ATEN CS682-AT User manual

CS682
USER MANUAL
USB 2.0 DVI KVM Switch

EMC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT: This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
The device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user's authority to
operate this equipment.
Warning: Operation of this equipment in a residential environment could
cause radio interference.
KCC Statement
RoHS
This product is RoHS compliant.

- 3 -
CS682 User Manual
Online Registration
Telephone Support
Technical Support
 For international online technical support – including
troubleshooting, documentation, and software updates:
http://eservice.aten.com
 For North American technical support:
International http://eservice.aten.com
International 886-2-8692-6959
China 86-400-810-0-810
Japan 81-3-5615-5811
Korea 82-2-467-6789
North America 1-888-999-ATEN ext 4988
1-949-428-1111
Email Support [email protected]
Online
Technical
Support
Troubleshooting
Documentation
Software Updates
http://www.aten-usa.com/support
Telephone Support 1-888-999-ATEN ext 4998

- 4 -
Package Contents
The CS682 USB 2.0 DVI KVM Switch package contains the
following items:
 1 CS682 2-Port USB 2.0 DVI KVM Switch
 1 Remote Port Selector
 1 User Manual*
 1 Quick Start Guide
Check to make sure that all the components are present and that
nothing got damaged in shipping. If you encounter a problem,
contact your dealer.
Read this manual thoroughly and follow the installation and
operation procedures carefully to prevent any damage to the unit,
and/or any of the devices connected to it.
*Features may have been added to the CS682 since this
manual was printed. Please visit our website to download the
most up-to-date version of the manual.
Copyright © 2019 ATEN
®
International Co., Ltd.
Manual Date: 2019-11-15 - Manual Part No. PAPE-1337-AT5G
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights
reserved. All other trademarks are the property of their respective owners.

- 5 -
Overview
The CS682 takes a giant step forward from prior cable KVM
models in the Petite series, by offering DVI functionality, USB 2.0
peripheral sharing (via a USB hub attached to the USB mouse
port), a rich bass experience for 2.1 surround systems, and a
firmware upgrade function that allows you to keep up with latest
available versions.
Another new feature of the CS682 is the implementation of a
remote port selector. This means that you can now control port
switching from the desktop while the switch itself can be placed
in a convenient, out-of-the-way, location. Also, in addition to new
hotkeys, the CS682 offers the latest mouse port-switching
function – simply double-click on the scroll wheel of a USB mouse
to change ports.
Furthermore, the CS682 features enhanced Video DynaSync
technology, which eliminates boot-up display problems and
optimizes resolution when switching between ports.
Finally, the CS682's new Power on detection feature means that
if one of the computers is powered off, switch will automatically
switch to the other powered-on computer.
Featuring an unbeatable combination of DVI functionality, USB
2.0 peripheral sharing convenience, and enhanced user-friendly
operations, the CS682 allows users to keep up with the latest
innovations in desktop multimedia applications.

- 6 -
Features
 One DVI video console controls two USB computers
 Fully DVI-Digital specification compliant
 Computer selection via remote port selector, hotkeys, and
USB mouse
 Audio-enabled – full bass response provides a rich
experience for 2.1 channel surround sound systems
 Multiplatform support – Windows 2000 / XP / Vista / 7, Mac,
Sun, Linux
 Compact design, built-in all-in-one cables (2 x 1.2 m)
 Superior video quality – up to 1920 x 1200
 Compatible with widescreen LCD monitors
 Video DynaSync – exclusive ATEN technology which
eliminates boot-up display problems and optimizes resolution
when switching between ports
 Power on detection – if either of the computers is powered
off, the CS682 will automatically switch to the other computer
 Supports multimedia keyboards
 Supports wireless keyboards and mice
 Console mouse port emulation/bypass feature supports most
mouse drivers and multifunction mice
 Mac/Sun keyboard support and emulation*
 USB 2.0 mouse port can be used for USB hub and USB
peripheral sharing
 HDCP Compliant
 Non-Powered
 Firmware upgradable
Note: 1. PC keyboard combinations emulate Mac/Sun
keyboards.
2. Mac/Sun keyboards work only with their own
computers.

