Atten GT-5150 User manual

GT
compatible
GT-5150 Multifunctional Desoldering Station User Manual

Contents
Copyright information
Description of common icons
Essential knowledge for users
Safety precautions
Disclaimer
Packing list
Schematic diagram of the whole equipment
Connection mode for the whole equipment
Connection steps for the whole equipment
Technical parameters
Description of working interface
Operations of temperature setup
Parameter setup
Total items of parameter setup menu of the host system
Host system setup parameters
Total items of parameter setup menu of the handle channel
Parameter setup menu of the handle channel
Connecting mode of the functional ground wire
Schematic diagram of the soldering
Care and maintenance
Product warranty
................................................................................................2
.....................................................................................2
....................................................................................2
.......................................................................................................2
...................................................................................................................2
................................................................................................................3
..............................................................4
...............................................................4
................................................................5
..................................................................................................6
................................................................................7
.................................................................................8
........................................................................................................10
.........................................11
.................................................................................11
....................................14
...........................................................15
......................................................18
.........................................................................18
..............................................................................................19
......................................................................................................20
After-sales contact ....................................................................................................20
Appendix ..................................................................................................................21
1

Warning
The design of this product (including internal software) and its accessories is under the protection of relevant state
laws. Any violation of the relevant rights of our company will be subject to legal sanctions. Users shall
consciously abide by the relevant state laws when using this product.
Thank you for using our products. Before using the product, please read this manual carefully and pay attention to
the relevant warnings and cautions mentioned in this manual.
Warning Misuse of this product may lead to serious injury or death to the user.
Caution Misuse of this product may lead to serious injury to the user or material damage to the object involved.
Users are required to have basic knowledge of common sense and electrical operations before using the product.
Minors shall use the product under the guidance of a professional or guardian.
Caution To avoid damaging the equipment and keep the safety of the operational environment, please
read this manual carefully and keep it well before use so that you may read it at any time when necessary.
To avoid electric shock or injury to the human body or fire hazard, the following basic rules must be observed
when using the equipment.In order to ensure personal safety, only parts and accessories approved or
recommended by the original factory can be used, otherwise serious consequences may occur!
We will take no responsibility for any personal injury or property damage caused by reasons other than the
product quality problem, which may include force majeure (natural disasters, etc.) or personal behavior during the
operation of this product.
This manual is organized, compiled and released by SHENZHEN ATTEN TECHNOLOGY CO., LTD. according
to the latest product features. We will not responsible for further notice of the subsequent improvement of the
product and this Manual.
When using this product, the soldering pencil/soldering tip, with the temperature up to 150-480℃, may cause
burns to the user or cause a fire due to improper application. So Users shall strictly observe the following rules:
Caution
● Keep this product away from flammable materials.
● Keep the product out of children's reach.
● Do not use this product if you are inexperienced or have no sufficient necessary knowledge without the guidance of related personnel.
● Do not use this product under wet environment or with wet hands to avoid electric shock.
● Do not modify this product and its accessories without authorization.
● Please turn off the power when replacing parts and iron tips, and not resume the use until the equipment is completely cooled down.
● Please use the accessories from the original factory when replacing the product parts.
● Make sure to turn off the power switch when the equipment is temporarily stopped or out of use.
2
Copyright information
Description of common icons
Essential knowledge for users
Safety precautions
Disclaimer
● To ensure the normal operation of this product’s ESD function, only three-core power cord shall be used as the host connecting line.
● Smoke will be generated during the soldering operations. So please pay attention to the smoke evacuation.
● Do not play or do other similar dangerous actions during using this equipment, because it can easily lead to injury to others or
yourself.
● Do not use this product for purposes other than soldering.
● Do not modify this product and accessories, otherwise the original warranty will be invalidated or damage may occur to the product.
● When plugging and unplugging the power cord and handle plug, please hold the plug body and do not pull the cord.
● Do not hit the product or its accessories too hard during the operation; otherwise damage may occur to the product.

