Atlantis Air Press Series Guide

User Manual &
Warranty Card
CAUTION:
Before using the Hot Beverage Dispenser, read this manual and follow all safety rules and
operating instructions.
HOT BEVERAGE
DISPENSER
Premix Based:
Recipe Based:
Micro - 2 Lane
Café Mini - 2 Lane
Café Plus - 3/4 Lane
Air Press Series - 2/4 Lane
Select (Multi Option)

Disclaimers:
Accessories shown are not part of the standard product package.
Actual design, colour and specification may vary from the sketches shown.
The picture is used for representation purpose only.
Note: The Machine specifications are subject to change without notice.
Current Publicaon in March 2021
First Published in March 2016
2
Manufactured By
THE VENDING COMPANY
Plot No - 28, Sector- 4, IIE, Sidcul, Pantnagar,
Rudrapur - 263153, Uttarakhand (INDIA)
Call : 70600 02944
Marketed By
VENDING UPDATES INDIA PVT. LTD.
B-23, Sector - 88, Phase II, Noida - 201305,
District Gautam Budh Nagar, Uar Pradesh (INDIA)
Plot No. - 35, Sector -155, Noida - 201310,
District Gautam Budh Nagar, Uar Pradesh (INDIA)
Customer Care
Email: service@atlansplus.com
Call : 85888 25888

Contents
3
Leer from the company
Product features
Introducon - Models
General specificaons
Installaon of machine
Connecng the electricity supply
Programming of 2 Lane Atlans
Programming of 3/4 Lane Atlans
Programming of Select Atlans
Programming in Atlans Micro
Operaon guideline
Beverage dispensing
Daily cleaning operaon
Daily canister filling/jar changing operaon
Descaling
Service guidelines
Exploded views with part’s name
Part replacement process of all crical components
Disposal of the machine
Dos & Don’ts
Warranty Card
04
05
05
06
07
08
08
10
10
12
13
13
14
16
17
19
21
25
33
33
34
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
S. No. Page No.

Leer from the company:
Please be sure to follow the instrucons in the
operaonal guideline to make the necessary sengs.
USER’S MANUAL
Please read the User
manual prior to using
the machine.
4
Congratulaons on the purchase of your Atlans hot beverage dispenser.
You will be impressed by its design, durability,
ease of use and the quality of the beverage
dispensed.
The is a fully automac Atlans hot beverage dispenser
dispensing machine. Each beverage is freshly prepared
at the press of a buon which guarantees high quality
of drink. User control of the machine is possible via a
touch-pad switch.
Keep these instrucons near the hot beverage machine
so that you and your operang staff have the required
informaon handy and can take the correct acon in
the event of any technical problems. In the event of any
service maer see
service manual.
Ensure staff access to
user manual !

Compact Design
Product Feature:
Designed to suit Indian climatic condions
Funcon Indicang LCD display
Thermal protecon for over heat
Suitable for Single Phase Operaon
Climate
Heat Fair Fall Snowfall
LCD
5
HOT BEVERAGE DISPENSER
MODELS DESCRIPTION
2 Lane Hot Premix Based Beverage Dispenser
3/4 Lane Hot Premix Based Beverage Dispenser
Select (7 Opons) Recipe Based Mul Opon Hot Beverage Dispenser
Introducon Models:
2/4 Lane Air Press Series Hot Premix/Recipe Based Beverage Dispenser
Micro Hot Premix Based Beverage Dispenser

