Atlantis Cafe Mini Series Guide

R
Manufactured by:
THE VENDING COMPANY
PLOT NO - 28, SECTOR- 4,
IIE, SIDCUL, PANTNAGAR,
RUDRAPUR, UTTARAKHAND
INDIA - 263153
Model :
Name of Purchaser :
Date of Purchase :
Serial No. of Unit :
Name and Address of the Seller :
Seller’s Stamp & Signature :
Manufactured by:
THE VENDING COMPANY
PLOT NO - 28, SECTOR- 4,
IIE, SIDCUL, PANTNAGAR,
RUDRAPUR, UTTARAKHAND
INDIA - 263153
Model :
Name of Purchaser :
Date of Purchase :
Serial No. of Unit :
Name and Address of the Seller :
Seller’s Stamp & Signature :
MERCHANT COPY
CUSTOMER COPY
Please read the instructions carefully prior to using the product. Please read the instructions carefully prior to using the product.
Actual design and color may vary from the images shown. Actual design and color may vary from the images shown.
The pictures are used for representation purposes only. The pictures are used for representation purposes only.
Note:- The machine specications are subject to change without notice. Note:- The machine specications are subject to change without notice.
Please read the instructions carefully prior to using the product.
Actual design and color may vary from the images shown.
The pictures are used for representation purposes only.
Note:- The machine specications are subject to change without notice.

1
USER’S MANUAL
Dear Customer, .
Congratulations on your purchase of the new Atlantis Hot Beverage Vendor.
This Product is guaranteed to be free from facts in workmanship and material,
under normal use and service, for a period of 12 months from date of original
purchase.
SPECIAL FEATURES OF THE ATLANTIS HOT BEVERAGE VENDOR
24 Volts DC motor
Fully programmable
Password protected
Magnetic sealing door to ensure that cockroaches do not get into the machine
IN CUP TEMPERATURE AS HIGH AT 85 DEGREE CAN BE OBTAINED
Manually adjustable solenoid valves
SS heating element
Waste tray with optional drain facility
Membrane switches for easy accessibility
Float valve with buzzer for low water level indication
Adjustable temperature through controller card
Compact and easy to maintain.
Easy to service
2
HOT BEVERAGE DISPENSER
INSTALLATION
Before using this machine, this manual must be read carefully.
The machine should not be installed in place that may exposed to sprayed
water and they likewise should not be cleaned using sprayed water.
The user or person responsible for relling & cleaning the machine must follow
the instructions set forth in this manual.
Do not touch the product with your hands & prevent liquids from falling inside
the product canisters.
If any maintenance task needs to performed & the machine is going to be
disconnected for a long time period, the boiler and canisters must be empty.
Only trained service technician are authorised service/dismantle any component
of the m/c.
Appropriate ELCB is be provided by the outlet before installation of the m/c.
Proper earthing is must with 3 pin, 15A supply socket at the outlet.
Switch off the power supply and unplug the main supply cord before carrying
out any cleaning and maintenance operations.
Do not touch the machine with wet or humid hands.
Do not unplug the machine from the source by pulling the power supply cable.
Do not allow children or untrained people to play with machine.
GENERAL SAFETY INSTRUCTIONS
Portable Drinking Water
INSTALLATION
Installation Required at Site
Free space required Refer m/c dimensions given in technical
data. Apart from space covered by the
m/c, 6” free space required all around
the m/c. for maintenance purpose.
Power Supply 230V, 50Hz, 15Amps power socket with
proper earthing & within 1.5 mtrs. distance
from m/c.
Quality of Water
Unpacking
Unpacking the m/c carefully at the installation site and securely place the
machine on a platform. Check contents of the packaging which consists of : -
a. Machine
b. Drip Tray Jali
c. User Manual with Warranty Card.
d. Machine Key
e. Main Lead 15Amp
1 Nos.
1 Set
1 Nos.
2 Nos.
1 Nos.
TECHNICAL SPECIFICATION
Weight (Kg.)
Dimensions (HxWxD) mm
Power (Watts)
Power Source
Operating Voltage
Start Up Time
Premix Canister /Capacity
Dispensing Rate
Front Door
Steam Dispersion
Hot Water Tank Material/Capacity
Descriptions
16
640x320x350
2000 Watts
220V/1p/50Hv
24 V DC
8 Minutes
2 Nos. of 1.2 Kg. each
4 cups per minutes
ABS Moulded
Exhaust Fan
SS 304 Stainless Steel
3.0 Ltr.
20
640x320x470
2000 Watts
220V/1p/50Hv
24 V DC
8 Minutes
3 Nos. of 1.2 Kg. each
4 cups per minutes
ABS Moulded
Exhaust Fan
SS 304 Stainless Steel
3.0 Ltr.
21
640x320x470
2000 Watts
220V/1p/50Hv
24 V DC
8 Minutes
4 Nos. of 1.2 Kg. each
4 cups per minutes
ABS Moulded
Exhaust Fan
SS 304 Stainless Steel
3.0 Ltr.
2 Lane 3 Lane 4 Lane
* Actual design, colour and specications may very from the images shown.

