Astral Pool DeckWell 330 User manual

330
1
Notice de Montage
Plateforme télescopique circulable pour piscine
Assembly Instructions
walkable telescopic platform for swimming pool
Instrucciones de Montaje
Plataforma telescópica y transitable para piscina

2
IT022 Ed.170220 - DeckWell 330
INDEX
#FR ENG ESP Pg
1 Composition du colis Box contents Contenido de la caja 3
2 Ordre d’assemblage Assembly order Orden de ensamblaje 6
3 Outillages et Accessoires Tools and Accessories Herramientas y Accesorios 7
4 Structure Principale DeckWell DeckWell Main Structure Estructura Principal DeckWell 8
5 Schéma DeckWell DeckWell diagram Esquema DeckWell 10
6 Composition module #1 -#4 Module #1 - #4 composition Composición módulo #1 -#4 12
8 Assemblage Structure Principale Assembly Main Structure Ensamblaje Estructura Principal 16
9 Assemblage modules #1 et #4 Assembly modules #1 and #4 Ensamblaje módulos #1 y #4 17
11 Liaison des modules sur la piscine Connecting and positioning modules
above the pool Colocación de módulos sobre piscina 22
12 Installation du deck (Deck Easyclip™) Deck floor installation (Deck Easyclip™) Instalación del deck (Deck Easyclip™) 23
13 Fixation au sol Ground fixing Fijación al suelo 24

3
Composition du colis / Package contents / Contenido de la caja
Français English Español Qty DW-330
Polycarbonate rectangulaire Polycarbonate plastic sheet Policarbonato rectangular 6
Polycarbonate découpé Cutted polycarbonate plastic sheet Policarbonato recortado 2
Profil d'encadrement RAL 7036 Frame profile RAL 7036 Perfil perimetral RAL 7036 8
Poutre d'appui Supporting beam Viga de apoyo 6
Rail de guidage Guide rail Raíl de guiado 1
Profil de finition (long) Finishing profile (long) Perfil embellecedor (largo) 4
Profil de finition (court) Finishing profile (short) Perfil embellecedor (corto) 4
Canne de manipulation Manipulating handle Pértiga manipulación 1
KITS (1 - 10) KITS (1 - 10) KITS (1 - 10)
Equerre acier inox Stainless steel angle bracket Escuadras acero inox 1
Equerres inox spéciales (Mod. 1-4)
Special stain. steel angle brackets
(Mod. 1-4)
Escuadras inox especial (Mod. 1-4) 1
Pièces fixation poutres fastening pieces (supporting beams) Piezas fijación vigas 1
Pièces fixation au sol (Mod. 1-4) Ground fastening pieces (Mod. 1-4) Piezas fijación al suelo (Mod. 1-4) 1
Butée de liaison des éléments
Stop and connecting piece (between
mod.)
Tope arrastre módulos 0
Caches plastique protection Plastic cover plates Tapas plástico para protección 1
Pièces fixation polycarbonate
Fasteners (Polycarbonate plastic
sheet)
Piezas de fijación para policarbonato 1
Chevilles fixation au sol Fixing pins on the ground Tacos fijación al suelo 1
Vis de fixation du rail Fixing screws (Guide rail) Tornillos fijación Raíl 1
Vis de jonction (général) Connecting screws (general) Tornillos de unión (general) 1
IT022 Ed.170220 - DeckWell 330

4
Composition du colis / Package contents / Contenido de la caja
REF Description Description Descripción Qty DW-330
MVB 02.143 Equerre inox 4mm Stainless steel angle bracket 4mm Equerre inox 4mm 14
KIT 1
REF Description Description Descripción Qty DW-330
MVB 02.144 Equerre inox 4mm spécial
Special stainless steel angle bracket
4mm
Escuadra inox 4mm especial 2
KIT 2
REF Description Description Descripción Qty DW-330
MVB 02.156 Pièce union 19/1826 I Connecting part 19/1826 I Pieza unión 19/1826 I 12
KIT 3
REF Description Description Descripción Qty DW-330
MVB 02.149 Pièce fixation au sol (Mod. 1-4) Ground fastening piece (Mod. 1-4) Pieza fijación suelo Mod. 1 / 4 2
KIT 4
REF Description Description Descripción Qty DW-330
MVB 02.145 Butée de liaison pliée inox Stainless stop, Connecting piece bent Tope arrastre plegado inox 0
DIN 912 Vis M8x30 Screw M8x30 Tornillo M8x30 0
DIN 127 Rondelle Grower M8 Spring washer M8 Arandela Grower M8 0
KIT 5
REF Description Description Descripción Qty DW-330
MVB 03.042 Cache protection d'angle Corner protection cap Tapa protección esquina 4
MVB 03.042 Cache protection Droite Right protection cap Tapa protección Derecha 0
MVB 03.042 Cache protection Gauche Left protection cap Tapa protección Izquierda 0
DIN 7504H Vis 4,2x13 plat
Screw 4,2x13 flat Tornillo 4,2x13 plano 18
MVB 05.014 Retouche peinture Painting retouch Retocador de pintura 1
KIT 6
IT022 Ed.170220 - DeckWell 330