USER’S MANUAL
6
General Specications:
Power Supply
Machine Dimension (W*D*H) (mm)
Net Weight (kg) Serving Options Continuous Dispensing Of 100ml Servings Dispensing Rate (cups/min) Product Serving Temperature Water Supply -input Options Cleaning Cycle Power Consumption Current Operating Method Boiler Capacity Heater Element (capacity Kw) Quantity Of Canisters Capacity of Canisters
Parameters
Image Features
Specications
Category
110V/230V-60Hz/50Hz-1ph
320 X 365 X 640 14 2 Options+ Hot water 21 cups 3 cups/min 72~84 deg C Bubble top/Pump/Online Automatic 2000 W 9.8 A Key pad
3 Ltr. 2000 W 2 1.1 kg
110V/230V-60Hz/50Hz-1ph
285 X 350 X 465 5.5 2 Options+ Hot water 8 cups 1 cup/min 72~84 deg C 5 ltr. manual lling Manual 500 W 2.3 A Key pad 1 Ltr. 500 W 2 1.1 kg
110V/230V-60Hz/50Hz-1ph
320x477x640 18.4 4 Options + Hot Water 21 cups 3 cups/min 72~84 deg C Bubble Top/ Pump/Online
Automatic 2000 W 9.8 A 3 Ltr.
2000 W 4 1.1 kg
110V/230V-60Hz/50Hz-1ph
320 X 477 X 640 19.3 7 Options 21 cups 3 cups/min 72~84 deg C Bubble Top/ Pump/Online
Automatic 2000 W 9.8 A Key pad
3 Ltr. 2000 W 4 1.1 kg
110V/230V-60Hz/50Hz-1ph
320 X 477 X 640 16.8/18.4 3/4 Options + Hot Water
21 cups 3 cups/min 72~84 deg C Bubble Top/Pump/Online Automatic 2000 W 9.8 A Key pad
3 Ltr. 2000 W 3/4 1.1 kg
2 Lane Select
4 Lane
Air Press
3/4 Lane 2 Lane
Air Press
Micro
110V/230V-60Hz/50Hz-1ph 320 X 365 x 640 14 2 Options+ Hot water 7 cups 1 cup/min 72~84 deg C Bubble top/Pump/Online Automatic 700 W 3.2 A Sensor based contact less dispenser 2 Ltr.
700 W 2 1.1 kg

1. Installaon Guidelines:
1.1 Locang the Machine:
1.2.1 Open the front door using the key provided. Remove all transit packing
and the installaon kit from the machine. Check for visual signs of damage which
may have occurred during transit. If the machine is damaged or any parts are
missing, you must contact authorised seller immediately.
1.1.1 The machine is suitable for indoor use only,
sited in an area with a recommended ambient
temperature not below 10° C and not exceeding
35° C. (image a)
(Image a)
1.1.2 Prior to moving the machine to its locaon, ensure
that there is sufficient access to ensure adequate
venlaon. 100 - 150 mm (4-6 inches) clearance must be
allowed between the back of the cabinet and the wall.
(Image b)
(Image b)
1.1.3 Ensure that the machine is situated on
a strong horizontal surface (See Specificaons table),
at a convenient height and in a posion where it is not
likely to be unstable. (Image c)
(Image c)
1.2 Installaon of Machine
1.2.2 The machine should be situated within one metre of
a drinking water supply from a rising main in case of pump.
Water Supply
by Jar
Water Supply
by RO
Plug
7
HOT BEVERAGE DISPENSER
1.2.3 Firstly break the seal of the potable drinking water
jar/source. Overturn the water bole on top of the
machine carefully to avoid air lock/vacuum venng,
1. 2.4 Remove the plug while changing the jar.

1.4 User Programming Mode:
1.4.1 Programming of Atlans 2 Lane
USER’S MANUAL
1.3.1 The machine must be connected to a 230 Volt 50Hz 6/16
amps switch socket outlet.
Aenon!
Risk to user!
1.3. Connecng the Electricity Supply:
The Atlans 2 Lane is a fully programmable machine which can be customized to the
customer's requirements. Please follow the simple instrucons below to program
your machine:
Press the STOP switch for 3 seconds and the machine enters the programming mode.
Now we would be using the COFFEE, TEA and HALF buons to program the machine.
Image (A)
8
A - Disconnected Condion B - Connected with 6/16 A
Important: If the power cord becomes damaged in any way it
must be replaced by a special lead available from the
manufacturer.
Immediately as we enter the programming mode, the display would show PREMIX
1 3.75. This indicates the dispensing me in seconds for the premix from the
canister 1. There would also be a cursor under the number before the decimal.
The COFFEE and TEA buons can be used to increase or decrease this number. Once
done, press the HALF buon and the cursor would then move to the digit aer the
decimal point. The HALF buon would hence forth play the role of an ENTER buon.