GT-5150 packing list
GT-5150 host
Operating manual
Power cord
1 set
1 set
1 Pcs
1 set
1 Pcs
1 Pcs
Product Certificate
3.5mm ground connector
Power cord Product Certificate
3.5mm ground connector
GT-5150 Host Manual
Optional accessories
3
Packing list
GT-Y150 (applicable to lead-free high-power welding)
GT-Y050 (applicable to precision welding)
GT-Y130 (applicable to conventional welding)
GT-N100 (applicable to precision welding)
GT-X150 desoldering gun
GT-X150 desoldering gun
GT
compatible
GT-5150 Multifunctional Desoldering Station Host Manual

1
3
4
5 2 8 967 10 11 121314
Vacuum pump interface
Interface for the soldering tool channel
Down arrow key /minus key
Rapid temperature key 1, Close key of the Interface for the
soldering tool channel, Setup menu switch key of the
Interface for the soldering tool channel
"Confirm" key, Menu key
Up arrow key /plus key
1
2
3
4
5
6
Rapid temperature key 2, System setup menu switch key
7
Rapid temperature key 3
Power supply public seat, access rated AC power
Power master switch
RS232 communication interface
USB Communication interface (This function is not available)
Functional grounding interface
8
9
10
11
12
13
Power insurance
14
Connection mode for the whole equipment-
GT-5150
1
Connection mode for the whole equipment
4
Schematic diagram of the whole equipment
USE ONLY WITH 250V FU SE

Connection steps for the whole equipment
Note
To avoid damaging the host, do not forget to turn off the power when inserting the plug into or removing
the plug from the soldering tools!
1
1
2
2
1 2
3 4
5

Technical parameters
Voltage
Product model
AC 230V±10% 50Hz（110V±10% 60Hz）
Power consumption
GT-5150
1
Security level Class 1 (Host of the controller) Class 3 (Accessories of soldering handle)
T 2.5A (230VAC) T 3A (110V AC)
150W
Power fuses
Temperature range 250℃~ 480℃/ 482℉~ 896℉(Configurable temperature range
depends on the connected accessories of the soldering handle)
Temperature accuracy ±10℃/ ±18℉
Vacuum pressure -600mmHg
Temperature stability ±2℃/ ±4℉
Number of tool channels
Functional ground
connection
3.5mm plug (which is hard grounding when not connected and is
directly connected to the protective ground wire)
Temperature adjustment
step
Long press to adjust 10 units at a time, short press to adjust 1
unit at a time
Standby mode 0~120minutes, the default time is 0 minutes, turn off Standby mode
Dormancy mode 0~120minutes, the default time is 0 minutes, turn off Dormancy mode
Rapid temperature 3 groups of temperature, which can be called quickly
Display resolution 240x160 Dots(white letters on blue)
System language English/Chinese
Communication address
range 1~255（not open yet）
Working conditions Temperature 0℃～40℃Relative humidity＜80％
Storage conditions Temperature -20℃～80℃Relative humidity＜80％
Dimension 315（L）×252（W）×127（H）mm
Approximately 4kgWeight
6

350
350 c
o
GT-X150
250 300 400
After connected with charger. Turn-on the power switch.The product will be working normally after the
screen display system version for 3 seconds.
Description of GT-5150 working interface
GT-5150 startup interface
GT-5150 normal working interface
Versio n:1 .0
ww w.atten.com
5150
1 2536 8 79 4 10
1
2
3
4
5
6
7
8
9
10
Status display area of channel, display power bar / product working status / abnormal code.
Channel fast temperature 3.
Fixed temperature icons display.
Display area of system temperature unit.
Channel fast temperature 2.
Channel fast temperature 1.
Soldering tool model display area of channel.
Set temperature display area of channel.
Actual temperature display area of channel, display of the indicative description of abnormal work conditions.
Vacuum pressure indication (the quantity of solder splash in the solder storage tank is for reference, the
indicated value is in direct proportion to the quantity of solder splash in the solder storage tank.)
7

Operations of temperature setup
0
260 c
o
GT-X15
250 300 400
50
0
259 c
o
GT-X15
250 300 400
Press “UP” arrow key to increase the temperature.1
Press “DOWN” arrow key to decrease the
temperature.
2
2
1
8
Quick temperature call of GT-5150
Short press the "1" key to quickly call the set value
at 250℃.
Note: Rapid temperature value can be changed and
configured in the channel menu.
50
0
250 c
o
GT-X15
250 300 400
260
259
250

Short press the "2" key to quickly call the set value at
300℃.
Likely, short press the "3" key to quickly call the set
value at 400℃.
9
Opening and closing of GT-5150 channels
Long press "1" key to open or close channel 1.
50
0
--- c
o
GT-X
OFF
15
250 300 400
50
0
300 c
o
GT-X15
250 300 400
00
00