- 7 -
3. To use the USB 2.0 mouse port as a USB hub, you
must first disable mouse emulation mode.
See Hotkey Summary Table, page 15 for
information.
System Requirements
Console
 A DVI monitor capable of the highest resolution that you will
be using on any computer in the installation
 A USB Keyboard and a USB Mouse
 Speakers and microphone (optional)
Computers
The following equipment must be installed on each computer that
is to be connected to the system:
 A DVI video port
 USB Type A port
 Speaker and microphone ports (optional)
Cables
The CS682’s innovative design features built-in KVM and audio
cables for extra convenience. No further cables are necessary.

- 8 -
Operating Systems
Supported operating systems are shown in the table, below:
OS Version
Windows
2000 / XP / Vista / 7
Linux RedHat 6.0 and higher
SuSE 8.2 and higher
Mandriva (Mandrake) 9.0 and higher
UNIX AIX 4.3 and higher
FreeBSD 3.51 and higher
Sun Solaris 9 and higher
Novell Netware 5.0 and higher
Mac OS 9 and higher
DOS 6.2 and higher

- 9 -
Components
CS682
Remote Port Selector
3
3
1
2
5
46
7
8
3

- 10 -
No. Component Description
1 Console Audio Ports Your console speakers and microphone
plug in here.
2 Console Monitor Port Your console DVI monitor plugs in here.
3 Port LEDs The Port LEDs indicate status.
The LED lights on to indicate that the
computer attached to the corresponding
port is selected and has the KVM focus.
The LED flashes to indicate that the
computer attached to its corresponding
port is being scanned by the Auto Scan
function.
The LED is off to indicate the port is not
selected.
4 KVM Cable The connectors on the built-in KVM
cables attach to the two computers in
your CS682 installation. See the diagram
on page 12 for further details.
5 Console Keyboard
Port
Your console USB keyboard plugs in
here.
6 Console Mouse Port Your console USB mouse plugs in here.
7 Remote Port Selector
Jack
The Remote Port Selector plugs in here.
8 Port Selection
Pushbutton
Press the Port Selection Pushbutton to
toggle the KVM and Audio focus
between the two computers.

- 11 -
Installation
1. Plug your keyboard and mouse into their USB ports, located
on the side of the CS682. The ports are color coded and
labeled with an appropriate icon.
Note: The mouse connector is actually a USB 2.0 port, and can
accept any USB compatible peripheral. You can even
connect a hub to install multiple USB devices (This may
require an extra power adapter).
2. Plug your monitor into the DVI port, located on the front of the
CS682. Power on the monitor.
3. Plug your speakers and microphone into the console audio
ports, located on the front of the CS682 (Optional).
4. Plug the USB, video, and audio connectors of the KVM
cables into their respective ports on the computers you are
installing.
5. If you choose to use the remote port selector, plug its cable
into the remote port selector jack, located on the side of the
unit.
6. Power on the computers.
Note:
 By default the switch links to the first computer that is
powered on.
 Make sure the computers and devices that the CS682
connects to are also properly grounded.
1. Make sure that the power to any device that you
connect to the installation has been turned off. You
must unplug the power cords of any computers that
have the Keyboard Power On function.
2. To prevent damage to your installation from power
surges or static electricity. It is important that all
connected devices are properly grounded.

- 12 -
Installation Diagram
2
3
1
5
4
KVM Cable
4
or
USB 2.0 Hub

- 13 -
Operation
The CS682 provides three convenient methods of selecting
computers: Manual – click the pushbutton on the Remote Port
Selector; Mouse – click the mouse’s scroll wheel; and Hotkey –
enter combinations from the keyboard.
Manual Port Selection
Press the port selection pushbutton on the Remote Port Selector
to toggle the KVM and Audio focus between the two computers.
The Port LED lights to indicate that the computer attached to its
corresponding port has the focus.
Note: Do not switch ports while a USB device is in operation. For
independent USB switching, please see the USB KVMP
switches on our website.
Mouse Port Selection
Simply double-click the scroll wheel on your USB mouse to
switch between ports. The mouse port-switching function allows
you to toggle back and forth between the ports.
Note: 1. This feature is only supported by USB 3-key scroll
wheel mice.
2. The default setting is OFF.
3. This feature is only supported when mouse emulation is
also enabled.
See Hotkey Summary Table, page 15 for further details.

- 14 -
Hotkey Port Selection
All hotkey operations begin by tapping the Scroll Lock key twice.
See the Hotkey Summary Table for full details.
Note: If using [Scroll Lock] conflicts with other programs, [Ctrl]
can be used instead.
Alternate Entering Hotkey Mode
 Press [Scroll Lock] [Scroll Lock] [x] [Enter]. The entering
hotkey mode hotkey is now [Ctrl].
or
 Press and hold the remote port selector switch for three
seconds. The entering hotkey mode hotkey is now [Ctrl].
Note: These procedures toggle between the two methods.