Press HALF (enter) again and the display would show WATER 1 6.0.
Follow the procedure to change the quanty of water in the drink 1 side as above.
9
HOT BEVERAGE DISPENSER
Press HALF again and the machine display shows “returns to the regular MAKE
YOUR CHOICE mode”.
Lastly pressing HALF would show CHANGE PASSWORD. Press TEA or COFFEE and
the YES opon appears. Press HALF again and ENTER the old password followed
by the new password twice.
Press HALF again and we have the USER MESSAGE change opon. Using the
COFFEE, TEA and HALF buons (for saving) you can actually change the name on
the display to your choice. A unique feature only on ATLANTIS machines.
Press HALF and the screen would show CNTR RESET. Pressing COFFEE
TEA would show YES then you have to enter the password and the counters of B1
and B2 would be reset to 0.
Next mode on pressing HALF is the SET DEFAULT opon. If you enable the same by
impung YES, then all sengs of water, powder, temp etc would be restored to the
factory sengs (password and user message remain same).
The default password is currently entered by pressing half 5 mes no number needs
to be entered.
Press HALF again and the display shows TEMP 82. Again this can be adjusted
(to a maximum of 90 degree) by using the coffee and tea (up and down) switches.
Press Half again and we now enter the SET FLUSH mode. Here we have the
following opons (all available using the COFFEE/TEA switches). If we want to flush
the machine at regular intervals, especially when not in use, then we should
enable – YES this opon.
Press HALF again and the display would show ENABLE COIN. (Only applicable to token
operated machine.) Using the COFFEE and TEA we can enable – YES or disable the
token mechanism – NO.
Press HALF buon again and the display show HOT WATER 6.0. This is the quanty
of water which is dispensed when we push the HOT WATER buon. The quanty
can be adjusted by using the COFFEE and TEA buons and saved by pressing the
HALF buon as above.
Press HALF again for WATER 2 (water from the drink 2 side). Make changes as above.
Note that the seng for WATER would always be 1.0 sec more than the respecve
premix. This would ensure that the water would always flow more than powder and
not allow accumulaon if powder in the mixing bowl.
Press HALF and the display would show PREMIX 2 3.75. This refers to the quanty
of premix from canister 2 dispensed. Changes can be made as above.

USER’S MANUAL
1.4.2 Programming of Atlans 3/4 Lane:
The 3 and 4 lane machines are programmed in a very similar manner to the Atlans 2 Lane.
The main differences have been highlighted.
1.4.3 Programming of Atlans Select:
Black
Coffee Café
Lae
Cappuccino Hot
Chocolate Hot
Milk
Tea
Premix
STOP
Mochaccino
Image (B)
Image (C )
10
Press stop switch for 3 sec and machine will enter the programming mode.
Now screen will show “SET DRINKS? : NO” , Press Key 1 (Black Coffee) key for YES; Then it
will show message Select Drink on the screen.
Now select required Bev; Bev1, Bev2, Bev3, Bev4, Bev5, Bev6, Bev7 which seng we want
to change by pressing their respecve key.
Note: Programming of the AIRPRESS series dispensers is same as the
regular café series dispensers, and can be done by holding your hand
in front of the sensors, just like you would press the buons on a
regular machine.
The five buons are named BEV 1, BEV 2, BEV 3, BEV 4, STOP. BEV 1 and BEV 2 buons
does the same funcon as the COFFEE/TEA buon to increase/decrease me and toggle to
enable or disable funcons. BEV 3 is the equivalent of the HALF buon in the 2 lane Café
mini and is primarily for saving and moving on to next mode. In the Café Plus, to get hot
water or half cup, just press the STOP buon once and then the BEV buon of your choice
to get hot water/half cup of drink from that lane. A longer press of the STOP buon and you
can enter the MENU mode and follow the same instrucons as the Café Mini programming.
For example by selecng Bev 1 it will show COFE WTR:06.00 which is the me for which
water from lane 1 is dispensed. This can be increased by pressing key 1 (Black Coffee) and
decreased by pressing key 2 (Coffee Lae) and saved by key 3 (Cappuccino). Post saving the
display will show COFE PDR: 02.00 we can increase and decrease the coffee powder
quanty as given above key 1 for increase and key 2 for decrease and save by key 3.
Post saving display will show COFE DLY: 02.00 here DLY stand for the providing a me delay
to powder from starng of the water.
This powder delay can be increased and decreased as above.

