AT&T CL4939 User manual

Quick start guide
CL4939
Big button big display
telephone/answering
system with caller ID/
call waiting

Introduction
This quick start guide provides you basic installation and use instructions.
A limited set of features are described in abbreviated form. For complete
instructions on how to use all features of this telephone, refer to your AT&T
CL4939 big button big display telephone user’s manual.
Table of contents
Telephone installation ......................................................................................................................1
Quick reference guide ......................................................................................................................3
Feature summary.................................................................................................................................5
Set date and time ...............................................................................................................................7
Line power mode (no AC power)................................................................................................7
Making and answering a call.........................................................................................................8
Options while on calls......................................................................................................................9
Speed dial ............................................................................................................................................10
Directory storage..............................................................................................................................11
Call history ..........................................................................................................................................12
Answering system............................................................................................................................15

1
If you subscribe to high-speed Internet service (DSL - digital subscriber
line) through your telephone line, you must install a DSL filter between the
telephone line cord and the telephone wall jack. The filter prevents noise and
caller ID problems caused by DSL interference. Please contact your DSL service
provider for more information about DSL filters.
Follow the steps below to install the telephone:
Telephone installation
Plug one end of the coiled handset cord into the handset jack on the left
side of the telephone base. Plug the other end into the handset and hang up.
1.
Plug one end of the telephone line cord into the TEL LINE jack on the back
of the telephone base. Plug the other end of the telephone line cord into a
telephone wall jack.
Plug the small end of the power adapter into the POWER jack on the back
of the telephone base. Plug the large end into a standard electrical outlet
not controlled by a wall switch.
2.
3.
Handset
Coiled handset cord
Telephone line
cord
DSL filter (not included) is
required if you have DSL
high-speed Internet service.
Telephone wall jackElectrical outlet
not controlled by
a wall switch

2
NOTES:
Use only the power adapter provided with this product. To obtain a
replacement, visit our website at www.telephones.att.com or call
1 [phone]. In Canada, dial 1 [phone].
The power adapter is intended to be correctly oriented in a vertical or floor
mount position. The prongs are not designed to hold the plug in place if it
is plugged into a ceiling, under-the-table or cabinet outlet.
You can use this telephone without the power adapter installed. In this
case, you can only make or answer calls with the handset, or adjust the
ringer volume or handset listening volume. For optimal performance, power
your telephone with the supplied power adapter.
•
•
•
Telephone installation
Lift the handset or press SPEAKER to check for a dial tone.
Move the top of the display up or down to adjust the angle of the screen
for maximum visibility.
4.
5.

3
Quick reference guide
REMOVE
While reviewing the
call history entries,
press and hold to
clear the call history.
While reviewing an
entry stored in the
directory or call history,
press to delete.
While entering names
(or numbers), press to
backspace and erase a
character (or digit).
DISPLAY DIAL
Press to dial the
number currently
displayed.
MEM
Press to access the
speed dial memory.
FLASH
During a call, press to
answer an incoming call
if you subscribe to call
waiting service provided
by your telephone
service provider.
Press to cancel an
operation and return to
idle mode.
CID/
Press to display the call
history.
While using the menu,
press to scroll through
the settings.
While reviewing the
directory or call history,
press to scroll down.
DIR/
Press to enter the
directory.
While using the menu,
press to scroll through
the settings.
While reviewing the
directory or call history,
press to scroll up.
SELECT
While using the menu,
press to save the
setting and move to the
next menu option.
REDIAL/PAUSE
While using the handset
or speakerphone, press
to dial the last number
dialed.
While storing numbers
in the speed dial
memory or directory,
press to copy the last
number dialed before
entering a digit.
While entering numbers,
press to insert a four-
second dialing pause.

