4E)
MCP
AMISPI 256 Mbit
Environment
Operating Temp
Storage Temp
Operating Humidity
Storage Humidity
-20ºC~ 40ºC
-40° C~ 85° C
5% ~ 90%
5% ~ 90%
Mechanical
Construction
Mounting
Dimensions (W x H x D)
Weight
Aluminum
VESA mounting, Wall mounting, Din-rail (By request)
171.8 x 50.05 x 109.45 mm
Net Weight: 1.6Kg
Audio
Interface Realtek ALC233/ALC256, High Definition Audio.
Watchdog Timer
Output
Interval
From Super I/O to drag RESETCON#
256 Segments, 0, 1,2, ...255sec
Ethernet
Controller/ Speed
Connector
iBOX-1365UE/D4, iBOX-1335UE/D4 :
Intel®I226LM with 10/100/1000/2500 Mbps,supports vPro
iBOX-1315UE/D4 :
Intel®I226LM with 10/100/1000/2500 Mbps
2 x RJ-45
Expansion Slot
M.2 1x M.2 (KeyE,2230) with PCIex1,USB 2.0 and CNVifor Wireless
Storage
M.2
SATA
1 x M.2(Key M,2242/2260/2280) with PCIeGen4 x4 forSSD
*M.2 Key M 2280(Supported by bracket)
1 x SATA3.0 (6.0 Gb/s)
Power Requirements
Input PWR
Power On
12V~19V DC-In Jack
AT/ATX Supported
- AT : Directly PWR on as power input ready
- ATX : Press button to PWR on after power input ready
Front I/O
USB
Audio
2 x USB3.2 Gen2 (Type A)
1 x USB4/Thunderbolt™ 4 (5V/3A,supports DP1.4a display output)
*For Thunderbolt support,please refertosupportlist.
1 x USB3.2 Gen2 (Type-C,5V/3A,supports DP1.4a display output)
2 x USB2.0
1 (headphone & microphone jack)
Rear I/O
HDMI
DisplayPort
Ethernet
USB
DC Jack
COM
1 x HDMI 2.0b
1 x DP1.4a
2 x 2.5 Gigabit LAN
2 x USB 3.2 Gen2 (Type-A)
1
1 x COM(RS-232)
Others
OS Support
TPM
Certifications
Packing List
Windows 10/11
TPM 2.0 onboard IC
CE, FCC
1 x 19V/90W Power Adapter
1 x Screw Package
1 x Wall mount kit
Memory
Technology
Capacity
Socket
Dual Channel DDR4 3200 MHz
64GB (32 GB per DIMM)
2 x 260-pin SO-DIMM
Graphics
Controller
HDMI
DisplayPort
MultiDisplay
Intel® Iris®XeGraphics for i7/i5 CPU
Intel®UHD Graphics for i3 CPU
HDMI 2.0b
Max resolution up to 4096x2160@60Hz
DisplayPort 1.4a, DP++
Max resolution up to 4096x2160@60Hz
Quad-Display (Included 2 outputs from Type-C)
Processor System
CPU
Chipset
BIOS
iBOX-1365UE/D4 (i7-1365UE, 2P+8E)
iBOX-1335UE/D4 (i5-1335UE, 2P+8E)
iBOX-1315UE/D4 (i3-1315UE, 2P+4E)
MCP
AMISPI 256 Mbit
Memory
Technology
Capacity
Socket
Dual Channel DDR4 3200 MHz
64GB (32 GB per DIMM)
2 x 260-pin SO-DIMM
Graphics
Controller
HDMI
DisplayPort
MultiDisplay
Intel® Iris®XeGraphics for i7/i5 CPU
Intel®UHD Graphics for i3 CPU
HDMI 2.0b
Max resolution up to 4096x2160@60Hz
DisplayPort 1.4a, DP++
Max resolution up to 4096x2160@60Hz
Quad-Display (Included 2 outputs from Type-C)
Processor System
CPU
Chipset
BIOS
iBOX-1365UE/D4 (i7-1365UE, 2P+8E)
iBOX-1335UE/D4 (i5-1335UE, 2P+8E)
iBOX-1315UE/D4 (i3-1315UE, 2P+4E)
MCP
AMISPI 256 Mbit

iBOX 1300/D4 Series
2 3
English
Environment
Operating Temp
Storage Temp
Operating Humidity
Storage Humidity
-20ºC~ 40ºC
-40° C~ 85° C
5% ~ 90%
5% ~ 90%
Mechanical
Construction
Mounting
Dimensions (W x H x D)
Weight
Aluminum
VESA mounting, Wall mounting, Din-rail (By request)
171.8 x 50.05 x 109.45 mm
Net Weight: 1.6Kg
Audio
Interface Realtek ALC233/ALC256, High Definition Audio.
Watchdog Timer
Output
Interval
From Super I/O to drag RESETCON#
256 Segments, 0, 1,2, ...255sec
Ethernet
Controller/ Speed
Connector
iBOX-1365UE/D4, iBOX-1335UE/D4 :
Intel®I226LM with 10/100/1000/2500 Mbps,supports vPro
iBOX-1315UE/D4 :
Intel®I226LM with 10/100/1000/2500 Mbps
2 x RJ-45
Expansion Slot
M.2 1x M.2 (KeyE,2230) with PCIex1,USB 2.0 and CNVifor Wireless
Storage
M.2
SATA
1 x M.2(Key M,2242/2260/2280) with PCIeGen4 x4 forSSD
*M.2 Key M 2280(Supported by bracket)
1 x SATA3.0 (6.0 Gb/s)
Power Requirements
Input PWR
Power On
12V~19V DC-In Jack
AT/ATX Supported
- AT : Directly PWR on as power input ready
- ATX : Press button to PWR on after power input ready
Front I/O
USB
Audio
2 x USB3.2 Gen2 (Type A)
1 x USB4/Thunderbolt™ 4 (5V/3A,supports DP1.4a display output)
*For Thunderbolt support,please refertosupportlist.
1 x USB3.2 Gen2 (Type-C,5V/3A,supports DP1.4a display output)
2 x USB2.0
1 (headphone & microphone jack)
Rear I/O
HDMI
DisplayPort
Ethernet
USB
DC Jack
COM
1 x HDMI 2.0b
1 x DP1.4a
2 x 2.5 Gigabit LAN
2 x USB 3.2 Gen2 (Type-A)
1
1 x COM(RS-232)
Others
OS Support
TPM
Certifications
Packing List
Windows 10/11
TPM 2.0 onboard IC
CE, FCC
1 x 19V/90W Power Adapter
1 x Screw Package
1 x Wall mount kit

