Asus Z016D User manual

E11572
User Guide
15060-80400000

First Edition/ August 2016
Model: ASUS_Z016D (ZS570KL)
Before you start, ensure that you have read all the
safety information and operating instructions in this
User Guide to prevent injury or damage to your
device.
NOTE: For the latest updates and more detailed
information, please visit www.asus.com.
Front features
Receiver
Front camera
Touch screen
display
Power key
Volume key
Touch keys
P-sensor
LED indicator

Side features
Audio jack
USB Type-C port Speaker
Power key
Volume key
Microphone
Microphone
Micro SIM, nano
SIM/ microSD
combo card slot
NOTES:
• ThemicroSIMcardslotsupportsGSM/
GPRS/EDGE,WCDMA/HSPA+/DC-HSPA+,
TD-SCDMA,CDMA2000,FDD-LTE,andTD-
LTEDSDSnetworkbands.
• ThemicroSDcardslotsupportsmicroSDand
microSDHCcardformats.

Rear features
Rear camera
Fingerprint
sensor
IR sensor
Rear cover
Camera
ash
NFC area

Charging your ASUS Phone
To charge your ASUS Phone:
1. ConnecttheUSBconnectorintothepower
adapter’s USB port.
2. ConnecttheotherendoftheUSBType-C
cabletoyourASUSPhone.
3. Plugthepoweradapterintoawallsocket.
NOTES:
• Useonlythepoweradapterthatcamewithyour
device.Usingadifferentpoweradaptermay
damage your device.
• UsingthebundledpoweradapterandASUSPhone
signalcabletoconnectyourASUSPhonetoa
poweroutletisthebestwaytochargeyourASUS
Phone.
• Theinputvoltagerangebetweenthewalloutletand
thisadapterisAC100V-240V.Theoutputvoltage
oftheUSBType-Ccableis+9V 2A,18W/
+5V 2A,10W.
IMPORTANT!
• WhenusingyourASUSPhonewhileitispluggedto
apoweroutlet,thegroundedpoweroutletmustbe
neartotheunitandeasilyaccessible.
• WhenchargingyourASUSPhonethroughyour
computer,ensurethatyouplugtheUSBType-C
cabletoyourcomputer’sUSB2.0/USB3.0port.
• AvoidchargingyourASUSPhoneinan
environmentwithambienttemperatureofabove
35oC(95oF).
3
1
2

1. Pushapinintothehole
onthemicroSIM/nano
SIM/microSDcardslotto
eject the tray out.
Installing a micro SIM/ nano SIM/
microSD card
To install a micro SIM/ nano SIM/ microSD card:
2. InsertthemicroSIM/nanoSIMormicroSD
card(s) into the card slot(s).
IMPORTANT!YoucanonlyusethenanoSIM
card or the microSD card at a time.
Micro-SIM1
Nano-SIM2
Micro-SIM1
Micro SD

CAUTION!
• Donotusesharptoolsorsolventonyour
device to avoid scratches on it.
• UseonlyastandardmicroSIMcardonyour
ASUSPhone.AnanotomicroSIMadapter
oratrimmedSIMcardmaynotproperlyt
intoandmaynotbedetectedbyyourASUS
Phone.
• DO NOT install an empty nano to micro
SIM adapter into the micro SIM card slot to
avoid irreversible damage.
3. Pushthetrayto
close it.
Using NFC
YoucanuseNFCinthefollowingthreescenarios:
Reader mode: Your phone reads information from a
contactlesscard,NFCtag,orotherNFCdevices.
PlacetheNFCareaofyourphoneonthe
contactlesscard,NFCtag,orNFCdevice.

Peer-to-Peer mode:Transfersphotos,contacts,
orotherdatabetweenyourphoneandanNFC-
enabledsmartphone.
BringtheNFCareasofbothsmartphonestogether,
withoutanyspacebetweenthem.
Card Emulation mode:Yourphonecanbeused
likeacontactlesscard.
PlacetheNFCareaofyourphoneontheNFCarea
oftheNFCreader.

CE RF Exposure Compliance
ThisdevicemeetstheEUrequirements(1999/519/
EC)onthelimitationofexposureofthegeneral
publictoelectromagneticeldsbywayofhealth
protection.
Forbody-wornoperation,thisdevicehasbeen
testedandmeetstheICNIRPguidelinesandthe
EuropeanStandardEN62209-2,forusewith
dedicatedaccessories.SARismeasuredwith
thisdeviceataseparationof0.5cmtothebody,
whiletransmittingatthehighestcertiedoutput
powerlevelinallfrequencybandsofthisdevice.
Useofotheraccessorieswhichcontainmetals
maynotensurecompliancewithICNIRPexposure
guidelines.
CE Mark Warning
CE marking for devices with wireless
LAN/ Bluetooth
Thisequipmentcomplieswiththerequirementsof
Directive1999/5/ECoftheEuropeanParliament
andCommissionfrom9March,1999governing
RadioandTelecommunicationsEquipmentand
mutualrecognitionofconformity.ThehighestCE
SARvaluesforthedeviceareasfollows:
• 0.663W/Kg(Head)@10g
• 0.970W/Kg(Body)@10g
Thisdeviceisrestrictedforindooruseonly
whenoperatingunder5150MHzto5350MHzof
frequencyrange.

For 5GHz WLAN: This equipment may be operated in:
AT BE BG CH CY CZ DE DK
EE ES FI FR GB GR HU IE
IT IS LI LT LU LV MT NL
NO PL PT RO SE SI SK TR
Using GPS (Global Positioning
System) on your ASUS Phone
TousetheGPSpositioningfeatureonyourASUS
Phone:
• Ensure that your device is connected to the
InternetbeforeusingGoogleMaporany
GPS-enabledapps.
• Forrst-timeuseofaGPS-enabledappon
your device, ensure that you are outdoors to
getthebestpositioningdata.
• WhenusingaGPS-enabledappon
your device inside a vehicle, the metallic
componentofthecarwindowandother
electronicdevicesmightaffecttheGPS
performance.
Prevention of Hearing Loss
Topreventpossiblehearingdamage,donotlisten
at high volume levels for long periods.
Laser safety information
CLASS1LASERPRODUCT
