Atlantic Rotating Cube 216 User manual

Rotating Cube 216
Item #: 28235872
216 CDs / 144 DVDs / 168 Blu-Rays
THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION. PLEASE
READ AND KEEP FOR FUTURE REFERENCE.
Lot Number:
Date:
Congratulations on your latest Atlantic purchase. Follow these instructions, and you’ll have this
new product assembled in no time. If you need any help, or to order replacement/missing parts,
please call 1-800-747-2660 or email [email protected].

1
Components Qty Components Qty
Phillips Screwdriver
Parts List
Item Item
Tools needed/ not included

2
Insert wooden dowels (G) and fasten cam screws (J) into panel (F). Insert cam locks (K) into side
panels (B). Attach side panels (B) to panel (F). Turn cam locks (K) clockwise to tighten.
Slide the divider panel (E) into side panels (B).
2
Kx4
Jx4
Gx4

3
Insert the wooden dowels (G) into side panels (B). Attach the panel (C) to side panels (B)
with screws (H).
Insert the wooden dowels (G) and cam screws (J) into panel (A). Insert cam locks (K) into side
panels (B). Attach side panels (B) to panel (A). Turn cam locks (K) clockwise to tighten.
3
4
Build 3 Sets
Hx4
Gx4
Jx4
Kx4
Gx4

4
5
6
Slide the divider panel (E) into side panels (B).
Insert the wooden dowels (G) into side panels (B). Attach the panel (C) to side panels (B)
with screws (H).
Build 3 Sets
Build 3 Sets
Gx4
Hx4

Attach the feet (N) to base (D) with screws (M). Then turn it over and stick the pads (P) onto
panel (D), flat where shown.
Remove the protective film from pads (P) and stick the pads onto panel (A), flat where shown.
5
7
8
Pad positions
Pad positions
Mx4
Nx4
Px4

6
9
Insert connectors (L) into panels (A and D). Stack the cubes one by one.
Lx4

Product Warranty
Atlantic Inc. warrants to the original purchaser that its products are free from defects in materials or
workmanship. If after inspection, we find that the product was defective in materials or workmanship,
we shall repair or replace the product at our discretion. This warranty does not cover accidental
damage, misuse, improper care or alteration and excludes claims for incidental or consequential
loss. This limited warranty applies to product purchased in the U.S. and Canada. This warranty gives
you specific legal rights and you may also have other rights which vary from State to State.
The warranty duration is one year.
Keep this Instruction Manual for future reference.
Keep your original proof of purchase (store receipt).
If parts are missing, DO NOT return to the store.
To order missing / replacement parts or for assembly assistance, please contact
[email protected].
Or call 1-800-747-2660 M-Th, 8am-5pm; Fri, 8am-12pm P.S.T.
U.S. and other foreign patents pending /
Patentes de los EUA y países extranjeros en trámite /
Brevets en cours pour les États-Unis et autres pays
All rights reserved / Derechos Reservados /
Tous droits réservés
Made in China / Hecho en China /
Fabriqué en Chine
www.atlantic-inc.com
R1.0 120911 #28235872
2012
7