11
Same process can be repeated for other drinks. For example, if we want to set
Bev 4 (Mochaccino) then enter Sengs by pressing the STOP key for 3 secs, say yes
(pressing key 1) to SELECT DRINKS, choose the Bev you want to adjust by pressing
that same key which is key 4 in our example. Display will show COFE WTR: 02.50,
increase by key 1, decrease by Key 2 and saved by key 3. Display will now show
COFE PDR: 02.10, adjustable with increase by key 1, decrease by key 2 and save by
key 3, then display will show as COFE DLY: 01.40 and then COFE WPR: 05.40 aer
that it will come M/C WTR: 03.76 It shows the water ming from the combo of
milk and chocolate chamber can be adjust by same method as above and so on.
Remember DLY is always provide DLY in powder from the starng of drink.
HOT BEVERAGE DISPENSER
Next window will show CHANGE PSWD?: NO. If you want to change password press
key 3 and enter old password and then enter your unique required password by key
1, and key 2 for entering value from 0 to 9.
Then display shows USER MESSAGE: YES. For changing user message press key 3
otherwise you can escape by key 8 (stop key). For changing it will ask for
password, message can be adjusted by key 1 and key 2, key 1 increase the
alphabecal values and key 2 go downwards in alphabecal values.
Then display shows CNTR Reset?: NO on changing to yes by key 1 it will ask for
password. Upon entering the 5 digit password it will reset the data of served drinks
to 00000.
Next window will show Set Default?: NO by pressing key 1 it can be change to yes on
enabling it, It will restore all the sengs, temp etc. to the factory sengs
(password and user message will not change)
On saving (press key 3) flush seng it shows Temperature: 88° C which we can adjust
temp 75 to 90° C save the temperature by key 3.
If don't want to change any drink seng then easily escape “SET DRINKS?: NO”
screen by pressing stop key. It shows “Auto Flush?: NO” We can change it for
60 min and 90 min by pressing key 1 and save by key 3. Timing for flushing is given
06.00 sec by default which adjustable increase by key 1 and decrease by key 2
and save by key 3.

Programming in Atlans Micro
USER’S MANUAL
Your “DIAL A TASTE” beverage center comes at a default seng for 70 ml cup size
change your cup size anyme!
2. When you change your default cup size the quanty of powder mix increases or
decreases proporonately to maintain beverage strength.
3. Increase of one point approximately increases water by 10 ml.
1. Set cup size by increasing or decreasing the ‘WATER’.
Your “DIAL A TASTE” beverage center comes at a default seng for 12 gm. premix
change your beverage strength anyme!
1. Set beverage strength by increasing or decreasing ‘PREMIX 1’ or
‘PREMIX 2’
2. When you change your beverage strength the quanty of water does not increase
or decrease proporonately.
3. Increase of one point in beverage strength increases powder quanty by
approximately 1.2 gm.
Your “DIAL A TASTE” beverage center comes at a default seng for 70 ml cup size to
change your default cup size/beverage strength.
4. Wait for 3 seconds.
Now your default cup size/beverage strength is set.
3. Select default cup size by increasing or decreasing increase in number
denotes higher cup capacity.
1. Press increase and decrease of ‘PREMIX1’ or ‘PREMIX2’ or ‘WATER’
together for 3 seconds unl you hear the beep.
2. Digit being programmed remains lit. Other digits blank out. Release buons.
For best results and to ensure smooth and uniform dispensing of beverage from the
machine, clean the canister elbows daily to remove premix powder that may have been
deposited in them.
12