1
Parameter setup
Hold "MENU" key until the load is completed (100%).
50%
5
0%
Loading...
2If the configuration page is under the protection of
password, the login to “Confirm” page shall be
authorized. Press "▲" or " " key to change the
input value, press “Enter" key to complete one input,
press the Rapid temperature key "3". Press the
“Logout” key to return to the main interface.
Log in
* *
EXIT
9
If there is no password protection, or after the correct
password is entered, it will jump to the System
Parameter setup interface. At this time, the system
parameters can be configured.
Note: Do not change or insert and remove the handle of the soldering tool while setting the channel
parameters to avoid damaging the welding accessories and the Host.
Press the Key 1 to enter channel setup and the Key 2 to
switch to system setup.
10
3
System set
Languages En
Unit C
Password * * *
Keypad tone ON
LCD Contrast 4 4
4
Channel Set
GT-X150
Temp Offset 0
Standby temp 250
Standby Delay OFF
Shutdown Delay
Shortcut Temp1
OFF
250

Total items of parameter setup menu of the host system
Used to set the system Language:
EN: English.
CN: Chinese.
The factory default is: English.
Used to set the system temperature unit:
℃: Celsius.
℉: Fahrenheit.
The factory default is: ℃.
Languages: Language displayed on the system menu.
Unit: Temperature unit displayed on the system.
Password: The authorization password to enter the
system parameters interface.
Keypad Tone: The switch to turn on and off the key
operation tone.
LCD Contrast: Contrast ratio adjustment displayed on
the screen.
Mode: Used to define the Host communication.
Net Address: Local communication address defined during
networking operation.
Factory Default: Resume the Host to the factory settings.
Exit: Press to return to the main interface.
Host system setup parameters
11
System Set
Languages En
Unit C
Password * * *
Keypad Tone ON
LCD Contrast 44
System setup
Mode Nor
Net Address 1
Factory Default ON
Exit
Languages System Set 〉Languages
System Set
Languages En
Unit C
Password * * *
Keypad Tone ON
LCD Contrast 44
Unit System Set 〉Unit
System Set
Languages En
Unit C
Password * * *
Keypad Tone ON
LCD Contrast 44

1. Used to lock the system and protect set parameters
of the system from being changed by unauthorized person.
2. Coordinate with the fixed temperature of parameter
setup of the handle channel, lock the temperature of
the whole equipment and control the welding process.
The factory default is: OFF.
Under the password setup state, enter a three-digit password, display
the prompt locked by the system and shut down the prompt window
3s later. Press Enter to resume password setup.
Used to open or close the prompt tone for key operation:
Open (ON): prompt tone is given for key operation.
Close (OFF): prompt tone is not given for key operation.
The factory default is: ON.
Used to set the contrast ratio of the display screen:
10: minimum contrast ratio.
100: maximum contrast ratio.
The factory default is: 44.
Enter the correct password, the system is
unlocked and the password is cancelled;
Enter the incorrect password, wrong password
will be reminded.
12
Password System Set 〉Password
System Set
Languages
En
Unit C
Password * * *
Keypad Tone ON
LCD Contrast 44
System Lock-in System Set 〉SystemLock-in
Set PIN code Locked
0 - - PIN Code ：
000
System unlock System Set 〉System unlock
Message
PIN code Error
Set PIN code
0 - -
Keypad Tone System Set 〉Keypad Tone
System Set
Languages
En
Unit C
Password * * *
Keypad Tone ON
LCD Contrast 44
LCD Contrast System Set 〉LCD Contrast
System Set
Languages
En
Unit C
Password * * *
Keypad Tone ON
LCD Contrast 44

Used to set the product communication mode:
Normal: close the communication function.
Host: used for function extension.
Slave: used for function extension.
The factory default is: normal.
Used for communication among many machines and can
be directed to 255 devices at most:
Adjustment range: 1-255 (used for function extension).
The factory default is: 1.
Used to restore system parameters and channel parameters to
factory default.
After the factory default is restored through click confirmation,
all system parameters and channel parameters will be restored
to factory default.
Note: it is intended for parameters corresponding to the
handles connected. The handles that have not been connected
to the host will not be restored to factory default.
13
Mode System Set 〉Mode
System Set
Unit C
Password * * *
Keypad Tone ON
LCD Contrast 44
Mode
Nor
Net Address System Set 〉Net Address
System Set
Password * * *
Keypad Tone ON
LCD Contrast 44
Mode
Nor
Net Address 1
Factory Default System Set 〉Factory Default
System Set
Keypad Tone ON
LCD Contrast 44
Mode
Nor
Net Address 1
Factory Default