5
Composition du colis / Package contents / Contenido de la caja
REF Description Description Descripción Qty DW-330
MVB 04.061 Cheville métallique M8 Metal pin M8 Taco metálico M8 4
MVB 05.114 Poignée à clé M8 Handle with key M8 Pomo para llave M8 2
MVB 05.025 Résine Fixation chevilles bonding resin for pin Resina de fijación para tacos 1
MVB 05.097 Clé
Key Llave 2
MVB 05.149 Porte-clés
Key chain Llavero 1
KIT 8
REF Description Description Descripción Qty DW-330
MVB 03.003 Buté extrême rail stop cap (ending rail) Tope extremo rail 2
DIN 7982 Vis 5,5x50 Conique Screw 5,5x50 conical Tornillo 5,5x50 Cónico 34
Taco 8x80 Cheville Nylon Nylon pin Taco Nylon 34
KIT 9
REF Description Description Descripción Qty DW-840 Qty DW-735 Qty DW-630
DIN 7991 Vis M6x16 Conique Screw M6x16 conical Tornillo M6x16 Cónico 91
KIT 10
REF Description Description Descripción Qty DW-330
MVB 03.043 Pièce fixation polycarbonate Fasteners (Polycarbonate plastic sheet) Pieza para fijación policarbonato 22
MVB 05.038 Silicone Silicon Silicona 1
KIT 7
IT022 Ed.170220 - DeckWell 330

6
Ordre d’assemblage / Chronological order of assembly/ Orden de ensamblaje
FRANÇAIS
1. Installation du rail.
2. Assemblage de structure principale.
3. Installation pièces fixation poutres.
4. Installation poutres + polycarbonate.
5. Mise en place des éléments #1 et #4
sur le bassin piscine.
6. Vérification du déplacement des
éléments #1 et #4 (SANS HABILLAGE)
7. Habillage des éléments #1 et #4
8. 10. Fixation au sol
ENGLISH
1. Guide rail intallation
2. Frame assembly (main structure)
3. Connecting parts assembly (beams)
4. Connecting polycarbonate/beam
assembly
5. Put the module #1 et #4 above
swimming pool.
6. Check the right sliding of modules #1
et #4 (WITHOUT DECK-FLOOR)
7. Deck-floor laying (mod. #1 and #4)
8. 10. Ground fixing
ESPAÑOL
1. Instalación del raíl.
2. Ensamblaje de estructura principal.
3. Instalación de piezas de fijación de
las vigas.
4. Instalación de vigas/policarbonato.
5. Colocación de los módulos sobre la
piscina.
6. Verificación del desplazamiento de
los módulos SIN DECK.
7. Instalación del Deck en módulos #1
y #4
8. 10. Fijación al suelo
IT022 Ed.170220 - DeckWell 330

7
Outillage et Accessoires / Tools and Accessories / Herramientas y Accesorios
Outillage Tools Herramientas Visuel
Visseuse
(Ph3 / Ph2)
Cordless screwdriver
(Ph3 / Ph2)
Atornillador
(Ph3 / Ph2)
Clé ALLEN:
3 / 4 / 6 mm
Allen key
3 / 4 / 6 mm
Llave ALLEN:
3 / 4 / 6 mm
Marteau caoutchouc Rubber mallet Maza Caucho
Perceuse
Foret Ø12 / Ø8
Electric drill
Bit Ø12 / Ø8
Taladro
Broca Ø12 / Ø8
Mètre à ruban Tape measure Cinta métrica
Pistolet Extrudeur Caulking gun Pistola silicona
Treteau (x4) Trestle (x4) Borriqueta (x4)
IT022 Ed.170220 - DeckWell 330

