Atlantis EASYTILE II User manual

BASE AND WASTE FITTING INSTRUCTIONS
BFK-EC-2017
EASYTILE 
EASY CLEAN WASTE FITTING
Included in this package:
Other equipment required
1 x
1 x
Tile Over waste insert
Waste Fitting –40mm Easy Clean


Broom
1 x
MB hairgrille

Accurate level
1 x
Waste installation key

Adhesive application / caulking gun
2 x
Sturdi Bond construction adhesive

Pozi screwdriver
1 x
White NG silicone

Tape measure
1 x
Quick Start Guide

Levelling compound and associated equipment
(only required for shower base being installed
into a concrete recess)
1 x
Base fitting instructions (this booklet)

The installation process requires the waste fitting to be installed at the same time as the base.
Atlantis recommends this is undertaken by a qualified plumber and carpenter.
Atlantis showers are supplied with Sturdibond to adhere the base to the floor substrate. It is
recommended that Gorilla Grip is used if the temperature drops below 5 degrees.

EASYTILE 
FLOOR PREPARATION –on any floor type
1. Sweep floor free of dust
2. Provide a hole for the waste fitting to a minimum size of 180mm x
180mm, FIGURE 1, in the correct position to suit the shower base.
3. Dry fit the shower base onto the flooring to ensure it is able to be
installed level. The top of the glazing channel(s) and top edges of
the upstands must be level. If not, apply packers under the
support rings where required to make level. Re-check that the
Waste Body Assembly is correctly aligned with the centre of the
base hole.
FIGURE 1
180mm
180mm
WASTE PREPARATION
4. Separate the components of the waste into:
A. the inner ring and waste cup
B. the waste body and body seal
5. Connect the waste body to the pipework, FIGURE 2, ensuring that
the body seal is in the correct position and 25mm below the floor
level, as in FIGURE 2 and 3
FIGURE 2
180mm x 180mm
hole in floor
25mm lower than floor level
FIGURE 3

BASE INSTALLATION
6. Clear floor of all debris and dust
7. Apply supplied construction adhesive liberally to the webbed
support rings
8. Install base in final position, ensuring that it is level
9. The inside face of the upstand must be close to flush with the
inside face of the wall board.
10. Screw the upstand of the shower base back to the extra nogging.
11. Allow suitable time for the base adhesive to cure. Keep the
shower base surface free of dust and dirt prior to the application
of your interlayer/waterproofing/tiles to the base.
WASTE CONNECTION
12. Insert the inner ring through the waste outlet in the shower base
and screw the inner ring into the waste body. Hand tighten using
the installation key.
13. Place the waste cup and Easy Clean component (not pictured) into
position within the inner ring.
TILE OVER WASTE INSERT
14.
IMPORTANT NOTES
-The wall glazing channels must be fitted to the wall after waterproofing, prior to tiling.