4
Quick reference guide
MENU
Press to enter the
menu.
While reviewing the call
history, press to store
the displayed name and
number in the directory.
MUTE
During a call, press
to mute the handset
or speakerphone
microphone. Press
again to resume your
conversation.
AUDIO ASSIST™
Some voices will sound
louder and clearer
if you press AUDIO
ASSIST while you are
on a call using the
handset.
RINGER VOL switch
Slide to adjust the
ringer volume.
VOL switch
Slide to adjust the
listening volume on the
handset.
VOL switch
Slide to adjust the
listening volume on the
speakerphone.
While playing
messages, slide to
adjust the playback
volume.
SPEAKER
Press to turn on the
base speakerphone.
Press again to end the
call.
Audio assistTM is a trademark of Advanced American Telephones.
REPEAT/MEMO
While the telephone
is playing the date
and time the current
message was received,
press to go back to the
previous message.
After the telephone
plays the date and time
the current message
was received, press
to repeat the current
message.
When the telephone is
idle, press to record a
memo.
/ANS ON/OFF
Press to turn the
answering system on
or off.
/DELETE
Press to delete the
message currently
playing.
Press twice to delete all
old messages when the
telephone is not in use.
SKIP/ANNC
During message
playback, press to skip
to the next message.
When the telephone
is idle, press to record,
play or delete the
outgoing announcement.
PLAY/STOP
Press to start or stop
message playback.
When recording a
memo or an outgoing
announcement, press to
stop recording.

5
Set features
You can customize how the features of this product work.
Press MENU repeatedly until the screen shows the desired feature, and
PRESS ARROWS TO SET scrolls on the screen.
Press DIR/or CID/until the screen displays your selected setting. Refer
to Feature summary below for a description of the features and your
choices.
Press SELECT or MENU to save your selection and automatically move
to the next option. When you finish setting features, the telephone
automatically returns to standby after 30 seconds, or you can press FLASH
to exit programming immediately.
Feature summary
Default settings are indicated by * in the following list.
Screen display Function Options
SET TIME/DATE Set the date and time. Use the dialing keys to
change the digits.
Refer to Set date and time on page 7 for details.
12:00AM 01-01
SET CONTRAST Adjust screen brightness to a comfortable level, from 1
(light) to 4 (dark).
1, 2*, 3, 4
REPEATED CALLS Choose whether new calls from the same number
are combined into one entry or listed separately in
the call history.
COMBINED
SEPARATE*
LANGUAGE Choose whether the display text appears in English,
Spanish or French.
ENGLISH*
ESPANOL
FRANCAIS
HOME AREA CODE Set the call log to store only seven digits of local
telephone numbers. If you normally dial 10 or 11
digits for calls within your own area code, leave this
blank or enter 000.
Refer to Set home area code in the user’s manual
for details.
HAC- _ _ _
LOCAL AREA CODE Program up to four local area codes that do not
require dialing a 1 before them. If you dial 10 digits
(area code + telephone number) for calls within your
own area code, include your area code as a local
area code.
Refer to Set local area code in the user’s manual for
details.
LAC 1- _ _ _
LAC 2- _ _ _
LAC 3- _ _ _
LAC 4- _ _ _
DIAL TYPE Set touch-tone or pulse dialing. TONE*
PULSE
1.
2.
3.
Feature summary

6
Screen display Function Options
# OF RINGS Set how many times the telephone rings before the
answering system picks up the call.
If you choose tS 2-4 (or tS 4-6), the answering
system answers after two (or four) rings when
there are new messages. When there are no new
messages, the answering system answers after four
(or six) rings. When you are retrieving messages from
a long distance call, it disconnects your call after
three (or five) rings to avoid long distance charges.
(These tS settings are also known as toll saver.)
Refer to To set the number of rings on page 17 for
details.
2, 3, 4*, 5, 6, 7,
tS 2-4, tS 4-6
MESSAGE ALERT Set whether there is an audible message alert every 15
seconds when there are new messages.
ON
OFF*
REMOTE CODE Select a three-digit number to allow remote access
from another telephone (away from your home or
office).
Refer to Remote access in the user’s manual for
details.
500*
PRIORITY CODE Select a three-digit number as your priority code
for the answering system. If the answering system
answers a call and the caller enters this priority
code, then the telephone plays a 30-second tone to
alert you to a priority caller.
Refer to Priority call in the user’s manual for details.
999*
CALL SCREENING Choose whether incoming messages are played
through the speaker while they are being recorded.
Refer to Call screening in the user’s manual for
details.
ON*
OFF
Feature summary