Press the key 1 in the system setup menu to enter parameter setup of channel;
Used to exit from parameter setup and return to the main
interface.
All parameters changed will be stored upon exit.
Reset the dialog box:
Select the function using “ ” or “ ”
and press Enter to execute this function.
Temp Offset: used to compensate for the
temperature output error of the handle.
Standby Temp: the temperature of the handle when
the system enters standby mode.
Standby Delay: open and close the standby mode.
Shutdown Delay: open and close the dormancy mode.
Shortcut Temp1: set temperature 1 for user’s quick call.
Total items of parameter setup menu of the handle channel
Shortcut Temp2: set temperature 2 for user’s quick call.
Shortcut Temp3: set temperature 3 for user’s quick call.
Fix Temp: after this function is started, the output
temperature stays at the set temperature value.
Temp UL: the maximum temperature that can
be set by the user in the main working interface.
Temp LL: the minimum temperature that can
be set by the user in the main working interface.
14
System Set
LCD Contrast 44
Mode
Nor
Net Address 1
Factory Default
Exit
ON
Reset
Factory default?
NO YES
Exit System Set 〉Exit
System Set
LCD Contrast 44
Mode
Nor
Net Address 1
Factory Default
Exit
Channel Set GT-X150
Temp Offset 0
Standby Temp 250
Standby Delay OFF
Shutdown Delay OFF
Shortcut Temp1 250
Channel Set GT-X150
Shortcut Temp2 300
Shortcut Temp3 400
Fix Temp OFF
Temp UL 480
Temp LL 250

Parameter setup menu of the handle channel
Used to compensate for the temperature output error of the
soldering pencil.
Compensation range: -50℃~+50℃, -90℉~+90℉.
In case of a positive value, the handle temperature will
increase to the set value.
In case of a negative value, the handle temperature will
decrease to the set value.
The factory default is: 0.
The temperature value when the handle enters standby mode:
250℃/482℉: the minimum standby temperature.
300℃/572℉: the maximum standby temperature.
When the set actual operational temperature is less than the set
standby temperature, the product will enter standby mode at
the actual operational temperature.
The factory default is: 250℃.
The delay time (unit: min) taken by the product to enter
standby mode automatically when the User leaves the handle
unused for a long time:
OFF: the product will not enter standby mode.
1-120: the product starts standby function and enters standby
mode within the specified time.
When the set actual operational temperature is less than the set
standby temperature, the product will enter standby mode at the
actual operational temperature.
The factory default is: OFF.
Note: if the user discovers that the temperature is inaccurate when replacing the heating core or the handle,
it can be corrected through parameter modification as follows:
1. Set the handle temperature to be corrected at a suitable value, e.g. 350℃/662℉.
2. After the temperature remains stable, test the actual temperature of the current handle heater tip using
temperature tester, e.g. the actual temperature is 365℃/689℉.
3. The actual temperature is 15℃/27℉higher than the set temperature when a conclusion is drawn through
analysis.
4. Set the temperature compensation value as -15℃or -27℉, that is, compensate for the output temperature
error.
15
Temp Offset Channel Set 〉Temp Offset
Channel Set GT-X150
0
Standby Temp 250
Standby Delay OFF
Shutdown Delay OFF
Shortcut Temp1 250
Temp Offset
Standby Temp Channel Set 〉Standby Temp
Channel Set GT-X150
0
Standby Temp 250
Standby Delay OFF
Shutdown Delay OFF
Shortcut Temp1 250
Temp Offset
Standby Delay Channel Set 〉Standby Delay
Channel Set GT-X150
0
Standby Temp 250
Standby Delay OFF
Shutdown Delay OFF
Shortcut Temp1 250
Temp Offset

The delay time (unit: min) taken by the product to enter
dormancy mode automatically when the User leaves the handle
unused for a long time:
OFF: the product will not enter standby mode.
1-120: the product starts dormancy function and enters dormancy
mode within the specified time.
The factory default is: OFF.
3 sets of data of set temperature for users’ quick call:
Limited to “maximum temperature” and “minimum
temperature”.
The factory default is:
Quick temperature 1: 250℃/482℉.
Quick temperature 2: 300℃/572℉.
Quick temperature 3: 400℃/752℉.
16
Shutdown Delay Channel Set 〉Shutdown Delay
Channel Set GT-X150
0
Standby Temp 250
Standby Delay OFF
Shutdown Delay OFF
Shortcut Temp1 250
Temp Offset
Shortcut Temp1 Channel Set 〉Shortcut Temp1
Channel Set GT-X150
0
Standby Temp 250
Standby Delay OFF
Shutdown Delay OFF
Shortcut Temp1 250
Temp Offset