2. Operaonal Guidelines:
2.1. Machine funcon:
The following procedure must be carried out by a trained installaon
engineer before the machine can be used for the first me.
2.1.2 Fill the canisters with the correct
ingredients, close the lids and re-fit canisters
into machine ensuring that they are returned
to their correct posions. Rotate the canister
outlets to their correct operang posions.
(Image c & image d)
2.1.3 While the machine is powering up, the
LCD will display the message as shown.
“PLEASE WAIT - HEATING”. Ensure that no
water overflows from the storage tank into
the machine.
HOT BEVERAGE DISPENSER
2.1.1 Ensure that the electrical and water
services to the machine are connected
correctly. Also ensure that you have
sufficient water quanty in the boiler or
the machine is connected to proper water
source and then turn on electrical supply.
Ensure that the waste tray is fied correctly
to the machine. (Image a & image b)
Image (a) Image (b)
Image (C) Image (d)
2.2 Beverage Dispensing:
2.2.1 Switch on the machine.
2.2.2 Put the cup on drip tray for dispensing the beverage.
2.2.3 Press the buon for required beverage. Desired beverage & dispensing
progress will be shown in display.
2.1.4 If display shows “Low Water Fill”, Then please give some me to fill up the
machine or check the bole on the top, If it is empty please replace the bole.
13

Cauon : Take care at dispensing me, don’t touch the hot beverage with your hand
during dispensing. Hot water can cause burns to user.
2.2.6 Aer dispensing the beverage switch off the tea & coffee machine if not in
use for long me.
Aenon!
Risk to user!
Aenon!
Hot Liquid
14
Note:
a) To clean plasc cup upper remove the plasc
cup upper, as you can see the image (a)
Image (a)
Open the cover of the water reservoir on top of the machine and fill will water.
Open the front door and remove the canisters. Fill the canisters with beverage mix
powder. Replace the canisters and close the door.
Plug the mains cord of the machine into the power outlet and switch on the mains.
Turn on the main switch at the back of the machine.
The machine will now be in the powered on mode and the ‘WAIT’ indicator would
be glowing indicang that the water is heang. The machine will be ready to
dispense once the ‘WAIT’ indicators turn off.
Open the dispensing area door and place empty cup on the tray under the beverage
outlet. Close the door.
Select the beverage cups size and strength using the respecve and buons
on the le hand side.
Press buon on the right hand side for the beverage selected. The machine will
dispense the drink.
Open the dispensing area door and remove the cup. Enjoy your cup of hot drink !
USER’S MANUAL
2.2.4 Wait for beverage dispensing.
2.2.5 Your beverage is ready to drink.
Dispensing in Micro
2.3 Daily Cleaning Operaon:
2.3.1 Material: Single use coon, food grade utensils, Detergent.
2.3.2 Hygiene: Wash hands thoroughly with water and soap before handling the
machine and products.
2.3.3 Use only potable water to clean the machine.

15
b) To clean plasc cup lower remove the plasc
cup lower, as you can see the image (b)
c) To clean mixi base lower rotate it clockwise
and remove, as you can see the image (c)
d) To clean mixi base rotate it clockwise and
remove, as you can see the image (d)
e) To clean mixing assembly open mixing
assembly impeller washer & o-ring and wash,
as you can see the image (e)
1. Clean elbow (image-f) on weekly basis.
Image (e)
Image (c)
Other part
Image (f)
Image (b)
HOT BEVERAGE DISPENSER
Image (d)

Image (g)
2. Canister (image-g) on weekly basis.
Carefully remove the Canister from its posion
& clean it . Set it back to the posion aer cleaning.
3. Ensure the drip tray empty and clean drip trey
(image-h) on weekly basis.
Carefully remove the drip tray from its posion
& clean it . Set it back to the posion aer cleaning.
2.4 Daily canister filling/Jar changing operaon
2.4.1 Canister filling:
1. In case of canister filling open the cap from
canister you can see the image (a).
2. Fill the premix aer opening the
cap you can see the image (b)
Image (h)
Image (a)
Image (b)
16
USER’S MANUAL