7
Set date and time
Follow the steps below to set the date and time.
Press MENU and the screen shows SET TIME/DATE.
Use the dialing keys (0through 9) to set the blinking digits. To enter a
number that is less than 10, you must enter a zero (0) before the number.
Use DIR/ or CID/ to move to the next or previous digit and # (pound
key) to choose between AM and PM.
After entering all the digits in SET TIME/DATE,The screen automatically
prompts SET YEAR. Use the dialing keys (0through 9) to set the blinking
digits.
Press SELECT or MENU to save the new setting and move to the next
option.
1.
2.
3.
4.
Line power mode (no AC power)
This telephone provides minimal functionality during a power failure. When AC
power is not available, the screen is blank and many telephone features do
not function. Only touch-tone dialing and volume adjustment (ringer volume
and handset volume) are supported. The telephone uses power from the
telephone line to enable you to make and answer calls using only the handset
and dialing keys.
To make a call during a power failure
Lift the handset and wait for a dial tone. The screen shows NO AC POWER.
Slowly dial a telephone number using the dialing keys. Wait to hear each
key tone and make sure the digit appears on the screen before pressing
the next dialing key.
NOTE: If the telephone is not powered by the supplied power adapter,
there is a delay when dialing digits.
To answer a call during a power failure
Lift the handset.
NOTE: The screen does not show incoming caller ID information during a
power failure.
1.
2.
•

8
Using the handset
To make a call:
Lift the handset, wait for a dial tone, and then dial a number.
To answer a call:
Lift the handset.
To end a call while using the handset:
Place the handset in the telephone base.
Using the speakerphone
To make a call:
Press SPEAKER, then dial a number.
To answer a call:
Press SPEAKER.
To end a call while using the speakerphone:
Press SPEAKER.
On hook dialing (predialing)
Use the dialing keys to enter a telephone number.
Press REDIAL/PAUSE to insert a four-second
dialing pause.
Press REMOVE to make corrections.
Press FLASH to return to idle mode.
Lift the handset to call.
-OR-
Press DISPLAY DIAL or SPEAKER to call using the speakerphone.
Switching between handset and speakerphone
To switch from handset to speakerphone during a call:
Press SPEAKER, then place the handset in the telephone base.
To switch from speakerphone to handset during a call:
Lift the handset.
•
•
•
•
•
•
1.
•
•
•
2.
•
•
Making and answering a call
12:00AM11-20 15
8887227702_

9
Audio assist™
Some voices will sound louder and clearer if you press AUDIO ASSIST while
you are on a call using the handset. Press AUDIO ASSIST again to turn the
feature off. This feature automatically turns off when you hang up. You must
press AUDIO ASSIST every time you want to activate the feature.
Mute
Use this feature during a telephone conversation to silence the handset or
speakerphone microphone.
To mute the call:
During a telephone conversation, press MUTE to silence the microphone.
The MUTE light turns on. You hear the other party, but the other party does
not hear you.
To take the call off mute:
Press MUTE and resume speaking. The MUTE light turns off.
-OR-
Mute is automatically canceled when you end the call.
NOTE: Switching between the handset and the speakerphone cancels the
mute function.
Flash/call waiting
If you subscribe to call waiting service from your telephone service provider,
you hear a beep if someone calls you while you are already on a call.
Press FLASH to put your current call on hold and take the new call.
Press FLASH anytime to switch back and forth between calls. For more
information on caller ID with call waiting, refer to About caller ID on
page 12.
•
•
•
•
Options while on calls