Membrane Switch Lock With Key PCB 2,3,4 Lane Drip Tray
Drip Tray Jali
Door Hinge Lower Overflow Nozzle Outlet Nozzle Cap Outlet Nozzle 3, 4 Way Door Supporter Metal Body Whipper Motor Rubber Feet Fuse Holder Indicator Gear Motor- 90 rpm Main Lead 15 amp Drain Set Relay 24DC-40 amp Steam Trap
Lock Patti -SS Solenoid Valve (DV)
Impeller Hot Tank Stand
Hot Tank Drain
Hot Tank - 2,3,4 Lane
Hot Tank Inlet
Thermostat 90 Steam Pipe Sensor EDP Foam Main Lead Socket 15amp NRV - Washer, Jali
Sensor Rubber Silicon Pipe (6x8, 8x12, 7x13) mm Front Door Supply SMPS Fiber Washer Main Switch Door Sheet Gasket Mixing Bowl-lower Mixing Bowl-upper Water Inlet Hinge Upper Funnel Black Puncturing Tube Black Back Plate
1. 2. 3. 4. 5. 6. 7. 8. 9.
10.
11.
12. 13. 14. 15. 16. 17. 18. 19. 20. 21. 22. 23. 24.
PART NAME
25. 26. 27. 28. 29. 30. 31. 32. 33. 34. 35. 36. 37. 38. 39. 40. 41. 42. 43. 44. 45. 46. 47. 48.
PART NAME
Flexible Pipe Canister Outlet Cover Canister Bush Front Canister Front Nut Canister Elbow Whipper Cover O Ring Whipper Button Whipper Base Whipper Washer Canister Cap Canister Gear Canister Body Canister Worm
Canister Back Nut Fan Cover Exhaust Fan Float Valve Steam Elbow Box Steam Box Washer
Steam Elbow Box Nut Clamp Strip Storage Tank
Fuse-15 amp
PART NAME
PART
NO.
PART
NO.
49. 50. 51. 52. 53. 54. 55. 56. 57. 58. 59. 60. 61. 62. 63. 64. 65. 66. 67. 68. 69. 70. 71. 72.
PART
NO.
PART IDENTIFICATION
HOT BEVERAGE DISPENSER
4 3
USER’S MANUAL
1
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21
22
23
24
25
31
30
29
28
27
26
32
33
34
35
36 37 38 39 40 41 42 43 44
49
48
47
46
45
50 51 52 53 54 55 56 57 58
59
60
61 62 63
64 65 66 67 68 69 70 71 72
PARTS IDENTIFICATION

PROGRAMMING INSTRUCTIONS – CAFÉ MINI
6
HOT BEVERAGE DISPENSER
The Atlantis Café mini is a fully programmable machine which can be customized
to the customer's requirements. Please follow the simple instructions below to
program your machine. .
Press the STOP switch for 3 sec. and the machine enters the programming mode
Now we would be using the COFFEE TEA and HALF switches to program the
m a c h i n e . .
Immediately as we enter the programming mode, the display would show PREMIX1
3.75. This indicates the dispensing time in seconds for the powder from the coffee
canister. There would also be a cursor under the number before the decimal
(3 in the above case). The COFFEE and TEA switches can be used to increase or
decrease this number. Once done, press the HALF switch and the cursor would then
move to the digit after the decimal point. The HALF switch would henceforth play
the role of an ENTER/SAVE button .
The increase or decrease would change in direct proportion to the settings. So a
setting at 5.0 would mean that 10% more powder is dispensed than at 4.5 sec.
Press HALF (enter) again and the display would show WATER1 5.0. The cursor
would be under the number 5. Follow the procedure to change the quantity of water
in the coffee side as above. .
Press HALF and the display would show PREMIX2 3.75. This refers to the quantity
of tea powder dispensed. Changes can be made as above. .
Press HALF again for WATER 2 (water from the tea side). Make changes as above.
Note that the setting for WATER would always be 1.0 sec more than the respective
premix. This would ensure that the water would always flow more than powder and
not allow accumulation of powder in the mixing bowl. .
Press HALF button again and the display shows HOT WATER 5.0. This is the
quantity of water which is dispensed when we push the HOT WATER button .