17
3. Aer filling the premix in the canister cover the
canister outlet by the cap, as you can see the image (c)
1. In case of changing of water jar disconnect the
machine, as you can see the image (a).
2. While changing the water jar, take care
that water should not flow on front of the door,
as you can see the image (b).
3. Use only approved potable drinking water
jar/source
2.4 Descaling
Descaling is in three stages:
Preparaon
Descaling
Rinsing
Descaler is causc!!!
Always follow the instrucon on
the descaler package.
2.4.2 Jar changing operaon:
Image (c)
Image (a)
Front door side
Image (b)
HOT BEVERAGE DISPENSER

Atlans doesn't recommend any descaling agent for descaling process.
Descaling Frequency:
Descaling to be done as per requirement.
Descaling Method:
1. Follow the instrucon given in descaling agent booklet.
2. Put the prepared descaling soluon into storage tank.
3. Turn on the machine and pump water through bubble top or pump into the
storage tank for 20 seconds.
4. Turn off the machine.
5. Let the machine cool with descaling soluon.
6. Turn on the machine aer 10 minutes and pump more water for 1 minute.
7. Turn the hot beverage dispenser machine off again and wait for the descaling
soluon to do its work .
8. Keep repeang the step above unl the storage tank is empty and all the
soluon should have been pumped through the machine & the lime scale will
have been removed.
9. Rinse your storage tank and fill it with fresh clean water.
10. Repeat this process again & your machine is descaled.
11. Flush the machine completely at least twice.
Dispense one hot beverage & throw it out to make sure all the descaling
soluon is gone.
18
USER’S MANUAL

19
3. Service Guideline:
3.1 Basic trouble shoong chart
Problem Cause & Remedy
1. If display shows
"Heang…" for a long me
1. Check loose connecons connuity at heater/
fuse/ holder relay/ terminals.
2. Check loose connecons at main controller card
connector & recfy.
3. Check 230 Volt AC supply across heater.
terminal, if power supply not detected replace
heater.
4. If Power supply not detected check DC signal
across relay terminals.
a) If power supply not detected replace relay.
b) If power Supply not detected, than replace
controller card.
2. If display shows
"LOW WATER FILL".
1. Check water level in bubble top.
2. Check connuity of float valve wire from
controller card to tank.
3. Overheang in Boiler tank. 1. Check loose connecon of temperature sensor
on the boiler.
2. Check DC supply across the relay if 24 V is not
detected then replace the relay.
3. Check bimetallic thermostat connecon properly.
4. Electric Shock. 1. Check earthing/ polarity in supply Socket.
2. Check water leaking inside the machine and
recfy it.
3. Check loose connecon of earthing wire machine
body.
4. Check connuity between machine body & earth
pin on 6/16 Amp power plug. If connuity is not there
replace power cord.
HOT BEVERAGE DISPENSER

5. As soon as machine is
switched on power supply
trips.
1. Check correct rang of MCB.
2. Change main lead if machine doesn’t trip then
replace main lead permanently.
3. Open one connecon of hot tank if adapter
trips again then replace the hot tank.
4. Open connecon of adapter if machine
trips again replace the adapter.
5. Check the phase of main supply is not short with
body.
6. Cold water tank is full, no
dispensing of water while
pressing dispensing buon
only premix is dispensing.
1. Check loose connecon & connuity between
main & DV connecons.controller card
2. Check connecons of DV.
3. Replace main board.
4. Replace the DV.
7. Variaon in end cup volume. 1. Check scaling in valve & clean it.
2. Replace dispense valve.
8. Premix clong in canister
elbow.
1. Check exhaust fan.
2. If exhaust working, check exhaust pipe
connected properly between fan & duct.
Connect it properly. If it is not working, check
loose connecon at exhaust fan.
3. Replace exhaust fan.
9. Variaon in end cup
taste.
1. Check level of ingredient inside the canister.
Refill if it is below minimum level.
2. Check whipper motor is working or not.
If it is not working, check the voltage across motor
terminal. (a) If power supply detected replace
whipper motor. (b) If power supply not detected
check loose connecon. (c) Replace main board.
20
USER’S MANUAL