10
Speed dial
This telephone has 10 speed dial memory locations where you can store
telephone numbers you wish to dial using fewer keys than usual.
To store a speed dial number
When the telephone is idle, press MEM. The screen shows LOCATION 1.
You can press a dialing key (0through 9),
DIR/or CID/to choose the desired speed dial
memory location for the new entry.
Press SELECT. The screen displays
ENTER NUMBER.
To copy the last number dialed, press
REDIAL/PAUSE (up to 24 digits).
-OR-
Use the dialing keys to enter the telephone
number (up to 24 digits).
To backspace and erase a digit, press REMOVE.
To insert a four-second dialing pause, press REDIAL/PAUSE. A Pappears
on the screen.
Press MEM or SELECT to save the setting. The screen shows STORED with a
confirmation tone and then returns to MEM.
To dial a speed dial number
When the telephone is idle, press MEM. The screen shows LOCATION 1.
Press a dialing key (0through 9), DIR/or CID/to choose the desired
speed dial memory location. The number is displayed on the screen.
Press DISPLAY DIAL to dial using the speakerphone or press DISPLAY
DIAL and then lift the handset to dial using the handset.
-OR-
Lift the handset or press SPEAKER.
Press MEM. The screen shows ENTER LOCATION.
Press a dialing key (0through 9) to choose the desired speed dial memory
location. The telephone dials the number automatically.
1.
2.
3.
4.
•
•
5.
1.
2.
3.
1.
2.
3.
12:00AM11-20 15
LOCATION 1
------------------
12:00AM11-20 15
ENTER NUMBER
8887227702_

11
This telephone has a directory where you can store up to 25 additional
telephone numbers and names. Numbers can be up to 24 digits and names
can be up to 15 characters.
To store a name and telephone number in the directory
When the telephone is idle, press DIR/ to enter the directory.
Press SELECT. The screen shows ENTER NUMBER.
To copy the last number dialed, press
REDIAL/PAUSE (up to 24 digits).
-OR-
Use the dialing keys to enter the telephone
number (up to 24 digits).
To backspace and erase a digit, press REMOVE.
To insert a four-second dialing pause, press
REDIAL/PAUSE. A Pappears on the screen.
Press SELECT. The screen shows ENTER NAME.
Use the dialing keys and Character chart on
page 30 of the user’s manual to enter the letters,
digits or symbols (up to 15 characters). Press keys
repeatedly until the desired characters show on
the screen.
To backspace and erase a character, press
REMOVE.
Press SELECT to save the entry.
Repeat Steps 2 through 6 to store more directory
entries.
-OR-
Press FLASH to return to idle mode.
To delete a directory entry
When the telephone is idle, press DIR/ to enter the directory.
Press DIR/or CID/to scroll through the directory entries.
-OR-
Press the dialing key for the first character of the entry you wish to review
until the character you are looking for is displayed. Then press DIR/or
CID/to scroll through the entries beginning with this character.
Press REMOVE to delete the displayed entry.
Press FLASH to return to idle mode.
NOTE: Directory entries cannot be edited. If you need to change an entry,
you will need to delete the entry and reenter the information.
1.
2.
3.
•
•
4.
5.
•
6.
7.
1.
2.
3.
4.
Directory storage
12:00AM11-20 15
CHRISTINE SMITH
888-722-7702
12:00AM11-20 15
ROBERT BROWN_
8003604121
12:00AM11-20 15
ENTER NUMBER
8003604121_
12:00AM11-20 15
ENTER NAME
8003604121

12
About caller ID
This telephone has a caller ID feature that works with the caller identification
service provided by your telephone service provider. There might be a fee
for this service, and it might not be available in all areas. This telephone can
provide information only if both you and the caller are in areas offering caller
identification service, and if both telephone service providers use compatible
equipment.
Caller ID with call waiting lets you see who is calling before you answer the
call, even when you are on another call.
How caller ID works
If you subscribe to caller ID service provided by your telephone service provider,
information about each caller is displayed after the first or second ring.
Call history
ERR 12:00AM11-2016 15
CHRISTINE SMITH
888-722-7702
Caller’s name
Caller’s number
Date of call
The call is missed
and has not been
reviewed.
The caller called
more than once.
Time of call
Entry number An error from the
incoming caller ID
Caller ID information appears on the screen as long as the telephone rings, for
30 seconds after the caller hangs up, or after the call is answered at another
telephone on the same line.