- 15 -
Hotkey Summary Table
Scan Interval Table
Combination Function
[Scroll
Lock]
[Scroll
Lock] +
[Enter] Toggles the KVM and Audio focus between the two
ports. If the KVM and Audio focus are on different
ports, only the KVM focus switches.
[k] [Enter] Only toggles the KVM focus.
[s] [Enter] Only toggles the Audio focus.
[a] [Enter] [n] Starts Auto Scan. The KVM focus cycles from port
to port at n second intervals.
Note: Replace n with a number between 1 and 4
(see Scan Interval Table below).
To exit Auto Scan, press [Esc] or [Spacebar]. Auto
Scanning stops when you exit Auto Scan mode.
[x] [Enter] Toggles the hotkey invocation key between [Scroll
Lock] and [Ctrl].
[m] [Enter] Enables/disables mouse emulation function.
[w] [Enter] Enables/disables mouse port-switching function.
[F2] [Enter] Activates Mac keyboard mapping.
[F3] [Enter] Activates Sun keyboard mapping.
[F10] [Enter] Auto detects keyboard operating platform.
[F4] [Enter] Lists current switch settings.
[F5] [Enter] Performs a USB keyboard and mouse reset.
[d] [Enter] Invokes the Video DynaSync function, which
eliminates boot-up display problems and optimizes
resolution when switching between ports.
[e] [Enter] Enables/Disables the Power on Detection feature.
[r] [Enter] Resets hotkeys to the default setting.
nSecs.
1 3 secs.
2 5 secs. (default)
3 10 secs.
4 20 secs.

- 16 -
Keyboard Emulation
Note: When using key combinations, press and release the first
key (Ctrl), then press and release the activation key.
PC Keyboard Mac Keyboard PC Keyboard Sun Keyboard
[Shift] Shift [Ctrl] [T] Stop
[Ctrl] Ctrl [Ctrl] [F2] Again
[Ctrl] [F3] Props
[Ctrl] [1] [Ctrl] [F4] Undo
[Ctrl] [2] [Ctrl] [F5] Front
[Ctrl] [3] [Ctrl] [F6] Copy
[Ctrl] [4] [Ctrl] [F7] Open
[Alt] Alt [Ctrl] [F8] Paste
[Print Screen] F13 [Ctrl] [F9] Find
[Scroll Lock] F14 [Ctrl] [F10] Cut
= [Ctrl] [1]
[Enter] Return [Ctrl] [2]
[Backspace] Delete [Ctrl] [3]
[Insert] Help [Ctrl] [4]
[Ctrl] F15 [Ctrl] [H] Help
Compose

-
+

- 17 -
The Firmware Upgrade Utility
To upgrade the CS682’s firmware, do the following:
1. From a computer that is not part of your KVM installation,
download the latest Firmware Upgrade package for the
CS682 from our Internet support site ( www.aten.com ).
2. Disconnect the CS682 from your KVM installation. Press and
hold the Remote Port Selector’s pushbutton. While you are
still holding the pushbutton, connect the KVM cable’s purple
USB connector to a USB port on the computer you have
downloaded the Firmware Upgrade package to.
3. The CS682 now enters Firmware Upgrade Mode. The two
Ports LEDs flash together to indicate that the unit is in
Firmware Upgrade Mode.
Note: While the CS682 is in Firmware Upgrade Mode, normal
keyboard and mouse functions are suspended. You
must complete the firmware upgrade or exit Firmware
Upgrade Mode to regain normal control of the console.
4. Run the Firmware Upgrade Package file. The Firmware
Upgrade Utility Welcome screen appears.
5. Read the License Agreement and enable to I Agree button.
6. Click Next to continue. The Firmware Upgrade Utility main
screen appears. All the devices capable of being upgraded by
the package are listed in the Devices List panel.
7. Select your device. Its description appears in the Device
Description panel. Click Next to perform the upgrade.
As the upgrade proceeds, status messages appear in the
Status Messages panel, and the progress towards completion
is shown in the Progress bar.
8. After the upgrade has completed, a screen appears to inform
you that procedure was successful. Click Finish to close the
Firmware Upgrade Utility.
9. Set up your KVM installation again. See Installation, page 11.

