Atos OpenScape CP600 User manual

OpenSpape Desk Phone
CP600
Quick Reference Guide
A31003-F9900-U102-01-7619
Unify Office

Provide feedback to further optimize this document to [email protected].
As reseller please address further presales related questions to the responsible
presales organization at Unify or at your distributor. For specific technical inquiries
you may use the support knowledgebase, raise - if a software support contract is in
place - a ticket via our partner portal or contact your distributor.
Our Quality and Environmental Management Systems are
implemented according to the requirements of the
ISO9001 and ISO14001 standards and are certified by an
external certification company.
Copyright © Unify Software and Solutions GmbH & Co. KG 07/2021
All rights reserved.
Reference No.: A31003-F9900-U102-01-7619
The information provided in this document contains merely general
descriptions or characteristics of performance which in case of actual
use do not always apply as described or which may change as a result
of further development of the products.
An obligation to provide the respective characteristics shall only exist if
expressly agreed in the terms of contract.
Availability and technical specifications are subject to change without
notice.
Unify,OpenScape, OpenStage and HiPath are registered trademarks of
Unify Software and Solutions GmbH & Co. KG. All other company,
brand, product and service names are trademarks or registered
trademarks of their respective holders.
atos.net

Unify Office by Ring Central
1
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
OpenScape
Desk Phone
CP600
Screens, Buttons, and Common Functions
Out
of-Office/Call
-
Forwarding Key
Notification LED
Audio
Keys
Dial Pad
Soft
Keys
Graphic
Display
Handset
Navigator
Menu Key

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
2
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
BUTTON DEFINITIONS
1. Notification LED
Signals incoming calls, new messages, or missed calls.
2. Out-of-Office/Call
Forwarding Key
Opens the Out-of-Office/Call Forwarding menu.
3. Graphic Display
Permits the intuitive use of the phone. If there are no calls taking place or settings
being made, the idle menu is displayed.
4. Soft Keys
Enables the user to access the function directly adjacent to the
Graphic Display.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
3
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
BUTTON DEFINITIONS
1. Dial Pad
Permits users to enter numbers or characters.
2. Menu Key
Opens different menus with telephone functions, applications, and configurations.
3. Navigator
Enables navigation and access to various menus in the Graphic Display.
4. Volume Control
Controls the volume level.
5. Mute Key
Switches the microphone on/off.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
4
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
6. Speaker Key
Switches the speaker on/off.
7. Headset Key
Enables the headset function.
PLACING AN OUTGOING CALL
Unhook the handset, then dial the
number or extension.
Dial the number or extension, then press the
upper-right soft key for hands-free mode.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
5
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
RECEIVING A CALL
Unhook the handset.
Press the upper-right soft key for
hands-free mode.
OR
ENDING A CALL
Hook the handset.
OR
Press the
upper
-
right soft key.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
6
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
PLACING A CALL ON HOLD
Use the Navigator to
locate
Hold
and press
OK
.
Press the soft key
adjacent to
Hold
.
OR

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
7
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
PLACING A CALL IN PUBLIC PARK
Dial
##*3
or use the Navigator to
locate
Favourites
and press
OK
.
Press the soft key adjacent
to
Favourites
.
OR
Listen to the announcement to determine which extension the call was parked.
The announcement is the only way to determine which extension the call was parked.
Use the Navigator to locate
Park
and press
OK
.
Press the
soft key adjacent to
Park
.
OR
Placing a call in public park puts the call on hold in a public location. The location is
accessible to any user by dialing the announced number or extension that the system
automatically assigns.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
8
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
RETRIEVING THE CALL FROM THE PUBLIC PARK LOCATION
On another phone, press the
star (*)
key followed by the parked call’s extension.
Example:
The call is parked at extension 813. Using another phone,
dial
*813
to retrieve the call from the public park location.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
9
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
PLACING A CALL IN PRIVATE PARK
Use the Navigator to locate
Favourites
and press
OK
.
Press the soft key adjacent
to
Favourites
.
OR
Placing a call into private park utilizes the Park Location Group feature. A call placed on hold
in this group is only visible and accessible to members using supported desk phones or the
RingCentral Phone application.
Under
Favourites
, navigate down
to
Park Location
.
Press
OK
. The call is now placed
in a private park location.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
10
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
RETRIEVING THE CALL FROM THE PRIVATE PARK LOCATION
Retrieve the call by pressing the bottom
soft key adjacent to the notification of the
park location.
On another phone, press the bottom
soft key to retrieve the call
from the private park location.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
11
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
TRANSFERRING A CALL –WARM
While on an active call, use the
Navigator to locate
Consult
,
then press
OK.
OR
Press the soft key adjacent to
Consult
.
Dial the number or extension that
you wish to consult.
Example: 302
Press
OK
.
When the called party answers,
use the Navigator to locate the
Complete transfer
option,
then press
OK
.
OR
Press the soft key adjacent to
Complete t
ransfer
.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
12
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
TRANSFERRING A CALL - BLIND
While on an active call, use the
Navigator to locate
Transfer
,
then press
OK.
Dial the number or extension
where you want the call to be
transferred. Example: 301
OR
Press the soft key adjacent to
Transfer
.
Press
OK
.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
13
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
TRANSFERRING TO VOICEMAIL
To transfer an incoming call to
voicemail, use the Navigator to
locate
Reject
, then press
OK.
OR
Press the soft key adjacent to
Reject
.
LISTENING TO VOICEMAIL
After transferring the call to voicemail,
a red icon with a pound sign appears
beside
Voicemail
.
Press
OK
.
Note: Voicemail can also be checked by
dialing
*86
.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
14
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
Enter the
PIN
and press
#
, then press
1
to listen to the message.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
15
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
ENABLE DO NOT DISTURB
Under
Favourites
,
navigate
down to
DND
.
Press
OK
to enable Do Not Disturb.
A pop-up message in the Graphic
Display indicates Do Not Disturb is on.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
16
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
DISABLE DO NOT DISTURB
Under
Favourites
,
navigate down to
DND
.
Press
OK
to disable Do Not Disturb.
A pop-up message in the Graphic
D
isplay in
dicate
s
Do Not Disturb is off
.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
17
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
INTERCOM
Press the soft key adjacent to
Intercom
.
Intercom is a peer
-
to
-
peer, two
-
way
communication between two devices/users.
OR
Dial
*85
and press
OK.
Dial the number or extension that you
want to connect to
Intercom
and
press
#
.

OpenScape Desk Phone CP600 | Screen, Buttons, and Common
Functions
18
A31003-F9900-U102-01-7619, 07/2021
Unify Office, OpenScape Deskphone CP600 Quick Reference Guide
PAGING
Dial
*84
and press
OK.
OR
Press the soft key adjacent to
Paging
.
Paging is a one
-
way broadcast
to
one or multiple devices/users
.
Dial the number of the group and press
#
. Example: 1#