The quantity can be adjusted by using the COFFEE and TEA buttons and saved by
pressing the HALF button as above. .
Press HALF again and the display shows TEMP 85. Again this can be adjusted (to a
maximum of 89 degree) by using the coffee and tea (up and down) switches.
THE DEFAULT PASSWORD IS CURRENTLY ENTERED BY PRESSING HALF 5
TIMES. NO NUMBER NEEDS TO BE ENTERED. .
Press HALF again and the display would show ENABLE COIN. Only applicable
to coin operated machine. Using the COFFEE and TEA we can enable – YES or
disable the coin mechanism - NO. .
5
USER’S MANUAL
Remove the machine form its outer packing and place the machine on a flat even
surface. .
Overturn a bottle of water (2 ltrs to 25 ltrs) over the machine .
DO NOT TURN THE MACHINE ON TILL THE WATER HAS COMPLETELY
FILLED UP INSIDE THE MACHINE. THIS POSITION IS REACHED WHEN
THE BUBBLES STOP APPEARING INSIDE THE BOTTLE. .
Switch the machine on from the mains and then from the switch behind the
front door. .
The Display would indicate “Please wait – heating” .
The display would toggle between the above sign and the temperature on the front
display. .
The cup counter comes on the screen after you push the half cup button for
3 seconds. .
The machine would not dispense till such time as the set water temperature is reached
Fill us the canisters with the premix (coffee in the left canister and tea in the right one)
Once the desired temperature has been reached, the machine is ready for dispensing
Make the desired choice from the membrane panel at the base of the door.
Please note that the first cup of coffee and tea would have less powder as the
machine has not yet been “primed”. .
PLEASE NOTE THAT THE MACHINE ARRIVES WITH DEFAULT SETTINGS
OF 12.7 GMS OF PREMIX AND 90 ml OF WATER. YOU CAN CUSTOMIZE
T H E S A M E T O Y O U R TA S T E B Y F O L L O W I N G T H E S I M P L E
INSTRUCTIONS BELOW. .
For half cup, please press the HALF switch and then your choice of either
COFFEE or TEA. .
Similarly for just hot water, press HOT WATER followed by COFFEE or TEA.
This feature can also be used for flushing out the system at the beginning of the
day for cleaning purposes. .
The STOP switch is used when an incorrect choice has been made and we would
like to abort the operation midway .
In case the temperature of the water is less than 10 degree C, of set temperature
the machine would not dispense any premix or water .
In case the water level in the container is low, the display would show
WATER LEVEL LOW and the buzzer would sound. The machine would not
dispense in this mode.
Please read the instructions below prior to using the machine.
USAGE INSTRUCTIONS FOR THE CAFÉ MINI

7
PROGRAMMING INSTRUCTIONS – CAFÉ PLUS
The 3 and 4 lane machines are programmed in a very similar manner to the Café mini.
The main differences have been highlighted .
The five buttons are named BEV 1, BEV 2, BEV 3, BEV 4, STOP. .
BEV 1 and BEV 2 buttons does the same function as the COFFEE button to
increase/decrease time and toggle to enable or disable functions. BEV 3 is the
equivalent of the HOT WATER button in the 2 lane Café mini and is primarily for
saving and moving on to next mode. .
IN the Café Plus, to get hot water or half cup, just press the STOP button once and
then the BEV button of your choice to get hot water/half cup of drink from that lane.
A longer press of the STOP button and you can enter the MENU mode and follow the
same instructions as the Café Mini programming. .
NOTE THAT THE ATLANTIS MACHINES HAVE A LOT OF OTHER FEATURES
LIKE LANGUAGE CHANGE AND CALIBRATION WHICH CAN BE ENABLED
UNDER SUPERVISION OF AN AUTHORISED ENGINEER FROM THE COMPANY.
Press HALF and the screen would show CNTR RESET. Pressing TEA would show
YES. Then you have to enter the password and the counters of coffee and tea would
be reset to 0. .
Press HALF again and we have the USER MESSAGE change option. Using the
COFFEE TEA and HALF buttons (for saving) you can actually change the name on the
display to your choice. A unique feature only on ATLANTIS machines.
Lastly pressing HALF would show CHANGE PASSWORD. Press TEA and the YES
option appears. Press HALF again and ENTER the old password followed by the new
password twice. .
Press HALF again and the machine display shows “returns to the regular MAKE
YOUR CHOICE mode.
USER’S MANUAL
Next mode on pressing HALF is the SET DEFAULT option. In you enable the same
by imputing YES, then all settings of water, powder, temp etc would be restored to the
factory settings. .
Press Half again and we now enter the SET FLUSH mode. Here we have the following
options (all available using the COFFEE/TEA switches). If we want to flush the machine
at regular intervals, specially when not in use, then we should enable – YES, this option.