- 18 -
Upgrade Failed
If the Upgrade Succeeded screen doesn’t appear, it means that
the upgrade failed to complete successfully, in which case you
should do the following:
1. Disconnect the USB connectors on the KVM cables from the
computer.
2. Press and hold the Remote Port Selector’s pushbutton. While
you are still holding the pushbutton, reconnect the KVM
cable’s USB connectors to the computer.
3. Power on the CS682. It will now work with the factory default
firmware. Follow steps 3 to 9 on page 17 again.
Troubleshooting
Symptom Possible Cause Action
Monitor does
not display
after the KVM
cable set is
hot-plugged.
DVI graphics card
is not compatible
with cable set hot-
plugging.
Power off all devices on the
installation; power off the CS682;
confirm all KVM cables are
properly connected; power on the
CS682; power on the computers.
Graphics card
driver is not up-to-
date.
Upgrade to the latest graphics
card driver.
Mouse and/or
keyboard is
not
responding.
Switch needs to
be reset.
Power off all devices on the
installation; power off the CS682;
wait five seconds; power on the
CS682 again.
Mouse port-
switching
function is not
responding.
Mouse does not
support this
function.
This feature is only supported by
USB 3-key scroll wheel mice.
Mouse emulation
is disabled.
Enable mouse emulation. See
Hotkey Summary Table, page 15,
for details.
Cannot switch
ports by
pressing
[Scroll Lock]
twice.
Keyboard is
incompatible with
[Scroll Lock]
invocation.
Switch to the alternate HSM
invocation keys. See Alternate
Entering Hotkey Mode, page 14,
for details.

- 19 -
Specifications
Function CS682
Computer Connections 2
Console Connections 1
Port Selection Remote Port Selector, Mouse, Hotkeys
Connectors Console
Ports
KB 1 x USB Type A Female (Silver)
Video 1 x DVI-D Female (White)
Mouse 1 x USB Type A Female (Silver)
Speakers 1 x Mini Stereo Jack Female (Green)
Mic. 1 x Mini Stereo Jack Female (Pink)
KVM Ports KB 2 x USB Type A Male (Purple)
Video 2 x DVI-D Male (Black)
Mouse 2 x USB Type A Male (Black)
Speakers 2 x Mini Stereo Jack Male (Green)
Mic. 2 x Mini Stereo Jack Male (Pink)
Remote Port Selector 1 x 2.5mm Audio Jack Female
LEDs KVM 2 (Green)
Remote Port Selector 2 (Green)
Cable Length KVM 2 x 1.2 m
Remote Port Selector 1. 8 m
Emulation KB / Mouse USB
Video 1920 x 1200
Scan Interval 3, 5, 10, 20 secs. (default 5 secs.)
Power Consumption DC5V: 1.95W: 22BTU
Environment Operating Temp. 0–50ºC
Storage Temp. -20–60ºC
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Plastic
Weight 0.49 kg
Dimensions (L x W x H) 11.15 x 7.80 x 2.40 cm

- 20 -
Factory Default Hotkey Settings
Limited Warranty
ATEN warrants its hardware in the country of purchase against flaws in
materials and workmanship for a Warranty Period of two [2] years
(warranty period may vary in certain regions/countries) commencing on
the date of original purchase. This warranty period includes the LCD
panel of ATEN LCD KVM switches. Select products are warranted for an
additional year (see A+ Warranty for further details). Cables and
accessories are not covered by the Standard Warranty.
What is covered by the Limited Hardware Warranty
ATEN will provide a repair service, without charge, during the Warranty
Period. If a product is detective, ATEN will, at its discretion, have the
option to (1) repair said product with new or repaired components, or (2)
replace the entire product with an identical product or with a similar
product which fulfills the same function as the defective product.
Replaced products assume the warranty of the original product for the
remaining period or a period of 90 days, whichever is longer. When the
products or components are replaced, the replacing articles shall become
customer property and the replaced articles shall become the property of
ATEN.
To learn more about our warranty policies, please visit our website:
http://www.aten.com/global/en/legal/policies/warranty-policy
Setting Default
Port Switching [Scroll Lock] [Scroll Lock]
Auto Scan Interval 5 seconds
Keyboard Operating Platform PC Compatible
Mouse Emulation On
Mouse Port-Switching Off
Power on Detection Enabled