After this function is started, the handle temperature stays at
the set temperature.
OFF: temperature lockout function is off.
250-480℃/482-896℉: temperature lockout is started, the
handle works at the fixed temperature, and the user cannot
change the set temperature in the main interface.
The fixed temperature is off when the temperature is lower
than 250℃/482℉.
The factory default is: OFF.
The maximum temperature that can be set by the user in the
main working interface.
The set maximum temperature is 480℃/896℉.
The set minimum value of the “maximum temperature”
should be no less than or equal to the “minimum
temperature”.
The factory default is: 450℃/842℉.
The minimum temperature that can be set by the user in the
main working interface.
The set maximum temperature is 250℃/482℉.
The set maximum value of the “minimum temperature”
should be no greater than or equal to the “maximum
temperature”.
The factory default is: 250℃/482℉.
Used to exit from parameter setup and return to the main
interface.
All parameters changed will be stored upon exit.
17
Fix Temp Channel Set 〉Fix Temp
OFF
250
300
400
OFF
Channel Set GT-X150
Shutdown Delay
Shortcut Temp1
Shortcut Temp2
Shortcut Temp3
Fix Temp
Temp UL Channel Set 〉Temp UL
GT-X150
250
300
400
OFF
Temp UL 450
Channel Set
Shortcut Temp1
Shortcut Temp2
Shortcut Temp3
Fix Temp
Temp LL Channel Set 〉Temp LL
GT-X150
300
400
OFF
450
Temp LL 250
Channel Set
Temp UL
Shortcut Temp2
Shortcut Temp3
Fix Temp
Exit Channel Set 〉Exit
GT-X150
400
OFF
450
250
Exit
Channel Set
Temp LL
Temp UL
Shortcut Temp3
Fix Temp

Connecting mode of the functional ground wire
Schematic diagram of the soldering
This product uses 3.5mm grounding plug, which is provided with the following four kinds of grounding modes:
Hard
grounding
Equipotential
connection
Floating
connection
Soft
grounding
18
Before the 3.5mm plug is inserted, the ground wire of the soldering
tool handle is connected directly to the protective ground wire of
the power line.
After the 3.5mm plug is inserted, the ground wire of the soldering
tool handle is connected to the 3 pins of the 3.5mm plug.
When the 3.5mm plug is direct connected to the socket instead of
being connected to the lead wire, the soldering tool handle is under
floating state and unconnected with any ground.
When the 3.5mm plug is connected to the ground via 1MΩ or
150KΩ resistor, electrostatic discharge loop is formed.
When the equipotential connection mode is chosen: the ground wire can
achieve the related function via being connected to the pin 1, 2, 3.
1
1
2
2
3
3
4
1MΩ/150K

Care and maintenance
Fault code or fault description
E-1：thermal fuse fault
Likely causes of the faults
1. In case open circuit fault occurs to the heating core, replace it.
2. In case poor contact occurs to the heating core, unplug and then
re-install it.
3. In case the internal connection cable inside the heating core & handle
is broken or heating core connection contact piece is damaged, repair the
broken lead wire or replace the soldering pencil.
E-2:sensor alarm
1. In case the heating core is damaged, replace it.
2. In case open circuit occurs to the lead wire of the Sensor, check the
lead wire of the soldering pencil.
E-3:zero-cross detection
abnormal alarm Send to the designated after-sales service outlet for maintenance.
E-4:abnormal temperature
alarm
In case the heating object loses heat too fast, which cannot reach the set
specified temperature even being heated for a long time. You need larger
power soldering equipment.
E-5:over-current protection 1. Short circuit occurs inside the heating core.
2. In case short circuit occurs to the internal lead wire of the soldering
pencil, please replace the soldering pencil
E-8: abnormal soldering
Tsui temperature
1. In case the temperature sensor is abnormal, please replace the heating core.
2. In case the soldering head temperature is too high, please cool the iron
head and then restart the equipment.
E-9: soldering Tsui handle
status
1. In case the handle is not compatible with this equipment, please
replace it with the handle produced by the original factory.
2. In case the internal circuit is abnormal, please send the equipment to
the designated after-sales outlet for maintenance.
Screen display fault:
In case the problem occurs, you can try to adopt the following measures
to solve it. If the problem still cannot be solved, please return the
equipment to the original factory for inspection.
1. Check if the socket switch is on.
2. Check if there is voltage on the socket.
3. Check if the plug with the power line is loose.
4. Check if the fuse is damaged (if so, please replace the fuse according
to the specifications)
Inaccurate temperature: 1. Use user temperature compensation function to correct the temperature.
2. Replace the heating core with one produced and sent by the original factory.
Mojibake:
1. In case there is strong interference source from the outside environment,
please change the application environment or evacuate from the interference
area.
2. In case the internal circuit is abnormal, please send the equipment to the
designated after-sales outlet for maintenance.
E-6:abnormal system voltage 1. In case the external power supply voltage is abnormal, please check if
the input voltage of the product meets the requirements.
2. In case the host of the product is damaged, please send it to the
designated after- sales outlet for maintenance.
19