13
About call history
Information about the last 65 incoming calls is stored in the call history.
The most recent call has the highest entry number. You can review the call
history to find out who has called, return the call, or save the caller’s name
and number into the directory or speed dial memory locations. If a call is
answered before the information appears on the screen, it is not saved in the
call history.
To store a call history entry in the directory or memory:
When the telephone is idle, press CID/ to enter the call history.
Press DIR/or CID/to scroll to the desired caller ID entry.
Press MENU or SELECT.
The screen shows COPY TO DIR. Press MENU or SELECT again to store
the displayed telephone number in the directory. The screen shows
STORED with a confirmation tone, then returns to the call history.
-OR-
The screen shows COPY TO DIR. Press DIR/or CID/to scroll to COPY
TO MEM.
Press SELECT. The screen shows ENTER LOCATION.
Press a dialing key (0through 9) to choose the desired speed dial
memory location to save the displayed telephone number. The screen
shows STORED with a confirmation tone and then returns to the call
history.
New and total calls
When your telephone is in idle mode, the screen
shows the total number of all incoming calls and the
number of calls that have not been reviewed.
1.
2.
3.
•
•
•
•
Call history
12:00AM11-20 15
16 CALLS 5 NEW

14
Call history
To return a call
Use the following steps to dial a telephone number in the call history.
When the telephone is idle, press CID/ to enter
the call history.
Press DIR/or CID/to scroll to the desired
caller ID entry.
Press DISPLAY DIAL to dial using the
speakerphone, or press DISPLAY DIAL and then
lift the handset to dial using the handset.
-OR-
If you need to add or remove the area code
or a 1 at the beginning of the number, do the
following:
Press # (pound key) repeatedly to scroll
through the various dialing formats.
Press DISPLAY DIAL to dial using the
speakerphone, or press DISPLAY DIAL and then lift the handset to dial
using the handset.
To delete a call history entry
When the telephone is idle, press CID/ to enter the call history.
Press DIR/or CID/to scroll to the caller ID entry.
Press REMOVE to delete the currently displayed entry. The screen shows
DELETED with a confirmation tone and then shows the next call history
entry, if any.
Press FLASH to return to idle mode.
To delete all call history entries
When the telephone is idle, press CID/ to enter the call history.
Press and hold REMOVE. The screen shows REMOVE ALL?
Press REMOVE within three seconds to confirm and delete all records from
the call history. The screen shows DELETED with a confirmation tone, then
CALL LOG EMPTY with an error tone. It then automatically returns to idle
mode. Once the entries are deleted, you cannot retrieve them.
-OR-
Press FLASH to exit and leave all caller ID entries intact.
1.
2.
3.
a.
b.
1.
2.
3.
4.
1.
2.
3.
1888-7227702
722-7702
1-722-7702
888-722-7702
12:00AM11-2016 15
CHRISTINE SMITH
888-722-7702
12:30AM11-20 15
7227702

15
Answering system
About the answering system and voicemail
You may have two different types of voice messages: those left on your
built-in answering system and those left on your service provider’s voicemail
system (fees may apply). Your telephone’s built-in answering system messages
and voicemail messages are separate.
To listen to your voicemail, you typically dial an access number provided by
your telephone service provider, followed by a security code or PIN. Some
service providers bundle or combine multiple services like voicemail and call
waiting, so you may not be aware that you have voicemail. To check what
services you have and how to access them, contact your telephone service
provider.
To use your voicemail service rather than your answering system, turn off
your answering system. To use your answering system rather than your
voicemail service, contact your telephone service provider to deactivate your
voicemail service. You can also use your telephone answering system and
voicemail together by setting your built-in answering system to answer before
voicemail answers. To learn how to program your voicemail settings, contact
your telephone service provider. Then, if you are on a call, or if the answering
system is busy recording a message and you receive another call, the second
caller can leave a voicemail message.
If you have voicemail provided by your telephone service provider, we
recommend setting your answering system to answer calls at least two rings
earlier than your voicemail is set to answer. For example, if your voicemail
answers after six rings, set your answering system to answer after four rings.
Some voicemail providers may program the delay before answering calls
in seconds instead of rings. In this case, allow six seconds per ring when
determining the appropriate setting.
Message capacity
The answering system can record up to 99 messages, depending on the
length of each message. Individual messages can be up to three minutes
long, and the total maximum recording time is 19 minutes. Messages remain
available for replay until you delete them.
If the recording memory is full, the message window displays F. Delete some
messages to make room for more.