4 5
English
1.3 Block Diagram
iBOX 1300/D4
Intel
Raptor Lake P
28W
INTEL
Burnside Bridge
Retimer
TCP0+USB2#5
TBT
Type C/TBT
Connector
Type C
Connector
eSPI
TCP1+USB2#6
HDMI
Connector
DP++
Connector
DP AUX/DDC
SWITCH
TCP3
2x USB3.2 Gen2
Connector
2xUSB3.2 Gen2(#1, #2)
RJ45
Connector
2.5G Intel
I226LM(vPro)
PCIex1(#5)
RJ45
Connector
2.5G Intel
I226LM
PCIex1(#9)
DDR4 3200MHZ SO-DIMM
Line out & Mic in
Combo Jack
Audio Realtek
ALC233
HDA
2x USB3.2 Gen2
Connector
2xUSB3.2 Gen2(#3, #4)
2x USB2.0
2x5 Header
2x USB2.0(P7, P8)
NUVOTON
NCT5525D
COM 232/422/485
2x5 Header
UART
CPU FAN1
FAN
SATA(#0) SATA Port
PCIe x1(#6)
M.2 Key E
CNVi
USB2.0(P10)
CPU PCIe x4 Port A(3:0)
M.2 Key M
SPI INFINEON
SLB9670XQ2.0
2x USB2.0(P1, P2)
TCP2
ITE
HDMI
RETIMER
TMDS
2x USB2.0(P3, P4)
DDR4 3200MHZ SO-DIMM

iBOX 1300/D4 Series
4 5
English
Chapter 2 Product Overview
is chapter provides diagrams showing the location of important components of
the iBOX 1300/D4 Series.
2.1 Front View
No. Description
1Audio (Mic-in, Line-out)
2 USB 4/underbolt™ 4 (5V/3A, supports DP1.4a display output)
3 USB 3.2 Gen2 (Type A)
4 USB 3.2 Gen2 (Type C, 5V/3A, supports DP1.4a display output)
5 USB 2.0 (Type A)
1 2 3 4 5

6 7
English
2.2 Rear View
No. Description
1COM Port
2 Power Button
3 2 x USB 3.2 Gen2 Ports (Type A)
4HDMI
5 RJ-45 (2.5G LAN)
6DC-IN
7DisplayPort
8 RJ-45 (2.5G LAN)
*ere are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection
Blinking Data Activity Orange 100Mbps/1Gbps
connection
On Link Green 2.5Gbps connection
ACT/LINK LED
SPEED LED
LAN Port
23
145
678

iBOX 1300/D4 Series
6 7
English
2.3 Inside View
No. Description
1SO-DIMM Slots
2 SATA 3.0 Connector
3 M.2 Slot (Key M)
4 M.2 Slot (Key E)
5 Hard disk drive tray (compatible with 2.5" SATA HDD/SSD)
SO-DIMM memory, hard drive and mSATA SSD are not included with this system.
1
3
2
4
5
D

8 9
English
Chapter 3 Hardware Installation
is chapter helps you install or remove important components.
3.1 How to Remove the Bottom Case
1. Remove the four screws on the bottom case.
2. en li up and remove the bottom panel.
1
2

iBOX 1300/D4 Series
8 9
English
3.2 How to Install the WiFi Module
1. Locate the WiFi Module slot on the motherboard.
2. Carefully insert the WiFi Module into the slot.
3. Tighten the screw to secure the WiFi Module to the motherboard.

10 11
English
3.3 How to Remove the M.2 SSD and the Bracket
1. Release the screw and carefully remove the M.2 SSD.
2. Release the screw and remove the bracket from the motherboard.

iBOX 1300/D4 Series
10 11
English
3.4 How to Install the M.2 SSD
1. Locate the M.2 slot on the motherboard.
2. Carefully insert the M.2 SSD into the slot.
3. Tighten the screw to secure the M.2 SSD to the motherboard.

12 13
English
3.5 How to Install the 2.5-inch Hard Drive
1. Remove the four screws on the bottom case. en li up and remove the bottom panel.
2. Attach the HDD cage to the bottom panel and secure it using the four screws. en
connect the SATA cable to the HDD.

iBOX 1300/D4 Series
12 13
English
3. Connect the SATA Data and Power Cable to the HDD.
4. Connect the SATA Cable to the connector.