We recommend this as well, because it not only cleans the water pathways, but also keeps
them warm. If you choose YES, then you can set the flush time interval to 10/ 30/60/90 mins
depending upon usage of the machine. If the machine is used extensively, then a higher
interval is recommended. .
8
Specific fault message will be displayed when the m/c stops dispensing.
List of fault messages, their possible cause and remedial action are listed blow.
TROUBLESHOOT
1. Check heater fuse. If fuse has blown off, replace it.
2. Check loose connections continuity at heater/
fuse/holder/relay/terminals
3. Check loose connections at main PCB connector
and rectify.
4. Check 230 volt AC supply across heater terminal,
if power supply not detected replace heater.
5. If power supply not detected, check DC signal
across relay terminals.
a.) If power supply not detected replace relay.
b.) If power supply not detected, then replace PCB.
1. If display show “Heating....”
for more than 10 minutes
2. If display shows
“Water tank empty”
3. Overheating in boiler tank
HOT BEVERAGE DISPENSER
1. Check water level in bottle top
2. Check continuity of sensor wire from PCB to tank
1. check loose connection of temperature sensor on
the boiler.
2. Check DC signal across heater relay terminal
a) If power supply not detected, replace repay.
b) if power supply not detected, replace
temperature sensor.
4. Electric shock
5. As soon as machine is
switched on power supply
trips.
1. Check earthing / polarity in supply socket.
2. Check water leaking inside the machine and
rectify it.
3. Ch loose connection of earthing wire with
machine body.
4. check continuity between machine body & earth
pin on 15 Amp power plug. if continuity is not there
replace power cord
1. Check correct rating of MCB.
2. Remove 15 Amp fuse & switch on. If it is tripping
again, reconnect the same & if it not tripping,
replace heater.

USER’S MANUAL
WARRANTY CONDITIONS
1. The guarantee extended herein is limited to the repair and/or replacement of defective
part (s), and the manufacturer would not be responsible for any consequential liability/
damage/ loss arising due to such defects .
2. Warranty card duly filled in and stamped by the dealer, along with a copy of the invoice
should be produced for and warranty claims. All expenses incurred in sending and
collecting the unit or part thereof from the authorized service center will be payable
by the customer .
3. This warranty dose not cover accessories such as main cord, relay, membrane
switch, funnel and plastic parts. .
This product is covered under a one year warranty to be free from defects is
workmanship and material under normal use and service for a period of 12 months
from the date of purchase.
HOT BEVERAGE DISPENSER
1. This warranty card has 2 parts. kindly ensure that the Merchant fills all parts correctly
2. Part A is the customer’s copy. It should be retained by you for your record.
3. Part B must be torn and mailed to the company’s address (mentioned there itself.)
4. In the event of a defect developing in the product, contact the Merchant. .
of company for obtaining warranty service by informing defect, Model & Serial No.
5. On your loading a complaint, trained technician will call on your promptly. In the
unlikely event of the technician deciding that the product requires attention at
customer care center, kindly arrange to deliver the Machine to the customer care
center for further action.
5. Any liquid except water in the container.
6. machine is shipped (out side premises) without prior information.
4. The warranty is void if : .
a) It is found that the unit has been subject of unauthorized installation or repair.
b) The voltage of the power supply is not within the specified limited .
_
(230 V 50Hz + 10%) .
c) The damage is caused during transit, due to accident, flood, fire, other natural
hazards, neglect of misuse.
WARRANTY INSTRUCTIONS FOR USER
9 10
6. Bubble top is full, no
dispensation of water while
pressing dispensing button
only premix is dispensing
7. Variation in end cup volume
8. Premix clotting in canister
elbow
9. Variation in end cup taste
3. Remove SMPS AC supply connector & switch on.
If it is tripping, reconnect the same & if it is not
tripping, replace SMPS.
4. Remove Exhaust fan wire & switch on. If it is not
tripping, replace exhaust fan.
1. Check loose connection & continuity between
main PCB & water level sensor.
2. Replace level sensor.
3. Replace main board
1. Check scaling in value & clean it.
2. replace dispense valve.
1. Check exhaust fan whether working or not.
2. If exhaust fan working, check exhaust pipe
connected properly between fan & duct. Connect
it properly. If it is not working, check loose
connections at exhaust fan.
3. Replace exhaust fan.
1. Check level of ingredient inside the canister.
Rell if it is below minimum level.
2. Check whipper motor whether working or not.
If it is not working, check the voltage across
motor terminal.
a) If power supply detected, replace whipper motor.
b) If power supply not detected, check loose connection.
c) Replace main board.