16
Answering system
Turn the answering system on or off
Press /ANS ON/OFF repeatedly to turn the
answering system on or off.
Record your outgoing announcement
The outgoing announcement is the message callers hear when calls are
answered by the answering system.
If the answering system is on, the telephone
automatically answers calls with “Hello, please leave a
message after the tone.“ You can use this announcement,
or replace it with a recording of your own.
Use the following steps to record an outgoing
announcement with a recording of your own.
Press SKIP/ANNC. The screen shows
REC PLAY and REC flashes.
Press SELECT. The screen shows USE STOP TO
END and you hear a long beep.
Speak towards the microphone (MIC) on the
telephone and maintain a distance of about
nine inches. You can record an announcement of up to two minutes.
Announcements shorter than one second are not recorded.
Press PLAY/STOP to end the recording. The recorded announcement
automatically plays back, then the telephone automatically returns to idle
mode and you hear a beep.
To play or delete the outgoing announcement
Press SKIP/ANNC. The screen shows REC PLAY DEL and REC flashes.
Press REPEAT/MEMO or SKIP/ANNC to scroll until PLAY or DEL flashes.
Press SELECT to play the current announcement. To delete the
announcement, press SELECT when DEL is flashing or press /DELETE
during playback.
•
1.
2.
3.
4.
1.
2.
3.
12:00AM11-20 15
REC PLAY

17
Answering system
To play and delete messages
Press PLAY/STOP to begin message playback.
Options during message playback:
To adjust the playback volume to a comfortable level, slide the VOL switch.
To skip to the next message, press SKIP/ANNC after the telephone plays
the day and time of the current message.
To go back to the previous message, press REPEAT/MEMO while the
telephone is playing the day and time of the current message.
To repeat the message currently playing, press REPEAT/MEMO after the
telephone plays the day and time of the current message.
To delete the message currently playing, press /DELETE.
To stop playback and exit, press PLAY/STOP .
To delete all old messages:
When the telephone is idle, press /DELETE twice to delete all old
messages. New (unheard) messages cannot be deleted until you have
listened to them.
To set the number of rings
Use this feature to set how many times the telephone rings before the
answering system picks up the call. The number of rings is four by default. To
change the setting, follow the steps below:
Press MENU repeatedly until the screen shows # OF RINGS.
Press DIR/or CID/to select 2, 3, 4*, 5, 6, 7, tS 2-4, or tS 4-6.
If you choose tS 2-4 (or tS 4-6), the answering system answers after two
(or four) rings when there are new messages. When there are no new
messages, the answering system answers after four (or six) rings. When
you are retrieving messages from a long distance call, it disconnects
your call after three (or five) rings to avoid long distance charges. (These
tS settings are also known as toll saver.)
Press SELECT or MENU to save your selection and automatically move to
the next option. The telephone automatically returns to standby after 30
seconds, or you can press FLASH to return to idle mode.
•
•
•
•
•
•
•
•
1.
2.
•
3.

Audio assist™ is a trademark of Advanced American Telephones.
© 2009-2010 Advanced American Telephones. All Rights Reserved.
AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to
Advanced American Telephones, San Antonio, TX 78219.
Printed in China. Issue 8 AT&T 11/10
www.telephones.att.com
