Atten ST-2150 User manual

The design of this product(including internal software) and its
accessories is under the protection of relevant state laws.Any
violation of the relevant rights of our company will be subject
to legal sanctions.Users shall consciously abide by the relevant
state laws when using this products.
1.Copyright information
We will take no responsibility for any personal injury or property
damage caused by reasons other than the product quality
problem,which may include force majeure (natural disasters,etc)
or personal behavior during the operation of this product.
This manual is organized ,compiled and released by SHENZHEN
ATTEN TECHNOLOGY CO., LTD. according to the latest product
features. We will not responsible for further notice of the
subsequent improvement of the product and this manual.
2.Disclaimer
Users are required to have basic knowledge of common sense
and electrical operations before using the product. Minors shall
use the product under the guidance of a professional or guardian.
3.Essential knowledge for users
This product is a portable, temperature-adjustable, high-
temperature control soldering iron. The ceramic heating
core uses a three-core grounded power cable to
effectively ensure the safety of the welding operation.
4.Product overview
*Automatically sleep after 10 minutes and shut down
after 20 minutes when the product stop operating
· Products use LCD display and LED display design
· Build in PID system equipped,adjust temperature
by button,operate easily .
· The handle structure is ergonomically designed for
comfortable grip.
· Display the temperature control status with a bright
blue LED.
· The heating wire and sensor are made of PTC material,
which is quick in temperature rise and precise in
temperature control.
· Auto-standby, auto-shut down is available.
· Using 3 cored power cable.
5.Features
ItemNo.
Voltage
Power
Temperature
range
Heater
Heating
indication
Temperature
unit
ST-2080
110/240VAC
80W
5set
adjustment
BlueLED
°C
ST-2150 ST-2080D ST-2150D
110/240VAC 110/240VAC 110/240VAC
150W 80W 150W
250°C~480°C
Four-core
PTCheater
250°C~480°C
Display
method
LED LED LCD LCD
°C ° °C/ F ° °C/ F
Temperature
accuracy
Temperature
stability
+
-10℃ +
-10℃ +
-10℃ +
-10℃
+
-2℃+
-2℃+
-2℃+
-2℃
6.Specification
5set
adjustment
Four-core
PTCheater Four-core
PTCheater Four-core
PTCheater
BlueLED BlueLED BlueLED
① ④ ⑤ ⑦ ⑧⑥② ③
①
②
③
④
⑤
⑥
⑦
⑧
Solderingtip
Stainlesssteeloutercasing
Shell
Minusbutton
Addbutton
Menubutton
LCDdisplay
3cordedpowercable
*Remark:ST-2080D/ST-2150D with LCD display.
(ST-2080D/ST-2150D)
Product feature
Operational Guide
A .Switch function
Charge on the product,short press power button,When
booting, the screen display the temperature, as shown
in picture 1; when shutdown,the screen display OFF,as
shown in picture 2
Picture 1 Picture 2

B.9 groups shortcut temperature adjustment
In the working state,press ＂＋＂＂－＂ switch
temperature group(the default temperature value
of 9 groups is: 250℃/482℉; 300℃/572℉;325℃/617℉;
350℃/662℉;375℃/707℉;400℃/752℉;425℃/797℉;
450℃/842℉;480℃/896℉。)
Normalworking
mode
Quicktemperature
adjustment
Temperature
compensation
adjustment
Temperature
unitswitching
Auto-sleep
functionsetting
Backtonormal
workingmode
C. Setting mode
(1)Quick temperature adjustment
While in the working state, press the power button to
enter the quick temperature adjustment, press the
＂＋＂＂－＂ button to adjust. Press fast adjustment,
adjust the range：250℃-480℃
(2)Temperature compensation adjustment
In the fast temperature adjustment state, short press the
power button to enter the temperature compensation
setting, press＂＋＂＂－＂ adjust, long press to adjust
quickly, the adjustment range: ± 50 ℃ / ± 90 ℉
(3)Temperature unit switching
In the temperature compensation adjustment state, short
press the power button to enter the unit setting, press
＂＋＂＂－＂ to switch C and F
(4) Auto-sleep function ON/OFF
In the temperature unit switching state,short press the
power button to enter the sleep setting ,press＂＋＂
＂－＂adjust, 1 means ON,0 means OFF
Short press the power button to enter the normal state.
D.Heating
When the product is heated. The power light flashes, the
brightness changes according to the power level, and
the selected gear light is long.
E.Warning
When ＂H-E＂displayed on the screen,there is no
temperature ,which indicates that the heating
element fails.
When ＂S-E＂displayed on the screen,there is a fault in
sensor,which signifies that there is something wrong
in sensor or the related circuit of the sensor.
（ST-2080/ST-2150)
Product feature
*Remark:ST-2080D/ST-2150D with LED display.
①④ ⑤ ⑦ ⑧⑥ ② ③
①
②
③
④
⑤
⑥
⑦
⑧
Solderingtip
Stainlesssteeloutercasing
Shell
Minusbutton
Addbutton
Menubutton
Temperaturesettinglight
3cordedpowercable
Operational Guide
A.Booting
Short press power button to boot,default 390℃ lights
long after booting.
B. Temperature switching
In the working state,short press ＂＋＂＂－＂to switch
temperature.
C. Shutdown
In the working state,short press power button,the light
of power button flashing after shutdown.
D. Heating
When the product is heated. The power light flashes, the
brightness changes according to the power level, and
the selected gear light is long.
E.Warning
When 5 lighting are all flashing ,which indicates that the
heating element fails.
When 5 lighting are all lighting , there is a fault in sensor,
which signifies that there is something wrong in sensor
or the related circuit of the sensor.