8
Structure Principale DeckWell / DeckWell Main Structure / Estructura Principal DeckWell
MOD1 MOD2
IT022 Ed.170220 - DeckWell 330

9
IT022 Ed.170220 - DeckWell 330

10
Schéma DeckWell / Deckwell diagram / Esquema DeckWell
37mm
L
LT
W
70 70
WT
DW330
L (mm) 1810
LT (mm) 3620
W (mm) 3476
WT (mm) 3616
70mm
IT022 Ed.170220 - DeckWell 330

11
R
½ R ½ R
Wp
WR
WR
R
Wp
WR
WR
Wp
WR
RAIL DW330
2 Ud. (3450)
1 Ud. (1500)
R (mm) 8400
WR
DW330
Wp = 3,15m
WR(min) 100 mm
WR( 0 ) 165 mm
WR(max)230 mm
Schéma DeckWell / Deckwell diagram / Esquema DeckWell
IT022 Ed.170220 - DeckWell 330

12
Composition module #1 - #4 / Module #1 - #4 composition / Composición módulo #1 -#4
KIT Ref
Qty
DW330
3
MVB
02.156
6
1
MVB
02.143
7
2
MVB
02.144
1
7
MVB
03.043
10
10 DIN
7991 42
4
MVB
02.149
1
6
MVB
03.042
2
6
DIN
7504H
8
PHOTO DW330
1
1
1
1
3
2
2
23
1
3
MOD1
MOD4
IT022 Ed.170220 - DeckWell 330

13
Vue éclatée module #1 / Exploded view module #1 / Vista descompuesta módulo #1
DIN 7991
M6x16
DIN 7991 M6x16 DIN 7991
M6x16
DIN 7991
M6x16
DIN 7991
M6x16
DIN 7991
M6x16
DIN 7504H
4,2x13 DIN 7504H
4,2x13
DIN 7991
M6x16 DIN 7991
M6x16
DIN 7991
M6x16
3
1
42
MVB
02.156
MVB
02.156
DIN 7991 M6x16
DIN 7991 M6x16
DIN 7991 M6x16
MVB
03.043
MVB
03.042
MOD1
DIN 7991 M6x16
DIN 7991 M6x16
DIN 7991 M6x16
IT022 Ed.170220 - DeckWell 330

14
Vue éclatée module #1 / Exploded view module #1 / Vista descompuesta módulo #1
DIN 7991
M6x16
DIN 7991
M6x16
DIN 7991
M6x16
DIN 7991
M6x16
DIN 7991
M6x16
DIN 7504H
4,2x13 DIN 7504H
4,2x13
DIN 7991
M6x16 DIN 7991
M6x16
DIN 7991
M6x16
7
5
86
MVB
02.156 MVB
02.156
DIN 7991 M6x16
DIN 7991 M6x16
DIN 7991 M6x16
MVB
03.043
MVB
03.042
MOD2
DIN 7991 M6x16
DIN 7991 M6x16
DIN 7991 M6x16
DIN 7991
M6x16
IT022 Ed.170220 - DeckWell 330

15
IT022 Ed.170220 - DeckWell 330

16
Assemblage Structure Principale / Assembly Main Structure / Ensamblaje Estructura Principal
4
2
2
A
AA
A
50%
DIN 7991 M6x16
A
MVB 02.144 MVB 02.143
4
6
8
6
8
IT022 Ed.170220 - DeckWell 330

17
Assemblage modules #1 et #4 / Assembly modules #1 and #4 / Ensamblaje módulos #1 y #4
B
B
B
BB
B
B
B
100%
DIN 7991 M6x16
B
B
B
B
B
3
1
2
4
DIN 7991
M6x16
MVB 02.149
IT022 Ed.170220 - DeckWell 330

18
B
B
B
B
5
7
86
B
B
B
BB
B
B
B
100%
DIN 7991 M6x16
B
DIN 7991
M6x16
Assemblage modules #1 et #4 / Assembly modules #1 and #4 / Ensamblaje módulos #1 y #4
MVB 02.149
IT022 Ed.170220 - DeckWell 330

19
i
1
i
2 3 4
Assemblage modules #1 et #4 / Assembly modules #1 and #4 / Ensamblaje módulos #1 y #4
IT022 Ed.170220 - DeckWell 330

Assemblage modules #1 et #4 / Assembly modules #1 and #4 / Ensamblaje módulos #1 y #4
20
1 2
3 4
MVB 03.043
IT022 Ed.170220 - DeckWell 330
